Toyota Sequoia Hybrid (2023 year). Manual in english - page 28





450

6-1. Maintenance and care

6-1.Maintenance and care

Working from top to bottom,
liberally apply water to the
vehicle body, wheel wells and
underside of the vehicle to
remove any dirt and dust.

Wash the vehicle body using
a sponge or soft cloth, such
as a chamois.

For hard-to-remove marks,
use car wash soap and rinse
thoroughly with water.

Wipe away any water.

Wax the vehicle when the
waterproof coating deterio-
rates.

If water does not bead on a clean
surface, apply wax when the vehi-
cle body is cool.

Automatic car washes

Fold the mirrors before washing

the vehicle.

Start washing from the front of the
vehicle. Extend the mirrors before
driving.

Turn off the power back door (if

equipped).

Brushes used in automatic car

washes may scratch the vehicle

surface, parts (wheel, etc.) and

harm your vehicle’s paint.

Rear spoiler may not be washable

in some automatic car washes.

There may also be an increased

risk of damage to vehicle.

High pressure car washes

As water may enter the cabin, do

not bring the nozzle tip near the

gaps around the doors or perimeter

of the windows, or spray these

areas continuously.

When using a car wash

If the door handle becomes wet

while the electronic key is within the

effective range, the door may lock

and unlock repeatedly. In that case,

follow the following correction pro-

cedures to wash the vehicle:

Place the key in a position 6 ft. (2

m) or more separate from the

vehicle while the vehicle is being

washed. (Take care to ensure that

the key is not stolen.)

Set the electronic key to battery-

saving mode to disable the Smart

key system. (

P.140)

Wheels and wheel ornaments

Remove any dirt immediately by

using a neutral detergent.

Wash detergent off with water

immediately after use.

To protect the paint from damage,

make sure to observe the follow-

ing precautions.

• Do not use acidic, alkaline or

abrasive detergent

• Do not use hard brushes

• Do not use detergent on the

wheels when they are hot, such

as after driving or parking in hot

weather

Brake pads and calipers

Rust may form if the vehicle is

parked with wet brake pads or disc

rotors, causing them to stick. Before

parking the vehicle after it is

washed, drive slowly and apply the

Cleaning and protect-

ing the vehicle exte-

rior

Perform cleaning in a man-
ner appropriate to each
component and its material.

Cleaning instructions

451

6-1. Maintenance and care

6

Maintena

nce
 a

nd ca

re

brakes several times to dry the

parts.

Bumpers and wheel arch mold-

ings

Do not scrub with abrasive cleaners.

Plated portions

If dirt cannot be removed, clean the

parts as follows:

Use a soft cloth dampened with an

approximately 5% solution of neu-

tral detergent and water to clean

the dirt off.

Wipe the surface with a dry, soft

cloth to remove any remaining

moisture.

To remove oily deposits, use alco-

hol wet wipes or a similar product.

WARNING

When washing the vehicle

Do not apply water to the inside of

the engine compartment. Doing

so may cause the electrical com-

ponents, etc. to catch fire.

Precautions regarding the

exhaust pipe

Exhaust gases cause the exhaust

pipe to become quite hot. When

washing the vehicle, be careful

not to touch the pipe until it has

cooled sufficiently, as touching hot

exhaust pipe can cause burns.

When cleaning the windshield

(vehicles with rain-sensing

windshield wipers)

Set the wiper switch to off.

If the wiper switch is in “AUTO”,

the wipers may operate unexpect-

edly in the following situations,

and may result in hands being

caught or other serious injuries

and cause damage to the wiper

blades.

Off

“AUTO”

When the upper part of the

windshield where the raindrop

sensor is located is touched by

hand

When a wet rag or similar is

held close to the raindrop sen-

sor

If something bumps against the

windshield

If you directly touch the raindrop

sensor body or if something

bumps into the raindrop sensor

Precaution regarding the rear

bumper with Blind Spot Moni-

tor

If the paint of the rear bumper is

chipped or scratched, the follow-

ing systems may not function cor-

rectly. If this occurs, consult your

Toyota dealer.

BSM

RCTA

452

6-1. Maintenance and care

WARNING

PKSB

NOTICE

To prevent paint deteriora-

tion and corrosion on the

body and components (alumi-

num wheels, etc.)

Wash the vehicle immediately in

the following cases:

• After driving near the sea coast

• After driving on salted roads

• If coal tar or tree sap is present

on the paint surface

• If dead insects, insect droppings

or bird droppings are present on

the paint surface

• After driving in an area contami-

nated with soot, oily smoke,

mine dust, iron powder or chem-

ical substances

• If the vehicle becomes heavily

soiled with dust or mud

• If liquids such as benzene and

gasoline are spilled on the paint

surface

If the paint is chipped or

scratched, have it repaired

immediately.

To prevent the wheels from cor-

roding, remove any dirt and

store in a place with low humid-

ity when storing the wheels.

Cleaning the exterior lights

Wash carefully. Do not use

organic substances or scrub

with a hard brush.

This may damage the surfaces

of the lights.

Do not apply wax to the sur-

faces of the lights.

Wax may cause damage to the

lenses.

When using an automatic car

wash (vehicles with rain-

sensing windshield wipers)

Set the wiper switch to the off

position.

If the wiper switch is in “AUTO”,

the wipers may operate and the

wiper blades may be damaged.

When using a high pressure

car wash

When washing the vehicle, do

not spray the camera or its sur-

rounding area directly with a

high pressure washer. Shock

applied from high pressure

water may cause the device to

not operate normally.

Do not spray water directly on

the radar which is equipped

behind the grill. Otherwise it

may cause the device to be

damaged.

Do not bring the nozzle tip close

to boots (rubber or resin manu-

factured cover), connectors or

the following parts. The parts

may be damaged if they come

into contact with high-pressure

water.

• Traction related parts

• Steering parts

• Suspension parts

• Brake parts

Keep the cleaning nozzle at

least 11.9 in. (30 cm) away from

the vehicle body. Otherwise

resin section, such as moldings

and bumpers, may be deformed

and damaged.

Also, do not continuously hold the
nozzle in the same place.

453

6-1. Maintenance and care

6

Maintena

nce
 a

nd ca

re

Remove dirt and dust using a
vacuum cleaner. Wipe dirty
surfaces with a cloth damp-
ened with lukewarm water.

If dirt cannot be removed,
wipe it off with a soft cloth
dampened with neutral deter-
gent diluted to approximately
1%.
Wring out any excess water
from the cloth and thoroughly
wipe off remaining traces of
detergent and water.

Shampooing the carpets

There are several commercial foam-

ing-type cleaners available. Use a

sponge or brush to apply the foam.

Rub in overlapping circles. Do not

use water. Wipe dirty surfaces and

let them dry. Excellent results are

obtained by keeping the carpet as

dry as possible.

Handling the seat belts

Clean with mild soap and lukewarm

water using a cloth or sponge. Also

check the belts periodically for

excessive wear, fraying or cuts.

NOTICE

Do not spray the lower part of

the windshield continuously.

If water enters the air conditioning
system intake located near the
lower part of the windshield, the
air conditioning system may not
operate correctly.

Do not wash the underside of

the vehicle using a high pres-

sure car washer.

When raising the windshield

wiper arms

Make sure to hold the hook parts

of the wiper arms to raise them.

Do not hold only the wiper blades

when raising them, or it may

cause deformation of the wiper

blades.

Hook parts

Cleaning the high mounted

stoplight

When using high-pressured car

washers, the tip of the nozzle

should be at least 20 in. (50 cm)

from the car body. Water can

seep lamp housing or the vehicle

cabin if the nozzle is closer to the

car body.

Cleaning and protect-

ing the vehicle interior

Perform cleaning in a man-
ner appropriate to each
component and its material.

Protecting the vehicle
interior

454

6-1. Maintenance and care

WARNING

Water in the vehicle

Do not get any of the SRS compo-

nents or wiring in the vehicle inte-

rior wet. (

P.37)

An electrical malfunction may

cause the airbags to deploy or not

function properly, resulting in

death or serious injury.

Cleaning the interior (espe-

cially instrument panel)

Do not use a polish wax or polish

cleaner. The instrument panel

may reflect off the windshield,

obstructing the driver’s view and

leading to an accident, resulting in

death or serious injury.

NOTICE

Cleaning detergents

Do not use the following types

of detergent, as they may dis-

color the vehicle interior or

cause streaks or damage to

painted surfaces:

• Areas other than the seats and

steering wheel: Organic sub-

stances such as benzene or

gasoline, alkaline or acidic solu-

tions, dye, and bleach

• Seats: Alkaline or acidic solu-

tions, such as thinner, benzene,

and alcohol

• Steering wheel: Organic sub-

stances, such as thinner, and

cleaner that contains alcohol

Do not use a polish wax or pol-

ish cleaner. The instrument

panel’s or other interior part’s

painted surface may be dam-

aged.

Preventing damage to leather

surfaces

Observe the following precautions

to avoid damage to and deteriora-

tion of leather surfaces:

Remove any dust or dirt from

leather surfaces immediately.

Do not expose the vehicle to

direct sunlight for extended peri-

ods of time. Park the vehicle in

the shade, especially during

summer.

Do not place items made of

vinyl, plastic, or containing wax

on the upholstery, as they may

stick to the leather surface if the

vehicle interior heats up signifi-

cantly.

Water on the floor

Do not wash the vehicle floor with

water.

Vehicle systems such as the

audio system may be damaged if

water comes into contact with

electrical components such as the

audio system above or under the

floor of the vehicle. Water may

also cause the body to rust.

When cleaning the inside of

the windshield

Do not allow glass cleaner to con-

tact the lens. Also, do not touch

the lens. (

P.244)

Cleaning the inside of the

back window

Do not use a glass cleaner to

clean the back window, as this

may cause damage to the back

window defogger heater wires

or antenna. Use a cloth damp-

ened with lukewarm water to

gently wipe the window clean.

Wipe the window in strokes run-

ning parallel to the heater wires

or antenna.

455

6-1. Maintenance and care

6

Maintena

nce
 a

nd ca

re

Remove dirt using a water-
dampened soft cloth or syn-
thetic chamois.

Wipe the surface with a dry,
soft cloth to remove any
remaining moisture.

Cleaning the areas with satin-

finish metal accents

The metal areas use a layer of real

metal for the surface. It is necessary

to clean them regularly. If dirty areas

are left uncleaned for long periods

of time, they may be difficult to

clean.

Remove dirt and dust using a
vacuum cleaner.

Wipe off any excess dirt and
dust with a soft cloth damp-
ened with diluted detergent.

Use a diluted water solution of
approximately 5% neutral wool
detergent.

Wring out any excess water
from the cloth and thoroughly
wipe off all remaining traces
of detergent.

Wipe the surface with a dry,
soft cloth to remove any
remaining moisture. Allow the

leather to dry in a shaded and
ventilated area.

Caring for leather areas

Toyota recommends cleaning the

interior of the vehicle at least twice a

year to maintain the quality of the

vehicle’s interior.

Remove dirt and dust using a
vacuum cleaner.

Wipe it off with a soft cloth
dampened with neutral deter-
gent diluted to approximately
1%.

Wring out any excess water
from the cloth and thoroughly
wipe off remaining traces of
detergent and water.

NOTICE

Be careful not to scratch or

damage the heater wires or

antenna.

Cleaning the areas with
satin-finish metal accents

Cleaning the leather areas

Cleaning the synthetic
leather areas

456

6-2. Maintenance

6-2.Maintenance

Repair and replacement

It is recommended that genuine

Toyota parts be used for repairs to

ensure performance of each sys-

tem. If non-Toyota parts are used in

replacement or if a repair shop other

than a Toyota dealer performs

repairs, confirm the warranty cover-

age.

Allow inspection and repairs to

be performed by a Toyota

dealer

Toyota technicians are well-

trained specialists and are kept up

to date with the latest service

information. They are well

informed about the operation of all

systems on your vehicle.

Keep a copy of the repair order. It

proves that the maintenance that

has been performed is under war-

ranty coverage. If any problem

should arise while your vehicle is

under warranty, your Toyota

dealer will promptly take care of it.

General maintenance should be
performed on a daily basis. This
can be done by yourself or by a
Toyota dealer.

Scheduled maintenance should
be performed at specified inter-
vals according to the mainte-
nance schedule.

For details about maintenance
items and schedules, refer to the
“Scheduled Maintenance Guide” or
“Owner’s Manual Supplement”.

Maintenance require-

ments

To ensure safe and econom-
ical driving, day-to-day care
and regular maintenance
are essential. It is the
owner’s responsibility to
perform regular checks.
Toyota recommends the
maintenance below.

WARNING

If your vehicle is not properly

maintained

Improper maintenance could

result in serious damage to the

vehicle and possible death or seri-

ous injury.

Handling of the 12-volt bat-

tery

Engine exhaust, some of its

constituents, and a wide variety

of automobile components con-

tain or emit chemicals known to

the State of California to cause

cancer and birth defects and

other reproductive harm. Work

in a well ventilated area.

Oils, fuels and fluids contained

in vehicles as well as waste pro-

duced by component wear con-

tain or emit chemicals known to

the State of California to cause

cancer and birth defects or

other reproductive harm. Avoid

exposure and wash any

affected area immediately.

12-volt battery posts, terminals

and related accessories con-

tain lead and lead compounds

which are known to cause brain

damage. Wash your hands after

handling. (

P.471)

General maintenance

Scheduled maintenance

457

6-2. Maintenance

6

Maintena

nce
 a

nd ca

re

Resetting the message indicat-

ing maintenance is required

After the required maintenance is

performed according to the mainte-

nance schedule, please reset the

message.

To reset the message, follow the

procedure described below:

1

Press

 or

 of meter control

switches and select

 on the

multi-information display.

2

Press

 or

 of meter control

switches and select “Vehicle Set-
tings”, and then press and hold

.

3

Press

 or

 of meter control

switches and select “Scheduled
Maintenance”, and then press

.

4

Select the “Yes” and press

.

You can perform some mainte-
nance procedures by yourself.
Please be aware that do-it-your-
self maintenance may affect
warranty coverage.

The use of Toyota repair manuals is
recommended.
For details about warranty cover-
age, refer to the separate “Owner’s
Warranty Information Booklet” or
“Owner’s Manual Supplement”.

Do-it-yourself mainte-
nance

General maintenance

Listed below are the general
maintenance items that
should be performed at the
intervals specified in the
“Owner’s Warranty Informa-
tion Booklet” or “Owner’s
Manual Supplement/Sched-
uled Maintenance Guide”. It
is recommended that any
problem you notice should
be brought to the attention
of your Toyota dealer or
qualified service shop for
advice.

WARNING

If the hybrid system is operat-

ing

Turn the hybrid system off and

ensure that there is adequate

ventilation before performing

maintenance checks.

Engine compartment

Items

Check points

Brake fluid

Is the brake fluid at
the correct level?
(

P.469)

Engine/inter-
cooler/power
control unit
coolant

Is the engine/inter-
cooler/power con-
trol unit coolant at
the correct level?
(

P.468)

Engine oil

Is the engine oil at
the correct level?
(

P.466)

458

6-2. Maintenance

Exhaust sys-
tem

There should not
be any fumes or
strange sounds.

Radiator/con-
denser/inter-
cooler

The radiator, con-
denser and inter-
cooler should be
free from foreign
objects. (

P.469)

Washer fluid

Is there sufficient
washer fluid?
(

P.470)

Vehicle interior

Items

Check points

12-volt battery

Check the connec-
tions. (

P.471)

Accelerator
pedal

• The accelerator

pedal should
move smoothly
(without uneven
pedal effort or
catching).

Automatic
transmission
“Park” mecha-
nism

• When parked on

a slope and the
shift lever is in P,
is the vehicle
securely
stopped?

Items

Check points

Brake pedal

• Does the brake

pedal move
smoothly?

• Does the brake

pedal have
appropriate
clearance from
the floor?

• Does the brake

pedal have the
correct amount
of free play?

Brakes

• The vehicle

should not pull to
one side when
the brakes are
applied.

• The brakes

should work
effectively.

• The brake pedal

should not feel
spongy.

• The brake pedal

should not get
too close to the
floor when the
brakes are
applied.

Head
restraints

• Do the head

restraints move
smoothly and
lock securely?

Indica-
tors/buzzers

• Do the indica-

tors and buzzers
function prop-
erly?

Items

Check points

459

6-2. Maintenance

6

Maintena

nce
 a

nd ca

re

Parking brake

• Does the park-

ing brake oper-
ate normally?

• When parked on

a slope and the
parking brake is
on, is the vehicle
securely
stopped?

Seat belts

• Do the seat belts

operate
smoothly?

• The seat belts

should not be
damaged.

Seats

• Do the seat con-

trols operate
properly?

Steering wheel

• Does the steer-

ing wheel rotate
smoothly?

• Does the steer-

ing wheel have
the correct
amount of free
play?

• There should not

be any strange
sounds coming
from the steer-
ing wheel.

Items

Check points

Vehicle exterior

Items

Check points

Doors

• Do the doors

operate
smoothly?

Engine hood

• Does the hood

lock system work
properly?

Fluid leaks

• There should not

be any signs of
fluid leakage
after the vehicle
has been parked.

Lights

• Do all the lights

come on?

460

6-2. Maintenance

The OBD system determines
that a problem exists some-
where in the emission control
system. Your vehicle may not
pass the I/M test and may need
to be repaired. Contact your
Toyota dealer to service the
vehicle.

When the 12-volt battery is
disconnected or discharged
Readiness codes that are set
during ordinary driving are
erased.
Also, depending on your driv-
ing habits, the readiness
codes may not be completely
set.

Tires

• Is the tire infla-

tion pressure
correct?

• The tires should

not be damaged
or excessively
worn.

• Have the tires

been rotated
according to the
maintenance
schedule?

• The wheel nuts

should not be
loose.

Windshield
wipers

• The wiper blades

should not show
any signs of
cracking, split-
ting, wear, con-
tamination or
deformation.

• The wiper blades

should clear the
windshield with-
out streaking or
skipping.

Items

Check points

Emission inspection

and maintenance (I/M)

programs

Some states have vehicle
emission inspection pro-
grams which include OBD
(On Board Diagnostics)
checks. The OBD system
monitors the operation of
the emission control sys-
tem.

If the malfunction indica-
tor lamp comes on

Your vehicle may not pass
the I/M test in the follow-
ing situations:

461

6-2. Maintenance

6

Maintena

nce
 a

nd ca

re

When the fuel tank cap is
loose
The malfunction indicator
lamp comes on indicating a
temporary malfunction and
your vehicle may not pass the
I/M test.

The error code in the OBD sys-
tem will not be cleared unless
the vehicle is driven 40 or more
times.

Contact your Toyota dealer to
prepare the vehicle for re-test-
ing.

When the malfunction
indicator lamp still
remains on after several
driving trips

If your vehicle does not
pass the I/M test

462

6-3. Do-it-yourself maintenance

6-3.Do-it-yourself maintenance

Do-it-yourself service

precautions

If you perform maintenance
by yourself, be sure to fol-
low the correct procedure
as given in these sections.

Maintenance

Items

Parts and tools

12-volt battery
condition
(

P.471)

• Grease
• Warm water
• Baking soda
• Distilled water
• Conventional

wrench (for ter-
minal clamp
bolts)

Brake fluid
level (

P.469)

• FMVSS No.116

DOT 3 or SAE
J1703 brake fluid
FMVSS No.116
DOT 4 or SAE
J1704 brake fluid

• Rag or paper

towel

• Funnel (used

only for adding
brake fluid)

Engine/inter-
cooler/power
control unit
coolant level
(

P.468)

• “Toyota Super

Long Life Cool-
ant” or a similar
high quality eth-
ylene glycol-
based non-sili-
cate, non-amine,
non-nitrite and
non-borate cool-
ant with longlife
hybrid organic
acid technology
For the U.S.A.:
“Toyota Super
Long Life Cool-
ant” is pre-mixed
with 50% cool-
ant and 50%
deionized water.
For Canada:
“Toyota Super
Long Life Cool-
ant” is pre-mixed
with 55% cool-
ant and 45%
deionized water.

• Funnel (used

only for adding
coolant)

Engine oil level
(

P.466)

• “Toyota Genuine

Motor Oil” or
equivalent

• Rag or paper

towel

• Funnel (used

only for adding
engine oil)

Fuses
(

P.495)

• Fuse with same

amperage rating
as original

Items

Parts and tools

463

6-3. Do-it-yourself maintenance

6

Maintena

nce
 a

nd ca

re

Light bulbs
(

P.499)

• Bulb with same

number and
wattage rating as
original

• Phillips-head

screwdriver

• Wrench

Radiator and
condenser
(

P.469)

Tire inflation
pressure
(

P.484)

• Tire pressure

gauge

• Compressed air

source

Washer fluid
(

P.470)

• Water or washer

fluid containing
antifreeze (for
winter use)

• Funnel (used

only for adding
water or washer
fluid)

Hybrid battery
(traction bat-
tery) air intake
vent (

P.489)

Flathead screw
driver

WARNING

The engine compartment contains

many mechanisms and fluids that

may move suddenly, become hot,

or become electrically energized.

To avoid death or serious injury,

observe the following precautions.

When working on the engine

compartment

Make sure that the “ACCES-

SORY” or “IGNITION ON” on

the multi-information display

and the “READY” indicator are

both off.

Items

Parts and tools

Keep hands, clothing and tools

away from the moving fan and

engine.

Be careful not to touch the

engine, inverter, radiator,

exhaust manifold, etc., right

after driving as they may be hot.

Oil and other fluids may also be

hot.

Do not leave anything that may

burn easily, such as paper and

rags, in the engine compart-

ment.

Do not smoke, cause sparks or

expose an open flame to fuel.

When working near the elec-

tric cooling fans or radiator

grille

Be sure the power switch is off.

With the power switch in ON, the

electric cooling fans may auto-

matically start to run if the air con-

ditioning is on and/or the coolant

temperature is high. (

P.469)

Safety glasses

Wear safety glasses to prevent

flying or falling material, fluid

spray, etc., from getting in your

eyes.

NOTICE

If you remove the air cleaner

filter

Driving with the air cleaner filter

removed may cause excessive

engine wear due to dirt in the air.

464

6-3. Do-it-yourself maintenance

1

Pull the hood lock release
lever.

The hood will pop up slightly.

2

Pull up the auxiliary catch
lever and lift the hood.

12-volt battery

P.471

Hood

Opening the hood

WARNING

Pre-driving check

Check that the hood is fully closed

and locked.

If the hood is not locked properly,

it may open while the vehicle is in

motion and cause an accident,

which may result in death or seri-

ous injury.

465

6-3. Do-it-yourself maintenance

6

Maintena

nce
 a

nd ca

re

Fuse boxes (

P.495)

Power control unit coolant reservoir (

P.468)

Intercooler coolant reservoir (

P.468)

Engine coolant reservoir (

P.468)

Engine oil filler cap (

P.466)

Engine oil level dipstick (

P.466)

Brake fluid reservoir (

P.469)

Engine radiator (

P.469)

Condenser (

P.469)

Electric cooling fans

Radiator cooling fan (

P.468)

Washer fluid tank (

P.470)

Intercooler radiators (

P.468)

Engine compartment

Components















Content      ..     26      27      28      29     ..
