192

3-2. Opening, closing and locking the doors

■

Note for the entry function

●

Even when the electronic key is within the effective range (detection areas),
the system may not operate properly in the following cases:
• The electronic key is too close to the window or outside door handle, near

the ground, or in a high place when the doors are locked or unlocked.

• The electronic key is on the instrument panel, luggage cover (if equipped)

or floor, or in the door pockets or glove box when the engine is started or
engine switch modes are changed.

●

Do not leave the electronic key on top of the instrument panel or near the
door pockets when exiting the vehicle. Depending on the radio wave recep-
tion conditions, it may be detected by the antenna outside the cabin and the
doors will become lockable from the outside, possibly trapping the electronic
key inside the vehicle.

●

As long as the electronic key is within the effective range, the doors may be
locked or unlocked by anyone. However, only the doors detecting the elec-
tronic key can be used to unlock the vehicle.

●

Even if the electronic key is not inside the vehicle, it may be possible to start
the engine if the electronic key is near the window.

●

The doors may lock or unlock if a large amount of water splashes on the
door handle, such as in the rain or in a car wash, when the electronic key is
within the effective range. (The doors will automatically be locked after
approximately 30 seconds if the doors or the glass hatch are not opened
and closed.)

●

If the wireless remote control is used to lock the doors when the electronic
key is near the vehicle, there is a possibility that the door may not be
unlocked by the entry function. (Use the wireless remote control to unlock
the doors.)

●

Touching the door lock sensor while wearing gloves may prevent lock oper-
ation.

●

When the lock operation is performed using the lock sensor, recognition sig-
nals will be shown up to two consecutive times. After this, no recognition
signals will be given.

: This setting can be customized at any authorized Toyota retailer or Toyota

authorized repairer, or any reliable repairer.

●

If the door handle becomes wet while the electronic key is within the effec-
tive range, the door may lock and unlock repeatedly. In this case, follow the
following correction procedures to wash the vehicle:
• Place the electronic key in a location 2 m (6 ft.) or more away from the

vehicle. (Take care to ensure that the key is not stolen.)

• Set the electronic key to battery-saving mode to disable the smart entry &

start system. (



P. 190)

193

3-2. Opening, closing and locking the doors

ati

on
of e
a

pon
ent

●

If the electronic key is inside the vehicle and a door handle becomes wet
during a car wash, a message may be shown on the multi-information dis-
play and a buzzer will sound outside the vehicle. To turn off the alarm, lock
all the doors.

●

The lock sensor may not work properly if it comes into contact with ice,
snow, mud, etc. Clean the lock sensor and attempt to operate it again, or
use the lock sensor on the lower part of the door handle.

●

A sudden approach to the effective range or door handle may prevent the
doors from being unlocked. In this case, return the door handle to the origi-
nal position and check that the doors unlock before pulling the door handle
again.

●

Unlocking the vehicle may take more time if another electronic key is within
the effective range.

■

When the vehicle is not driven for extended periods

●

To prevent theft of the vehicle, do not leave the electronic key within 2 m
(6 ft.) of the vehicle.

●

The smart entry & start system can be deactivated in advance. (



P. 769)

●

Setting the electronic key to battery-saving mode helps to reduce key bat-
tery depletion. (



P. 190)

■

To operate the system properly

Make sure to carry the electronic key when operating the system. Do not get
the electronic key too close to the vehicle when operating the system from the
outside of the vehicle.
Depending on the position and holding condition of the electronic key, the key
may not be detected correctly and the system may not operate properly. (The
alarm may go off accidentally, or the door lock prevention function may not
operate.)

■

If the smart entry & start system does not operate properly

●

Locking and unlocking the doors: Use the mechanical key. (



P. 719)

●

Starting the engine:



P. 720

■

Customization

Settings (e.g. smart entry & start system) can be changed.
(Customizable features:



P. 769)

■

If the smart entry & start system has been deactivated in a customized
setting

●

Locking and unlocking the doors:
Use the wireless remote control or mechanical key. (



P. 165, 719)

●

Starting the engine and changing engine switch modes:



P. 720

●

Stopping the engine:



P. 272

194

3-2. Opening, closing and locking the doors

WARNING

■

Caution regarding interference with electronic devices

●

People with implantable cardiac pacemakers, cardiac resynchronization
therapy-pacemakers or implantable cardioverter defibrillators should
maintain a reasonable distance between themselves and the smart entry
& start system antennas. (



P. 187)

The radio waves may affect the operation of such devices. If necessary,
the entry function can be disabled. Ask any authorized Toyota retailer or
Toyota authorized repairer, or any reliable repairer for details, such as the
frequency of radio waves and timing of the emitted radio waves. Then,
consult your doctor to see if you should disable the entry function.

●

Users of any electrical medical device other than implantable cardiac
pacemakers, cardiac resynchronization therapy-pacemakers or implanta-
ble cardioverter defibrillators should consult the manufacturer of the
device for information about its operation under the influence of radio
waves.
Radio waves could have unexpected effects on the operation of such
medical devices.

Ask any authorized Toyota retailer or Toyota authorized repairer, or any reli-
able repairer for details on disabling the entry function.

195

3-3. Adjusting the seats

ati

on
of e
a

pon
ent

Front seats



Manual seat



Power seat

Adjustment procedure

Seat position adjustment lever
Seatback angle adjustment
lever

Vertical height adjustment
lever (driver’s side only)
Lumbar support adjustment
switch (driver’s side only)

1
2

Seat position adjustment switch
Seatback angle adjustment
switch
Seat cushion (front) angle
adjustment switch (driver’s side
only)

Vertical height adjustment
switch (driver’s side only)
Lumbar support adjustment
switch (driver’s side only)

1
2

196

3-3. Adjusting the seats

When the occupant’s lower back
presses against the seatback
during a rear-end collision, the
head restraint moves slightly for-
ward and upward to help reduce
the risk of whiplash on the seat
occupant.

■

Getting in the vehicle

Pull the seatback angle adjust-
ment lever and fold down the
seatback. The seat will slide
forward.
Move the seat to the front-most
position

■

Getting out of the vehicle

Depress the release pedal and
fold down the seatback. The
seat will slide forward.
Move the seat to the front-most
position

Make sure that no passenger is
seated on the front passenger
seat before depressing the
release pedal.

■

After passengers have entered/exited the vehicle

Lift up the seatback and slide the seat backward until it locks.

Active head restraints

Moving a front passenger’s seat for second seat access (3-door
models)

197

3-3. Adjusting the seats

ati

on
of e
a

pon
ent

■

When adjusting the seat

●

Make sure that any surrounding passengers or objects are not contact the
seat.

●

Take care when adjusting the seat so that the head restraint does not touch
the ceiling and sun visor.

■

Active head restraints

Even small forces applied to the seatback may cause the head restraint to
move. Pushing up a locked head restraint forcibly may appear the head
restraint inner structure. These do not indicate problems.

WARNING

■

When adjusting the seat position

●

Take care when adjusting the seat position to ensure that other passen-
gers are not injured by the moving seat.

●

Do not put your hands under the seat or near the moving parts to avoid
injury.
Fingers or hands may become jammed in the seat mechanism.

■

Seat adjustment

●

To reduce the risk of sliding under the lap belt during a collision, do not
recline the seat more than necessary.
If the seat is too reclined, the lap belt may slide past the hips and apply
restraint forces directly to the abdomen, or your neck may contact the
shoulder belt, increasing the risk of death or serious injury in the event of
an accident.
Adjustments should not be made while driving as the seat may unexpect-
edly move and cause the driver to lose control of the vehicle.

●

After adjusting the seat, make sure that the seat is locked in position.
(manual seat only)

During
rear-end
collision

Inner
structure

198

3-3. Adjusting the seats

Rear seats



■

Second seat (if equipped)



3-door models

Seatback angle adjustment
lever



5-door models with double fold function seats

Seatback angle adjustment
lever



5-door models with walk-in function seats

Seatback angle adjustment
lever
Seat position adjustment
lever



: If equipped

Adjustment procedure

199

3-3. Adjusting the seats

ati

on
of e
a

pon
ent

■

Third seat (if equipped)



Power seat

Seatback angle adjustment
switch

■

Getting in the vehicle (right side only [left-hand drive vehicles]
or left side only [right-hand drive vehicles])

Pull the seatback angle adjust-
ment lever and fold down the
seatback. The seat will slide
forward.
Move the seat to the front-most
position

■

Getting out of the vehicle (right side only [left-hand drive vehi-
cles] or left side only [right-hand drive vehicles])

Pull the release lever and fold
down the seatback. The seat
will slide forward.
Move the seat to the front-most
position

Make sure that no passenger is
seated on the second seat
before pulling the release lever.

■

After passengers have entered/exited the vehicle

Lift up the seatback and slide the seat backward until it locks.

Moving a second seat for third seat or luggage compartment
access (5-door models with walk-in function seats)

200

3-3. Adjusting the seats

■

Before tumbling the second seats

Lower the head restraints to the
lowest position.

Use the seat belt hangers to
prevent the belts from being
tangled.
Make sure that the seat belts
are removed from the hangers
before using them.

Tumbling the second seats (3-door models)

201

3-3. Adjusting the seats

ati

on
of e
a

pon
ent

■

Tumbling the second seats

Pull the seatback angle lever
and fold them down.

Pull the seat lock release
lever on the back and swing
the whole seat up and for-
ward.

■

Returning the second seats

Push the knob to unlock the
seat, swing the whole seat
down and swing the seatback
up.

202

3-3. Adjusting the seats

■

Before folding down the second seatbacks

Stow the center seat belt buckle
with the hook-and-loop fastener
and lower the head restraints to
the lowest position.

■

Folding down second seatbacks

Swing the bottom cushion up
by pulling the lock release
strap.

Push the seatback lock
release button and fold them
down.

To return the second seatbacks
to their original positions, lift
them up until they lock.

Folding down the second seatbacks (5-door models with double
fold function seats)

203

3-3. Adjusting the seats

ati

on
of e
a

pon
ent

■

Before folding down the second seatbacks

Lower the head restraints to the
lowest position.

■

Folding down second seatbacks

Pull the seatback lock release
lever and fold them down.

To return the second seatbacks
to their original positions, lift
them up until they lock.

Folding down the second seatbacks (5-door models with walk-in
function seats)

204

3-3. Adjusting the seats

■

Folding down second center seatback only (5-door models)

■

If you cannot raise the seatback

Pull the center seatback lock release
lever behind the seatback and fold it
down.
To return the center seatback to its origi-
nal position, lift it up until it locks.

Release the seat belt lock by:

Pushing on the lower front edge of the
seatback to slacken the seat belt.
Let the seat belt retract a little.

205

3-3. Adjusting the seats

ati

on
of e
a

pon
ent

■

Before folding down the third seats

Lower the head restraints to the
lowest position.

Pass the seat belts through the
seat belt hangers and secure
the seat belt plates.

This prevents the shoulder belt
from being damage.
Make sure that the seat belts
are removed from the hangers
before using them.

■

Folding down the third seats



From back door side

Pull the seat cushion/seatback
lock release lever and fold the
seatback down.

The seat cushion is stowed
automatically.

Folding down the third seats (manual seat)

206

3-3. Adjusting the seats



From rear door side

Pull the seat cushion lock
release lever.

The seat cushion is stowed
automatically.

Pull the seatback lock
release lever and fold them
down.

■

Returning the third seats

From rear door side, unlock
the seatbacks by pulling the
lock release lever, and lift
them up until they lock.

Pull the grip and carry the
seat cushions out.

207

3-3. Adjusting the seats

ati

on
of e
a

pon
ent

Right seat return switch
Right seat fold switch
Left seat return switch
Left seat fold switch

The switches can be operated from both the rear door side and the back
door side.

■

Before folding down the third seats

Pass the seat belts through the
seat belt hangers and secure
the seat belt plates.

This prevents the shoulder belt
from being damage.
Make sure that the seat belts
are removed from the hangers
before using them.

Folding down the third seats (power seat)



Left-hand drive vehicles



Right-hand drive vehicles

1
2
3
4

Content .. 10 11 12 13 ..
