Toyota Land Cruiser Prado (2023 year). Manual in english - page 32

514

6-1. Using the air conditioning system and defogger

■

Ventilation and air conditioning odors

●

To let fresh air in, set the air conditioning system to the outside air mode.

●

During use, various odors from inside and outside the vehicle may enter into
and accumulate in the air conditioning system. This may then cause odor to
be emitted from the vents.

●

To reduce potential odors from occurring:
• It is recommended that the air conditioning system be set to outside air

mode prior to turning the vehicle off.

• The start timing of the blower may be delayed for a short period of time

immediately after the air conditioning system is started in automatic
mode.

■

The rear window defogger, outside rear view mirror defogger and wind-
shield wiper de-icer (if equipped) can be operated when



Vehicles without a smart entry & start system

The engine switch is in the “ON” position.



Vehicles with a smart entry & start system

The engine switch is in IGNITION ON mode.

■

When the windshield wiper de-icer (if equipped) is on



Vehicles without Heated Windshield Defroster

The windshield wiper de-icer will automatically turn off after approximately 15
minutes.



Vehicles with Heated Windshield Defroster

●

The windshield wiper de-icer will automatically turn off. The operation time
varies depending on the outside temperature.

●

The lower the outside temperature, the longer the operation (at most 8 min-
utes).

●

If the outside temperature is high, the operation will stop in few seconds.

■

Heated Windshield Defroster (if equipped)

When the windshield wiper de-icer is operated, the Heated Windshield
Defroster will operate automatically at the same time, preventing ice from
building up on the windshield.

■

If “Out. temp over 5°C. Full deicer unavailable. Use defroster.” is dis-
played (vehicles with the Heated Windshield Defroster and the multi-
information display type B)

Indicates that the windshield wiper de-icer is not available.
Use the defogger.

■

When the Heated Windshield Defroster (if equipped) is on (vehicles with
1GD-FTV engine)

Operation of the outer second seat heaters and the luggage compartment
power outlet (220 V AC) are disabled.

515

6-1. Using the air conditioning system and defogger

6

In

teri
or f
eatu

res

■

Air conditioning system while the engine is stopped by the Stop & Start
system (



P. 395)

●

If the windshield is fogged up

●

If an odor comes from the air conditioning system

●

If the fans slow down or stop

■

Air conditioning filter



P. 617

■

Customization

Settings (e.g. A/C automatic mode button operation) can be changed.
(Customizable features:



P. 769)

WARNING

■

To prevent the windshield from fogging up

●

Do not use

 during cool air operation in extremely humid weather. The

difference between the temperature of the outside air and that of the wind-
shield can cause the outer surface of the windshield to fog up, blocking
your vision.

■

To prevent burns

●

Do not touch the rear view mirror surfaces when the outside rear view mir-
ror defoggers are on.

●

Do not touch the glass at lower part of the windshield or to the side of the
front pillars when the windshield wiper de-icer is on. (vehicles with wind-
shield wiper de-icer)

●

Do not touch the windshield (especially the lower part) as the surfaces can
become very hot when the windshield wiper de-icer is on. (vehicles with
Heated Windshield Defroster)

NOTICE

■

To prevent battery discharge

Do not leave the air conditioning system on longer than necessary when the
engine is off.

●

Do not place anything on the instrument
panel which may cover the air outlets.
Otherwise, air flow may be obstructed,
preventing the windshield defoggers
from defogging.

516

6-1. Using the air conditioning system and defogger

Rear manual air conditioning system



■

Adjusting the temperature setting

Turn

 clockwise (warm) or counterclockwise (cool).

■

Adjusting the fan speed setting

Turn

 clockwise (increase) or counterclockwise

(decrease).
Turning the knob to “OFF” turns off the fan.

■

Changing the air flow mode

Press any button of

,

 or

.



: If equipped

Press the “REAR” button on the front manual air conditioning
control panel to use the rear manual air conditioning system.

517

6-1. Using the air conditioning system and defogger

6

In

teri
or f
eatu

res

■

Location of air outlets

The air outlets and air volume
changes according to the
selected air flow mode.

■

Adjusting the air flow direction and opening/closing the air
outlets

Direct air flow to the left or
right, up or down.
Turn the knob fully to the
back of the vehicle to close
the vent.

Air outlets

1

2

NOTICE

■

To prevent battery discharge

Do not leave the air conditioning system on longer than necessary when the
engine is off.

518

6-1. Using the air conditioning system and defogger

Rear automatic air conditioning system



■

Adjusting the temperature setting

Press “



” on the “TEMP” button to increase the temperature and “



”

to decrease the temperature.

■

Adjusting the fan speed setting

Press “



” on

 to increase the fan speed and “



” to decrease

the fan speed.
Press the “OFF” button to turn the fan off.

■

Changing the air flow mode



Vehicles without outer second seat heaters

Press any button of

,

 or

.



Vehicles with outer second seat heaters

Press .

The air flow mode switch each time the button is pressed.



: If equipped

Air outlets and fan speed are automatically adjusted according
to the temperature setting.



Vehicles without outer second
seat heaters



Vehicles with outer second
seat heaters

519

6-1. Using the air conditioning system and defogger

6

In

teri
or f
eatu

res

■

Using the automatic mode

Press the “AUTO” button.
Adjust the temperature setting.
To stop the operation, press the “OFF” button.

■

If the system is operated manually in automatic mode

If the fan speed setting or air flow modes are operated, the auto-
matic mode indicator goes off. However, automatic mode for func-
tions other than that operated are maintained.

■

Location of air outlets

The air outlets and air volume
changes according to the
selected air flow mode.

■

Adjusting the air flow direction and opening/closing the air
outlets

Direct air flow to the left or
right, up or down.
Turn the knob fully to the
back of the vehicle to close
the vent.

Air conditioning controls

Air outlets

1

2

3

1

2

520

6-1. Using the air conditioning system and defogger

NOTICE

■

To prevent battery discharge

Do not leave the air conditioning system on longer than necessary when the
engine is off.

521

6-1. Using the air conditioning system and defogger

6

In

teri
or f
eatu

res

Power heater



On/off

The power heater turns on about
30 seconds after you press the
switch and it takes about another
55 seconds to warm up.

■

Power heater can be operated when

●

The engine is running.

●

The outside temperature is low.

●

The engine coolant temperature is low.

■

Normal characteristics of power heater operation

The following cases do not indicate a malfunction.

●

When the power heater is turned on or off, some white smoke and a slight
odor may be emitted from the power heater exhaust that is located under
the floor.

●

When the power heater is being used under extremely cold conditions,
vapor may be visible from its exhaust.

●

When the power heater is turned off, you may hear a sound in the engine
compartment for about 2 minutes until the power heater turns off completely.

■

After the heater is off

We recommend not restarting the heater for 10 minutes after you turn it off.
Otherwise, a noise may be heard as the heater ignites.

■

When refueling your vehicle

The engine must be turned off. Turning the engine off turns the power heater
off.



: If equipped

This feature is used to keep the cab warm in cold conditions.

522

6-1. Using the air conditioning system and defogger

WARNING

■

To prevent burns or damage on your vehicle

NOTICE

■

To prevent damage to your vehicle

●

Do not turn the heater on and off repeatedly in 5 minute intervals as this
can shorten the life of the heater components. If the engine must be turned
on and off repeatedly within short intervals (such as when the vehicle is
being used for delivery purposes), turn the heater off.

●

Do not modify or open the heater without consulting any authorized Toyota
retailer or Toyota authorized repairer, or any reliable repairer. This may
cause a heater malfunction or a fire.

●

Be careful not to splash water or spill liquid directly on the heater or on the
heater fuel pump. This may cause the heater to malfunction.

●

Keep the intake and exhaust pipes of the heater free from water, snow,
ice, mud, etc. If the pipes become clogged, this can cause the heater to
malfunction.

●

If you notice anything unusual, such as a fluid leak, smoke or poor opera-
tion, turn off the heater and have your vehicle checked by any authorized
Toyota retailer or Toyota authorized repairer, or any reliable repairer.

●

Do not touch the heater or its exhaust
pipe as they are hot.

●

Keep flammable items such as fuel
away from the heater and its exhaust
pipe. This may cause a fire.

523

6-1. Using the air conditioning system and defogger

6

In

teri
or f
eatu

res

Heated steering wheel



/seat heaters



/

seat ventilators





: If equipped

Heated steering wheel and seat heaters heat the side grips of the
steering wheel and seats. Seat ventilators maintain good airflow
by blowing air from the seats.

WARNING

●

Care should be taken to prevent injury if anyone in the following categories
comes in contact with the steering wheel and seats when the heater is on:
• Babies, small children, the elderly, the sick and the physically chal-

lenged

• Persons with sensitive skin
• Persons who are fatigued
• Persons who have taken alcohol or drugs that induce sleep (sleeping

drugs, cold remedies, etc.)

●

Observe the following precautions to prevent the minor burns or overheat-
ing:
• Do not cover the seat with a blanket or cushion when using the seat

heater.

• Do not use seat heater more than necessary.

NOTICE

●

Do not put heavy objects that have an uneven surface on the seat and do
not stick sharp objects (needles, nails, etc.) into the seat.

●

To prevent battery discharge, do not use the functions when the engine is
off.

524

6-1. Using the air conditioning system and defogger

Turns the steering wheel heater
on/off

The indicator light comes on when
the heater is operating.

■

The heated steering wheel can be used when



Vehicles without a smart entry & start system

The engine switch is in the “ON” position.



Vehicles with a smart entry & start system

The engine switch is in IGNITION ON mode.

■

Timer

The heated steering wheel will automatically turn off after about 30 minutes.

Heated steering wheel (if equipped)

525

6-1. Using the air conditioning system and defogger

6

In

teri
or f
eatu

res



Vehicles with an automatic transmission



Vehicles with a manual transmission

Turns the seat heater on

The indicator light comes on.
The higher the number is, the warmer the seat becomes.

Front seat heaters (if equipped)

526

6-1. Using the air conditioning system and defogger

■

Front seats



Vehicles with an automatic transmission



Vehicles with a manual transmission

Turns the seat heater on

The indicator light comes on.
The higher the number is, the warmer the seat becomes.

Blows air from the seat

The indicator light comes on.
The higher the number is, the stronger the airflow becomes.

■

Outer second seats

For left second seat
For right second seat
High heating temperature
Low heating temperature

To turn on the seat heater, press
“HI” or “LO”.

Off

Seat heaters and ventilators (if equipped)

1

2

1
2
3
4

5

527

6-1. Using the air conditioning system and defogger

6

In

teri
or f
eatu

res

■

The seat heaters/seat ventilators can be used when



Vehicles without a smart entry & start system

The engine switch is in the “ON” position.



Vehicles with a smart entry & start system

The engine switch is in IGNITION ON mode.

■

The outer second seat heaters can not be used when (vehicles with 1GD-
FTV engine)

The Heated Windshield Defroster (if equipped) is operating.

■

When not in use

Set the knob at “0”. The indicator light will turn off.

528

6-2. Using the interior lights

Interior lights list

Personal/interior lights (



P. 529)

Ornament illumination

*

 (if equipped)

Inside door handle lights

*

 (if equipped)

Shift lever light (if equipped)
Footwell lights

*

 (if equipped)

Engine switch light
Door pocket lights

*

 (if equipped)

Running board lights (if equipped)
Outer foot lights (if equipped)

*

: The brightness of the lights can be adjusted (



P. 530)

1
2
3
4
5
6
7
8
9

529

6-2. Using the interior lights

6

In

teri
or f
eatu

res

Off
The personal/Interior lights and interior light can be individually
turned on or off.
Door position
The personal/interior lights come on when a door is opened. They
turn off when the doors are closed.
On
The personal/interior lights cannot be individually turned off.



Front

Turns the lights on/off

Personal/interior lights main switch

Personal/interior lights

1

2

3
