259

3-2. Opening, closing and locking the doors

3

O

p

er

ati

on
of e
ac

h c
o

m

pon
ent

WARNING

■

Caution regarding interference with electronic devices

●

People  with  implantable  cardiac  pacemakers,  cardiac  resynchronization
therapy-pacemakers or implantable cardioverter defibrillators should main-
tain  a  reasonable  distance  between  themselves  and  the  smart  entry  &
start system antennas. (



P. 205)

The radio waves may affect the operation of such devices. If necessary,
the entry function can be disabled. Ask any authorized Toyota retailer or
Toyota authorized repairer, or any reliable repairer for details, such as the
frequency  of  radio  waves  and  timing  of  the  emitted  radio  waves.  Then,
consult your doctor to see if you should disable the entry function.

●

Users  of  any  electrical  medical  device  other  than  implantable  cardiac
pacemakers,  cardiac  resynchronization  therapy-pacemakers  or  implant-
able  cardioverter  defibrillators  should  consult  the  manufacturer  of  the
device  for  information  about  its  operation  under  the  influence  of  radio
waves.
Radio  waves  could  have  unexpected  effects  on  the  operation  of  such
medical devices.

Ask any authorized Toyota retailer or Toyota authorized repairer, or any reli-
able repairer for details on disabling the entry function.

260

3-3. Adjusting the seats

Front seats



Manual seat

Seat position adjustment lever
Seatback  angle  adjustment
lever
Vertical height adjustment lever
(if equipped)
Lumbar  support  adjustment
switch (if equipped)



Power seat (driver’s side only)

Seat position adjustment switch
Seatback  angle  adjustment
switch
Seat  cushion  (front)  angle
adjustment switch
Vertical

height

adjustment

switch
Lumbar  support  adjustment
switch

Adjustment procedure

261

3-3. Adjusting the seats

3

O

p

er

ati

on
of e
ac

h c
o

m

pon
ent

WARNING

■

When adjusting the seat position

●

Take care when adjusting the seat position to ensure that other passen-
gers are not injured by the moving seat.

●

Do not put your hands under the seat or near the moving parts to avoid
injury.
Fingers or hands may become jammed in the seat mechanism.

●

Make sure to leave enough space around the feet so they do not get stuck.

■

Seat adjustment

●

Be careful that the seat does not hit passengers or luggage.

●

To  reduce the  risk  of sliding under  the  lap  belt during  a  collision,  do not
recline the seat more than necessary.
If the seat is too reclined, the lap belt may slide past the hips and apply
restraint  forces  directly  to  the  abdomen,  or  your  neck  may  contact  the
shoulder belt, increasing the risk of death or serious injury in the event of
an accident.
Adjustments should not be made while driving as the seat may unexpect-
edly move and cause the driver to lose control of the vehicle.

●

Manual  seat  only:  After  adjusting  the  seat,  make  sure  that  the  seat  is
locked in position.

262

3-3. Adjusting the seats

Rear seats

Park the vehicle in a safe place.

Apply the parking brake firmly and shift the shift lever to P. (



P. 313)

Adjust the position of the front seat and the angle of the seatback.
(



P. 260)

Depending on the position of the front seat, if the seatback is folded back-
ward, it may interfere with the operation of the rear seat.

Lower the head restraint of the rear seat. (



P. 264)

Pull  the  seatback  lock  release
lever and fold the seatback down.

To  avoid  trapping  the  seat  belt
between the seat and the inside of
the  vehicle,  pass  the  seat  belt
inside the seat belt guide and then
return  the  seatback  securely  to
the locked position.

The seatbacks of the rear seats can be folded down.

Before folding down the seatbacks

Folding down the seatbacks

1

2

3

Returning the rear seatbacks

Seat belt

guide

263

3-3. Adjusting the seats

3

O

p

er

ati

on
of e
ac

h c
o

m

pon
ent

WARNING

Observe  the  following  precautions.  Failure  to  do  so  may  result  in  death  or
serious injury.

■

When folding the rear seatbacks down

●

Do not fold the seatbacks down while driving.

●

Stop the vehicle on level ground, set the parking brake and shift the shift
lever to P.

●

Do not allow anyone to sit on a folded seatback or in the luggage compart-
ment while driving.

●

Do not allow children to enter the luggage compartment.

●

Do not allow anyone to sit on the rear center seat if the rear right seat is
folded down, as the seat belt buckle for the rear center seat belt is then
concealed under the folded seat and cannot be used.

●

Be careful not to get your hand caught when folding the rear seatbacks.

●

Adjust  the  position  of  the  front  seats  before  folding  down  the  rear  seat-
backs so that the front seats do not interfere with the rear seatbacks when
folding down the rear seatbacks.

■

After returning the rear seatback to the upright position

●

Make sure that the seatback is securely
locked  in  position  by  lightly  pushing  it
back and forth.
If  the  seatback  is  not  securely  locked,
the  red  marking  will  be  visible  on  the
seatback lock release lever. Make sure
that the red marking is not visible.

●

Check that the seat belts are not twisted
or caught in the seatback.
If the seat belt gets caught between the
seatback’s  securing  hook  and  latch,  it
may damage the seat belt.

264

3-3. Adjusting the seats

Head restraints

Up

Pull the head restraint up.

Down

Push the head restraint down while
pressing the lock release button.

Up

Pull the head restraint up.

Down

Push the head restraint down while
pressing the lock release button.

Head restraints are provided for all seats.

Front seats

Lock release button

Rear seats

Lock release button

265

3-3. Adjusting the seats

3

O

p

er

ati

on
of e
ac

h c
o

m

pon
ent

■

Removing the head restraints

Pull the head restraint up while pressing the lock release button.



Front seats



Rear seats

Lock release button

Lock release button

266

3-3. Adjusting the seats

■

Installing the head restraints

Align the head restraint with the installation holes and push it down to the lock
position.
Press and hold the lock release button when lowering the head restraint.

■

Adjusting the height of the front seat head restraints

■

Adjusting the rear seat head restraints

Always  raise  the  head  restraint  one  level  from  the  stowed  position  when
using.



Front seats



Rear seats

Make  sure  that  the  head  restraints  are
adjusted  so  that  the  center  of  the  head
restraint is closest to the top of your ears.

Lock release button

Lock release button

267

3-3. Adjusting the seats

3

O

p

er

ati

on
of e
ac

h c
o

m

pon
ent

WARNING

■

Head restraint precautions

Observe the following precautions regarding the head restraints. Failure to
do so may result in death or serious injury.

●

Use the head restraints designed for each respective seat.

●

Adjust the head restraints to the correct position at all times.

●

After  adjusting  the  head  restraints,  push  down  on  them  and  make  sure
they are locked in position.

●

Do not drive with the head restraints removed.

268

3-4. Adjusting the steering wheel and mirrors

Steering wheel

Hold  the  steering  wheel  and
push the lever down.

Adjust  to  the  ideal  position  by
moving the steering wheel hori-
zontally and vertically.

After  adjustment,  pull  the  lever  up
to secure the steering wheel.

To  sound  the  horn,  press  on  or
close to the

 mark.

Adjustment procedure

1

2

Horn

269

3-4. Adjusting the steering wheel and mirrors

3

O

p

er

ati

on
of e
ac

h c
o

m

pon
ent

■

After adjusting the steering wheel

Make sure that the steering wheel is securely locked.
The horn may not sound if the steering wheel is not securely locked.

WARNING

■

Caution while driving

Do not adjust the steering wheel while driving.
Doing so may cause the driver to mishandle the vehicle and cause an acci-
dent, resulting in death or serious injury.

■

After adjusting the steering wheel

Make sure that the steering wheel is securely locked.
Otherwise,  the  steering  wheel  may  move  suddenly,  possibly  causing  an
accident, resulting in death or serious injury. Also, the horn may not sound if
the steering wheel is not securely locked.

270

3-4. Adjusting the steering wheel and mirrors

Inside rear view mirror

The height of the rear view mirror can be adjusted to suit your driving
posture.

Adjust the height of the rear view
mirror by moving it up and down.



Manual anti-glare inside rear view mirror

Reflected light from the headlights of vehicles behind can be reduced
by operating the lever.

Normal position
Anti-glare position

The rear view mirror’s position can be adjusted to enable suffi-
cient confirmation of the rear view.

Adjusting the height of rear view mirror

Anti-glare function

271

3-4. Adjusting the steering wheel and mirrors

3

O

p

er

ati

on
of e
ac

h c
o

m

pon
ent



Auto anti-glare inside rear view mirror

Responding  to  the  level  of  brightness  of  the  headlights  of  vehicles
behind, the reflected light is automatically reduced.

Changing  automatic  anti-glare
function mode
On/off

When  the  automatic  anti-glare
function  is in on mode,  the indica-
tor illuminates.
The function will be set to on mode
each  time  the  power  switch  is
turned to ON mode.
Pressing the button turns the func-
tion to off mode. (The indicator also
turns off.)

■

To prevent sensor error (vehicles with an auto anti-glare inside rear view
mirror)

Indicator

To ensure that the sensors operate prop-
erly, do not touch or cover them.

WARNING

Do not adjust the position of the mirror while driving.
Doing  so  may  lead  to  mishandling  of  the  vehicle  and  cause  an  accident,
resulting in death or serious injury.

272

3-4. Adjusting the steering wheel and mirrors

Outside rear view mirrors

To select a mirror to adjust, turn
the switch.

Left
Right

To adjust the mirror, operate the
switch.

Up
Right
Down
Left

Adjustment procedure

1

2

273

3-4. Adjusting the steering wheel and mirrors

3

O

p

er

ati

on
of e
ac

h c
o

m

pon
ent



Manual type

Push the mirror back in the direc-
tion of the rear of the vehicle.



Power type

Folds the mirrors
Extends the mirrors

Putting the outside rear view mirror
folding  switch  in  the  neutral  posi-
tion  sets  the  mirrors  to  automatic
mode.
Automatic mode allows the folding
or  extending  of  the  mirrors  to  be
linked  to  locking/unlocking  of  the
doors.

■

Mirror angle can be adjusted when

The power switch is in ACCESSORY or ON mode.

■

When the mirrors are fogged up

The outside rear view mirrors can be cleared using the mirror defoggers. Turn
on the rear window defogger to turn  on the outside  rear  view mirror  defog-
gers. (



P. 550)

Folding and extending the mirrors

274

3-4. Adjusting the steering wheel and mirrors

■

Using the automatic folding/extending mirror function in cold weather (if
equipped)

When the automatic folding/extending mirror function is used in cold weather,
the  outside  rear  view  mirrors  could  freeze  up  and  automatic  folding  and
extension may not be possible. In this event, remove any ice and snow from
the  outside rear view mirror,  then  operate the  mirror  manually by using  the
mirror fold switch or moving the mirror by hand.

■

Customization

The automatic mirror folding and extending operation can be changed.
(Customizable features:



P. 779)

WARNING

■

Important points while driving

Observe the following precautions while driving.
Failure  to do so may result  in  loss  of control  of the vehicle and cause  an
accident, resulting in death or serious injury.

●

Do not adjust the mirrors while driving.

●

Do not drive with the mirrors folded.

●

Both the driver and passenger side mirrors must be extended and properly
adjusted before driving.

■

When a mirror is moving

To avoid personal injury and mirror malfunction, be careful not to get your
hand caught by the moving mirror.

■

When the mirror defoggers are operating

Do not touch the rear view  mirror  surfaces,  as  they can become very  hot
and burn you.
