Toyota Land Cruiser Prado (2023 year). Manual in english

224

3-4. Adjusting the steering wheel and mirrors

Outside rear view mirrors



Left-hand drive vehicles (type A)

To select a mirror to adjust,
press the switch.

Left
Right

To adjust the mirror, press the
switch.

Up
Right
Down
Left

Adjustment procedure

1
2

1
2
3
4

225

3-4. Adjusting the steering wheel and mirrors

ati

on
of e
a

pon
ent



Left-hand drive vehicles (type B)

To select a mirror to adjust,
press the switch.

Left
Right

To adjust the mirror, press the
switch.

Up
Right
Down
Left



Right-hand drive vehicles

To select a mirror to adjust, turn
the switch.

Left
Right

To adjust the mirror, operate the
switch.

Up
Right
Down
Left

1
2

1
2
3
4

1
2

1
2
3
4

226

3-4. Adjusting the steering wheel and mirrors



Left-hand drive vehicles (type A)

Press the switch to fold the mir-
rors.

Press it again to extend them to
the original position.



Left-hand drive vehicles (type B)

Automatic mode allows the folding or extending of the mirrors to be
linked to locking/unlocking of the doors.

Folds the mirrors
Extends the mirrors

Putting the outside rear view mirror
folding switch is in neutral position
sets the mirrors in automatic mode.



Right-hand drive vehicles

Folds the mirrors
Extends the mirrors

Vehicles with automatic mode:
Putting the outside rear view mirror
folding switch is in neutral position
sets the mirrors in automatic mode.
Automatic mode allows the folding
or extending of the mirrors to be
linked to locking/unlocking of the
doors.

Folding and extending the mirrors

1
2

227

3-4. Adjusting the steering wheel and mirrors

ati

on
of e
a

pon
ent

When the mirror select switch is in the L or R position, the outside rear
view mirrors will automatically angle downwards when the vehicle is
reversing in order to give a better view of the ground.
To disable this function, move the mirror select switch to the neutral
position (between L and R).

■

Adjusting the mirror angle when the vehicle is reversing

With the shift lever in R, adjust the mirror angle at a desired posi-
tion. The adjusted angle will be memorized and the mirror will auto-
matically tilt to the memorized angle whenever the shift lever is
shifted to R from next time.

The memorized downward tilt position of the mirror is linked to the nor-
mal position (angle adjusted with the shift lever in other than R). There-
fore, if the normal position is changed after adjustment, the tilt position
will also change. When the normal position is changed, readjust the
angle in reversing.

■

Mirror angle can be adjusted when



Vehicles without a smart entry & start system

The engine switch is in the “ACC” or “ON” position.



Vehicles with a smart entry & start system

The engine switch is in ACCESSORY or IGNITION ON mode.

■

When the mirrors are fogged up

Turn on the mirror defoggers to defog the mirrors. (



P. 501, 510)

Linked mirror function when reversing (if equipped)

228

3-4. Adjusting the steering wheel and mirrors

■

Automatic adjustment of the mirror angle (vehicles with driving position
memory)

A desired mirror face angle can be entered to memory and recalled automati-
cally by the driving position memory. (



P. 212)

■

Using automatic mode in cold weather (if equipped)

When automatic mode is used in cold weather, the door mirror could freeze
up and automatic stowing and return may not be possible. In this event,
remove any ice and snow from the door mirror, then either operate the mirror
using manual mode or move the mirror by hand.

■

Customization (if equipped)

The automatic mirror folding and extending operation can be changed.
(Customizable features:



P. 769)

WARNING

■

Important points while driving

Observe the following precautions while driving.
Failing to do so may result in loss of control of the vehicle and cause an
accident, resulting in death or serious injury.

●

Do not adjust the mirrors while driving.

●

Do not drive with the mirrors folded.

●

Both the driver and passenger side mirrors must be extended and properly
adjusted before driving.

■

When a mirror is moving

To avoid personal injury and mirror malfunction, be careful not to get your
hand caught by the moving mirror.

■

When the mirror defoggers are operating

Do not touch the rear view mirror surfaces, as they can become very hot
and burn you.

NOTICE

■

If ice should jam the mirror

Do not operate the control or scrape the mirror face. Use a spray de-icer to
free the mirror.

229

3-5. Opening and closing the windows and moon roof

ati

on
of e
a

pon
ent

Power windows

The power windows can be opened and closed using the switches.
Operating the switch moves the windows as follows:

Closing
One-touch closing

Opening
One-touch opening

: To stop the window partway, oper-

ate the switch in the opposite direc-
tion.

Press the switch down to lock the
passenger window switches.

Use this switch to prevent children
from accidentally opening or clos-
ing a passenger window.

Opening and closing procedures

1
2
3
4

Window lock switch

230

3-5. Opening and closing the windows and moon roof

■

The power windows can be operated when



Vehicles without a smart entry & start system

The engine switch is in the “ON” position.



Vehicles with a smart entry & start system

The engine switch is in IGNITION ON mode.

■

Operating the power windows after turning the engine off



Vehicles without a smart entry & start system

The power windows can be operated for approximately 45 seconds even
after the engine switch is turned to the “ACC” or “LOCK” position. They can-
not, however, be operated once either front door is opened.



Vehicles with a smart entry & start system

The power windows can be operated for approximately 45 seconds even
after the engine switch is turned to ACCESSORY mode or turned off. They
cannot, however, be operated once either front door is opened.

■

Jam protection function

If an object becomes jammed between the window and the window frame
while the window is closing, window movement is stopped and the window is
opened slightly.

■

Catch protection function

If an object becomes caught between the door and window while the window
is opening, window movement is stopped.

231

3-5. Opening and closing the windows and moon roof

ati

on
of e
a

pon
ent

■

When the window cannot be opened or closed

When the jam protection function or catch protection function operates
unusually and the door window cannot be opened or closed, perform the fol-
lowing operations with the power window switch of that door.

●

Stop the vehicle. With the engine switch in the “ON” position (vehicles with-
out a smart entry & start system) or IGNITION ON mode (vehicles with a
smart entry & start system), within 4 seconds of the jam protection function
or catch protection function activating, continuously operate the power win-
dow switch in the one-touch closing direction or one-touch opening direction
so that the door window can be opened and closed.

●

If the window cannot be opened and closed even when performing the
above operations, perform the following procedure for function initialization.

Turn the engine switch to the “ON” position (vehicles without a smart
entry & start system) or the engine switch to IGNITION ON mode (vehi-
cles with a smart entry & start system).
Pull and hold the power window switch in the one-touch closing direction
and completely close the window.
Release the power window switch for a moment, resume pulling the
switch in the one-touch closing direction, and hold it there for approxi-
mately 6 seconds or more.
Press and hold the power window switch in the one-touch opening direc-
tion. After the door window is completely opened, continue holding the
switch for an additional 1 second or more.
Release the power window switch for a moment, resume pushing the
switch in the one-touch opening direction, and hold it there for approxi-
mately 4 seconds or more.
Pull and hold the power window switch in the one-touch closing direction
again. After the window is completely closed, continue holding the switch
for a further 1 second or more.

If you release the switch while the window is moving, start again from the
beginning.
If the window reverses and cannot be fully closed or opened, have the vehi-
cle inspected by any authorized Toyota retailer or Toyota authorized
repairer, or any reliable repairer.

■

Door lock linked window operation

The power windows can be opened and closed using the wireless remote
control or key if customized at any authorized Toyota retailer or Toyota autho-
rized repairer, or any reliable repairer. (



P. 165, 166)

■

Customization

Settings (e.g. linked door lock operation) can be changed.
(Customizable features:



P. 769)

232

3-5. Opening and closing the windows and moon roof

WARNING

Observe the following precautions.
Failing to do so may result in death or serious injury.

■

Closing the windows

●

The driver is responsible for all the power window operations, including the
operation for the passengers. In order to prevent accidental operation,
especially by a child, do not let a child operate the power windows. It is
possible for children and other passengers to have body parts caught in
the power window. Also, when riding with a child, it is recommended to use
the window lock switch. (



P. 229)

●

Check to make sure that all passengers do not have any part of their body
in a position where it could be caught when a window is being operated.

●

When using the wireless remote control or mechanical key and operating
the power windows, operate the power window after checking to make
sure that there is no possibility of any passenger having any of their body
parts caught in the window. Also, do not let a child operate window by the
wireless remote control or mechanical key. It is possible for children and
other passengers to get caught in the power window.

●

When exiting the vehicle, turn the engine switch to the “LOCK” position
(vehicles without a smart entry & start system) or off (vehicles with a smart
entry & start system), carry the key and exit the vehicle along with the
child. There may be accidental operation, due to mischief, etc., that may
possibly lead to an accident.

■

Jam protection function

●

Never use any part of your body to intentionally activate the up jam protec-
tion function.

●

The jam protection function may not work if something gets jammed just
before the window is fully closed. Be careful not to get any part of your
body jammed in the window.

■

Catch protection function

●

Never use any part of your body or clothing to intentionally activate the
catch protection function.

●

The catch protection function may not work if something gets caught just
before the window is fully opened. Be careful not to get any part of your
body or clothing caught in the window.

233

3-5. Opening and closing the windows and moon roof

ati

on
of e
a

pon
ent

Moon roof



Opens the moon roof

The moon roof stops slightly before
the fully open position to reduce
wind noise.
Press the switch again to fully open
the moon roof.

Closes the moon roof

: Lightly press either end of the

moon roof switch to stop the moon
roof partway.

Tilts the moon roof up

Tilts the moon roof down

: Lightly press either end of the

moon roof switch to stop the moon
roof partway.



: If equipped

Use the overhead switches to open and close the moon roof and
tilt it up and down.

Opening and closing

Tilting up and down

1
2

234

3-5. Opening and closing the windows and moon roof

■

The moon roof can be operated when



Vehicles without a smart entry & start system

The engine switch is in the “ON” position.



Vehicles with a smart entry & start system

The engine switch is in IGNITION ON mode.

■

Operating the moon roof after turning the engine off



Vehicles without a smart entry & start system

The moon roof can be operated for approximately 45 seconds after the
engine switch is turned to the “ACC” or “LOCK” position. It cannot, however,
be operated once either front door is opened.



Vehicles with a smart entry & start system

The moon roof can be operated for approximately 45 seconds after the
engine switch is turned to ACCESSORY mode or turned off. It cannot, how-
ever, be operated once either front door is opened.

■

Jam protection function

If an object is detected between the moon roof and the frame while the moon
roof is closing or tilting down, travel is stopped and the moon roof opens
slightly.

■

Sunshade

The sunshade can be opened and closed manually. However, the sunshade
will open automatically when the moon roof is opened.

■

Door lock linked moon roof operation

The moon roof can be opened and closed using the wireless remote control
or key if customized at any authorized Toyota retailer or Toyota authorized
repairer, or any reliable repairer. (



P. 165, 166)

■

Moon roof open reminder function

An alarm will sound when the driver’s door is opened with the moon roof not
fully closed and the engine switch off.

■

When the moon roof does not close normally

Perform the following procedure:

●

If the moon roof closes but then re-opens slightly

Stop the vehicle.

Press and hold “



” on the

The moon roof will close, re-open and pause for approximately 10 sec-
onds.

Then it will close again, tilt up and pause for approximately 1 sec-

ond. Finally, it will tilt down, open and close.
Check to make sure that the moon roof is completely closed and then
release the switch.

235

3-5. Opening and closing the windows and moon roof

ati

on
of e
a

pon
ent

●

If the moon roof tilts down but then tilts back up

Stop the vehicle.

Press and hold “



” on the

until the moon roof moves into the tilt

up position and stops.

Release “



” on the

once and then press and hold “



” on the

again.

The moon roof will pause for approximately 10 seconds in the tilt up posi-
tion.

Then it will adjust slightly and pause for approximately 1 second.

Finally, it will tilt down, open and close.
Check to make sure that the moon roof is completely closed and then
release the switch.

: If the switch is released at the incorrect time, the procedure will have to

be performed again from the beginning.

: If the switch is released after the above mentioned 10 second pause,

automatic operation will be disabled. In that case, press and hold “



” on

the

or “



” on the

and the moon roof will tilt up and pause for

approximately 1 second. Then it will tilt down, open and close. Check to
make sure that the moon roof is completely closed and then release the
switch.

If the moon roof does not fully close even after performing the above proce-
dure correctly, have the vehicle inspected by any authorized Toyota retailer or
Toyota authorized repairer, or any reliable repairer.

■

Customization

Settings (e.g. linked door lock operation) can be changed.
(Customizable features:



P. 769)

236

3-5. Opening and closing the windows and moon roof

WARNING

Observe the following precautions.
Failing to do so may cause death or serious injury.

■

Opening the moon roof

●

Do not allow any passengers to put their hands or heads outside the vehi-
cle while it is moving.

●

Do not sit on top of the moon roof.

■

Closing the moon roof

●

The driver is responsible for moon roof opening and closing operations.
In order to prevent accidental operation, especially by a child, do not let a
child operate the moon roof. It is possible for children and other passen-
gers to have body parts caught in the moon roof.

●

Check to make sure that all passengers do not have any part of their bod-
ies in a position where it could be caught when the moon roof is being
operated.

●

When using the wireless remote control or mechanical key and operating
the moon roof, operate the moon roof after checking to make sure that
there is no possibility of any passenger having any of their body parts
caught in the moon roof. Also, do not let a child operate moon roof by the
wireless remote control or mechanical key. It is possible for children and
other passengers to get caught in the moon roof.

●

■

Jam protection function

●

Never use any part of your body to intentionally activate the jam protection
function.

●

The jam protection function may not work if something gets caught just
before the moon roof fully closes.

237

Driving

4-1. Before driving

Driving the vehicle .............238
Cargo and luggage ............251
Trailer towing

(with towing hitch)............254

4-2. Driving procedures

Engine (ignition) switch

(vehicles without a smart
entry & start system)........266

Engine (ignition) switch

(vehicles with a smart
entry & start system)........270

Automatic transmission .....280
Manual transmission..........287
Turn signal lever ................291
Parking brake ....................292
DPF (Diesel Particulate

Filter) system (1GD-FTV
engine only).....................293

4-3. Operating the lights and

wipers

Headlight switch ................299
AHB (Automatic High

Beam)..............................314

Fog light switch..................319
Windshield wipers and

washer.............................321

Rear window wiper and

washer.............................327

Headlight cleaner switch....329

4-4. Refueling

Opening the fuel

tank cap ...........................331

4-5. Using the driving support

systems

Toyota Safety Sense .........335
PCS (Pre-Collision

System) ...........................342

LDA (Lane Departure

Alert with Yaw Assist
Function)..........................353

RSA (Road Sign Assist).....364
Dynamic radar cruise

control..............................370

Cruise control.....................387
Stop & Start system ...........391
Driving mode select

switches...........................401

Toyota parking

assist-sensor ...................404

Driving assist systems .......416
BSM

(Blind Spot Monitor).........422
• BSM function .................426
• RCTA function ...............429

4-6. Driving tips

Winter driving tips ..............436

238

4-1. Before driving

Driving the vehicle



P. 266, 270



Automatic transmission
With the brake pedal depressed, shift the shift lever to D. (



P. 280)

Release the parking brake. (



P. 292)

Gradually release the brake pedal and gently depress the accelera-
tor pedal to accelerate the vehicle.



Manual transmission
While depressing the clutch pedal, shift the shift lever to 1.
(



P. 287)

Release the parking brake. (



P. 292)

Gradually release the clutch pedal. At the same time, gently
depress the accelerator pedal to accelerate the vehicle.



Automatic transmission
With the shift lever in D, depress the brake pedal.

Vehicles with Stop & Start system: If the Stop & Start system is enabled,
depressing the brake pedal will stop the engine.

If necessary, set the parking brake.

If the vehicle is to be stopped for an extended period of time, shift the shift
lever to P or N. (



P. 280)



Manual transmission
While depressing the clutch pedal, depress the brake pedal.
If necessary, set the parking brake.

If the vehicle is to be stopped for an extended period of time, shift the shift
lever to N. (



P. 287)

The following procedures should be observed to ensure safe
driving:

Starting the engine

Driving

Stopping

239

4-1. Before driving

riv



Automatic transmission
With the shift lever in D, depress the brake pedal.
Set the parking brake (



P. 292), and shift the shift lever to P

(



P. 280).

Vehicles without a smart entry & start system:
Turn the engine switch to the “LOCK” position to stop the engine.
Vehicles with a smart entry & start system:
Press the engine switch to stop the engine.
Lock the door, making sure that you have the key on your person.

If parking on a hill, block the wheels as needed.



Manual transmission
While depressing the clutch pedal, depress the brake pedal.
Shift the shift lever to N. (



P. 287)

Set the parking brake. (



P. 292)

If parking on a hill, shift the shift lever to 1 or R as needed.

If parking on a hill, block the wheels as needed.

Parking the vehicle

Toyota Land Cruiser Prado (2023 year). Manual in english - page 14
