290

6-1. Maintenance and care

Cleaning the synthetic leather areas

⚫

Remove dust using a vacuum cleaner

⚫

Wipe it off with a soft cloth dampened with neutral detergent diluted to

approximately 1%

⚫

Wring out any excess water from the cloth and thoroughly wipe off

remaining traces of detergent and water

⬛

Caring for leather areas

Toyota recommends cleaning the interior of the vehicle at least twice a year to

maintain the quality of the vehicle’s interior.

⬛

Carpet cleaning

Toyota recommends that you keep the carpet dry at all times. To clean the car-

pet, a commercially available foam-type cleaner can be used.
Use a sponge or brush to spread the foam over the carpet and work it in a cir-

cular motion. Do not apply water directly. Wipe off and dry.

⬛

Seat belts

Clean with mild soap and lukewarm water using a cloth or sponge.
Also check the seat belts periodically for excessive wear, fraying or cuts.

WARNING

⬛

Water in the vehicle

⚫

Do not splash or spill liquid in the vehicle.
Doing so may cause electrical components, etc., to malfunction or catch fire.

⚫

Do not get any of the SRS airbag components or wiring in the vehicle interior
wet. (

➞

P. 37)

An electrical malfunction may cause the SRS airbags to deploy or not func-

tion properly, resulting in death or serious injury.

⬛

Cleaning the interior (especially instrument panel)

Do not use a polish wax or polish cleaner. The instrument panel may reflect off

the windshield, obstructing the driver’s view and leading to an accident, result-

ing in death or serious injury.

⬛

Caution: Area around the seats

Be very careful when putting your hand under a seat, such as when cleaning

the interior of the vehicle or picking up anything that has fallen under the seat.

Your hand may strike the seat rail or the base of the seat and be injured.

291

6-1. Maintenance and care

Mai
ntenance and car

e

6

NOTICE

⬛

Cleaning detergents

⚫

Do not use the following types of detergent, as they may discolor the vehicle
interior or cause streaks or damage to painted surfaces:

⦁

Non-seat portions: Organic solvents such as benzene or gasoline, alkaline

or acid solutions, dye, and bleach

⦁

Seats: Alkaline or acid solutions, such as thinner, benzene, and alcohol

⚫

Do not use a polish wax or polish cleaner.
The paint on the instrument panel or other interior part may be peeled off,

dissolved, or deformed.

⚫

Do not use glass cleaner or alcohol on the lens cover of the meter.
It may cause discoloration or cracking.

⚫

Do not use silicone spray around the switches. The silicone will adhere to the
internal electrical components and may cause a failure.

⬛

Preventing damage to leather surfaces

Observe the following precautions to avoid damage to and deterioration of

leather surfaces:

⚫

Remove any dust or dirt from leather surfaces immediately

⚫

Avoid prolonged exposure to direct sunlight
Park the vehicle in the shade, especially during summer

⚫

Do not place items made of vinyl, plastic, or containing wax on the uphol-
stery, as they may stick to the leather surface if the vehicle interior heats up

significantly

⬛

Water on the floor

Do not wash the vehicle floor with water.
If water comes into contact with audio system or electrical components under

the floor carpet of the vehicle, it may cause the malfunction of the vehicle, or

rusting of the vehicle body.

⬛

Cleaning the inside of the rear window (vehicles with the rear window defogger)

⚫

Do not use window washing detergent, etc., for such solutions can damage
the hot wires. Instead, gently wipe the window along its hot wires with cloth

dampened with water or warm water.

⚫

Be careful not to scratch or damage the hot wires.

⬛

When using liquid fragrance

Secure the container so that it does not spill. Also, do not place it on the instru-

ment panel or near the meter.
If liquid spills and adheres to the plastic parts, cloth materials, or the lens cover

of the meter, it may cause discoloration or cracking.

292

6-2. Maintenance

Maintenance requirements

To ensure safe and economical driving, day-to-day care and regular

maintenance are essential. Toyota recommends the following main-

tenance:

General maintenance

General maintenance should be performed on a daily basis. This can be

done by yourself or by a Toyota dealer.

Scheduled maintenance

⚫

Scheduled maintenance should be performed at specified intervals

according to the maintenance schedule.

The interval for scheduled maintenance is determined by the odometer reading or

the time interval, whichever comes first, shown in the schedule.
Maintenance beyond the last period should be performed at the same intervals.

⚫

Where to go for maintenance service?

It makes good sense to take your vehicle to your local Toyota dealer for maintenance

service as well as other inspections and repairs.
Toyota technicians are well-trained specialists receiving the latest service information

through technical bulletins, service tips and in-dealership training programs. They

learn to work on Toyota before they work on your vehicle, rather than while they are

working on it. Doesn’t that seem like the best way?
Your Toyota dealer has invested a lot of money in special Toyota tools and service

equipment. It helps them to do the job better and at less cost.
Your Toyota dealer’s service department will perform all of the scheduled mainte-

nance on your vehicle reliably and economically.
Rubber hoses (for cooling and heater system, brake system and fuel system) should

be inspected by a qualified technician according to the Toyota maintenance sched-

ule.
Rubber hoses are particularly important maintenance items. Have any deteriorated

or damaged hoses replaced immediately. Note that rubber hoses will deteriorate

with age, resulting in swelling, chafing or cracking.

293

6-2. Maintenance

Mai
ntenance and car

e

6

Do-it-yourself maintenance

⚫

What about do-it-yourself maintenance?

Many of the maintenance items are easy to do yourself if you have a little mechanical

ability and a few basic automotive tools. Simple instructions for how to perform them

are presented in this section.
Note, however, that some maintenance tasks require special tools and skills. These

are best performed by qualified technicians. Even if you are an experienced do-it-

yourself mechanic, we recommend that repairs and maintenance be conducted by

your Toyota dealer who will keep a record of maintenance on your vehicle. This

record could be helpful should you ever require Warranty Service.

⬛

Does your vehicle need repairs?

Be on the alert for changes in performance and sounds, and visual tip-offs that

indicate service is needed. Some important clues are:

⚫

Engine misses, stumbling or pinging

⚫

Appreciable loss of power

⚫

Strange engine noises

⚫

A fluid leak under the vehicle (However, water dripping from the air condi-
tioning system after use is normal.)

⚫

Change in exhaust sound (This may indicate a dangerous carbon monoxide leak.
Drive with the windows open and have the exhaust system checked immediately.)

⚫

Flat-looking tires, excessive tire squeal when cornering, uneven tire wear

⚫

Vehicle pulls to one side when driven straight on a level road

⚫

Strange noises related to suspension movement

⚫

Loss of brake effectiveness, spongy feeling brake pedal or clutch pedal (vehi-
cles with a manual transmission), pedal almost touches the floor, vehicle

pulls to one side when braking

⚫

Engine coolant temperature continually higher than normal

If you notice any of these clues, take your vehicle to your Toyota dealer as soon

as possible. Your vehicle may need adjustment or repair.

WARNING

⬛

If your vehicle is not properly maintained

Improper maintenance could result in serious damage to the vehicle and pos-

sible death or serious injury.

⬛

Handling of the battery

Battery posts, terminals and related accessories contain lead and lead com-

pounds which are known to cause brain damage. Wash your hands after han-

dling. (

➞

P. 321)

294

6-2. Maintenance

Scheduled maintenance

Perform maintenance by the schedule as follows:

Maintenance schedule requirements

Your vehicle needs to be serviced in according to the normal maintenance

schedule. (See “Maintenance schedule”.)
If you mainly operate your vehicle under one or more of the special oper-

ating conditions below, some of the maintenance schedule items need to

be serviced more frequently in order to keep your vehicle in good condi-

tion. (See “Additional maintenance schedule”.)

⬛

Road Condition

⚫

Operating on rough or muddy roads, or roads with melted snow

⚫

Operating on dusty roads (Roads in areas where their pavement rate is

low, or a cloud of dust often arises and the air is dry.)

⬛

Driving Condition

⚫

Heavily loaded vehicle (Example: Using a car top carrier, etc.)

⚫

Repeated short trips less than 8 km (5 miles) and outside temperatures

remain below freezing (Engine temperature will not reach to normal

temperature)

⚫

Extensive idling and/or low speed driving for a long distance such as

police, taxi or door-to-door delivery use

⚫

Continuous high speed driving (80% or more of maximum vehicle

speed) for over 2 hours

295

6-2. Maintenance

Mai
ntenance and car

e

6

Maintenance schedule (except for Mexico)

Maintenance operations : I = Inspect, correct or replace as necessary

R = Replace, change or lubricate

SERVICE

INTERVAL:

ODOMETER READING

MONTHS

(Odometer

reading or

months,

whichever

comes first.)

x1000

km

1

10 20 30 40 50 60 70 80

x1000

miles

1

6

12 18 24 30 36 42 48

BASIC ENGINE COMPONENTS

1 Valve clearance

(1KR-VET engine)

I

96

2 Drive belts

I

I

I

I

24

3 Engine oil

(WA-VE engine)

R

R

R

R

R

R

R

R

6

4 Engine oil

(1KR-VET engine)

Replace when the maintenance reminder

appears.*

1

―

5 Engine oil filter

(WA-VE engine)

R

R

R

R

R

R

R

R

6

6 Engine oil filter

(1KR-VET engine)

Replace when the maintenance reminder

appears.*

1

―

7 Cooling and heater

system*

2

I

I

24

8 Engine coolant

First replace at 160000 km (100000 miles),

then replace every 80000 km (48000 miles)

―

9 Exhaust pipes and

mountings

I

I

I

I

12

IGNITION SYSTEM

10 Spark plugs

Replace at every 100000 km (60000 miles)

―

11 Battery

I

I

I

I

I

I

I

I

I

12

296

6-2. Maintenance

FUEL AND EMISSION CONTROL SYSTEMS

12 Fuel filter*

3

R

96

13 Air cleaner filter

I

R

I

R

I: 24

R: 48

14

Fuel tank cap, fuel

lines, connections

and fuel vapor con-

trol valve*

2

I

I

24

15 Charcoal canister

I

I

24

CHASSIS AND BODY

16 Clutch pedal

(1KR-VET engine)

I

I

I

I

I

I

I

I

12

17 Clutch pedal

(WA-VE engine)

I

I

I

I

I

I

I

I

12

18 Brake pedal and

parking brake

I

I

I

I

I

I

I

I

6

19

Brake linings and

drums (include park-

ing brake linings and

drums)

I

I

I

I

12

20 Brake pads and discs

I

I

I

I

6

21 Brake fluid

I

I

I

R

I

I

I

R

I: 6

R: 24

22 Clutch fluid

(1KR-VET engine)

I

I

I

R

I

I

I

R

I: 6

R: 24

23 Brake pipes and

hoses

I

I

I

I

12

24

Steering wheel, link-

age and steering

gear box

I

I

I

I

12

SERVICE

INTERVAL:

ODOMETER READING

MONTHS

(Odometer

reading or

months,

whichever

comes first.)

x1000

km

1

10 20 30 40 50 60 70 80

x1000

miles

1

6

12 18 24 30 36 42 48

297

6-2. Maintenance

Mai
ntenance and car

e

6

*1

Replace both the engine oil and oil filter, even when the maintenance
reminder does not appear, after 6 months have passed, since the last oil
change.

*2

After 80000 km (48000 miles) or 48 months inspection, inspect every 20000
km (12000 miles) or 12 months.

*3

Including the filter in fuel tank.

25 Drive shaft boots

I

I

I

I

I

I

I

I

6

26 Front wheel align-

ment (toe-in)

I

I

48

27 Suspension ball joint

and dust cover

I

I

I

I

12

28

Manual transmis-

sion oil (including

front differential)

I

R

I: 48

R: 96

29

Continuously varia-

ble transmission

fluid (including front

differential)

Inspect every 12 months, Replace every

100000 km (60000 miles)

―

30 Front and rear sus-

pension

I

I

I

I

12

31 Tires and inflation

pressure

I

I

I

I

I

I

I

I

6

32 Lights, horns, wipers

and washers

I

I

I

I

I

I

I

I

6

33 Air conditioning filter

R

R

R

R

24

SERVICE

INTERVAL:

ODOMETER READING

MONTHS

(Odometer

reading or

months,

whichever

comes first.)

x1000

km

1

10 20 30 40 50 60 70 80

x1000

miles

1

6

12 18 24 30 36 42 48

298

6-2. Maintenance

Additional maintenance schedule (except for Mexico)

Refer to the following table for normal maintenance schedule items

requiring more frequent service specific to the type of severe conditions.

(For outline, see “Maintenance schedule requirements”.)

A-1: Operating on rough or muddy roads, or roads with melted snow

Inspection*

1

 of brake linings and drums

(include parking brake linings and drums)

Every 10000 km (6000 miles) or 6

months

Inspection*

1

 of brake pads and discs

Every 10000 km (6000 miles) or 3

months

Inspection*

1

 of brake pipes and hoses

Every 10000 km (6000 miles) or 6

months

Inspection*

1

 of steering wheel, linkage

and steering gear box

Every 5000 km (3000 miles) or 3

months

Inspection*

1

 of suspension ball joint and

dust cover

Every 10000 km (6000 miles) or 6

months

Inspection*

1

 or replacement of continu-

ously variable transmission fluid (includ-

ing front differential)

I: Every 5000 km (3000 miles) or 3

months

R: Every 50000 km (30000 miles)

Inspection*

1

 of front and rear suspension Every 10000 km (6000 miles) or 6

months

Tightening of bolts and nuts on chassis

and body*

2

Every 10000 km (6000 miles) or 6

months

A-2: Operating on dusty roads (Roads in areas where their pavement rate is

low, or a cloud of dust often arises and the air is dry.)

Replacement of engine oil

(WA-VE engine)

Every 5000 km (3000 miles) or 3

months

Replacement of engine oil

(1KR-VET engine)

Replace when the maintenance

reminder appears.*

3

Replacement of engine oil filter

(WA-VE engine)

Every 5000 km (3000 miles) or 3

months

Replacement of engine oil filter

(1KR-VET engine)

Replace when the maintenance

reminder appears.*

3

Inspection*

1

 or replacement of air cleaner

filter

I: Every 2500 km (1500 miles) or 3

months

R: Every 20000 km (12000 miles) or 48

months

299

6-2. Maintenance

Mai
ntenance and car

e

6

Inspection*

1

 of brake linings and drums

(include parking brake linings and drums)

Every 10000 km (6000 miles) or 6

months

Inspection*

1

 of brake pads and discs

Every 10000 km (6000 miles) or 3

months

Inspection*

1

 or replacement of continu-

ously variable transmission fluid (includ-

ing front differential)

I: Every 5000 km (3000 miles) or 3

months

R: Every 50000 km (30000 miles)

Replacement of air conditioning filter

Every 20000 km (12000 miles) or 24

months

B-1: Heavily loaded vehicle (Example: Using a car top carrier, etc.)

Replacement of engine oil

(WA-VE engine)

Every 5000 km (3000 miles) or 3

months

Replacement of engine oil

(1KR-VET engine)

Replace when the maintenance

reminder appears.*

3

Replacement of engine oil filter

(WA-VE engine)

Every 5000 km (3000 miles) or 3

months

Replacement of engine oil filter

(1KR-VET engine)

Replace when the maintenance

reminder appears.*

3

Inspection*

1

 of brake linings and drums

(include parking brake linings and drums)

Every 10000 km (6000 miles) or 6

months

Inspection*

1

 of brake pads and discs

Every 10000 km (6000 miles) or 3

months

Replacement of manual transmission oil

(including front differential)

Every 40000 km (24000 miles) or 48

months

Inspection*

1

 or replacement of continu-

ously variable transmission fluid

(including front differential)

I: Every 5000 km (3000 miles) or 3

months

R: Every 50000 km (30000 miles)

Inspection*

1

 of front and rear suspension Every 10000 km (6000 miles) or 6

months

Tightening of bolts and nuts on chassis

and body*

2

Every 10000 km (6000 miles) or 6

months

B-2: Repeated short trips less than 8 km (5 miles) and outside temperatures remain

below freezing (Engine temperature will not reach to normal temperature)

Replacement of engine oil (WA-VE engine) Every 5000 km (3000 miles) or 3

months

Replacement of engine oil

(1KR-VET engine)

Replace when the maintenance

reminder appears.*

3

300

6-2. Maintenance

*1

Perform correction or replacement as necessary.

*2

For seat mounting bolts, front and rear suspension member retaining bolts.

*3

Replace both engine oil and oil filter every 3 months, in which the vehicle is
mainly driven in dirt or dusty roads, when the maintenance reminder does not
appear.

Replacement of engine oil filter

(WA-VE engine)

Every 5000 km (3000 miles) or 3

months

Replacement of engine oil filter

(1KR-VET engine)

Replace when the maintenance

reminder appears.*

3

Inspection*

1

 or replacement of continu-

ously variable transmission fluid

(including front differential)

I: Every 5000 km (3000 miles) or 3

months

R: Every 50000 km (30000 miles)

B-3: Extensive idling and/or low speed driving for a long distance such as

police, taxi or door-to-door delivery use

Replacement of engine oil

(WA-VE engine)

Every 5000 km (3000 miles) or 3

months

Replacement of engine oil

(1KR-VET engine)

Replace when the maintenance

reminder appears.*

3

Replacement of engine oil filter

(WA-VE engine)

Every 5000 km (3000 miles) or 3

months

Replacement of engine oil filter

(1KR-VET engine)

Replace when the maintenance

reminder appears.*

3

Inspection*

1

 of brake linings and drums

(include parking brake linings and drums)

Every 10000 km (6000 miles) or 6

months

Inspection*

1

 of brake pads and discs

Every 10000 km (6000 miles) or 3

months

Inspection*

1

 or replacement of continu-

ously variable transmission fluid

(including front differential)

I: Every 5000 km (3000 miles) or 3

months

R: Every 50000 km (30000 miles)

B-4: Continuous high speed driving (80% or more of maximum vehicle speed)

for over 2 hours

Replacement of manual transmission oil

(including front differential)

Every 40000 km (24000 miles) or 48

months

Inspection*

1

 or replacement of continu-

ously variable transmission fluid

(including front differential)

I: Every 5000 km (3000 miles) or 3

months

R: Every 50000 km (30000 miles)

301

6-2. Maintenance

Mai
ntenance and car

e

6

Maintenance schedule (For Mexico)

Maintenance operations : I = Inspect, correct or replace as necessary

R = Replace, change or lubricate

SERVICE

INTERVAL:

ODOMETER READING

MONTHS

(Odometer

reading or

months,

whichever

comes first.)

x1000

km

10

20

30

40

50

60

70

80

x1000

miles

6

12

18

24

30

36

42

48

BASIC ENGINE COMPONENTS

1 Valve clearance

I

96

2 Drive belts

I

I

I

I

24

3 Engine oil

Replace when the maintenance reminder
appears.

*1

―

4 Engine oil filter

Replace when the maintenance reminder
appears.

*1

―

5

Cooling and heater
system

*2

I

I

24

6 Engine coolant

First replace at 160000 km (100000 miles),

then replace every 80000 km (50000 miles)

―

7

Exhaust pipes and

mountings

I

I

I

I

12

IGNITION SYSTEM

8 Spark plugs

Replace at every 100000 km (60000 miles)

―

FUEL AND EMISSION CONTROL SYSTEMS

9 Fuel filter

*3

R

96

10 Air cleaner filter

I

R

I

R

I: 24

R: 48

11

Fuel tank cap, fuel

lines, connections

and fuel vapor con-

trol valve*

2

I

I

24

12 Charcoal canister

I

I

24

302

6-2. Maintenance

CHASSIS AND BODY

13

Brake linings and

drums (include park-

ing brake linings and

drums)

I

I

I

I

12

14 Brake pads and discs

I

I

I

I

6

15 Brake fluid

I

I

I

R

I

I

I

R

I: 6

R: 24

16 Clutch fluid

I

I

I

R

I

I

I

R

I: 6

R: 24

17 Brake pipes and

hoses

I

I

I

I

12

18

Steering wheel, link-

age and steering

gear box

I

I

I

I

12

19 Drive shaft boots

I

I

I

I

I

I

I

I

6

20 Suspension ball joint

and dust cover

I

I

I

I

12

21

Manual transmis-

sion oil (including

front differential)

I

R

I: 48

R: 96

22

Continuously varia-

ble transmission

fluid (including front

differential)

Inspect every 12 months, Replace every

100000 km (60000 miles)

―

23 Front and rear sus-

pension

I

I

I

I

12

24 Front wheel align-

ment (toe-in)

I

I

48

25 Air conditioning filter

R

R

R

R

24

SERVICE

INTERVAL:

ODOMETER READING

MONTHS

(Odometer

reading or

months,

whichever

comes first.)

x1000

km

10

20

30

40

50

60

70

80

x1000

miles

6

12

18

24

30

36

42

48

303

6-2. Maintenance

Mai
ntenance and car

e

6

REMARKS: See page 306 for general maintenance items.

*1

Replace both the engine oil and oil filter, even when the maintenance
reminder does not appear, after 6 months have passed, since the last oil
change.

*2

After 80000 km (48000 miles) or 48 months inspection, inspect every 20000
km (12000 miles) or 12 months.

*3

Including the filter in fuel tank.

Additional maintenance schedule (For Mexico)

Refer to the following table for normal maintenance schedule items

requiring more frequent service specific to the type of severe conditions.

(For outline, see “Maintenance schedule requirements”.)

A-1: Operating on rough or muddy roads, or roads with melted snow

Inspection

*1

 of brake linings and drums

(include parking brake linings and drums)

Every 10000 km (6000 miles) or 6

months

Inspection

*1

 of brake pads and discs

Every 10000 km (6000 miles) or 3

months

Inspection

*1

 of brake pipes and hoses

Every 10000 km (6000 miles) or 6

months

Inspection

*1

 of steering wheel, linkage

and steering gear box

Every 5000 km (3000 miles) or 3

months

Inspection

*1

 of suspension ball joint and

dust covers

Every 10000 km (6000 miles) or 6

months

Inspection

*1

 or replacement of continu-

ously variable transmission fluid (includ-

ing front differential)

I: Every 5000 km (3000 miles) or 3

months

R: Every 50000 km (30000 miles)

Inspection

*1

 of front and rear suspension

Every 10000 km (6000 miles) or 6

months

Tightening of bolts and nuts on chassis
and body

*2

Every 10000 km (6000 miles) or 6

months

A-2: Operating on dusty roads (Roads in areas where their pavement rate is

low, or a cloud of dust often arises and the air is dry.)

Replacement of engine oil

Replace when the maintenance
reminder appears.

*3

304

6-2. Maintenance

Replacement of engine oil filter

Replace when the maintenance
reminder appears.

*3

Inspection

*1

 or replacement of air cleaner

filter

I: Every 2500 km (1500 miles) or 3

months

R: Every 20000 km (12000 miles) or 48

months

Inspection

*1

 of brake linings and drums

(include parking brake linings and drums)

Every 10000 km (6000 miles) or 6

months

Inspection

*1

 of brake pads and discs

Every 10000 km (6000 miles) or 3

months

Inspection

*1

 or replacement of continu-

ously variable transmission fluid (includ-

ing front differential)

I: Every 5000 km (3000 miles) or 3

months

R: Every 50000 km (30000 miles)

Replacement of air conditioning filter

Every 20000 km (12000 miles) or 24

months

B-1: Heavily loaded vehicle (Example: Using a car top carrier, etc.)

Replacement of engine oil

Replace when the maintenance
reminder appears.

*3

Replacement of engine oil filter

Replace when the maintenance
reminder appears.

*3

Inspection

*1

 of brake linings and drums

(include parking brake linings and drums)

Every 10000 km (6000 miles) or 6

months

Inspection

*1

 of brake pads and discs

Every 10000 km (6000 miles) or 3

months

Replacement of manual transmission oil

(including front differential)

Every 40000 km (24000 miles) or 48

months

Inspection

*1

 or replacement of continu-

ously variable transmission fluid (includ-

ing front differential)

I: Every 5000 km (3000 miles) or 3

months

R: Every 50000 km (30000 miles)

Inspection

*1

 of front and rear suspension

Every 10000 km (6000 miles) or 6

months

Tightening of bolts and nuts on chassis
and body

*2

Every 10000 km (6000 miles) or 6

months

305

6-2. Maintenance

Mai
ntenance and car

e

6

*1

Perform correction or replacement as necessary.

*2

For seat mounting bolts, front and rear suspension member retaining bolts.

*3

Replace both engine oil and oil filter every 3 months, in which the vehicle is
mainly driven in dirt or dusty roads, when the maintenance reminder does not
appear.

B-2: Repeated short trips less than 8 km (5 miles) and outside temperatures

remain below freezing (Engine temperature will not reach to normal tem-

perature)

Replacement of engine oil

Replace when the maintenance
reminder appears.

*3

Replacement of engine oil filter

Replace when the maintenance
reminder appears.

*3

Inspection

*1

 or replacement of continu-

ously variable transmission fluid (includ-

ing front differential)

I: Every 5000 km (3000 miles) or 3

months

R: Every 50000 km (30000 miles)

B-3: Extensive idling and/or low speed driving for a long distance such as

police, taxi or door-to-door delivery use

Replacement of engine oil

Replace when the maintenance
reminder appears.

*3

Replacement of engine oil filter

Replace when the maintenance
reminder appears.

*3

Inspection

*1

 of brake linings and drums

(include parking brake linings and drums)

Every 10000 km (6000 miles) or 6

months

Inspection

*1

 of brake pads and discs

Every 10000 km (6000 miles) or 3

months

Inspection

*1

 or replacement of continu-

ously variable transmission fluid (includ-

ing front differential)

I: Every 5000 km (3000 miles) or 3

months

R: Every 50000 km (30000 miles)

B-4: Continuous high speed driving (80% or more of maximum vehicle speed)

for over 2 hours

Replacement of manual transmission oil

(including front differential)

Every 40000 km (24000 miles) or 48

months

Inspection

*1

 or replacement of continu-

ously variable transmission fluid (includ-

ing front differential)

I: Every 5000 km (3000 miles) or 3

months

R: Every 50000 km (30000 miles)
