7-2. Steps to take in an emergency

hen
trou

e ari

■

The tire pressure warning light may come on due to natural causes

The tire pressure warning light may come on due to natural causes such as
natural air leaks or tire inflation pressure changes caused by temperature. In
this case, adjusting the tire inflation pressure will turn off the warning light
(after a few minutes).

■

When a tire is replaced with a spare tire (if equipped)

Vehicles with full-size  spare  tire: The spare tire  is also  equipped  with  a tire
pressure  warning  valve  and  transmitter. The  tire  pressure  warning  light  will
turn on if the tire inflation pressure of the spare tire is low. If a tire goes flat,
the  tire  pressure  warning  light  will  not  turn  off  even  though  the  flat  tire  has
been replaced with the spare tire. Replace the spare tire with the repaired tire
and adjust the tire inflation pressure. The tire pressure warning light will go off
after a few minutes.
Vehicles with compact spare tire: The compact spare tire is not equipped with
a tire pressure warning valve and transmitter. If a tire goes flat, the tire pres-
sure warning light will not turn off even though the flat tire has been replaced
with the spare tire. Replace the spare tire with the repaired tire and adjust the
tire inflation  pressure. The  tire pressure warning  light will  go off  after a  few
minutes.

■

Conditions that the tire pressure warning system may not function prop-
erly



P. 619

■

If the tire pressure warning light frequently comes on after blinking for
1 minute

If the tire pressure warning light frequently comes on after blinking for
1 minute when the power switch is turned to ON mode, have it checked by
any authorized Toyota retailer or Toyota authorized repairer, or any reliable
repairer.

■

Warning buzzer

In some cases, the buzzer may not be heard because of noisy place or an
audio sound.

688

7-2. Steps to take in an emergency

WARNING

■

If both the ABS and the brake system warning lights remain on

Stop your vehicle in a safe place immediately and contact any authorized
Toyota retailer or Toyota authorized repairer, or any reliable repairer. The
vehicle will become extremely unstable during braking, and the ABS system
may fail, which could cause an accident resulting in death or serious injury.

■

When the electric power steering system warning light comes on

When  the  light  comes  on  yellow,  the  assist  to  the  power  steering  is
restricted. When the light comes on red, the assist to the power steering is
lost  and  handling  operations  of  the  steering  wheel  become  extremely
heavy.  When  steering  wheel  operations  are  heavier  than  usual,  grip  the
steering wheel firmly and operate it using more force than usual.

■

If the tire pressure warning light comes on

Be sure to observe the following precautions. Failure to do so could cause a
loss of vehicle control and result in death or serious injury.

●

Stop your vehicle in a safe place as soon as possible. Adjust the tire infla-
tion pressure immediately.

●

Vehicles with spare tire: If the tire pressure warning light comes on even
after tire inflation pressure adjustment, it is probable that you have a flat
tire. Check the tires. If a tire is flat, change it with the spare tire and have
the flat tire repaired by the nearest any authorized Toyota retailer or Toyota
authorized repairer, or any reliable repairer.

●

Vehicles with emergency tire puncture repair kit: If the tire pressure warn-
ing light comes on even after tire inflation pressure adjustment, it is proba-
ble that you have a flat tire. Check the tires. If a tire is flat, repair the flat tire
by using emergency tire puncture repair kit. (



P. 697)

●

Avoid abrupt maneuvering and braking. If the vehicle tires deteriorate, you
could lose control of the steering wheel or the brakes.

■

If a blowout or sudden air leakage should occur

The tire pressure warning system may not activate immediately.

689

7-2. Steps to take in an emergency

hen
trou

e ari

NOTICE

■

To ensure the tire pressure warning system operates properly

Do not install tires with different specifications or makers, as the tire pres-
sure warning system may not operate properly.

690

7-2. Steps to take in an emergency

If a warning message is displayed

Multi-information display

If any of the warning messages are shown again after the following
actions have been performed, contact any authorized Toyota retailer
or Toyota authorized repairer, or any reliable repairer.

The multi-information display shows warnings of system mal-
functions, incorrectly performed operations, and messages that
indicate a need for maintenance. When a message is shown,
perform the correction procedure appropriate to the message.

691

7-2. Steps to take in an emergency

hen
trou

e ari

The warning lights and warning buzzers operate as follows depending
on the content of the message. If a message indicates the need for
inspection by a dealer, have the vehicle inspected by any authorized
Toyota retailer or Toyota authorized repairer, or any reliable repairer
immediately.

: A buzzer sounds the first time a message is shown on the multi-informa-

tion display.

Messages and warnings

System

warning

light

Warning

buzzer

Warning



Sounds

• Indicates an important situation, such as when a

system related to driving is malfunctioning or that
danger may result if the correction procedure is
not performed

• Indicates a situation, such as when damage to

the vehicle or danger may result

Comes on

or flashes

Sounds

Indicates an important situation, such as when the
systems shown on the multi-information display
may be malfunctioning



Does not

sound

• Indicates a condition, such as malfunction of

electrical components, their condition, or indi-
cates the need for maintenance

• Indicates a situation, such as when an operation

has been performed incorrectly, or indicates how
to perform an operation correctly

692

7-2. Steps to take in an emergency

■

Warning messages

The warning messages explained below may differ from the actual messages
according to operation conditions and vehicle specifications.

■

If a message that indicates the need for visiting your Toyota dealer is
displayed

The system or part shown on the multi-information display is malfunctioning.
Have the vehicle inspected by any authorized Toyota retailer or Toyota autho-
rized repairer, or any reliable repairer immediately.

■

If a message about an operation is shown

●

If a message about an operation of the accelerator pedal or brake pedal is
shown
A warning message about an operation of the brake pedal may be shown
while the driving assist systems such as PCS (Pre-Collision System) (if
equipped) or the dynamic radar cruise control with full-speed range (if
equipped) is operating. If a warning message is shown, be sure to deceler-
ate the vehicle or follow the instruction shown on the multi-information dis-
play.

●

A warning message is shown when Brake Override System operates.
(



P. 284)

●

A warning message is shown when Drive-Start Control or Parking Support
Brake (if equipped) operates (



P. 284, 475). Follow the instructions on the

multi-information display.

●

If a message about an operation of the power switch is shown
An instruction for operation of the power switch is shown when the incorrect
procedure for starting the hybrid system is performed or the power switch is
operated incorrectly. Follow the instructions shown on the multi-information
display to operate the power switch again.

●

If a message about a shift operation is shown
To prevent the shift lever from being operated incorrectly or the vehicle from
moving unexpectedly, a message that requires shifting the shift lever may
be shown on the multi-information display. In that case, follow the instruction
of the message and shift the shift lever.

●

If a message or image about an open/close state of a part or replenishment
of a consumable is shown
Confirm the part indicated by the multi-information display or a warning light,
and then perform the coping method such as closing the open door or
replenishing a consumable.

693

7-2. Steps to take in an emergency

hen
trou

e ari

■

If a message that indicates the need for referring to Owner’s Manual is
displayed

●

If “Engine Coolant Temperature High.”is shown, follow the instructions
(



P. 755).

●

If the following messages are shown, there may be a malfunction. Immedi-
ately stop the vehicle in a safe place and contact any authorized Toyota
retailer or Toyota authorized repairer, or any reliable repairer. Continuing to
drive the vehicle may be dangerous.
• “Braking Power Low.”
• “Charging System Malfunction.”
• “Engine Oil Pressure Low.”

●

If the following messages are shown, there may be a malfunction. Immedi-
ately have the vehicle inspected by any authorized Toyota retailer or Toyota
authorized repairer, or any reliable repairer.
• “Hybrid System Malfunction.”
• “Check Engine.”
• “Hybrid Battery System Malfunction.”
• “Accelerator system Malfunction.”
• “Entry & Start System Malfunction.”
• “Exhaust filter full.” (



P. 529)

• “Hybrid System Stopped”
• “Engine Stopped”

●

If the “Low 12-Volt Battery.” is shown,
• When the display goes off after several seconds (displays for about 6

seconds):
Maintain the hybrid system operation for more than 15 minutes and
charge the 12-volt battery.

• When the display does not go off:

Start up the hybrid system using the procedures:



P. 747

●

If “Maintenance required for Traction battery cooling parts. See owner’s
manual.” is shown, the filters may be clogged, the air intake vents may be
blocked, or there may be a gap in the duct. Therefore, perform the following
correction procedure.
• If the air intake vents and filters of the hybrid battery (traction battery) are

dirty, perform the procedure on P. 638 to clean them.

• If the warning message is shown when the air intake vents and filters of

the hybrid battery (traction battery) are not dirty, have the vehicle
inspected by any authorized Toyota retailer or Toyota authorized repairer,
or any reliable repairer immediately.

694

7-2. Steps to take in an emergency

■

If “Engine Oil Level Low. Add or Replace Oil.”is displayed

The engine oil level is low. Check the level of the engine oil, and add if neces-
sary.
This message may appear if the vehicle is stopped on a slope. Move the
vehicle to a level surface and check to see if the message disappears.

■

If “Hybrid System Stopped. Steering Power Low.”is displayed

This message is displayed if the hybrid system is stopped while driving.
When steering wheel operations are heavier than usual, grip the steering
wheel firmly and operate it using more force than usual.

■

If “Hybrid System Overheated. Reduced Output Power.” is shown

This message may be shown when driving under severe operating condi-
tions. (For example, when driving up a long steep hill.)
Handling method:



P. 755

■

If “Depress Brake When Vehicle is Stopped. Hybrid System may Over-
heat.” is shown

The message may be shown when the accelerator pedal is depressed to hold
the vehicle while the vehicle is stopped on an uphill, etc.
The hybrid system may overheat. Release the accelerator pedal and depress
the brake pedal.

■

If “Traction battery needs to be protected. Shift into

to restart.” is

shown

This message is displayed when the hybrid battery (traction battery) charge
has become extremely low because the shift lever has been left in N for a cer-
tain amount of time.
When operating the vehicle, shift to P and restart the hybrid system.

■

If “Traction battery needs to be protected. Refrain from the use of
position.” is shown

This message may be displayed when the shift lever is in N.
As the hybrid battery (traction battery) cannot be charged when the shift lever
is in N, shift the shift lever to P when the vehicle is stopped.

■

If “Shift is in

Release Accelerator Before Shifting” is shown

Message is displayed when the accelerator pedal has been depressed and
the shift lever is in N.
Release the accelerator pedal and shift the shift lever to D or R.

■

If “Shift to

Before Exiting Vehicle” is shown

Message is displayed when the driver’s door is opened without turning the
power switch to off with the shift lever in any position other than P.
Shift the shift position to P.

695

7-2. Steps to take in an emergency

hen
trou

e ari

■

If “Auto Power OFF to Conserve Battery” is shown

The power switch has been turned off by the automatic power off function.
When starting the hybrid system next time, operate the hybrid system for
approximately 5 minutes to recharge the 12-volt battery.

■

If “A New Key has been Registered. Contact Your Dealer for Details.” is
shown

This message will be displayed each time the driver’s door is opened when
the doors are unlocked from the outside for approximately one week after a
new electronic key has been registered.
If this message is displayed but you have not had a new electronic key regis-
tered, ask any authorized Toyota retailer or Toyota authorized repairer, or any
reliable repairer to check if an unknown electronic key (other than those in
your possession) has been registered.

■

If a message that indicates the malfunction of front camera is displayed

The following systems may be suspended until the problem shown in the
message is resolved. (



P. 365, 679)

●

PCS (Pre-Collision System)

●

LTA (Lane Tracing Assist)

●

Dynamic radar cruise control with full-speed range

●

RSA (Road Sign Assist)

●

Automatic High Beam

: If equipped

■

If a message that indicates the malfunction of radar sensor is displayed

The following systems may be suspended until the problem shown in the
message is resolved. (



P. 365, 679)

●

PCS (Pre-Collision system)

●

LTA (Lane Tracing Assist)

●

Dynamic radar cruise control with full-speed range

: If equipped

696

7-2. Steps to take in an emergency

■

If “Radar Cruise Control Unavailable See Owner’s Manual” is shown

The dynamic radar cruise control with full-speed range system is suspended
temporarily or until the problem shown in the message is resolved. (causes
and coping methods:



P. 365)

■

If “Radar Cruise Control unavailable.” is shown

The dynamic radar cruise control with full-speed range system cannot be
used temporarily. Use the system when it becomes available again.

■

Warning buzzer



P. 687

NOTICE

■

If “Maintenance required for Traction battery at your dealer.” is shown
(2ZR-FXE engine [except for Guadelope, Martinique, F. Guiana and
Greenland])

This message indicates that the hybrid battery (traction battery) may require
inspection or replacement. Have the vehicle inspected by any authorized
Toyota retailer or Toyota authorized repairer, or any reliable repairer imme-
diately. Do not continue driving the vehicle, as the hybrid system may
become not able to be started again.

■

If “Low 12-Volt Battery. See Owner’s Manual.” is displayed frequently

The 12-volt battery may have deteriorated. As the battery may discharge in
this state when left unattended, have the battery inspected by any autho-
rized Toyota retailer or Toyota authorized repairer, or any reliable repairer.

697

7-2. Steps to take in an emergency

hen
trou

e ari

If you have a flat tire (vehicles with an

emergency tire puncture repair kit)

Vehicles equipped with an emergency tire puncture repair kit do
not have a spare tire equipped.
A puncture caused by a nail or screw passing through the tire
tread can be repaired temporarily with the emergency tire punc-
ture repair kit.

WARNING

■

If you have a flat tire

Do not continue driving with a flat tire.
Driving even a short distance with a flat tire can damage the tire and the
wheel beyond repair, which could result in an accident.
Driving with a flat tire may cause a circumferential groove on the side wall.
In such a case, the tire may explode when using a repair kit.

698

7-2. Steps to take in an emergency

●

Stop the vehicle in a safe place on a hard, flat surface.

●

Set the parking brake.

●

Shift the shift lever to P.

●

Stop the hybrid system.

●

Turn on the emergency flashers.

●

Check the degree of the tire damage.

A  tire  should  only  be  repaired
with  the  emergency  tire  punc-
ture  repair  kit  if  the  damage  is
caused by a nail or screw pass-
ing through the tire tread.

• Do not remove the nail or

screw  from  the  tire.  Remov-
ing the object may widen the
opening  and  make  emer-
gency  repair  with  the  repair
kit impossible.

• To avoid sealant leakage, move the vehicle until the area of the

puncture, if known, is positioned at the top of the tire.

Before repairing the tire

699

7-2. Steps to take in an emergency

hen
trou

e ari

■

A flat tire that cannot be repaired with the emergency tire puncture repair
kit

In the following cases, the tire cannot be repaired with the emergency tire
puncture repair kit. Contact any authorized Toyota retailer or Toyota autho-
rized repairer, or any reliable repairer.

●

When the tire is damaged due to driving without sufficient air pressure

●

When the tire lost air pressure due to a crack or damage in the tire sidewall

●

When the tire is visibly separated from the wheel

●

When the cut or damage to the tread is 4 mm (0.16 in.) long or more

●

When the wheel is damaged

●

When two or more tires have been punctured

●

When there is more than one hole or cut in the damaged tire

700

7-2. Steps to take in an emergency



Type A

Towing eyelet
Jack handle (if equipped)

Wheel nut wrench (if equipped)

Jack (if equipped)

Emergency tire puncture repair kit

: A jack, jack handle and wheel nut wrench can be purchased at any autho-

rized Toyota retailer or Toyota authorized repairer, or any reliable repairer.

Location of the emergency tire puncture repair kit and tools

701

7-2. Steps to take in an emergency

hen
trou

e ari



Type B

Towing eyelet
Emergency tire puncture repair kit
Wheel nut wrench (if equipped)

Jack (if equipped)

Jack handle (if equipped)

: A jack, jack handle and wheel nut wrench can be purchased at any autho-

rized Toyota retailer or Toyota authorized repairer, or any reliable repairer.

Toyota C-HR (2023 year). Manual in english - page 37
