Toyota Tundra Hybrid (2023 year). Manual in english

563

8-2. Customization

Vehicle

specifications

■

Head-up Display

(



P.102)

: If equipped

■

Door lock (



P.113, 120, 527)

Function

Default setting

Customized

setting

Head-up display

Off

— O —

Hybrid System Indicator

Off

— O —

Route guidance to destina-
tion/street name

Off

— O —

Driving support system dis-
play

Off

— O —

Compass

Off

— O —

Audio system operation sta-
tus

Off

— O —

Function

Default setting

Customized

setting

Unlocking using a mechani-
cal key

Driver’s door

unlocked in

one step, all

doors

unlocked in

two step

All doors

unlocked in

one step

— — O

Automatic door locking func-
tion

Shift position

linked door

locking opera-

tion

Off

O — O

Speed linked

door locking

operation

Automatic door unlocking
function

Shift position

linked door

unlocking
operation

Off

O — O

Driver’s door

linked door

unlocking
operation

564

8-2. Customization

■

Smart key system and wireless remote control (



P.113, 120,

128)

■

Smart key system (



P.113, 120, 128)

■

Wireless remote control (



P.111, 113, 121)

Function

Default setting

Customized

setting

Operating signal (Buzzers)

Off

O — O

1 to 7

Operation signal (Emergency
flashers)

Off

O — O

Time elapsed before auto-
matic door lock function is
activated if door is not
opened after being unlocked

60 seconds

30 seconds

O — O

120 seconds

Open door warning buzzer
(When locking the vehicle)

Off

— — O

Function

Default setting

Customized

setting

Smart key system

Off

— — O

Smart door unlocking

Driver’s door

All the doors

O — O

Time elapsed before unlock-
ing all the door when gripping
and holding the driver’s door
handle

2 seconds

Off

— — O

1.5 seconds

2.5 seconds

Number of consecutive door
lock operations

2 times

As many as

desired

— — O

Function

Default setting

Customized

setting

Wireless remote control

Off

— — O

Unlocking operation

Driver’s door

unlocked in

one step, all

doors

unlocked in

two step

All doors

unlocked in

one step

O — O

565

8-2. Customization

Vehicle

specifications

■

Rear seat reminder (



P.115)

■

Tailgate opening alert (



P.122)

■

Driving position memory (



P.137)

Tailgate opening operation

Press and hold

(short)

One short

press

— — O

Push twice

Press and hold

(long)

Off

Theft deterrent panic mode

Off

— — O

Locking operation when door
opened

Off

O — O

Function

Default setting

Customized

setting

Indication to prevent mis-
placement in the rear seat

Off

— O —

Function

Default setting

Customized

setting

Tailgate opening alert

Off

— O —

Function

Default setting

Customized

setting

Selecting doors linked to the
memory recall function

Driver’s door

All doors

— — O

Driver’s seat slide movement
when exiting the vehicle

Full

Off

O — O

Partial

Steering wheel movement

Tilt only

Off

O — O

Telescopic

only

Tilt and tele-

scopic

Function

Default setting

Customized

setting

566

8-2. Customization

■

Outside rear view mirrors (



P.155)

■

Power windows and panoramic moon roof

(



P.160, 164)

: If equipped

■

Turn signal lever (



P.204)

■

Automatic light control system (



P.211)

Function

Default setting

Customized

setting

Automatic mirror folding and
extending operation

Linked to the

locking/

unlocking of

the doors

Off

— — O

Linked to oper-

ation of the

power switch

Function

Default setting

Customized

setting

Mechanical key linked opera-
tion

Off

— — O

Wireless remote control
linked operation

Off

On (open only) — — O

Wireless remote control
linked operation signal
(buzzer)

Off

— — O

Side windows open warning
function

Off

— — O

Sliding roof open warning
function

Off

— — O

Function

Default setting

Customized

setting

Times of flashing of the lane
change signal flashers

Off

— — O

4 to 7

Function

Default setting

Customized

setting

Light sensor sensitivity

Standard

-2 to 2

O — O

567

8-2. Customization

Vehicle

specifications

■

Lights (



P.211)

: Except for Canada

■

PCS (Pre-Collision System) (



P.230)

: The system is automatically enabled each time the power switch is turned

to ON.

■

LTA (Lane Tracing Assist) (



P.242)

Time elapsed before head-
lights automatically turn off
after doors are closed

30 seconds

Off

O — O

60 seconds

90 seconds

Windshield wiper linked
headlight illumination

Off

— — O

Function

Default setting

Customized

setting

Daytime running lights

Off

O — O

Welcome lamp (if equipped)

Off

— — O

Function

Customized setting

PCS (Pre-Collision System)

On/Off

— O —

Adjust alert timing

Early/Middle/Late

— O —

Function

Customized setting

Lane centering function

On/Off

— O —

Alert type

Steering wheel vibra-

tion/Buzzer

— O —

Alert sensitivity

High/Standard

— O —

Vehicle sway warning func-
tion

On/Off

— O —

Vehicle sway warning sensi-
tivity

High/Standard/Low

— O —

Function

Default setting

Customized

setting

568

8-2. Customization

■

RSA (Road Sign Assist)

(



P.253)

: If equipped

■

BSM (Blind Spot Monitor) (



P.267)

■

Intuitive parking assist (



P.274)

Function

Customized setting

RSA (Road Sign Assist)

On/Off

— O —

Excess speed notification
method

No notification/Display

only/Display and buzzer

— O —

Excess speed notification
level

1 mph (2 km/h)/3 mph (5

km/h)/5 mph (10 km/h)

— O —

Other notifications method
(No-entry notification)

No notification/Display

only/Display and buzzer

— O —

Function

Default setting

Customized

setting

BSM (Blind Spot Monitor)

Off

— O —

Outside rear view mirror indi-
cator brightness

Bright

Dim

— O —

Alert timing for presence of
approaching vehicle (sensi-
tivity)

Intermediate

Early

— O —

Late

Only when

vehicle

detected in

blind spot

Function

Default setting

Customized

setting

Intuitive parking assist

Off

— O —

Buzzer volume

Level 2

Level 1

— O —

Level 3

569

8-2. Customization

Vehicle

specifications

■

RCTA (Rear Cross Traffic Alert) (



P.281)

■

Automatic air conditioning system (



P.400)

■

Illumination (



P.410)

: If equipped

Function

Default setting

Customized

setting

RCTA (Rear Cross Traffic
Alert)

Off

— O —

Buzzer volume

Level 2

Level 1

— O —

Level 3

Function

Default setting

Customized

setting

A/C mode with auto

Off

O — O

Function

Default setting

Customized

setting

Time elapsed before the inte-
rior lights and cargo lamp
turn off

15 seconds

Off

O — O

7.5 seconds

30 seconds

Operation of the per-
sonal/interior lights after the
power switch is turned off

Off

— — O

Operation of the per-
sonal/interior lights when the
doors are unlocked

Off

— — O

Operation of the per-
sonal/interior lights when you
approach the vehicle with the
electronic key on your per-
son

Off

— — O

Ambient lights

Off

— — O

570

8-2. Customization

■

Driving mode select switch

(



P.358)

: If equipped

■

Vehicle customization

●

When the smart key system is off,

the entry unlock function cannot

be customized.

●

When the doors remain closed

after unlocking the doors and the

timer activated automatic door

lock function activates, signals will

be generated in accordance with

the operation buzzer volume and

operational signal (Emergency

flashers) function settings.

●

Some settings can be changed

using a switch or the multimedia

system. If a setting is changed

using a switch, the changed set-

ting will not be reflected on the

multimedia system until the power

switch is turned off and then to

ON.

Function

Default setting

Customized

setting

Powertrain control in Cus-
tom mode

Normal

Power

O — —

Eco

Suspension control in Cus-
tom mode

Normal

Sport

O — —

Comfort

Steering control in Custom
mode

Normal

Sport

O — —

571

8-3. Initialization

Vehicle

specifications

8-3.Initialization

: If equipped

Items to initialize

The following items must be initialized for normal system
operation after such cases as the 12-volt battery being recon-
nected, or maintenance being performed on the vehicle:

List of items to initialize

Item

When to initialize

Reference

PKSB (Parking
Support Brake)

• After reconnecting or changing

the 12-volt battery

P.292

Maintenance
required reminder
message

• After the maintenance is per-

formed

P.449, 459

Tire pressure warn-
ing system

• When the tire inflation pressure

is changed, such as when
changing traveling speed or load
weight.

• When the tire inflation pressure

is changed, such as when the
tire size is changed.

• When rotating the tires.
• After performing the transmitter

ID code registration procedure.

P.470

Toyota parking
assist monitor

• 12-volt battery has been rein-

stalled.

• The steering wheel has been

moved while the 12-volt battery
was being reinstalled.

• 12-volt battery power is low.

P.307, 341, 354

Panoramic view
monitor

Multi-terrain Moni-
tor

573

For ow

ner
s

For owners

9-1. For owners

Reporting safety defects for

U.S. owners...............

574

Reporting safety defects for

Canadian owners ......

574

Seat belt instructions for

Canadian owners (in
French)......................

575

SRS airbag instructions for

Canadian owners (in
French)......................

577

Camper information ....

585

574

9-1. For owners

9-1.For owners

Reporting safety

defects for U.S. own-

ers

If you believe that your vehicle
has a defect which could
cause a crash or could cause
injury or death, you should
immediately inform the
National Highway Traffic
Safety Administration
(NHTSA) in addition to notify-
ing Toyota Motor Sales,
U.S.A., Inc. (Toll-free: 1-800-
331-4331).

If NHTSA receives similar
complaints, it may open an
investigation, and if it finds
that a safety defect exists in a
group of vehicles, it may order
a recall and remedy cam-
paign. However, NHTSA can-
not become involved in
individual problems between
you, your dealer, or Toyota
Motor Sales, U.S.A., Inc.

To contact NHTSA, you may
call the Vehicle Safety Hotline
toll-free at 1-888-327-4236
(TTY: 1-800-424-9153); go to

http://www.safercar.gov

; or

write to: Administrator,
NHTSA, 1200 New Jersey
Ave. SE., Washington, DC
20590. You can also obtain
other information about motor
vehicle safety from

http://www.safercar.gov

Reporting safety

defects for Canadian

owners

Canadian customers who
wish to report a safety-related
defect to Transport Canada,
Defects Investigations and
Recalls, may telephone the
toll-free hotline 1-800-333-
0510, mail Transport Canada -
ASFAD, 330 Sparks Street,
Ottawa, ON, K1A 0N5, or
complete the online form at

https://www.tc.gc.ca/recalls

Les clients canadiens
désireux de rendre compte
d’un défaut lié à la sécurité
auprès de Transport Canada,
Enquêtes sur les défauts et
rappels, peuvent appeler gra-
tuitement l’assistance télépho-
nique au 1-800-333-0510,
écrire un courriel à Transports
Canada - ASFAD, 330 Sparks
Street, Ottawa, ON, K1A 0N5,
ou remplir la déclaration en
ligne à l’adresse

https://www.tc.gc.ca/rappels

575

9-1. For owners

For ow

ner
s



Déroulez la sangle diagonale
de telle sorte qu’elle passe
bien sur l’épaule, sans pour
autant être en contact avec le
cou ou glisser de l’épaule.



Placez la sangle abdominale
le plus bas possible sur les
hanches.



Réglez la position du dossier
de siège. Asseyez-vous le
dos le plus droit possible et
calez-vous bien dans le siège.



Ne pas vriller la ceinture de

sécurité.

■

Manipulation des ceintures
de sécurité

Avec un chiffon ou une éponge,
nettoyez à l’aide d’un savon
doux et de l’eau tiède. Vérifiez
aussi les ceintures régulière-
ment pour vous assurer qu’elles
ne présentent pas d’usure
excessive, d’effilochage ou de
coupures.

Seat belt instructions

for Canadian owners

(in French)

The following is a French
explanation of seat belt
instructions extracted from
the seat belt section in this
manual.

See the seat belt section for
more detailed seat belt
instructions in English.

Utilisation correcte des
ceintures de sécurité

AVERTISSEMENT

■

Lorsque vous utilisez la cein-

ture de sécurité du siège cen-

tral arrière

Ne pas utiliser la ceinture de

sécurité du siège central arrière

avec une de ses deux boucles

déverrouillée. Si une seule des

boucles est verrouillée, tout frein-

age brusque ou collision peut

entraîner des blessures graves,

voire mortelles.

Entretien et nettoyage

576

9-1. For owners

AVERTISSEMENT

■

État et usure des ceintures de

sécurité

Inspectez les ceintures de sécu-

rité périodiquement. Contrôlez

qu’elles ne sont pas entaillées,

effilochées, et que leurs ancrages

ne sont pas desserrés. Ne pas uti-

liser une ceinture de sécurité

défectueuse avant qu’elle ne soit

remplacée. Une ceinture de sécu-

rité défectueuse n’apporte aucune

garantie de protection de l’occu-

pant contre des blessures graves,

voire mortelles.

577

9-1. For owners

For ow

ner
s

■

Emplacement des coussins gonflables SRS



Coussins gonflables SRS frontaux

Coussin gonflable SRS conducteur/passager avant
Participent à la protection de la tête et du thorax du conducteur et
du passager avant contre les chocs avec les éléments de l’habita-
cle

Coussins gonflables SRS de genoux
Participe à la protection du conducteur et du passager avant



Coussins gonflables SRS latéraux et rideau

Coussins gonflables SRS latéraux avant

SRS airbag instructions for Canadian owners (in

French)

The following is a French explanation of SRS airbag instruc-
tions extracted from the SRS airbag section in this manual.

See the SRS airbag section for more detailed SRS airbag instruc-
tions in English.

Système de coussins gonflables SRS

578

9-1. For owners

Participent à la protection du haut du corps des occupants aux
places avant

Coussins gonflables SRS rideau

• Participent principalement à la protection de la tête des occupants assis

dans les sièges des places extérieures

• Participent à empêcher les occupants d’être éjectés du véhicule en cas

de retournement de celui-ci

■

Composition du système de coussins gonflables SRS

Capteurs d’impact avant

Coussins gonflables de genoux

Coussin gonflable passager avant

Capteurs d’impact latéral (avant)

Coussins gonflables rideau

Capteurs d’impact latéral (porte avant)

Capteurs de classification d’occupant du siège passager avant

Témoins indicateurs “AIR BAG ON” et “AIR BAG OFF”

Coussins gonflables latéraux

Prétensionneurs et limiteurs d’effort de ceinture de sécurité

579

9-1. For owners

For ow

ner
s

Capteurs d’impact latéral (arrière)

Coussin gonflable conducteur

Témoin d’alerte SRS

Contacteur de boucle de ceinture de sécurité conducteur

Capteur de position du siège conducteur

Contacteur de boucle de ceinture de sécurité passager avant

Boîtier électronique de coussins gonflables

Votre véhicule est équipé de COUSSINS GONFLABLES INTELLI-
GENTS (ADVANCED AIRBAGS) conçus selon les normes de sécu-
rité américaines applicables aux véhicules à moteur (FMVSS208).
Le boîtier électronique de coussins gonflables (ECU) utilise les infor-
mations reçues des capteurs, etc. détaillés dans le schéma ci-des-
sus de composition du système pour commander le déploiement
des coussins gonflables. Ces informations comprennent des infor-
mations sur la gravité de la collision et les occupants. Le déploie-
ment rapide des coussins gonflables est obtenu au moyen d’une
réaction chimique dans les dispositifs pyrotechniques, qui produit un
gaz inoffensif permettant d’amortir le mouvement des occupants.

AVERTISSEMENT

■

Précautions avec les couss-

ins gonflables SRS

Respectez les précautions suiva-

ntes concernant les coussins gon-

flables SRS.

À défaut, des blessures graves,

voire mortelles, pourraient

s’ensuivre.

●

Le conducteur et tous les pas-

sagers à bord du véhicule

doivent porter leur ceinture de

sécurité correctement.

Les coussins gonflables SRS

sont des dispositifs de protec-

tion complémentaires aux cein-

tures de sécurité.

Toyota Tundra Hybrid (2023 year). Manual in english - page 35
