127

2-1. Instrument cluster

2

Vehicle

 statu

s information an

d in
dicator

s

Charge area

Hybrid Eco area

Eco area

Power area

Displayed content is the same as
that displayed on the meter (Hybrid
System Indicator).
For details, refer to P.91.

■

Tachometer

Displays the engine speed in
revolutions per minute.

■

Outside temperature dis-
play

This is displayed when the
power switch is turned on or the
low temperature indicator
flashes.

■

Outside temperature display

●

When the ambient temperature is

approximately 37°F (3°C) or

lower, the low outside temperature

indicator will flash for approxi-

mately 10 seconds and the out-

side temperature display will turn

off. In this case, the display will be

displayed again when the outside

temperature becomes approxi-

mately 41°F (5°C) or higher.

●

In the following situations, the cor-

rect outside temperature may not

be displayed, or the display may

take longer than normal to

change:

• When stopped, or driving at low

speeds (less than 12 mph [20

km/h])

• When the outside temperature

has changed suddenly (at the

entrance/exit of a garage, tunnel,

etc.)

●

When “--” or “E” is displayed, the

system may be malfunctioning.

Take your vehicle to your Toyota

dealer.

A

B

C

D

128

2-1. Instrument cluster

Meter control switches

Multi-information display

Multimedia Display

The energy monitor can be used
to check the vehicle drive status,
hybrid system operation status
and energy regeneration status.

■

Display procedure



Multi-information display

Use the meter control switches,
display the energy monitor on
the multi-information display.

For detail regarding the multi-infor-
mation display, refer to P.105, 117.



Multimedia Display

Touch

 from the main menu,

then touch “Energy flow”.

■

Reading the display

The arrows will appear in accor-
dance with the energy flow.
When there is no energy flow,
arrows will not be displayed.

The color of the arrows will change
as follows
Blue: When the hybrid battery (trac-
tion battery) is regenerated or
charged.
Orange: When the hybrid battery
(traction battery) is in use.
Red: When the gasoline engine is
in use.



Multi-information display (7-
inch multi-information display)

The image shows all the arrows as
an example. The actual display will
vary depending on conditions.

Gasoline engine

Hybrid battery (traction bat-
tery)P.105

Front tires

Rear tires

Energy monitor/con-

sumption screen

You can view the status of
your hybrid system and fuel
consumption information
on the multi-information
display and Multimedia Dis-
play.

System components

Energy monitor

A

B

C

A

B

C

D

129

2-1. Instrument cluster

2

Vehicle

 statu

s information an

d in
dicator

s



Multi-information display
(12.3-inch multi-information
display)

Gasoline engine

Front tires

Rear tires

Hybrid battery (traction bat-
tery)



Multimedia Display

The image shows all the arrows as
an example. The actual display will
vary depending on conditions.

Gasoline engine

Front electric motor (traction
motor)

Hybrid battery (traction bat-
tery)

Rear electric motor (traction
motor)

Rear tires

Front tires

■

Hybrid battery (traction battery)

status

The display changes in 8 levels

according to the remaining charge

amount of the hybrid battery (trac-

tion battery).

●

The figure shows the multi-infor-

mation display as an example for

explanation.

●

These images are examples only,

and may vary slightly from actual

conditions.

Low

High

■

Remaining charge amount

warning of hybrid battery (trac-

tion battery)

●

The buzzer sounds intermittently

when the hybrid battery (traction

battery) remains without charging

while the shift lever is in N, or the

remaining charge amount drops

below a certain level. If the

remaining charge amount drops

further, the buzzer sounds contin-

uously.

●

When a warning message is

shown on the multi-information

display and the buzzer sounds,

follow the instructions displayed

on the screen to perform trouble-

shooting.

A

B

C

D

A

B

C

D

E

F

A

B

130

2-1. Instrument cluster

■

Display procedure

Touch

 from the main menu,

then touch “Trip information”.

■

Current fuel consumption
screen

If a screen other than current
fuel consumption screen is dis-
played, touch “Current”.

Use the displayed average fuel
consumption as a reference.
Some screens may vary depending
on the type of multi-media display.
The image is an example only, and
may vary slightly from actual condi-
tions.

Resetting the consumption
data

Fuel consumption in the past
15 minutes

Current fuel consumption

Average vehicle speed since
the hybrid system was
started.

Trip range

Elapsed time since the hybrid
system was started.

■

History screen

If a screen other than history
screen is displayed, touch “His-
tory”.

Use the displayed average fuel
consumption as a reference.
Some screens may vary depending
on the type of multi-media display.
The image is an example only, and
may vary slightly from actual condi-
tions.

Latest fuel consumption

Best recorded fuel consump-
tion

Previous fuel consumption
record

Resetting the history data

Updating the latest fuel con-
sumption data

■

Updating the history data

Update the latest fuel consumption

by touching “Update” to measure

the current fuel consumption again.

■

Resetting the data

The fuel consumption data can be

deleted by touching “Clear data”.

■

Trip range

Displays the estimated maximum

distance that can be driven with the

Consumption screen

A

B

C

D

E

F

A

B

C

D

E

131

2-1. Instrument cluster

2

Vehicle

 statu

s information an

d in
dicator

s

quantity of fuel remaining.
This distance is computed based on

your average fuel consumption. As

a result, the actual distance that can

be driven may differ from that dis-

played.

133

3

3

Before

driving

Before driving

3-1. Key information

Keys ............................

134

3-2. Opening, closing and

locking the doors

Side doors...................

137

Back door....................

142

Smart key system .......

154

3-3. Adjusting the seats

Front seats ..................

159

Rear seats...................

160

Driving position memory

..................................

162

Head restraints............

166

3-4. Adjusting the steering

wheel and mirrors

Steering wheel ............

168

Inside rear view mirror

169

Digital Rear-view Mirror

..................................

170

Outside rear view mirrors

..................................

181

3-5. Opening, closing the win-

dows

Power windows ...........

183

134

3-1. Key information

3-1.Key information

The following keys are provided
with the vehicle.

Electronic keys

• Operating the smart key system

(



P.154)

• Operating the wireless remote

control function (



P.136)

Mechanical keys

Key number plate

■

When riding in an aircraft

When bringing an electronic key

onto an aircraft, make sure you do

not press any buttons on the elec-

tronic key while inside the aircraft

cabin. If you are carrying an elec-

tronic key in your bag etc., ensure

that the buttons are not likely to be

pressed accidentally. Pressing a

button may cause the electronic key

to emit radio waves that could inter-

fere with the operation of the air-

craft.

■

Electronic key battery depletion

●

The standard battery life is 1 to 2

years.

●

If the battery becomes low, an

alarm will sound in the cabin and a

message will be displayed on the

multi-information display when the

hybrid system stops.

●

To reduce key battery depletion

when the electronic key is to not

be used for long periods of time,

set the electronic key to the bat-

tery-saving mode. (



P.156)

●

As the electronic key always

receives radio waves, the battery

will become depleted even if the

electronic key is not used. The fol-

lowing symptoms indicate that the

electronic key battery may be

depleted. Replace the battery

when necessary.

• The smart key system or the wire-

less remote control does not oper-

ate.

• The detection area becomes

smaller.

• The LED indicator on the key sur-

face does not turn on.

You can replace the battery by your-
self (



P.424). However, as there is

a danger that the electronic key may
be damaged, it is recommended
that replacement is carried out by
your Toyota dealer.

●

To avoid serious deterioration, do

not leave the electronic key within

3 ft. (1 m) of the following electri-

cal appliances that produce a

magnetic field:

• TVs

• Personal computers

• Cellular phones, cordless phones

and battery chargers

• Table lamps

• Induction cookers

●

If the electronic key is near the

vehicle for longer than necessary,

even if the smart key system is not

operated, the key battery may

become depleted faster than nor-

mal. When not operating the

smart key system, it is recom-

mended to not stay with the elec-

tronic key near the vehicle longer

than necessary.

Keys

Key types

A

B

C

135

3-1. Key information

3

Before

driving

■

If a message regarding the state

of the electronic key or power

switch mode, etc. is shown

To prevent trapping the electronic

key inside the vehicle, leaving the

vehicle carrying the electronic key

on your person without turning the

power switch to OFF or other pas-

sengers from unintentionally taking

the key out of the vehicle, etc., a

message that prompts the user to

confirm the state of the electronic

key or power switch mode may be

shown on the multi-information dis-

play. In those cases, follow the

instructions on the display immedi-

ately.

■

If “Key Battery Low Replace

Key Battery” is displayed on

the multi-information display

The electronic key has a low bat-

tery. Replace the electronic key bat-

tery. (



P.424)

■

Replacing the battery



P.424

■

Confirmation of the registered

key number

The number of keys already regis-

tered to the vehicle can be con-

firmed. Ask your Toyota dealer for

details.

■

If “A New Key has been Regis-

tered Contact Your Dealer for

Details” is displayed on the

multi-information display

This message will be displayed

each time the driver’s door is

opened when the doors are

unlocked from the outside for

approximately 10 days after a new

electronic key has been registered.

If this message is displayed but you

have not had a new electronic key

registered, ask your Toyota dealer

to check if an unknown electronic

key (other than those in your pos-

session) has been registered.

NOTICE

■

To prevent key damage

●

Do not drop the keys, subject

them to strong shocks or bend

them.

●

Do not expose the keys to high

temperatures for long periods of

time.

●

Do not get the keys wet or wash

them in an ultrasonic washer,

etc.

●

Do not attach metallic or mag-

netic materials to the keys or

place the keys close to such

materials.

●

Do not disassemble the keys.

●

Do not attach a sticker or any-

thing else to the surface of the

electronic key.

●

Do not place the keys near

objects that produce magnetic

fields, such as TVs, audio sys-

tems and induction cookers.

●

Do not place the keys near

medical electrical equipment

such as low-frequency therapy

equipment or microwave ther-

apy equipment, and do not

receive medical attention with

the keys on your person.

■

Carrying the electronic key

on your person

Carry the electronic key 3.9 in.

(10 cm) or more away from elec-

tric appliances that are turned on.

Radio waves emitted from electric

appliances within 3.9 in. (10 cm)

of the electronic key may interfere

with the key, causing the key to

not function properly.

■

In case of a smart key system

malfunction or other key-

related problems



P.466

136

3-1. Key information

The electronic keys are
equipped with the following
wireless remote control:

Locks all the doors (



P.137)

Unlocks all the doors
(



P.137)

Opens the side windows

*

(



P.137)

Opens and closes the power
back door (



P.143)

Sounds the alarm (



P.136)

*

: This setting must be customized

at your Toyota dealer.

■

Theft deterrent panic mode

When

 is pressed for longer

than about 1 second, an alarm will
sound intermittently and the vehicle
lights will flash to deter any person
from trying to break into or damage
your vehicle.
To stop the alarm, press any button
on the electronic key.

To take out the mechanical key,
slide the release lever

 and

take the key out.

The mechanical key can only be
inserted in one direction, as the key
only has grooves on one side. If the
key cannot be inserted in a lock cyl-
inder, turn it over and re-attempt to
insert it.
After using the mechanical key,
store it in the electronic key. Carry
the mechanical key together with
the electronic key. If the electronic
key battery is depleted or the entry
function does not operate properly,
you will need the mechanical key.
(



P.467)

■

If you lose your mechanical

keys



P.465

■

If a wrong key is used

The key cylinder rotates freely to

isolate inside mechanism.

NOTICE

■

When an electronic key is lost



P.465

Wireless remote control

A

B

C

D

E

Using the mechanical key

A

137

3-2. Opening, closing and locking the doors

3

Before

driving

3-2.Opening, closing and locking the doors

■

Using the entry function

Carry the electronic key to
enable this function.

1

Grip the driver’s door handle
to unlock the door. Holding
the driver’s door handle for
approximately 2 seconds
unlocks all the doors.
Grip the front passenger’s
door handle or rear door han-
dle (some models) to unlock
all the doors

*

.

Make sure to touch the sensor on
the back of the handle.
The doors cannot be unlocked for 3
seconds after the doors are locked.

*

: The door unlock settings can be

changed. (



P.137)

2

Touch the lock sensor (the
indentation on the surface of
the door handle) to lock the
doors.

Check that the door is securely
locked.

■

Using the wireless remote
control

1

Locks all the doors

Check that the door is securely
locked.

2

Unlocks all the doors

Pressing the button unlocks the
driver’s door. Pressing the button
again within 5 seconds unlocks the
other doors.
Press and hold to open the side
windows.

*

*

: This setting must be customized

at your Toyota dealer.

■

Switching the door unlock func-

tion

It is possible to set which doors the

entry function unlocks using the

wireless remote control. Perform the

switching operation in the vehicle or

within approximately 3.2 ft. (1 m) of

the vehicle.

1

Turn the power switch to OFF.

2

When the indicator light on the
key surface is not on, press and
hold

,

 or

 for

Side doors

The vehicle can be locked
and unlocked using the
entry function, wireless
remote control, door lock
switches or inside lock but-
tons.

Unlocking and locking the
doors from the outside

138

3-2. Opening, closing and locking the doors

approximately 5 seconds while
pressing and holding

.

The setting changes each time an
operation is performed, as shown
below. (When changing the setting
continuously, release the buttons,
wait for at least 5 seconds, and
repeat step

2

.)

*1

:Vehicles with 7-inch multi-infor-

mation display

*2

:Vehicles with 12.3-inch multi-

information display

To prevent unintended triggering of
the alarm, unlock the doors using
the wireless remote control and
open and close a door once after
the settings have been changed. (If
a door is not opened within 60 sec-
onds after

 is pressed, the

doors will be locked again and the

alarm will automatically be set.)
In a case that the alarm is triggered,
immediately stop the alarm.
(



P.81)

■

Impact detection door lock

release system

In the event that the vehicle is sub-

ject to a strong impact, all the doors

are unlocked. Depending on the

force of the impact or the type of

accident, however, the system may

not operate.

■

Operation signals

Doors: A buzzer sounds and the

emergency flashers flash to indicate

that the doors have been

locked/unlocked. (Locked: Once;

Unlocked: Twice)
Side windows: A buzzer sounds to

indicate that the side windows are

operating.

■

Security feature

If a door is not opened within

approximately 60 seconds after the

vehicle is unlocked, the security fea-

ture automatically locks the vehicle

again. (However, depending on the

location of the electronic key, the

key may be detected as being in the

vehicle. In this case, vehicle may be

unlocked.)

■

When the door cannot be

locked by the lock sensor on

the surface of the door handle

When the door cannot be locked

even if the lock sensor on the sur-

face of the door handle is touched

by a finger, touch the lock sensor

with the palm.
When gloves are being worn,

remove the gloves.

Multi-informa-

tion dis-

play/Beep

Unlocking func-

tion

*1

*2

Exterior: Beeps
3 times

Holding the
driver’s door han-
dle unlocks only
the driver’s door.

Holding the pas-
senger’s door
handle or press-
ing the back door
opener switch
unlocks all the
doors.

*1

*2

Exterior: Beeps
twice

Holding a door
handle or press-
ing the back door
opener switch
unlocks all the
doors.

139

3-2. Opening, closing and locking the doors

3

Before

driving

■

Door lock buzzer

If an attempt to lock the doors using

the smart key system is made when

a door other than the door you are

locking is open, a buzzer sounds

continuously for 5 seconds. Fully

close all the doors, and lock the

vehicle once more.

■

Setting the alarm

Locking the doors will set the alarm

system. (



P.81)

■

Conditions affecting the opera-

tion of the smart key system or

wireless remote control



P.156

■

If the smart key system or the

wireless remote control does

not operate properly

●

Use the mechanical key to lock

and unlock the doors. (



P.467)

●

Replace the key battery with a

new one if it is depleted. (



P.424)

■

If the 12-volt battery is dis-

charged

The doors cannot be locked and

unlocked using the smart key sys-

tem or wireless remote control. Lock

or unlock the doors using the

mechanical key. (



P.467)

■

Rear seat reminder function

●

In order to remind you not to for-

get luggage, etc. in the rear seat,

when the power switch is turned to

OFF after any of the following con-

ditions are met, a buzzer will

sound and a message will be dis-

played on the multi-information

display for approximately 6 sec-

onds.

• The hybrid system is started

within 10 minutes after opening

and closing a rear door.

• A rear door has been opened and

closed after the hybrid system

was started.

However, if a rear door is opened
and then closed within approxi-
mately 2 seconds, the rear seat
reminder function may not operate.

●

The rear seat reminder function

determines that luggage, etc. has

been placed in a rear seat based

on opening and closing of a rear

door. Therefore, depending on the

situation, the rear seat reminder

function may not operate and you

may still forget luggage, etc. in the

rear seat, or it may operate unnec-

essarily.

●

The rear seat reminder function

can be enabled/disabled.

(



P.507)

■

Customization

Settings (e.g. unlocking function

using a key) can be changed.

(Customizable features:



P.506)

WARNING

■

To prevent an accident

Observe the following precautions

while driving the vehicle.

Failure to do so may result in a

door opening and an occupant

could be thrown out of the vehicle,

resulting in death or serious

injury.

●

Ensure that all doors are prop-

erly closed and locked.

●

Do not pull the inside handle of

the doors while driving.

Be especially careful for the

front doors, as the doors may

be opened even if the inside

lock buttons are in locked posi-

tion.

140

3-2. Opening, closing and locking the doors

■

Using the door lock
switches

1

Locks all the doors

2

Unlocks all the doors

■

Using the inside lock but-
tons

1

Locks the door

2

Unlocks the door

The front doors can be opened by
pulling the inside handle even if the
lock buttons are in the lock position.

■

Locking the front doors from

the outside without a key

1

Move the inside lock button to

the lock position.

2

Close the door.

The door cannot be locked if the

power switch is in ACC or ON, or

the electronic key is left inside the

vehicle.
Depending on the position of the

electronic key, the key may not be

detected correctly and the door may

be locked.

■

Open door warning buzzer

If the vehicle speed reaches 3 mph

(5 km/h), a buzzer sounds to indi-

cate that the door(s) or the hood is

not fully closed.

The open door(s) or hood is dis-

played on the multi-information dis-

play.

■

When all the doors are locked

with the entry function or wire-

less remote control

●

The doors cannot be unlocked

with the door lock switch.

WARNING

●

Set the rear door child-protector

locks when children are seated

in the rear seats.

■

When opening or closing a

door

Check the surroundings of the

vehicle such as whether the vehi-

cle is on an incline, whether there

is enough space for a door to

open and whether a strong wind

is blowing. When opening or clos-

ing the door, hold the door handle

tightly to prepare for any unpre-

dictable movement.

■

When using the wireless

remote control or mechanical

key and operating the power

windows

Operate the power window after

checking to make sure that there

is no possibility of any passenger

having any of their body parts

caught in the side window. Also,

do not allow children to operate

the wireless remote control or

mechanical key. It is possible for

children and other passengers to

get caught in the side window.

Unlocking and locking the
doors from the inside

141

3-2. Opening, closing and locking the doors

3

Before

driving

●

The door lock switches can be

reset by unlocking all the doors

with the entry function or wireless

remote control.

The door cannot be opened
from inside the vehicle when the
lock is set.

1

Unlock

2

Lock

These locks can be set to prevent
children from opening the rear
doors. Push down on each rear
door switch to lock both rear doors.

The following functions can be
set or canceled:

For instructions on customizing,
refer to P.500.

Rear door child-protector
lock

Automatic door locking
and unlocking systems

Function

Operation

Speed linked
door locking
function

All doors are
automatically
locked when
vehicle speed is
approximately 12
mph (20 km/h) or
higher.

Shift position
linked door lock-
ing function

All doors are
automatically
locked when
shifting the shift
lever to position
other than P.

Shift position
linked door
unlocking func-
tion

All doors are
automatically
unlocked when
shifting the shift
lever to P.

Driver’s door
linked door
unlocking func-
tion

All doors are
automatically
unlocked when
driver’s door is
opened within
approximately 45
seconds after
turning the power
switch to OFF.

142

3-2. Opening, closing and locking the doors

Back door

The back door can be
locked/unlocked and
opened/closed by the fol-
lowing procedures.

WARNING

Observe the following precau-

tions.

Failure to do so may result in

death or serious injury.

■

Before driving

●

Make sure that the back door is

fully closed.

If the back door is not fully

closed, it may open unexpect-

edly while driving and hit near-

by objects or luggage in the lug-

gage compartment may be

thrown out, causing an acci-

dent.

●

Do not allow children to play in

the luggage compartment.

If a child is accidentally locked

in the luggage compartment,

they could get heat exhaustion

or other injuries.

●

Do not allow a child to open or

close the back door.

Doing so may cause the back

door to operate unexpectedly,

or cause the child’s hands,

head, or neck to be caught by

the closing back door.

■

Important points while driving

●

Keep the back door closed

while driving.

If the back door is left open, it

may hit near-by objects or lug-

gage in the luggage compart-

ment may be thrown out,

causing an accident.

●

Never let anyone sit in the lug-

gage compartment.

In the event of sudden braking,

sudden swerving or a collision,

they are susceptible to death or

serious injury.

■

Operating the back door

Observe the following precau-

tions.

Failure to do so may cause parts

of the body to be caught, resulting

in death or serious injury.

●

Remove any heavy loads, such

as snow and ice, from the back

door before opening it. Failure

to do so may cause the back

door to suddenly shut again

after it is opened.

●

When opening or closing the

back door, thoroughly check to

make sure the surrounding area

is safe.

●

If anyone is in the vicinity, make

sure they are safe and let them

know that the back door is

about to open or close.

●

Use caution when opening or

closing the back door in windy

weather as it may move

abruptly in strong wind.

●

The back door may suddenly

shut if it is not opened fully,

while on a steep incline. Make

sure that the back door is

secured before using the lug-

gage compartment.

143

3-2. Opening, closing and locking the doors

3

Before

driving

■

Using the entry function

Carry the electronic key to
enable this function.

1

Unlocks all the doors

The doors cannot be unlocked for 3
seconds after the doors are locked.

2

Locks all the doors

Check that the door is securely

locked.

■

Using the wireless remote
control



P.137

■

Operation signals



P.138

■

Security feature



P.138

■

Using the door lock
switches



P.140

■

Using the wireless remote
control

Press and hold the switch.

The power back door automatically
opens/closes.
Pressing the switch while the power
back door is opening/closing stops
the operation. When the switch is
pressed again during the halted
operation, the back door will per-
form the reverse operation.

WARNING

●

When closing the back door,

take extra care to prevent your

fingers etc. from being caught.

●

Do not pull on the back door

spindle (



P.151) to close the

back door, and do not hang on

the back door spindle.

Doing so may cause hands to

be caught or the back door spin-

dle to break, causing an acci-

dent.

Unlocking and locking the
back door from the out-
side

Unlocking and locking the
back door from the inside

Opening/closing the back
door
