433

5-4. Using the other interior features

Interior

featur

Pull the armrest down for use.



Type A



Type B

An assist grip installed on the
pillar can be used when getting
in or out of the vehicle and oth-
ers.

NOTICE

●

When other wireless keys (that

emit radio waves) are being

used nearby

In addition, excluding the above-
mentioned, when the charger
does not perform normally or the
operation display lamp is flashing
continuously, it is considered that
the wireless charger is malfunc-
tioning. Contact authorized Toyota
dealer.

■

To prevent failure or damage

to data

●

Do not bring magnetic cards,

such as credit cards, or mag-

netic recording media, etc.,

close to the charger while

charging, otherwise, data may

disappear under the influence of

magnetism. Also, do not bring

precision instruments such as

wrist watches, etc., close to the

charger, as such objects may

break.

●

Do not leave portable devices in

the cabin. The temperature

inside the cabin may become

high, when under the sun, and

cause damage to the device.

■

To prevent 12-volt battery dis-

charge

When the hybrid system is

stopped, do not use the wireless

charger for a long time.

Armrest

NOTICE

■

To prevent damage to the

armrest

Do not place too much strain on

the armrest.

Assist grips

434

5-4. Using the other interior features



Type A



Type B

The power outlet can be used

for 12 V accessories that run on
less than 10 A.
Open the lid.

■

The power outlet can be used

when

The power switch is in ACC or ON.

■

When stopping the hybrid sys-

tem

Disconnect electrical devices with

charging functions, such as mobile

battery packs. If such devices are

left connected, the hybrid system

may not stop normally.

NOTICE

■

To prevent damage to the

assist grip

Do not hang any heavy object or

put a heavy load on the assist

grip.

Coat hooks

WARNING

■

Items that must not be hung

on the hook

Do not hang a coat hanger or

other hard or sharp object on the

hook. If the SRS curtain shield air-

bags deploy, these items may

become projectiles that cause

death or serious injury.

Power outlet (12 VDC)

NOTICE

■

To avoid damaging the power

outlet

Close the power outlet lid when

the power outlet is not in use.

Foreign objects or liquids that

enter the power outlet may cause

a short circuit.

■

To prevent the fuse from

being blown

Do not use an accessory that

uses more than 12 V 10 A.

■

To prevent 12-volt battery dis-

charge

Do not use the power outlet lon-

ger than necessary when the

hybrid system is off.

435

5-4. Using the other interior features

Interior

featur

Please use as a power supply
for electronic devices that use
less than 120 VAC.

■

Using the power outlets



Rear of the console box

Open the lid.



Luggage compartment

Open the lid.

■

When turning the power
outlets on

Press the “AC120V” switch.
The power outlets can be used
when the indicator on the
“AC120V” switch is illuminated.
The power outlets are turned
off/on each time the “AC120V”
switch is pressed.

■

Maximum available capac-
ity of the power outlet



While the vehicle is being
driven

The maximum capacity of the
power outlet is always 120 V
AC/100 W.



When the vehicle is stationary

• The maximum capacity is

restricted to 120 V AC/100 W
when the shift lever is moved to
any positions other than P or N.

• The maximum capacity is 120 V

AC/400 W when the shift lever is
in P or N.

The maximum capacity of 400
W can only be restored by turn-
ing the power outlet main switch
off and then on again under con-
dition described above.

■

When connecting a device

Open the lid, and fully and
securely insert the plug of the
device into the power outlet.

Power outlets (120 VAC)
(if equipped)

436

5-4. Using the other interior features



Rear of the console box



Luggage compartment

■

When turning the power
outlets off

Turn the connected devices
off.

Press the “AC120V” switch to
turn the power outlets off.

Disconnect each plug from
the power outlets.

Close the lid of each power
outlet.

■

The power outlet can be used

when

The hybrid system is operating.

■

Electronic devices that can be

connected to the power outlets

Use electronic devices that can be

connected to the 120 VAC power

outlets. Depending on the devices

being used, the current flow may

become high and the electric power

for a moment may exceed the regu-

lated capacity. If the regulated

capacity is exceeded by the elec-

tronic devices being used, the pro-

tection function of the power outlet

may operate and power outlet may

not be able to be used, but this is

not a malfunction. However,

observe the following precautions:

●

Depending on the devices used, it

may cause interference with TV

and radio broadcasts.

●

Observe the precautions that are

stated in the instruction manuals

for each of the electronic devices.

●

It is assumed that many typical

general electronic devices will not

be used within the vehicle. The

following problems may occur

when using electronic devices

within the vehicle.

• Electronic device malfunction due

to vibrations while driving.

• Electronic device malfunction or

poor operations due to tempera-
ture changes

within the vehicle.

• The installation is unstable and

may not operate normally as the

compartment within the vehicle is

not flat.

: Depending on the weather, sea-

son, usage environment, etc., the
vehicle compartment may
undergo extreme high or low tem-
peratures.

■

Power outlet

The power outlet on the console box

is a device in order to use electronic

devices within the vehicle.

■

Devices which may not operate

correctly

The following 120 VAC devices may

not operate properly:

●

Devices with high initial peak watt-

age

●

Measuring devices that process

precise data

●

Devices that require an extremely

437

5-4. Using the other interior features

Interior

featur

stable power supply

●

Devices that require a constant

power supply from the power out-

let, such as a device with a timer.

■

When the power supply func-

tion cannot be used

If the “AC120V” switch is pressed

but the switch indicator does not illu-

minate, the protection circuit may

have operated.
In this case, perform the appropriate

procedures as follows.

●

Disconnect the plug of each

device from the power outlets,

check that the total power con-

sumption of all devices to be con-

nected to the power outlets,

reconnect the devices and then

press the “AC120V” switch again.

●

Disconnect the plug of each

device from the power outlets,

check that the devices are not

malfunctioning, reconnect the

devices and then press the

“AC120V” switch again.

●

If the temperature inside the vehi-

cle is high, such as after the vehi-

cle has been parked under the

sun, move the vehicle to a shaded

area, use the air conditioning sys-

tem to sufficiently cool the interior,

and then press the “AC120V”

switch again.

If the power outlets cannot be used

even after performing the appropri-

ate procedures above, have the

vehicle inspected by your Toyota

dealer.

●

If any electrical device has mal-

functioned, park the vehicle in a

safe location and turn the

“AC120V” switch off.

●

If the protection function activates

and power is cut, perform the fol-

lowing procedure.

Stop the vehicle in a safe place

and set the parking brake.

Ensure that the shift lever is in P

or N.

Check that the power consumed

by the electrical devices is within

400 W and any device has not

malfunctioned.

Press the “AC120V” switch.

If the inside of the vehicle is hot,
open the windows to lower the tem-
perature and turn the switch back on
once the inside of the vehicle
reaches a normal temperature. If
following the procedure above does
not restore power, have the vehicle
inspected at your Toyota dealer.

WARNING

■

For safe use

Observe the following precau-

tions.
Failure to do so may lead to an

accident, resulting in death or

serious injury.

●

Do not use devices such as the

following when driving:

• Devices which cannot be prop-

erly secured within the vehicle.

• Devices which may distract the

driver and be a hindrance to

safe driving, such as a TV, DVD

player, etc.

• Unsecured devices which gen-

erate heat, such as a toaster,

microwave, electric heater, elec-

tric kettle, coffee maker, etc., as

they may cause burns or a fire

in the case of sudden braking or

an accident.

• Devices which may fall under

the pedals and prevent the

brake pedal from being

depressed.

438

5-4. Using the other interior features

WARNING

●

Do not use devices which pro-

duce steam while the windows

are closed. Doing so may cause

the windows to fog up, reducing

visibility and making it difficult to

drive safely. Also, the steam

may damage or negatively

affect other devices. If the

device must be used, stop the

vehicle and open the windows

before use.

●

Do not use damaged electronic

devices. The power supply

function may not be able to be

used.

●

Do not disconnect the plug of a

device while your hands are wet

or insert a pin or other object

into the power outlet. Also, if a

liquid or snow is on the power

outlet, dry the outlet before

using it.

●

Do not attempt to modify, disas-

semble or repair a power outlet.

For information on repairs, con-

tact your Toyota dealer.

●

Do not let children touch the

power outlets.

●

Keep the power outlets free of

dust and foreign matter. Also,

regularly clean the power outlet.

●

If the plug of a device fits

loosely in a power outlet, even

though it is fully inserted,

replace the power outlet. For

information on replacement,

contact your Toyota dealer.

■

Using the power outlets while

parked or stopped

Observe the following precau-

tions.
Failure to do so may lead to an

accident, possibly resulting in

death or serious injury.

●

Do not leave the vehicle unat-

tended while the hybrid system

is operating and a device is con-

nected to a power outlet.

●

Do not place luggage or get

near the vicinity of the tailpipe.

●

Make sure that the hood is

closed. Do not put your head or

hands anywhere inside the

engine room, as the cooling

fans may operate suddenly. If

too close, hands and clothing

(especially a tie, scarf, etc.) may

get caught in a fan.

●

Do not stop the vehicle near

objects which burn easily.

●

Install and use appropriately

related devices to make air sup-

ply and exhaust ventilation pos-

sible in places where ventilation

is bad, such as within garages,

and places where the vehicle is

surrounded (places where snow

accumulates).

●

Do not use in places where ven-

tilation is bad, such as within

garages where there are no air

supply and exhaust ventilation

devices, and places where the

vehicle is surrounded (places

where snow accumulates, etc.).

●

Do not use the power outlets if

the vehicle has a vehicle cover

installed.

●

Do not sleep in the vehicle while

using devices such as an elec-

tric heater.

■

Devices to be connected

●

Read the instruction manual

included with the electronic

device being used and observe

the precautions that are stated

regarding the product.

●

Do not use when the power plug

or electronic device are dam-

aged.

439

5-4. Using the other interior features

Interior

featur

To set the visor in the forward
position, flip it down.

To set the visor in the side
position, flip down, unhook,
and swing it to the side.

To use the side extender,
place the visor in the side
position, then slide it back-
ward.

WARNING

●

Malfunctions or poor operations

may occur when the outside

temperatures are particularly

high or low.

●

Normal operations may not be

possible for electronic devices

that require level installation.

●

Excluding electronic devices

with waterproof specifications,

do not use in places where it

can be covered by rain or water,

or places with lots of humidity.

●

Do not use medical equipment

as the power supply function

may temporarily stop depending

the conditions of the vehicle.

NOTICE

Observe the following precau-

tions.
Failure to do so may lead to the

power outlets not operating cor-

rectly or damage to the vehicle or

a connected device.

■

To avoid short circuit or mal-

function

●

Do not set a device which gen-

erates heat near the interior

components or on a seat. Heat

may cause these parts to melt

or burn.

●

Do not use devices which are

sensitive to vibration or heat in

the vehicle.

These devices may malfunction

due to vibration while driving or

heat while the vehicle is parked

in the sun.

●

When not using a power outlet,

make sure to close the cover. If

foreign matter or a liquid enters

the power outlet, it may cause a

malfunction or short circuit.

●

Do not use a multi-point outlet

adapter as doing so may over-

load the power outlet.

●

Immediately stop using if there

is an unusual amount of heat

being felt from the power outlet.

■

When the ambient tempera-

ture is high

If the temperature inside the vehi-

cle is high, such as after the vehi-

cle has been parked under the

sun, move the vehicle to a shaded

area, use the air conditioning sys-

tem to sufficiently cool the interior,

and then press the “AC120V”

switch again.

Sun visors

440

5-4. Using the other interior features

Open the cover.

The vanity light turns on.

■

To prevent 12-volt battery dis-

charge

If the vanity lights remain on when

the power switch is turned off, the

lights will go off automatically after

20 minutes.

Pull up the tab of the sunshade
and hook the shade on using
the anchors.

To retract the sunshade, unhook
the sunshade and retract it slowly.



Second seat



Third seat

Vanity mirrors

NOTICE

■

To prevent the 12-volt battery

from being discharged

Do not leave the vanity lights on

for extended periods while the

hybrid system is off.

Rear door sunshades (if
equipped)

NOTICE

■

To ensure normal operation

of the sunshades

Observe the following precau-

tions:

●

Do not place anything where it

may hinder the opening/closing

of the rear door sunshades.

●

Do not attach items to the rear

door sunshades.

●

Do not apply excessive load to

the rear door sunshades while

they are hanging from the

hooks.

●

Do not operate the rear door

sunshade while the rear door is

opening/closing.

●

Do not store the rear door sun-

shade in a tilted position. If

stored in a tilted position, the

rear door sunshade screen may

become creased.

441

5-4. Using the other interior features

Interior

featur

■

HomeLink

programming pro-

cedure

The programming procedures can

also be found at the following URL.

Website: www.homelink.com/toyota

For support, contact customer sup-

port at the following.
Help Line: 1-800-355-3515

The HomeLink

wireless control

system in your vehicle has 3
buttons which can be pro-
grammed to operate 3 different
devices. Refer to the program-
ming methods on the following
pages to determine the method
which is appropriate for the
device.

NOTICE

■

To prevent damage to the rear

door sunshade

Observe the following precau-

tions:

●

Do not use the rear door sun-

shade when either hook is

detached. When the rear door is

opened/closed, the rear door

sunshade may be damaged.

●

Do not pull on the screen while

the hooks are attached. The

screen may be damaged.

Garage door opener

The garage door opener can
be programmed using the
HomeLink

to operate

garage doors, gates, entry
doors, door locks, home
lighting systems, security
systems, and other devices.

System components

442

5-4. Using the other interior features



Vehicles with auto anti-glare
inside rear view mirror

HomeLink

indicator light

Garage door operation indi-
cators

HomeLink

icon

Illuminates while HomeLink

operating.

Buttons



Vehicles with Digital Rear-
view Mirror

HomeLink

indicator light

Illuminates above each button
selected.

HomeLink

icon

Garage door operation indi-
cators

HomeLink

logo

Appears while HomeLink

is oper-

ating. When the menu button
(



P.160) is pressed, the logo dis-

appears even while the HomeLink

is operating.

Setting icon

Press the menu button to change
the setting.

Menu buttons

HomeLink

buttons

■

Codes stored in the Home-
Link

memory

●

The registered codes are not

erased even if the 12-volt battery

cable is disconnected.

●

If learning failed when registering
a different code to a HomeLink

button that already has a code

registered to it, the already regis-

tered code will not be erased.

■

Certification



P.624

WARNING

■

When programming a garage

door or other remote control

device

The garage door or other device

may operate, so ensure people

and objects are out of danger to

prevent potential harm.

443

5-4. Using the other interior features

Interior

featur

■

Before programming Home-
Link



During programming, it is pos-
sible that garage doors,
gates, or other devices may
operate. For this reason,
make sure that people and
objects are clear of the
garage door or other devices
to prevent injury or other
potential harm.



It is recommended that a new
battery be placed in the
remote control transmitter for
more accurate programming.



Garage door opener motors
manufactured after 1995 may
be equipped with rolling code

protection. If this is the case,
you may need a stepladder or
other sturdy, safe device to
reach the “Learn” or “Smart”
button on the garage door
opener motor.

■

Programming HomeLink

Steps

through

must be per-

formed within 60 seconds, oth-
erwise the indicator light will
stop flashing and programming
will not be successfully com-
pleted.

Vehicles with Digital Rear-
view Mirror: Press the Home-
Link

button or menu button

When the HomeLink

button

is pressed: Homelink

Train-

ing Tutorial will be displayed
to assist you programming
the HomeLink

When the menu button is pressed:
Press the menu button

and

select the “SET UP”. Homelink

Training Tutorial will be displayed to
assist you programming the Home-
Link

Press and release the Home-
Link

button you want to pro-

gram and check that the
HomeLink

indicator light

flashes (orange).

Point the remote control
transmitter for the device at
the rear view mirror, 1 to 3 in.
(25 to 75 mm) from the
HomeLink

buttons.

WARNING

■

Conforming to federal safety

standards

Do not use the HomeLink

com-

patible transceiver with any

garage door opener or device that

lacks safety stop and reverse fea-

tures as required by federal safety

standards.
This includes any garage door

that cannot detect an interfering

object. A door or device without

these features increases the risk

of death or serious injury.

■

When operating or program-
ming HomeLink

Never allow a child to operate or
play with the HomeLink

buttons.

Programming the Home-
Link

444

5-4. Using the other interior features

Keep the HomeLink

indicator light

in view while programming.

Program a device.



Programming a device other
than an entry gate (for U.S.A.
owners)

Press and hold the remote control
transmitter button until the Home-
Link

indicator light changes from

slowly flashing orange to rapidly
flashing green (rolling code) or con-
tinuously lit green (fixed code), then
release the button.



Programming an entry gate
(for U.S.A. owners)/Program-
ming a device in the Cana-
dian market

Press and release the remote con-
trol transmitter button at 2 second
intervals, repeatedly, until the
HomeLink

indicator light changes

from slowly flashing (orange) to
rapidly flashing (green) (rolling

code) or continuously lit (green)
(fixed code).

Test the HomeLink

opera-

tion by pressing the newly
programmed button and
observing the indicator light:



HomeLink

indicator light illu-

minates: Programming of a
fixed code device has com-
pleted. The garage door or
other device should operate
when a HomeLink

button is

pressed and released.



HomeLink

indicator light

flashes rapidly: The garage
door opener motor or other
device is equipped with a roll-
ing code. To complete pro-
gramming, firmly press and
hold the HomeLink

button

for 2 seconds then release it.



If the garage door or other
device does not operate, pro-
ceed to “Programming a roll-
ing code system”.

Repeat the steps above to
program another device for
any of the remaining Home-
Link

buttons.

■

Programming a rolling code
system

Two or more people may be
necessary to complete rolling
code programming.

Locate the “Learn” or “Smart”
button on the garage door
opener motor in the garage.

445

5-4. Using the other interior features

Interior

featur

This button can usually be found

where the hanging antenna wire is

attached to the unit. The name and

color of the button may vary by

manufacturer. Refer to the owner’s

manual supplied with the garage

door opener motor for details.

Press and release the
“Learn” or “Smart” button.

Perform

within 30 seconds after

performing

Press and hold the desired
HomeLink

button (inside the

vehicle) for 2 seconds and
release it. Repeat this
sequence
(press/hold/release) up to 3
times to complete program-
ming.
If the garage door opener
motor operates when the
HomeLink

button is

pressed, the garage door

opener motor recognizes the
HomeLink

signal.

■

Enabling 2-way communi-
cation with a garage door
(only available for compati-
ble devices)

When enabled, 2-way communi-
cation allows you to check the
status of the opening and clos-
ing of a garage door through
indicators in your vehicle.
2-way communication is only
available if the garage door
opener motor used is a compati-
ble device. (To check device
compatibility, refer to
www.homelink.com.)

Within 5 seconds after pro-
gramming the garage door
opener has been completed,
if the garage door opener
motor is trained to Home-
Link

, both garage door

operation indicators will flash
rapidly (green) and the light
on the garage door opener
motor will blink twice, indicat-
ing that 2-way communica-
tion is enabled.

If the indicators do not flash, per-

446

5-4. Using the other interior features

form

and

within the first 10

presses of the HomeLink

button

after programming has been com-

pleted.

Press a programmed Home-
Link

button to operate a

garage door.

Within 1 minute of pressing
the HomeLink

button, after

the garage door operation
has stopped, press the
“Learn” or “Smart” button on
the garage door opener
motor. Within 5 seconds of
the establishment of 2-way
communication with the
garage door opener, both
garage door operation indica-
tors in the vehicle will flash
rapidly (green) and the light
on the garage door opener
motor will blink twice, indicat-
ing that 2-way communica-
tion is enabled.

■

Reprogramming a single
HomeLink

button

When the following procedure is
performed, buttons which
already have devices registered
to them can be overwritten:

Press and hold the desired
HomeLink

button.

When the HomeLink

indica-

tor starts flashing orange,
release the HomeLink

but-

ton and perform “Program-
ming HomeLink

”

(it takes

20 seconds for the Home-

Link

indicator to start flash-

ing).

■

Before programming

●

Install a new battery in the trans-

mitter.

●

The battery side of the transmitter

must be pointed away from the
HomeLink

buttons.

Press the appropriate Home-
Link

button. The HomeLink

indicator light should turn on.
The status of the opening and
closing of a garage door is
shown by the garage door
opener indicators.



Vehicles with auto anti-glare
inside rear view mirror

Opening

Closing

Operating HomeLink

447

5-4. Using the other interior features

Interior

featur



Vehicles with Digital Rear-
view Mirror

Opening

Closing

This function is only available if the
garage door opener motor used is a
compatible device. (To check
device compatibility, refer to
www.homelink.com.)

The indicators can operate
within approximately 820 ft. (250
m) of the garage door. However,
if there are obstructions
between the garage door and
the vehicle, such as houses and
trees, feedback signals from the
garage door may not be
received.

To recall the previous door oper-
ation status, press and release

either HomeLink

buttons

and

(vehicles

with auto anti-glare inside rear
view mirror),

and

(vehicles

with Digital Rear-view Mirror),
simultaneously. The last
recorded status will be dis-
played for 3 seconds.

Press and hold the 2 outside
buttons for 10 seconds until the
HomeLink

indicator light

changes from continuously lit
(orange) to rapidly flashing
(green).
