Toyota GR Corolla (2023 year). Manual in english

369

8-1. Specifications

Vehicle

specificatio

: Table 1 -Occupant loading and distribution for vehicle normal load for var-

ious designated seating capacities

Sidewall separation

The parting of the rubber compound from
the cord material in the sidewall

Snow tire

A tire that attains a traction index equal to
or greater than 110, compared to the
ASTM E-1136 Standard Reference Test
Tire, when using the snow traction test as
described in ASTM F-1805-00, Standard
Test Method for Single Wheel Driving Trac-
tion in a Straight Line on Snow-and
Ice-Covered Surfaces, and which is

marked with an Alpine Symbol (

) on at

least one sidewall

Test rim

The rim on which a tire is fitted for testing,
and may be any rim listed as appropriate
for use with that tire

Tread

That portion of a tire that comes into con-
tact with the road

Tread rib

A tread section running circumferentially
around a tire

Tread separation

Pulling away of the tread from the tire car-
cass

Treadwear indicators (TWI)

The projections within the principal
grooves designed to give a visual indica-
tion of the degrees of wear of the tread

Wheel-holding fixture

The fixture used to hold the wheel and tire
assembly securely during testing

Tire related term

Meaning

Designated seating

capacity, Number of

occupants

Vehicle normal load,

Number of occupants

Occupant distribution in

a normally loaded vehi-

cle

2 through 4

2 in front

5 through 10

2 in front, 1 in second

seat

370

8-1. Specifications

11 through 15

2 in front, 1 in second

seat, 1 in third seat, 1 in

fourth seat

16 through 20

2 in front, 2 in second

seat, 2 in third seat, 1 in

fourth seat

Designated seating

capacity, Number of

occupants

Vehicle normal load,

Number of occupants

Occupant distribution in

a normally loaded vehi-

cle

371

8-2. Customization

Vehicle

specificatio

8-2.Customization

■

Changing by using the
audio system screen

Select

on the main menu.

Select “Vehicle customize”.

Select the item to change the
settings of from the list.

For functions that can be turned
on/off, select

(ON)/

(OFF).

■

Changing by using the
meter control switches

Select

of the multi-infor-

mation display.

Press

to select the

desired item to be custom-
ized.

Press or press and hold

The available settings will differ
depending on if

is pressed or

pressed and held. Follow the

instructions on the display.

Some function settings are changed simultaneously with other func-
tions being customized. Contact your Toyota dealer for further
details.

Settings that can be changed using the audio system screen
Settings that can be changed using the meter control switches
Settings that can be changed by your Toyota dealer

Customizable features

Your vehicle includes a vari-
ety of electronic features
that can be personalized to
suit your preferences. The
settings of these features
can be changed using the
multi-information display,
the audio system, or at your
Toyota dealer.

Customizing vehicle fea-
tures

WARNING

■

During customization

As the engine needs to be run-

ning during customization, ensure

that the vehicle is parked in a

place with adequate ventilation. In

a closed area such as a garage,

exhaust gases including harmful

carbon monoxide (CO) may col-

lect and enter the vehicle. This

may lead to death or a serious

health hazard.

NOTICE

■

During customization

To prevent battery discharge,

ensure that the engine is running

while customizing features.

Customizable features

372

8-2. Customization

Definition of symbols: O = Available, — = Not available

■

Gauges, meters and multi-information display (



P.68, 72, 76)

Function

Default setting Customized setting

Language

English

French

O O —

Spanish

Units

miles (MPG)

km (km/L)

— O —

km (L/100 km)

miles (MPG Impe-

rial)

Meter Type

1-dial

non-dial

— O —

Change with Drive

Mode

REV Indicator

Off

— O —

Rev setting

6500 rpm

2000 to 7000 rpm

— O —

Rev Peak

Off

— O —

Fuel economy

Total average

(Average fuel

consumption

[after reset])

Trip average (Aver-

age fuel consump-

tion [after start])

— O —

Drive information items
(First item)

Distance

Average vehicle

speed

— O —

Elapsed time

Drive information items
(Second item)

Elapsed time

Distance

— O —

Average vehicle

speed

TRIP A Items (First
item)

Distance

Average vehicle

speed

— O —

Elapsed time

TRIP A Items (Second
item)

Average vehi-

cle speed

Distance

— O —

Elapsed time

TRIP B Items (First
item)

Distance

Average vehicle

speed

— O —

Elapsed time

373

8-2. Customization

Vehicle

specificatio

:For details about each function:



P.83

:The default setting varies according to country.

:This setting changes in accordance with My Settings.

■

Door lock (



P.89, 93, 341)

■

Rear seat reminder function (



P.91)

■

Smart key system and wireless remote control (



P.89, 96)

TRIP B Items (Second
item)

Average vehi-

cle speed

Distance

— O —

Elapsed time

Pop-up display

Off

— O —

Function

Default setting Customized setting

Unlocking using a
mechanical key

Driver’s door

unlocked in

one step, all

doors

unlocked in

two step

All doors unlocked

in one step

— — O

Locking/unlocking of the
back door when all
doors are
locked/unlocked

Off

— — O

Function

Default setting Customized setting

Rear seat reminder
function

Off

— O —

Function

Default setting Customized setting

Operating signal (Buzz-
ers)

Off

O — O

1 to 7

Operation signal (Emer-
gency flashers)

Off

O — O

Function

Default setting Customized setting

374

8-2. Customization

: This setting changes in accordance with My Settings.

■

Smart key system (



P.89, 96)

: This setting changes in accordance with My Settings.

■

Wireless remote control (



P.87, 89, 93)

Time elapsed before
automatic door lock
function is activated if
door is not opened after
being unlocked

60 seconds

Off

O — O

30 seconds

120 seconds

Open door warning
buzzer

Off

— — O

Function

Default setting Customized setting

Smart key system

Off

— — O

Smart door unlocking

Driver’s door

All the doors

O — O

Time elapsed before
unlocking all the door
when gripping and hold-
ing the driver’s door
handle

2.0 seconds

Off

— — O

1.5 seconds

2.5 seconds

Number of consecutive
door lock operations

2 times

As many as

desired

— — O

Function

Default setting Customized setting

Wireless remote control

Off

— — O

Unlocking operation

Driver’s door

unlocked in

one step, all

doors

unlocked in

two step

All doors unlocked

in one step

O — O

Theft deterrent panic
mode

Off

— — O

Locking operation when
door opened

Off

O — O

Function

Default setting Customized setting

375

8-2. Customization

Vehicle

specificatio

: This setting changes in accordance with My Settings.

■

Power windows (



P.111)

■

Engine switch (



P.127)

■

Automatic light control system (



P.136)

: This setting changes in accordance with My Settings.

■

Lights (



P.136)

:This setting changes in accordance with My Settings.

:If equipped

Function

Default setting Customized setting

Mechanical key linked
operation

Off

— — O

Wireless remote control
linked operation

Off

On (open only)

— — O

Wireless remote control
linked operation signal
(buzzer)

Off

— — O

Function

Customized setting

ACC customization
Enabling/Disabling ACC
mode

On/Off

O — O

Function

Default setting Customized setting

Light sensor sensitivity

Standard

-2 to 2

O — O

Time elapsed before
headlights automatically
turn off after doors are
closed

30 seconds

Off

O — O

60 seconds

90 seconds

Windshield wiper linked
headlight illumination

Off

— — O

Function

Default setting Customized setting

Daytime running light
system

*1, 2

Off

O — O

376

8-2. Customization

■

PCS (Pre-Collision System) (



P.155)

:The system is automatically enabled each time the engine switch is

turned to ON.

:This setting changes in accordance with My Settings.

■

LDA (Lane Departure Alert system) (



P.170)

: This setting changes in accordance with My Settings.

■

Dynamic radar cruise control (



P.177)

: This setting changes in accordance with My Settings.

■

RSA (Road Sign Assist)

(



P.175)

Function

Customized setting

Pre-Collision System

On, Off

— O —

Warning timing

Later, Default, Earlier

— O —

Function

Customized setting

Lane Departure Alert
system

On, Off

— O —

Alert timing

Default, Earlier

— O —

Alert options

Vibration, Beep

— O —

Function

Default setting

Acceleration setting

High, Mid, Low

— O —

Guide message

On, Off

— O —

Curve speed reduction

High, Mid, Low, Off

— O —

Function

Default setting

Road Sign Assist

On, Off

— O —

Excess speed notifica-
tion method

None, Visual, Visual&Audible

— O —

377

8-2. Customization

Vehicle

specificatio

:If equipped

:This setting changes in accordance with My Settings.

■

Driver break suggestion (



P.170)

■

BSM (Blind Spot Monitor)

(



P.187)

: If equipped

■

RCTA (Rear Cross Traffic Alert) function

(



P.192)

: If equipped

Other notifications
method

None, Visual, Visual&Audible

— O —

Excess speed notifica-
tion level

5 mph (10 km/h), 3 mph (5 km/h), 1

mph (2 km/h)

— O —

Function

Default setting

Driver break suggestion

On, Off

— O —

Function

Default setting Customized setting

BSM (Blind Spot Moni-
tor)

Off

— O —

Outside rear view mirror
indicator brightness

Bright

Dim

— O —

Alert timing for pres-
ence of approaching
vehicle (sensitivity)

Intermediate

Early

— O —

Late

Function

Default setting Customized setting

RCTA (Rear cross traf-
fic alert)

Off

— O —

Buzzer volume of RCTA
when operating

Level2

Level1

— O —

Level3

Function

Default setting

378

8-2. Customization

■

Safe Exit Assist

(



P.198)

: If equipped

■

Driving mode select switch (



P.202)

■

Automatic air conditioning system (



P.214)

: This setting changes in accordance with My Settings.

Function

Default setting Customized setting

Safe Exit Assist

Off

— O —

Outside rear view mir-
rors display

Off

— O —

Detection sensitivity

Middle

High

— O —

Low

Function

Default setting Customized setting

Powertrain control in
custom mode

Normal

Sport

O — —

Eco

Chassis control in cus-
tom mode

Normal

Sport

O — —

Air conditioning operat-
ing in custom mode

Normal

Eco

O — —

Function

Default setting Customized setting

Switching between out-
side air and recirculated
air mode linked to auto-
matic mode switch oper-
ation

Off

O — O

A/C auto switch opera-
tion

Off

O — O

379

8-2. Customization

Vehicle

specificatio

■

Illumination (



P.223)

: This setting changes in accordance with My Settings.

■

Vehicle customization

●

When the smart key system is off,

Smart door unlocking cannot be

customized.

●

When the doors remain closed

after unlocking the doors and the

automatic door lock function is

activated, the signals will be gen-

erated in accordance with the

operation signal (buzzer) and the

operation signal (emergency

flashers) settings.

■

In the following situations, cus-

tomize mode in which the set-

tings can be changed through

the multi-information display

will automatically be turned off

●

A warning message appears after

the customize mode screen is dis-

played

●

The engine switch is turned off.

●

The vehicle begins to move while

the customize mode screen is dis-

played.

Function

Default setting Customized setting

Time elapsed before the
interior lights turn off

15 seconds

Off

O — O

7.5 seconds

30 seconds

Operation after the
engine switch is turned
off

Off

— — O

Operation when the
doors are unlocked

Off

— — O

Operation when you
approach the vehicle
with the electronic key
on your person

Off

— — O

380

8-3. Initialization

8-3.Initialization

Items to initialize

The following items must be initialized for normal system
operation after such cases as the battery being reconnected,
or maintenance being performed on the vehicle:

List of items to initialize

Item

When to initialize

Reference

Tire pressure warn-
ing system

• When rotating front and rear

tires which have different tire
inflation pressures.

• When changing the tire size.
• When the tire inflation pressure

is changed such as when
changing traveling speed or load
weight.

• When changing between two

registered wheel sets.

P.282

381

For ow

ner
s

For owners

9-1. For owners

Reporting safety defects for

U.S. owners...............

382

Reporting safety defects for

Canadian owners ......

382

Seat belt instructions for

Canadian owners (in
French)......................

383

SRS airbag instructions for

Canadian owners (in
French)......................

384

382

9-1. For owners

9-1.For owners

Reporting safety

defects for U.S. own-

ers

If you believe that your vehicle
has a defect which could
cause a crash or could cause
injury or death, you should
immediately inform the
National Highway Traffic
Safety Administration
(NHTSA) in addition to notify-
ing Toyota Motor Sales,
U.S.A., Inc. (Toll-free:
1-800-331-4331).

If NHTSA receives similar
complaints, it may open an
investigation, and if it finds
that a safety defect exists in a
group of vehicles, it may order
a recall and remedy cam-
paign. However, NHTSA can-
not become involved in
individual problems between
you, your dealer, or Toyota
Motor Sales, U.S.A., Inc.

To contact NHTSA, you may
call the Vehicle Safety Hotline
toll-free at 1-888-327-4236
(TTY: 1-800-424-9153); go to

http://www.safercar.gov

; or

write to: Administrator,
NHTSA, 1200 New Jersey
Ave. SE., Washington, DC
20590. You can also obtain
other information about motor
vehicle safety from

http://www.safercar.gov

Reporting safety

defects for Canadian

owners

Canadian customers who
wish to report a safety-related
defect to Transport Canada,
Defects Investigations and
Recalls, may telephone the
toll-free hotline
1-800-333-0510, mail Trans-
port Canada - ASFAD, 330
Sparks Street, Ottawa, ON,
K1A 0N5, or complete the
online form at
https://www.tc.gc.ca/recalls.

383

9-1. For owners

For ow

ner
s



Déroulez la sangle diagonale
de telle sorte qu'elle passe
bien sur l'épaule, sans pour
autant être en contact avec le
cou ou glisser de l'épaule.



Placez la sangle abdominale
le plus bas possible sur les
hanches.



Réglez la position du dossier
de siège. Asseyez-vous le
dos droit et calez-vous bien
dans le siège.



Ne vrillez pas la ceinture de

sécurité.

■

Traitement des ceintures de
sécurité

Nettoyez avec un chiffon ou une
éponge humidifiés avec de l'eau
savonneuse tiède. Vérifiez
régulièrement que les ceintures
ne sont pas usées, effilochées
ou entaillées excessivement.

Seat belt instructions

for Canadian owners

(in French)

The following is a French
explanation of seat belt
instructions extracted from
the seat belt section in this
manual.

See the seat belt section for
more detailed seat belt
instructions in English.

Utilisation correcte des
ceintures de sécurité

Entretien et soin

AVERTISSEMENT

■

Détérioration et usure des

ceintures de sécurité

Inspectez le système de ceintures

de sécurité régulièrement. Con-

trôlez l'absence de coupures,

d'effilochages et de pièces

desserrées. N'utilisez pas une

ceinture de sécurité endommagée

avant qu'elle ne soit remplacée.

Une ceinture de sécurité endom-

magée ne permet pas de protéger

un occupant de blessures graves

ou mortelles.

384

9-1. For owners

■

Emplacement des coussins gonflables SRS



Coussins gonflables frontaux SRS

Coussin gonflable conducteur/coussin gonflable du passager
avant SRS

Participe à la protection de la tête et du thorax du conducteur et du pas-
sager avant contre les chocs contre les éléments de l'habitacle

Coussin gonflable de genoux SRS

Participe à la protection du conducteur

Coussin gonflable de coussin de siège SRS

Contribue à retenir le passager avant

SRS airbag instructions for Canadian owners (in

French)

The following is a French explanation of SRS airbag instruc-
tions extracted from the SRS airbag section in this manual.

See the SRS airbag section for more detailed SRS airbag instruc-
tions in English.

Système de coussins gonflables SRS

Toyota GR Corolla (2023 year). Manual in english - page 23
