Toyota Supra (2023 year). Manual in english

249

3-1. CONTROLS

CON

ROLS

mm.

If the vehicle is equipped with
the forgotten warning function, a
warning can be output if a
mobile phone with Qi capability
was forgotten in the wireless
charging tray when leaving the
vehicle.
The forgotten warning is dis-
played in the instrument cluster.

Via Toyota Supra Command:

“My Vehicle”

“System settings”

“Wireless charging tray”

“Forgotten mobile device
alert”

The charge current may be
reduced or the charging process
may be temporarily interrupted
in the following situations:



Due to excessive tempera-
tures on the surface of the
tray and mobile phone.



If there are objects between
the mobile phone and the
wireless charging tray.



Due to protective sleeves and
covers that exceed a thick-
ness of 0.07 in/2 mm.



Due to protective sleeves and
covers made of unsuitable
material, e.g., with magnetic
parts.



Due to add-on parts for
mobile phone, e.g., holders.



By settings on the mobile
phone, for instance for
charging. Follow the relevant
instructions control display
and in the instructions for the
mobile phone, if applicable.

LED displays

Color

Meaning

Blue

The mobile phone is
charging.
Depending on the model
and the vehicle, the blue
LED is no longer illumi-
nated once the inserted
mobile phone with Qi
capability is fully charged.

Orange

The mobile phone is not
charging.
Temperature on the
mobile phone possibly
too high or foreign object
in the charging tray.

Red

The mobile phone is not
charging.
Contact your Toyota
dealer.

Forgotten warning

General information

Activating

System limits

250

3-1. CONTROLS

Your car is equipped with a wire-
less charging tray (WCA) to
charge your mobile phone and
connect it to the mobile network.
To ensure the best possible con-
nection a signal booster
(LTE-Compensator) is used in
conjunction with the WCA. The
following paragraphs refer to
this booster:
This is a CONSUMER device.
BEFORE USE, you MUST
REGISTER THIS DEVICE with
your wireless provider and have
your provider's consent. Most
wireless providers consent to
the use of Compensators. Some
providers may not consent to
the use of this device on their
network. If you are unsure, con-
tact your provider. You MUST
operate this device with
approved antennas and cables
as specified by the manufac-
turer. Antennas MUST be
installed at least 20 cm (8
inches) from any person. You
MUST cease operating this
device immediately if requested
by the FCC or a licensed wire-
less service provider. Warning
E911 location information may
not be provided or may be inac-
curate for calls served by using
this device.
Please observe additionally the

following information



Sprint Nextel will allow con-
sumers to register their signal
boosters by calling their
toll-free number.



T-Mobile online registration
link:
(www.T-Mobile.com/Booster-
Registration);
(https://saqat.t-mobile.com/sit
es/SignalBooster#).



Verizon’s online registration
link: (http://www.verizonwire-
less.com/wcms/con-
sumer/register-signal-booster.
html).



AT&T online registration link
(https://secu-
rec45.securewebses-
sion.com/attsignal-booster.co
m/).



U.S.Cellular online registra-
tion link (http://www.uscellu-
lar.com/uscellular/support/fcc-
booster-registration.jsp).

Before use you must register
your booster device with your
wireless provider.
If you should be requested by
the FCC to cease operating your
booster you are not allowed to
insert your mobile phone in the
charging tray anymore unless
the booster is permanently
deactivated by your Toyota
dealer.
You must not remove the
booster from the car nor use it

LTE-Compensator - Infor-
mation and User Manual

251

3-1. CONTROLS

CON

ROLS

with any other than the prein-
stalled coupling device or
antenna. Any modification of the
existing antenna or coupling
device as well as the use of
other antennas or coupling
devices will cause the cease of
the booster’s operating license.
The booster device fulfills the
network protections tandards as
required by the FCC, such as
intermodulation limits, oscillation
detection and gainlimits.
Booster Manufacturer: Kathrein
Automotive
Model Number: LTECOMPB0
Part Number: 6803145-01
FCC-ID: 2ACC7LTECOMPB0

This chapter describes all stan-
dard, country-specific and
optional features offered with
the series. It also describes fea-
tures and functions that are not
necessarily available in your
vehicle, e.g., due to the selected
options or country versions. This
also applies to safety-related
functions and systems. When
using these functions and sys-
tems, the applicable laws and
regulations must be observed.

Storage compart-

ments

Vehicle features and
options

Safety information

WARNING

Loose objects or devices with a

cable connection to the vehicle,

for instance mobile phones, can

be thrown into the car’s interior

while driving, for instance in the

event of an accident or during

braking and evasive maneuvers.

There is a risk of injury. Secure

loose objects or devices with a

cable connection to the vehicle in

the car’s interior.

NOTICE

Anti-slip pads such as anti-slip

mats can damage the dashboard.

There is a risk of damage to prop-

erty. Do not use anti-slip pads.

252

3-1. CONTROLS

The vehicle interior contains
multiple storage compartments
for stowing objects.

Pull the handle.
The light in the glove compart-
ment switches on.

Fold cover closed.

The glove compartment can be
locked with an integrated key,
refer to page 87. This prevents
access to the glove compart-
ment.
After the glove compartment is
locked, the remote control can
be handed over without the inte-
grated key, for instance when
the vehicle is parked by valet
parking.

There are storage compart-
ments in the doors.

Storage compartments

Glove compartment

Safety information

WARNING

Folded open, the glove compart-

ment protrudes in the car's inte-

rior. Objects in the glove

compartment can be thrown into

the car's interior while driving, for

instance in the event of an acci-

dent or during braking and eva-

sive maneuvers. There is a risk of

injury. Always close the glove

compartment immediately after

using it.

Opening

Closing

Locking

Compartments in the
doors

General information

Safety information

WARNING

Breakable objects, such as glass

bottles or glasses, can break in

the event of an accident or a brak-

ing or evasive maneuver. Broken

glass can be scattered in the car's

interior. There is a risk of injury or

risk of damage to property. Do not

use any breakable objects while

driving. Only stow breakable

objects in closed storage com-

partments.

253

3-1. CONTROLS

CON

ROLS

Cup holders

Safety information

WARNING

Unsuitable containers in the cup

holders may damage the cup

holders or be thrown about the

car’s interior in the event of an

accident, an evasive maneuver,

or forceful braking. Spilled liquids

can distract from the traffic condi-

tions and lead to an accident. Hot

drinks can damage the cup holder

or lead to scalding. There is a risk

of injury or risk of damage to prop-

erty. Do not force objects into the

cup holder. Use lightweight, shat-

terproof, and sealable containers.

Do not transport hot beverages.

Cargo area

Vehicle features and
options

Loading

Safety information

WARNING

High gross weight can overheat

the tires, damage them internally

and cause a sudden drop in tire

inflation pressure. Driving charac-

teristics may be negatively

impacted, reducing lane stability,

lengthening the braking distances

and changing the steering

response. There is a risk of an

accident. Pay attention to the per-

mitted load capacity of the tires

and never exceed the permitted

gross weight.

254

3-1. CONTROLS

Locate the statement “The
combined weight of occu-
pants and cargo should
never exceed XXX kg or XXX
lbs” on your vehicle’s plac-
ard.

Determine the combined
weight of the driver and pas-
sengers that will be riding in
your vehicle.

Subtract the combined
weight of the driver and pas-
sengers from XXX kg or XXX
lbs.

The resulting figure equals
the available amount of cargo
and luggage load capacity.
For example, if the “XXX”
amount equals 1,400 lbs and
there will be five 150 lbs pas-
sengers in your vehicle, the
amount of available cargo
and luggage load capacity is
650 lbs (1,400–750 (5 x 150)
= 650 lbs).

Determine the combined
weight of luggage and cargo
being loaded on the vehicle.
That weight may not safely
exceed the available cargo
and luggage load capacity
calculated in Step

If your vehicle will be towing
a trailer, load from your trailer
will be transferred to your
vehicle. Consult this manual
to determine how this
reduces the available cargo
and luggage load capacity of
your vehicle.

WARNING

Loose object or devices with a

cable connection to the vehicle,

for instance mobile phones, can

be thrown about the car’s interior

while driving, for instance in the

event of an accident or during

braking and evasive maneuvers.

There is a risk of injury. Secure

loose objects or devices with a

cable connection to the vehicle in

the car’s interior.

WARNING

Improperly stowed objects can

shift and be thrown into the car’s

interior, for instance in the event

of an accident or during braking

and evasive maneuver. Vehicle

occupants can be hit and injured.

There is a risk of injury. Stow and

secure objects and cargo prop-

erly.

NOTICE

Fluids in the cargo area can

cause damage. There is a risk of

damage to property. Make sure

that no fluids leak in the cargo

area.

Steps for Determining Cor-
rect Load Limit

255

3-1. CONTROLS

CON

ROLS

The maximum load is the sum of
the weight of the occupants and
the cargo.
The greater the weight of the
occupants, the less cargo that
can be transported.



Cover sharp edges and cor-
ners on the cargo.



Heavy cargo: stow as far for-
ward and as low as possible,
ideally directly behind the
cargo partition.



Fasten the aids for securing
the load to the lashing eyes in
the cargo area.



Smaller and lighter cargo:
secure with ratchet straps or
with a cargo net or draw
straps.



Larger and heavy cargo:
secure with cargo straps.

: if equipped

Attach load securing aids, such
as lashing straps, tensioning
straps, draw straps or cargo
nets, to the lashing eyes in the
cargo area.

There are four lashing eyes in
the cargo area for securing
cargo.

Load

Stowing and securing
cargo

Lashing eyes in the cargo
area*

General information

Lashing eyes

Multi-function hook

General information

256

3-1. CONTROLS

A multi-function hook is located
on the left and right side in the
cargo area.

A tensioning strap is available
on the right side trim for fasten-
ing small objects.

Small objects can be stowed in
the net on the left side. To trans-
port larger objects, slide the net
down. Grab the top of the net as
close as possible to the edge
next to the holder. At first, a
resistance must be overcome.

A storage compartment is avail-
able on the right side of the
cargo area.

Unlock the cover of the right
side panel, arrow

, and fold up,

arrow

The cover can be removed for
stowing bulky items.

Unhook the retaining straps
on the tailgate.

Safety information

WARNING

Improper use of the multi-function

hooks can lead to a risk of objects

flying about during braking and

evasive maneuvers, for example.

There is a risk of injury and risk of

damage to property. Only hang

lightweight objects, such as shop-

ping bags, from the multi-function

hooks. Only transport heavy lug-

gage in the cargo area if it has

been appropriately secured.

Tensioning strap

Net

Storage compartment on
the right side

General information

Opening

Luggage cover

Removing

260

4-1. DRIVING TIPS

4-1.DRIVING TIPS

Moving parts need to begin
working together smoothly.
The following instructions will
help you to achieve a long vehi-
cle life and good efficiency.
During break-in, do not use the
Launch Control, refer to page
136.

Do not exceed the maximum
engine and road speed:



For gasoline engine 4,500
rpm and 100 mph/160 km/h.

Avoid full load or kickdown
under all circumstances.

The engine and vehicle speed
can gradually be increased.

Tire traction is not optimal due to
manufacturing circumstances
when tires are brand-new; they
achieve their full traction poten-
tial after a break-in time.
Drive conservatively for the first
200 miles/300 km.

Things to remember

when driving

Vehicle features and
options

Breaking-in period

General information

Safety information

WARNING

Due to new parts and compo-

nents, safety and driver assis-

tance systems can react with a

delay. There is a risk of an acci-

dent. After installing new parts or

with a new vehicle, drive conser-

vatively and intervene early if nec-

essary. Observe the break-in

procedures of the respective parts

and components.

Engine, transmission, and
axle drive

Up to 1,200 miles/2,000 km

From 1,200 miles/2,000 km

Tires

261

4-1. DRIVING TIPS

DR
IVING TIPS

Brake discs and brake pads only
reach their full effectiveness
after approx. 300 miles/500 km.
Drive moderately during this
break-in period.

The function of the clutch
reaches its optimal level only
after a distance driven of
approx. 300 miles/500 km.
During this break-in period,
engage the clutch gently.

Observe the break-in proce-
dures again, if components
mentioned above are replaced.

Brake system

Clutch

Following part replace-
ment

General driving notes

Closing the trunk lid

Safety information

WARNING

An open trunk lid protrudes from

the vehicle and can endanger

occupants and other traffic partici-

pants or damage the vehicle in

the event of an accident, braking

or evasive maneuvers. In addi-

tion, exhaust fumes may enter the

car's interior. There is a risk of

injury or risk of damage to prop-

erty. Do not drive with the trunk lid

open.

Ice on window glass

NOTICE

The window will be lowered

slightly when pulling on the door

handle. In the event of frost, the

window may freeze up and not be

lowered. There is a risk of dam-

age to property. When pulling on

the door handle, make sure that

the window is lowered. If neces-

sary, remove snow and ice from

the window. Do not open the door

with force.

Hot exhaust gas system

WARNING

High temperatures can occur

underneath the body, for instance

caused by the exhaust gas sys-

tem, while driving. Contact with

the exhaust gas system can

cause burns. There is a risk of

injury. Do not touch the hot

exhaust gas system, including the

exhaust pipe.

WARNING

If combustible materials, such as

leaves or grass, come in contact

with hot parts of the exhaust gas

system, these materials can

ignite. There is a risk of fire and

injuries. Do not remove the heat

shields installed and never apply

undercoating to them. Make sure

that no combustible materials can

come in contact with hot vehicle

parts in driving operation, idle or

during parking.

262

4-1. DRIVING TIPS

When visibility is poor due to
fog, even if it is daytime, turn the
low beam headlights on to make
your vehicle more visible to
other vehicles, etc. Drive with
caution at a low speed, using
the centerline, guardrails, tail-
lights of a preceding vehicle,
etc., as guide.

When the vehicle is being blown
by crosswinds, drive at a lower
speed and grip the steering
wheel stronger than normal.
The vehicle is especially sus-
ceptible to crosswinds when
exiting a tunnel or underpass,
when driving on a bridge or
embankment, or when passing
or being passed by a truck or
other large vehicle.



During a rain storm or when
the road surface is wet, the
road surface may be slippery
and visibility may be reduced.
In this case, turn the low
beam headlights on to make
your vehicle more visible to

Mobile communication
devices in the vehicle

WARNING

Vehicle electronics and mobile

phones can influence one

another. There is radiation due to

the transmission operations of

mobile phones. There is a risk of

injury or risk of damage to prop-

erty. If possible, in the car's inte-

rior use only mobile phones with

direct connections to an exterior

antenna in order to exclude

mutual interference and deflect

the radiation from the car's inte-

rior.

Driving in inclement
weather

When visibility is poor due to
fog

During strong wind

When it is raining

263

4-1. DRIVING TIPS

DR
IVING TIPS

other vehicles, etc. Increase
the distance between your
vehicle and preceding vehi-
cles and drive safely at a
lower speed than normal,
avoiding sudden accelera-
tion, braking or steering oper-
ations.



Use the rear defroster and air
conditioning system to pre-
vent the windows from fog-
ging up.



Hydroplaning is more likely to
occur when driving on ruts or
through large puddles.

On wet or slushy roads, a
wedge of water can form
between the tires and road sur-
face.
This phenomenon is referred to
as hydroplaning. It is character-
ized by a partial or complete
loss of contact between the tires
and the road surface, ultimately
undermining your ability to steer
and brake the vehicle.

When driving through water, fol-
low the following:



Deactivate Auto Start/Stop
function.



Drive through calm water

only.



Drive through water only if it is
not deeper than maximum 9.8
inches/25 cm.



Drive through water no faster
than walking speed, up to 3
mph/5 km/h.

The vehicle is equipped with an
Antilock Braking System ABS as
a standard feature.
Perform an emergency stop in
situations that require such.
Steering is still responsive. You
can still avoid any obstacles with
a minimum of steering effort.
Pulsation of the brake pedal and
sounds from the hydraulic cir-
cuits indicate that the Antilock
Braking System ABS is in its
active mode.
In certain braking situations, the

Hydroplaning

Driving through water

General information

Safety information

NOTICE

When driving too quickly through

too deep water, water can enter

into the engine compartment, the

electrical system or the transmis-

sion. There is a risk of damage to

property. When driving through

water, do not exceed the maxi-

mum indicated water level and the

maximum speed for driving

through water.

Braking safely

General information

264

4-1. DRIVING TIPS

perforated brake discs can emit
functional noises. However,
functional noises have no effect
on the performance and opera-
tional reliability of the brake.

When roads are wet, salted, or
in heavy rain, gently press the
brake pedal every few miles.
Ensure that this action does not
endanger other traffic.
The heat generated during brak-
ing dries brake discs and brake
pads and protects them against
corrosion.
In this way braking efficiency will
be available when you need it.

■

General information

Drive long or steep downhill gra-
dients in the gear that requires
least braking effort. Otherwise,
the brakes may overheat and
reduce brake efficiency.
You can increase the engine's
braking effect by shifting down,
going all the way to first gear, if
needed.

■

Safety information

Corrosion on the brake discs
and contamination on the brake
pads are increased by the fol-
lowing circumstances:



Low mileage.



Extended periods when the
vehicle is not used at all.

Objects in the area around
the pedals

WARNING

Objects in the driver's floor area

can limit the pedal distance or

block a depressed pedal. There is

a risk of an accident. Stow objects

in the vehicle such that they are

secured and cannot enter into the

driver's floor area. Use floor mats

that are suitable for the vehicle

and can be safely attached to the

floor. Do not use loose floor mats

and do not layer several floor

mats. Make sure that there is suf-

ficient clearance for the pedals.

Ensure that the floor mats are

securely fastened again after they

were removed, for instance for

cleaning.

Driving in wet conditions

Hills

WARNING

Light but consistent brake pres-

sure can lead to high tempera-

tures, brakes wearing out and

possibly even brake failure. There

is a risk of an accident. Avoid

placing excessive stress on the

brake system.

WARNING

In idle state or with the engine

switched off, safety functions, for

instance engine braking effect,

braking assistance and steering

assistance, may not be available.

There is a risk of accident. Do not

attempt to drive in idle state or

with the engine switched off.

Brake disc corrosion

265

4-1. DRIVING TIPS

DR
IVING TIPS



Infrequent use of the brakes.



Aggressive, acidic, or alka-
line cleaning agents.

Corrosion buildup on the brake
discs will cause a pulsating
effect on the brakes in their
response - generally this cannot
be corrected.

When using the automatic air
conditioning, condensation
water develops and collects
underneath the vehicle.

Higher mechanical and thermal
loads during racetrack operation
lead to increased wear. This
wear is not covered by the war-
ranty. The vehicle is not
designed for use in motor sports
competition.
Have vehicle checked by your
Toyota dealer before and after
driving on a racetrack.

The vehicle contains advanced
technologies for the reduction of
consumption and emission val-
ues.
The fuel consumption depends
on various factors, such as driv-
ing style, road conditions, main-
tenance or environmental
factors.
Carrying out certain measures,
such as a moderate driving style
and regular maintenance, can
influence fuel consumption and
the environmental impact.

Condensation water under
the parked vehicle

Driving on racetracks

Saving fuel

Vehicle features and
options

Reducing fuel consump-
tion

General information

266

4-1. DRIVING TIPS

Additional weight increases fuel
consumption.

Attached parts on the vehicle
impair the aerodynamics and
increase the fuel consumption.

Open windows increase air
resistance and therefore lead to
greater fuel consumption.

Tires can affect consumption in
various ways, for instance tire
size may influence consump-
tion.

Check and, if needed, correct
the tire inflation pressure at least
twice a month and before start-
ing on a long trip.
Low tire inflation pressure
increases rolling resistance and
thus raises fuel consumption
and tire wear.

Do not wait for the engine to
warm-up while the vehicle
remains stationary. Start driving
right away, but at moderate
engine speeds.
This is the quickest way of
warming the cold engine up to
operating temperature.

Driving smoothly and proactively
reduces fuel consumption.
Avoid unnecessary acceleration
and braking.
By maintaining a suitable dis-
tance to the vehicle driving
ahead of you.

Driving at low engine speeds
lowers fuel consumption and
reduces wear.
If necessary, observe the vehi-
cle's gear shift indicator, refer to
page 149.

When approaching a red light,
take your foot off the accelerator
and let the vehicle coast to a
halt.
For going downhill take your foot
off the accelerator and let the

Remove unnecessary
cargo

Remove attached parts fol-
lowing use

Closing the windows

Tires

General information

Check the tire inflation pres-
sure regularly

Drive away without delay

Look well ahead when
driving

Avoid high engine speeds

Use coasting conditions

Toyota Supra (2023 year). Manual in english - page 16
