Toyota GR Corolla (2023 year). Manual in english

321

7-2. Steps to take in an emergency

Whe

n tr

ouble

ises

■

Dynamic radar cruise control indicator (warning buzzer)

■

Cruise control indicator (warning buzzer)

■

Driving assist information indicator

: If equipped

■

Slip indicator

Warning light

Details/Actions

(Orange)

Indicates a malfunction in the dynamic radar cruise control.



Follow the instructions displayed on the multi-infor-
mation display. (



P.325)

Warning light

Details/Actions

(Orange)

Indicates a malfunction in the cruise control.



Follow the instructions displayed on the multi-infor-
mation display. (



P.325)

Warning light

Details/Actions

Indicates either of the following systems may be malfunc-
tioning.



PCS (Pre-Collision System)



LDA (Lane Departure Alert)

Indicates one of the following systems is malfunctioning or
disabled.



BSM (Blind Spot Monitor)



RCTA(Rear cross traffic alert)



SEA (Safe Exit Assist)



Follow the instructions displayed on the multi-infor-
mation display. (



P.325)

Warning light

Details/Actions

Indicates a malfunction in:



The VSC system;



The TRAC system; or



The hill-start assist control system



Have the vehicle inspected by your Toyota dealer
immediately.

322

7-2. Steps to take in an emergency

■

iMT indicator

■

Warning buzzer

In some cases, the buzzer may not

be heard due to being in a noisy

location or audio sound.

■

Front passenger detection sen-

sor, seat belt reminder and

warning buzzer

●

If luggage is placed on the front

passenger seat, the front passen-

ger detection sensor may cause

the warning light to flash and the

warning buzzer to sound even if a

passenger is not sitting in the

seat.

●

If a cushion is placed on the seat,

the sensor may not detect a pas-

senger, and the warning light may

not operate properly.

■

SRS warning light

This warning light system monitors

the airbag sensor assembly, front

impact sensors, side impact sensors

(front door), side impact sensors

(front), driver’s seat position sensor,

driver’s seat belt buckle switch, front

passenger’s seat belt buckle switch,

“AIR BAG ON” indicator light, “AIR

BAG OFF” indicator light, seat belt

pretensioners, airbags, intercon-

necting wiring and power sources.

(



P.31)

■

If the malfunction indicator

lamp comes on while driving

First check the following:

●

Is the fuel tank empty?

If it is, fill the fuel tank immediately.

●

Is the fuel tank cap loose?

If it is, tighten it securely.

The light will go off after several

driving trips.

If the light does not go off even after

several trips, contact your Toyota

dealer as soon as possible.

■

Electric power steering system

warning light (warning buzzer)

When the battery charge becomes

insufficient or the voltage temporar-

ily drops, the electric power steering

system warning light may come on

and the warning buzzer may sound.

■

When the tire pressure warning

light comes on

Inspect the tires to check if a tire is

punctured.
If a tire is punctured:



P.329

If none of the tires are punctured:

Turn the engine switch off then turn

it to ON. Check if the tire pressure

warning light comes on or blinks.



If the tire pressure warning light

blinks for approximately 1 minute

then stays on

There may be a malfunction in the

tire pressure warning system. Have

the vehicle inspected by your Toyota

dealer immediately.



If the tire pressure warning light

comes on

After the temperature of the tires

has lowered sufficiently, check

the inflation pressure of each tire

and adjust them to the specified

level.

If the warning light does not turn

off even after several minutes

have elapsed, check that the

inflation pressure of each tire is

at the specified level and perform

initialization. (



P.283)

Warning light

Details/Actions

(Orange)

Indicates a malfunction in the iMT



Have the vehicle inspected by your Toyota dealer
immediately.

323

7-2. Steps to take in an emergency

tro

■

The tire pressure warning light

may come on due to natural

causes

The tire pressure warning light may

come on due to natural causes such

as natural air leaks and tire inflation

pressure changes caused by tem-

perature. In this case, adjusting the

tire inflation pressure will turn off the

warning light (after a few minutes).

■

Conditions that the tire pres-

sure warning system may not

function properly



P.280

WARNING

■

If both the ABS and the brake

system warning lights remain

Stop your vehicle in a safe place

immediately and contact your Toy-

ota dealer.

The vehicle will become

extremely unstable during brak-

ing, and the ABS system may fail,

which could cause an accident

resulting in death or serious injury.

■

When the electric power

steering system warning light

comes on

When the light comes on yellow,

the assist to the power steering is

restricted. When the light comes

on red, the assist to the power

steering is lost and handling oper-

ations of the steering wheel

become extremely heavy.

When steering wheel operations

are heavier than usual, grip the

steering wheel firmly and operate

it using more force than usual.

■

If the tire pressure warning

light comes on

Be sure to observe the following

precautions.

Failure to do so could cause a

loss of vehicle control and result

in death or serious injury.

●

Stop your vehicle in a safe place

as soon as possible. Adjust the

tire inflation pressure immedi-

ately.

●

If the tire pressure warning light

comes on even after tire infla-

tion pressure adjustment, it is

probable that you have a flat

tire. Check the tires. If a tire is

flat, repair the flat tire by using

emergency tire puncture repair

kit.

●

Avoid abrupt maneuvering and

braking.

If the vehicle tires deteriorate,

you could lose control of the

steering wheel or the brakes.

■

If a blowout or sudden air

leakage should occur

The tire pressure warning system

may not activate immediately.

■

Maintenance of the tires

Each tire, including the spare (if

provided), should be checked

monthly when cold and inflated to

the inflation pressure recom-

mended by the vehicle manufac-

turer on the vehicle placard or tire

inflation pressure label (tire and

load information label). (If your

vehicle has tires of a different size

than the size indicated on the

vehicle placard or tire inflation

pressure label [tire and load infor-

mation label], you should deter-

mine the proper tire inflation

pressure for those tires.)

324

7-2. Steps to take in an emergency

WARNING

As an added safety feature, your

vehicle has been equipped with a

tire pressure monitoring system

(TPMS-tire pressure warning sys-

tem) that illuminates a low tire

pressure telltale (tire pressure

warning light) when one or more

of your tires is significantly

under-inflated. Accordingly, when

the low tire pressure telltale (tire

pressure warning light) illumi-

nates, you should stop and check

your tires as soon as possible,

and inflate them to the proper

pressure. Driving on a signifi-

cantly under-inflated tire causes

the tire to overheat and can lead

to tire failure. Under-inflation also

reduces fuel efficiency and tire

tread life, and may affect the vehi-

cle’s handling and stopping ability.

Please note that the TPMS (tire

pressure warning system) is not a

substitute for proper tire mainte-

nance, and it is the driver’s

responsibility to maintain correct

tire pressure, even if under-infla-

tion has not reached the level to

trigger illumination of the TPMS

low tire pressure telltale (tire pres-

sure warning light).

Your vehicle has also been

equipped with a TPMS (tire pres-

sure warning system) malfunc-

tion indicator to indicate when the

system is not operating properly.

The TPMS (tire pressure warning

system) malfunction indicator is

combined with the low tire pres-

sure telltale (tire pressure warning

light). When the system detects a

malfunction, the telltale will flash

for approximately one minute and

then remain continuously illumi-

nated. This sequence will con-

tinue upon subsequent vehicle

start-ups as long as the malfunc-

tion exists. When the malfunction

indicator is illuminated, the sys-

tem may not be able to detect or

signal low tire pressure as

intended.

TPMS (tire pressure warning sys-

tem) malfunctions may occur for a

variety of reasons, including the

installation of replacement or

alternate tires or wheels on the

vehicle that prevent the TPMS

(tire pressure warning system)

from functioning properly. Always

check the TPMS (tire pressure

warning system) malfunction tell-

tale after replacing one or more

tires or wheels on your vehicle to

ensure that the replacement or

alternate tires and wheels allow

the TPMS (tire pressure warning

system) to continue to function

properly.

NOTICE

■

To ensure the tire pressure

warning system operates

properly

Do not install tires with different

specifications or makers, as the

tire pressure warning system may

not operate properly.

325

7-2. Steps to take in an emergency

Whe

n tr

ouble

ises

■

Warning messages

The warning messages explained

below may differ from the actual

messages according to operation

conditions and vehicle specifica-

tions.

■

Warning buzzer

A buzzer may sound when a mes-

sage is displayed.

The buzzer may not be audible if the

vehicle is in a noisy location or if the

audio system volume is high.

■

If “Engine Stopped Steering

Power Low” is displayed

This message is displayed if the

engine is stopped while driving.

When steering wheel operations are

heavier than usual, grip the steering

wheel firmly and operate it using

more force than usual.

■

If “Auto Power OFF to Conserve

Battery” is displayed

Power was cut off due to the auto-

matic power off function. Next time

when starting the engine, increase

the engine speed slightly and main-

tain that level for approximately 5

minutes to recharge the battery.

■

If “Headlight System Malfunc-

tion Visit Your Dealer” is dis-

played

The following systems may be mal-

functioning. Have the vehicle

inspected by your Toyota dealer

immediately.

●

The LED headlight system

●

Automatic High Beam

■

If “AWD System Malfunction

2WD Mode Engaged Visit Your

Dealer” or “AWD System Over-

heated Switching to 2WD

Mode” is displayed

This message may be displayed

when driving under extremely high

load conditions.
Drive the vehicle at low speeds and

stop the vehicle in a safe place until

the message is cleared.
If the message is not cleared, have

the vehicle inspected by your Toyota

dealer.

■

If “System Malfunction Visit

Your Dealer” is displayed

Indicates one of the following sys-

tems is disabled.

●

PCS (Pre-Collision System)

●

LDA (Lane Departure Alert)

●

LTA (Lane Tracing Assist)

●

AHB (Automatic High Beam)

●

Dynamic radar cruise control

●

RSA (Road Sign Assist) (if

equipped)

If a warning message

is displayed

The multi-information dis-
play shows warnings for
system malfunctions and
incorrectly performed oper-
ations, and messages that
indicate a need for mainte-
nance. When a message is
displayed, perform the
appropriate corrective
action for the message.
If a warning message is dis-
played again after the
appropriate actions have
been performed, contact
your Toyota dealer.
Additionally, if a warning
light comes on or flashes at
the same time that a warn-
ing message is displayed,
take the appropriate correc-
tive action for the warning
light. (



P.316)

326

7-2. Steps to take in an emergency

●

BSM (Blind Spot Monitor) (if

equipped)

●

RCTA (Rear Cross Traffic

Alert) (if equipped)

●

SEA (Safe Exit Assist) (if

equipped)

Have the vehicle inspected by your
Toyota dealer immediately.

■

If “System Stopped See

Owner’s Manual” is displayed

Indicates one of the following sys-

tems is disabled.

●

PCS (Pre-Collision System)

●

LDA (Lane Departure Alert)

●

LTA (Lane Tracing Assist)

●

AHB (Automatic High Beam)

●

Dynamic radar cruise control

●

RSA (Road Sign Assist) (if

equipped)

●

BSM (Blind Spot Monitor) (if

equipped)

●

RCTA (Rear Cross Traffic

Alert) (if equipped)

●

SEA (Safe Exit Assist) (if

equipped)

Follow the following correction
methods.
• Check the voltage of the battery
• Check the sensors that the Toyota

Safety Sense 3.0 uses for foreign

matter covering them. Remove

them if any. (



P.150)

Indicates the sensors may not be

operating properly. (



P.153, 191,

195, 201)
• When problems are solved and

the sensors are operational, this

indication may disappear by itself.

■

If “System Stopped Front Cam-

era Low Visibility See Owner’s

Manual” is displayed

Indicates one of the following sys-

tems is disabled.

●

PCS (Pre-Collision System)

●

LDA (Lane Departure Alert)

●

LTA (Lane Tracing Assist)

●

AHB (Automatic High Beam)

●

Dynamic radar cruise control

●

RSA (Road Sign Assist) (if

equipped)

Follow the following correction
methods.
• Using the windshield wipers,

remove the dirt or foreign matter

from the windshield.

• Using the air conditioning system,

defog the windshield.

• Close the hood, remove any stick-

ers, etc. to clear the obstruction in

front of the front camera.

■

If “System Stopped Front Cam-

era Out of Temperature Range

Wait until Normal Temperature”

is displayed

Indicates one of the following sys-

tems is disabled.

●

PCS (Pre-Collision System)

●

LDA (Lane Departure Alert)

●

LTA (Lane Tracing Assist)

●

AHB (Automatic High Beam)

●

Dynamic radar cruise control

●

RSA (Road Sign Assist) (if

equipped)

Follow the following correction
methods.
• If the front camera is hot, such as

after the vehicle is parked in the

sun, use the air conditioning sys-

tem to decrease the temperature

around the front camera

• If a sunshade was used when the

327

7-2. Steps to take in an emergency

Whe

n tr

ouble

ises

vehicle was parked, depending on

its type, the sunlight reflected from

the surface of the sunshade may

cause the temperature of the front

camera to become excessively

high

• If the front camera is cold, such

after the vehicle is parked in an

extremely cold environment, use

the air conditioning system to

increase the temperature around

the front camera

■

If “System Stopped Front Radar

Sensor Blocked Clean Radar

Sensor” is displayed

Indicates one of the following sys-

tems is disabled.

●

PCS (Pre-Collision System)

●

LDA (Lane Departure Alert)

●

LTA (Lane Tracing Assist)

●

AHB (Automatic High Beam)

●

Dynamic radar cruise control

Follow the following correction
methods.
• Check if there is any foreign mat-

ter attached to the radar sensor or

radar sensor cover and clean

them if necessary (



P.150)

• This message may be displayed

when driving in an open area with

few nearby vehicles or structures,

such as a desert, grasslands, sub-

urbs, etc. The message may be

cleared by driving the vehicle in an

area with structures, vehicles, etc.

nearby.

■

If “System Stopped Front Radar

Sensor Out of Temperature

Range Wait until Normal Tem-

perature” is displayed

Indicates one of the following sys-

tems is disabled.

●

PCS (Pre-Collision System)

●

LDA (Lane Departure Alert)

●

LTA (Lane Tracing Assist)

●

AHB (Automatic High Beam)

●

Dynamic radar cruise control

Follow the following correction
methods.
The temperature of the radar sensor

is outside of the operating range.

Wait for the temperature to become

appropriate.

■

If “System Stopped Front Radar

In Self Calibration See Owner’s

Manual” is displayed

Indicates one of the following sys-

tems is disabled.

●

PCS (Pre-Collision System)

●

LDA (Lane Departure Alert)

●

LTA (Lane Tracing Assist)

●

AHB (Automatic High Beam)

●

Dynamic radar cruise control

Follow the following correction
methods.
• Check if there is any foreign mat-

ter attached to the radar sensor or

radar sensor cover and clean

them if necessary (



P.150)

• The radar sensor may be mis-

aligned and will be adjusted auto-

matically while driving. Continue

driving for a while.

■

If “Cruise Control Unavailable

See Owner’s Manual” is dis-

played

Indicates one of the following sys-

tems is disabled.

●

Dynamic radar cruise control

●

Cruise control

A message is displayed when the
driving assist switch is pushed
repeatedly.
Press the driving assist switch
quickly and firmly.

■

If “Maintenance Required

Soon” is displayed

Indicates that all maintenance

according to the driven distance on
the maintenance schedule

should

328

7-2. Steps to take in an emergency

be performed soon.
Comes on approximately 4500

miles (7200 km) after the message

has been reset. If necessary, per-

form maintenance. Please reset the

message after the maintenance is

performed. (



P.259)

: Refer to the separate “Scheduled

Maintenance” or “Owner’s Man-
ual Supplement” for the mainte-
nance interval applicable to your
vehicle.

■

If “Maintenance Required Visit

Your Dealer” is displayed

Indicates that all maintenance is

required to correspond to the driven

distance on the maintenance sched-
ule

Comes on approximately 5000

miles (8000 km) after the message

has been reset. (The indicator will

not work properly unless the mes-

sage has been reset.) Perform the

necessary maintenance. Please

reset the message after the mainte-

nance is performed. (



P.259)

: Refer to the separate “Scheduled

Maintenance” or “Owner’s Man-
ual Supplement” for the mainte-
nance interval applicable to your
vehicle.

■

If “Engine Maintenance

Required Visit Your Dealer” is

shown

The engine or an engine component

is malfunctioning. Have the vehicle

inspected by your Toyota dealer

immediately.

■

If a message that indicates the

need for visiting your Toyota

dealer is displayed

The system or part shown on the

multi-information display is malfunc-

tioning. Have the vehicle inspected

by your Toyota dealer immediately.

■

If a message that indicates the

need for referring to Owner’s

Manual is displayed

●

If “Engine Coolant Temp High

Stop in a Safe Place See Owner's

Manual” is displayed, follow the

instructions accordingly. (



P.348)

●

If any of the following messages

are displayed on the multi-infor-

mation display, it may indicate a

malfunction. Have the vehicle

inspected by your Toyota dealer

immediately.

• “Smart Key System malfunction

See owner's manual”

●

If any of the following messages

are displayed on the multi-infor-

mation display, it may indicate a

malfunction. Immediately stop the

vehicle and contact your Toyota

dealer.

• “Braking Power Low Stop in a

Safe Place See Owner's Manual”

• “12-Volt Battery Charging System

Malfunction Stop in a Safe Place

See Owner's Manual”

• “Oil pressure low Stop in a safe

place See owner's manual”

329

7-2. Steps to take in an emergency

tro



Stop the vehicle in a safe
place on a hard, flat surface.



Set the parking brake.



Shift the shift lever to R.



Stop the engine.



Turn on the emergency flash-
ers. (



P.308)



Check the degree of the tire
damage.

A tire should only be repaired
with the emergency tire punc-
ture repair kit if the damage is
caused by a nail or screw pass-
ing through the tire tread.
• Do not remove the nail or

screw from the tire. Removing
the object may widen the
opening and make emer-
gency repair with the repair kit
impossible.

• To avoid sealant leakage,

move the vehicle until the
area of the puncture, if
known, is positioned at the
top of the tire.

If you have a flat tire

Your vehicle is not equipped
with a spare tire, but instead
is equipped with an emer-
gency tire puncture repair
kit.

A puncture caused by a nail
or screw passing through
the tire tread can be
repaired temporarily using
the emergency tire puncture
repair kit. (The kit contains a
bottle of sealant. The seal-
ant can be used only once
to temporarily repair one
tire without removing the
nail or screw from the tire.)
Depending on the damage,
this kit cannot be used to
repair the tire. (



P.329)

After temporarily repairing
the tire with the kit, have the
tire repaired or replaced by
your Toyota dealer. Repairs
conducted using the emer-
gency tire puncture repair
kit are only a temporary
measure. Have the tire
repaired and replaced as
soon as possible.

WARNING

■

If you have a flat tire

Do not continue driving with a flat

tire.

Driving even a short distance with

a flat tire can damage the tire and

the wheel beyond repair, which

could result in an accident.

Before repairing the tire

330

7-2. Steps to take in an emergency

■

A flat tire that cannot be

repaired with the emergency

tire puncture repair kit

In the following cases, the tire can-

not be repaired with the emergency

tire puncture repair kit. Contact your

Toyota dealer.

●

When the tire is damaged due to

driving without sufficient air pres-

sure

●

When there are any cracks or

damage at any location on the

tire, such as on the side wall,

except the tread

●

When the tire is visibly separated

from the wheel

●

When the cut or damage to the

tread is 0.16 in. (4 mm) long or

●

When the wheel is damaged

●

When two or more tires have been

punctured

●

When more than 2 sharp objects

such as nails or screws have

passed through the tread on a sin-

gle tire

●

When the sealant has expired

Towing eyelet
Emergency tire puncture repair kit



Bottle

Location of the emergency tire puncture repair kit and
tools

Emergency tire puncture
repair kit components

331

7-2. Steps to take in an emergency

tro

Sticker



Compressor

Air pressure gauge
Compressor switch
Power plug
Hose
Air release cap

■

Note for checking the emer-

gency tire puncture repair kit

Check the sealant expiry date occa-

sionally.

The expiry date is shown on the bot-

tle. Do not use sealant whose expiry

date has already passed. Other-

wise, repairs conducted using the

emergency tire puncture repair kit

may not be performed properly.

■

Emergency tire puncture repair

kit

●

The emergency tire puncture

repair kit is for filling the car tire

with air.

●

The sealant has a limited life

span. The expiry date is marked

on the bottle. The sealant should

be replaced before the expiry

date. Contact your Toyota dealer

for replacement.

●

The sealant stored in the emer-

gency tire puncture repair kit can

be used only once to temporarily

repair a single tire. If the sealant in

the bottle and other parts of the kit

have been used and need to be

replaced, contact your Toyota

dealer.

●

The compressor can be used

repeatedly.

●

The sealant can be used when the

outside temperature is from -40°F

(-40°C) to 140°F (60°C).

●

The kit is exclusively designed for

size and type of tires originally

installed on your vehicle. Do not

use it for tires that a different size

than the original ones, or for any

other purposes.

●

If the sealant gets on your clothes,

it may stain.

●

If the sealant adheres to a wheel

or the surface of the vehicle body,

the stain may not be removable if

it is not cleaned at once. Immedi-

ately wipe away the sealant with a

wet cloth.

●

During operation of the repair kit,

a loud operation noise is pro-

duced. This does not indicate a

malfunction.

●

Do not use to check or to adjust

the tire pressure.

WARNING

■

Caution while driving

●

Store the repair kit in the lug-

gage compartment.

Injuries may result in the event

of an accident or sudden brak-

ing.

332

7-2. Steps to take in an emergency

Remove the deck mat.

Take out the emergency tire
puncture repair kit.

Take out the repair kit from
the plastic bag.

Attach the sticker enclosed with the

bottle on the specified locations.

(See step

Pull out the hose and power
plug from the bottom side of
the compressor.

Connect the bottle to the
compressor.

Make sure to press the bottle until

its claws are securely engaged to

the compressor and no longer visi-

WARNING

●

The repair kit is exclusively only

for your vehicle.

Do not use repair kit on other

vehicles, which could lead to an

accident causing death or seri-

ous injury.

●

Do not use repair kit for tires

that are different size than the

original ones, or for any other

purpose. If the tires have not

been completely repaired, it

could lead to an accident caus-

ing death or serious injury.

■

Precautions for use of the

sealant

●

Ingesting the sealant is hazard-

ous to your health. If you ingest

sealant, consume as much

water as possible, and then

immediately consult a doctor.

●

If sealant gets in eyes or

adheres to skin, immediately

wash it off with water. If discom-

fort persists, consult a doctor.

Taking out the emer-
gency tire puncture repair
kit

Emergency repair method

333

7-2. Steps to take in an emergency

Whe

n tr

ouble

ises

ble.

Connect the hose to the bot-
tle.

Make sure to insert the hose until

its claw is securely engaged to the

bottle.

Remove the valve cap from
the valve of the punctured
tire.

Extend the hose. Remove
the air release cap from the
hose.

You will use the air release cap

again. Therefore keep it in a safe

place.

Connect the hose to the
valve.

Screw the end of the hose clock-

wise as far as possible.

334

7-2. Steps to take in an emergency

Make sure that the compres-
sor switch is off.

Connect the power plug to
the power outlet socket.
(



P.230)

Attach the sticker provided

with the tire puncture repair
kit to a position easily seen
from the driver’s seat.

Check the specified tire infla-

tion pressure.

Tire inflation pressure is specified

on the label on the driver’s side pil-

lar as shown. (

Start the engine. (

To inject the sealant and

inflate the tire, turn the com-
pressor switch on.

335

7-2. Steps to take in an emergency

Whe

n tr

ouble

ises

Inflate the tire until the speci-

fied air pressure is reached.

The sealant will be injected
and the pressure will spike to
between 44 psi (300 kPa, 3.0
kgf/cm

or bar) and 58 psi

(400 kPa, 4.0 kgf/cm

or bar),

then gradually decrease.
The air pressure gauge will
display the actual tire inflation
pressure about 1 to 5 min-
utes after the switch is turned
on.

Turn the compressor switch off and

then check the tire inflation pres-

sure. Being careful not to over

inflate, check and repeat the infla-

tion procedure until the specified

tire inflation pressure is reached.
The tire can be inflated for about 5

to 20 minutes (depending on the

outside temperature). If the tire

inflation pressure is still lower than

the specified point after inflation for

25 minutes, the tire is too damaged

to be repaired. Turn the compres-

sor switch off and contact your Toy-

ota dealer.
If the tire inflation pressure exceeds

the specified air pressure, let out

some air to adjust the tire inflation

pressure. (



P.337, 358)

With the compressor switch

off, disconnect the hose from
the valve on the tire and then
pull out the power plug from
the power outlet socket.

Some sealant may leak when the

hose is removed.

Install the valve cap onto the

valve of the emergency
repaired tire.

Attach the air release cap to

the end of the hose.

If the air release cap is not

attached, the sealant may leak and

the vehicle may get dirty.

Temporarily store the bottle

in the luggage compartment
while it is connected to the
compressor.

To spread the liquid sealant

evenly within the tire, imme-
diately drive safely for about
3 miles (5 km) below 50 mph
(80 km/h).

336

7-2. Steps to take in an emergency

After driving, stop your vehi-

cle in a safe place on a hard,
flat surface and reconnect
the repair kit.

Remove the air release cap from

the hose before reconnecting the

hose.

Turn the compressor switch

on and wait for several sec-
onds, then turn it off. Check
the tire inflation pressure.

If the tire inflation pressure is
under 19 psi (130 kPa, 1.3
kgf/cm

or bar): The puncture

cannot be repaired. Contact
your Toyota dealer.
If the tire inflation pressure is
19 psi (130 kPa, 1.3
kgf/cm

or bar) or higher, but

less than the specified air
pressure: Proceed to step

If the tire inflation pressure is
the specified air pressure
(



P.358): Proceed to step

Turn the compressor switch

on to inflate the tire until the
specified air pressure is
reached. Drive for about 3
miles (5 km) and then per-
form step

Attach the air release cap to

the end of the hose.

If the air release cap is not

attached, the sealant may leak and

the vehicle may get dirty.

Store the bottle in the lug-

gage compartment while it is
connected to the compres-
sor.

Taking precautions to avoid

sudden braking, sudden
acceleration and sharp turns,
drive carefully at under 50
mph (80 km/h) to the nearest
Toyota dealer that is less
than 62 miles (100 km) away
for tire repair or replacement.

When having the tire repaired or

replaced, make sure to tell the Toy-

ota dealer that the sealant is

injected.

Toyota GR Corolla (2023 year). Manual in english - page 20
