370

7-2. Steps to take in an emergency

Tighten down the towing eye-
let securely using a wheel nut
wrench (if equipped) or hard
metal bar.

Securely attach cables or
chains to the towing eyelet.

Take care not to damage the vehi-

cle body.

Enter the vehicle being towed
and start the hybrid system.

If the hybrid system does not start,

turn the power switch to ON.

Shift the shift lever to N and
release the parking brake.
Turn automatic mode off.
(



P.184)

When the shift lever cannot
be shifted:



P.181

■

While towing

If the hybrid system is off, the power

assist for the brakes and steering

will not function, making steering

and braking more difficult.

■

Wheel nut wrench

Vehicle without wheel nut wrench:

Wheel nut wrench can be pur-

chased at your Toyota dealer.
Vehicle with wheel nut wrench:

Wheel nut wrench is installed in

trunk. (



P.399)



Fluid leaks under the vehicle.
(Water dripping from the air
conditioning after use is nor-
mal.)



Flat-looking tires or uneven
tire wear



Engine coolant temperature
gauge needle continually
points higher than normal.



Changes in exhaust sound



Excessive tire squeal when
cornering



Strange noises related to the
suspension system



Pinging or other noises
related to the hybrid system



Engine missing, stumbling or
running roughly



Appreciable loss of power



Vehicle pulls heavily to one

If you think something

is wrong

If you notice any of the fol-
lowing symptoms, your
vehicle probably needs
adjustment or repair. Con-
tact your Toyota dealer as
soon as possible.

Visible symptoms

Audible symptoms

Operational symptoms

371

7-2. Steps to take in an emergency

Whe

n tr

ouble

ises

side when braking



Vehicle pulls heavily to one
side when driving on a level
road



Loss of brake effectiveness,
spongy feeling, pedal almost
touches the floor

372

7-2. Steps to take in an emergency

■

Brake system warning light (warning buzzer)

■

Brake system warning light (warning buzzer)

■

High coolant temperature warning light

(warning buzzer)

: This light illuminates on the multi-information display.

If a warning light turns on or a warning buzzer

sounds

Calmly perform the following actions if any of the warning
lights comes on or flashes. If a light comes on or flashes, but
then goes off, this does not necessarily indicate a malfunction
in the system. However, if this continues to occur, have the
vehicle inspected by your Toyota dealer.

Actions to the warning lights or warning buzzers

Warning light

Details/Actions

(U.S.A.)

(Red)

(Canada)

Indicates that:



The brake fluid level is low; or



The brake system is malfunctioning



Immediately stop the vehicle in a safe place and con-
tact your Toyota dealer. Continuing to drive the vehi-
cle may be dangerous.

Warning light

Details/Actions

(Yellow)

Indicates a malfunction in:



The regenerative braking system;



The electronically controlled brake system; or



The parking brake system



Have the vehicle inspected by your Toyota dealer
immediately.

Warning light

Details/Actions

Indicates that the engine coolant temperature is exces-
sively high



Immediately stop the vehicle in a safe place.
Handling method (



P.414)

373

7-2. Steps to take in an emergency

Whe

n tr

ouble

ises

■

Hybrid system overheat warning light

(warning buzzer)

: This light illuminates on the multi-information display.

■

Charging system warning light

■

Low engine oil pressure warning light

(warning buzzer)

: This light illuminates on the multi-information display.

■

Malfunction indicator lamp (warning buzzer)

Warning light

Details/Actions

Indicates that the temperature of the hybrid system is
excessively high



Stop the vehicle in a safe place.
Handling method (



P.414)

Warning light

Details/Actions

Indicates a malfunction in the vehicle’s charging system



Immediately stop the vehicle in a safe place and con-
tact your Toyota dealer.

Warning light

Details/Actions

Indicates that the engine oil pressure is excessively low



Immediately stop the vehicle in a safe place and con-
tact your Toyota dealer.

Warning light

Details/Actions

(U.S.A.)

(Canada)

Indicates a malfunction in:



The hybrid system;



The electronic engine control system; or



The electronic throttle control system



Immediately stop the vehicle in a safe place and con-
tact your Toyota dealer.

374

7-2. Steps to take in an emergency

■

SRS warning light (warning buzzer)

■

ABS warning light

■

Inappropriate pedal operation warning light

(warning buzzer)

: This light illuminates on the multi-information display.

Warning light

Details/Actions

Indicates a malfunction in:



The SRS airbag system;



The front passenger occupant classification system; or



The seat belt pretensioner system



Have the vehicle inspected by your Toyota dealer
immediately.

Warning light

Details/Actions

(U.S.A.)

(Canada)

Indicates a malfunction in:



The ABS; or



The brake assist system



Have the vehicle inspected by your Toyota dealer
immediately.

Warning light

Details/Actions

When a buzzer sounds:



Brake Override System is malfunctioning



Drive-Start Control is malfunctioning



Drive-Start Control is operating



Follow the instructions displayed on the multi-infor-
mation display. (



P.382)

When a buzzer does not sound:
Brake Override System is operating.



Release the accelerator pedal and depress the brake
pedal.

375

7-2. Steps to take in an emergency

Whe

n tr

ouble

ises

■

Electric power steering system warning light (warning
buzzer)

■

Low fuel level warning light

■

Driver’s and front passenger’s seat belt reminder light (warn-
ing buzzer)

: Driver’s seat belt warning buzzer:

The driver’s seat belt warning buzzer sounds to alert the driver that his or
her seat belt is not fastened. Once the power switch is turned to ON, the
buzzer sounds. If the seat belt is still unfastened, the buzzer sounds inter-
mittently for a certain period of time after the vehicle reaches a certain
speed.
Front passenger’s seat belt warning buzzer:
The front passenger’s seat belt warning buzzer sounds to alert the front
passenger that his or her seat belt is not fastened. If the seat belt is unfas-
tened, the buzzer sounds intermittently for a certain period of time after the
vehicle reaches a certain speed.

Warning light

Details/Actions

(Red/yellow)

Indicates a malfunction in the EPS (Electric Power Steer-
ing) system



Have the vehicle inspected by your Toyota dealer
immediately.

Warning light

Details/Actions

2WD models:
Indicates that remaining fuel is approximately 1.7 gal. (6.4 L
, 1.4 Imp. gal.) or less
AWD models:
Indicates that remaining fuel is approximately 1.6 gal. (6.0 L
, 1.3 Imp. gal.) or less



Refuel the vehicle.

Warning light

Details/Actions

Warns the driver and/or front passenger to fasten their seat
belts



Fasten the seat belt.
If the front passenger’s seat is occupied, the front
passenger’s seat belt also needs to be fastened to
make the warning light (warning buzzer) turn off.

376

7-2. Steps to take in an emergency

■

Rear passengers’ seat belt reminder lights (warning buzzer)

: Rear passengers’ seat belt warning buzzer:

The rear passengers’ seat belt warning buzzer sounds to alert the rear pas-
senger that his or her seat belt is not fastened. If the seat belt is unfas-
tened, the buzzer sounds intermittently for a certain period of time, after the
seat belt is fastened and unfastened and the vehicle reaches a certain
speed.

■

Tire pressure warning light

Warning light

Details/Actions

(4.2-inch dis-

play)

(7-inch display)

Warns the rear passengers to fasten their seat belts



Fasten the seat belt.

Warning light

Details/Actions

When the light comes on after blinking for approximately 1
minute (a buzzer does not sounds):
Malfunction in the tire pressure warning system



Have the system checked by your Toyota dealer.

When the light comes on (a buzzer sounds):
Low tire inflation pressure from natural causes



After the temperature of the tires has lowered suffi-
ciently, check the inflation pressure of each tire and
adjust them to the specified level. (



P.342)

Low tire inflation pressure from flat tire



Immediately stop the vehicle in a safe place and per-
form the necessary actions. (



P.380)

377

7-2. Steps to take in an emergency

Whe

n tr

ouble

ises

■

PCS warning light (warning buzzer)

■

LTA indicator (warning buzzer)

■

LDA indicator (warning buzzer)

■

PDA indicator (warning buzzer)

■

Dynamic radar cruise control indicator (warning buzzer)

Warning light

Details/Actions

Indicates a malfunction in the PCS (Pre-Collision System).



Follow the instructions displayed on the multi-infor-
mation display. (



P.382)

If the PCS (Pre-Collision System) or VSC (Vehicle Stability
Control) system is disabled, the PCS warning light will illu-
minate.



P.212

Warning light

Details/Actions

(Orange)

Indicates a malfunction in the LTA (Lane Tracing Assist).



Follow the instructions displayed on the multi-infor-
mation display. (



P.382)

Warning light

Details/Actions

(Orange)

Indicates a malfunction in the LDA (Lane Departure Alert).



Follow the instructions displayed on the multi-infor-
mation display. (



P.382)

Warning light

Details/Actions

(Orange)

Indicates a malfunction in the PDA (Proactive Driving
Assist).



Follow the instructions displayed on the multi-infor-
mation display. (



P.382)

Warning light

Details/Actions

(Orange)

Indicates a malfunction in the dynamic radar cruise control.



Follow the instructions displayed on the multi-infor-
mation display. (



P.382)

378

7-2. Steps to take in an emergency

■

Cruise control indicator (warning buzzer)

■

Driving assist information indicator

: If equipped

■

Slip indicator

Warning light

Details/Actions

(Orange)

Indicates a malfunction in the cruise control.



Follow the instructions displayed on the multi-infor-
mation display. (



P.382)

Warning light

Details/Actions

Indicates either of the following systems may be malfunc-
tioning.



PCS (Pre-Collision System)



LDA (Lane Departure Alert)



Follow the instructions displayed on the multi-infor-
mation display. (



P.382)

Indicates one of the following systems is malfunctioning or
disabled.



BSM (Blind Spot Monitor)



RCTA(Rear cross traffic alert)



SEA (Safe Exit Assist)



Follow the instructions displayed on the multi-infor-
mation display. (



P.382)

Warning light

Details/Actions

Indicates a malfunction in:



The VSC system;



The TRAC system; or



The hill-start assist control system



Have the vehicle inspected by your Toyota dealer
immediately.

379

7-2. Steps to take in an emergency

Whe

n tr

ouble

ises

■

Parking brake indicator

■

Brake hold operated indicator

■

Warning buzzer

In some cases, the buzzer may not

be heard due to being in a noisy

location or audio sound.

■

Front passenger detection sen-

sor, seat belt reminder and

warning buzzer

●

If luggage is placed on the front

passenger seat, the front passen-

ger detection sensor may cause

the warning light to flash and the

warning buzzer to sound even if a

passenger is not sitting in the

seat.

●

If a cushion is placed on the seat,

the sensor may not detect a pas-

senger, and the warning light may

not operate properly.

■

Operation of rear passengers’

seat belt reminder lights

●

The rear passengers’ seat belt

reminder lights will illuminate for

approximately 60 seconds after

either rear door has been opened

and closed.

●

If any rear seat belt is fastened

and then unfastened, the corre-

sponding light for that seat will illu-

minate continuously. If either rear

door is opened and closed while a

rear passengers’ seat belt light is

illuminated, it will turn off approxi-

mately 60 seconds after the door

is closed.

■

SRS warning light

This warning light system monitors

the airbag sensor assembly, front

impact sensors, side impact sensors

(front door), side impact sensors

(front), driver’s seat position sensor,

driver’s seat belt buckle switch, front

passenger seat belt buckle switch,

“AIR BAG ON” indicator light, “AIR

BAG OFF” indicator light, seat belt

pretensioners, airbags, intercon-

necting wiring and power sources.

(



P.32)

■

Electric power steering system

warning light (warning buzzer)

When the 12-volt battery charge

becomes insufficient or the voltage

temporarily drops, the electric power

Warning light

Details/Actions

(Flashes)

(U.S.A.)

(Flashes)
(Canada)

It is possible that the parking brake is not fully engaged or
released



Operate the parking brake switch once again.

This light comes on the parking brake is not released. If the
light turns off after the parking brakes is fully released, the
system is operating normally.

Warning light

Details/Actions

(Flashes)

Indicates a malfunction in the brake hold system



Have the vehicle inspected by your Toyota dealer
immediately.

380

7-2. Steps to take in an emergency

steering system warning light may

come on and the warning buzzer

may sound.

■

When the tire pressure warning

light comes on

Inspect the tires to check if a tire is

punctured.
If a tire is punctured:



P.387, 398

If none of the tires are punctured:

Turn the power switch off then turn it

to ON. Check if the tire pressure

warning light comes on or blinks.



If the tire pressure warning light

blinks for approximately 1 minute

then stays on

There may be a malfunction in the

tire pressure warning system. Have

the vehicle inspected by your Toyota

dealer immediately.



If the tire pressure warning light

comes on

After the temperature of the tires

has lowered sufficiently, check

the inflation pressure of each tire

and adjust them to the specified

level.

If the warning light does not turn

off even after several minutes

have elapsed, check that the

inflation pressure of each tire is

at the specified level and perform

initialization. (



P.333)

■

The tire pressure warning light

may come on due to natural

causes

The tire pressure warning light may

come on due to natural causes such

as natural air leaks and tire inflation

pressure changes caused by tem-

perature. In this case, adjusting the

tire inflation pressure will turn off the

warning light (after a few minutes).

■

When a tire is replaced with a

spare tire

Vehicles with a compact spare tire:

The compact spare tire is not

equipped with a tire pressure warn-

ing valve and transmitter. If a tire

goes flat, the tire pressure warning

light will not turn off even though the

flat tire has been replaced with the

spare tire. Replace the spare tire

with the repaired tire and adjust the

tire inflation pressure. The tire pres-

sure warning light will go off after a

few minutes.

■

Conditions that the tire pres-

sure warning system may not

function properly



P.329

WARNING

■

If both the ABS and the brake

system warning lights remain

Stop your vehicle in a safe place

immediately and contact your Toy-

ota dealer.

The vehicle will become

extremely unstable during brak-

ing, and the ABS system may fail,

which could cause an accident

resulting in death or serious injury.

■

When the electric power

steering system warning light

comes on

When the light comes on yellow,

the assist to the power steering is

restricted. When the light comes

on red, the assist to the power

steering is lost and handling oper-

ations of the steering wheel

become extremely heavy.

When steering wheel operations

are heavier than usual, grip the

steering wheel firmly and operate

it using more force than usual.

■

If the tire pressure warning

light comes on

Be sure to observe the following

precautions.

Failure to do so could cause a

loss of vehicle control and result

in death or serious injury.

381

7-2. Steps to take in an emergency

tro

WARNING

●

Stop your vehicle in a safe place

as soon as possible. Adjust the

tire inflation pressure immedi-

ately.

●

Vehicles with a compact spare

tire: If the tire pressure warning

light comes on even after tire

inflation pressure adjustment, it

is probable that you have a flat

tire. Check the tires. If a tire is

flat, change it with the spare tire

and have the flat tire repaired by

the nearest Toyota dealer.

●

Vehicles with emergency tire

puncture repair kit: If the tire

pressure warning light comes

on even after tire inflation pres-

sure adjustment, it is probable

that you have a flat tire. Check

the tires. If a tire is flat, repair

the flat tire by using emergency

tire puncture repair kit.

●

Avoid abrupt maneuvering and

braking.

If the vehicle tires deteriorate,

you could lose control of the

steering wheel or the brakes.

■

If a blowout or sudden air

leakage should occur

The tire pressure warning system

may not activate immediately.

■

Maintenance of the tires

Each tire, including the spare (if

provided), should be checked

monthly when cold and inflated to

the inflation pressure recom-

mended by the vehicle manufac-

turer on the vehicle placard or tire

inflation pressure label (tire and

load information label). (If your

vehicle has tires of a different size

than the size indicated on the

vehicle placard or tire inflation

pressure label [tire and load infor-

mation label], you should deter-

mine the proper tire inflation

pressure for those tires.)

As an added safety feature, your

vehicle has been equipped with a

tire pressure monitoring system

(TPMS-tire pressure warning sys-

tem) that illuminates a low tire

pressure telltale (tire pressure

warning light) when one or more

of your tires is significantly

under-inflated. Accordingly, when

the low tire pressure telltale (tire

pressure warning light) illumi-

nates, you should stop and check

your tires as soon as possible,

and inflate them to the proper

pressure. Driving on a signifi-

cantly under-inflated tire causes

the tire to overheat and can lead

to tire failure. Under-inflation also

reduces fuel efficiency and tire

tread life, and may affect the vehi-

cle’s handling and stopping ability.

Please note that the TPMS (tire

pressure warning system) is not a

substitute for proper tire mainte-

nance, and it is the driver’s

responsibility to maintain correct

tire pressure, even if under-infla-

tion has not reached the level to

trigger illumination of the TPMS

low tire pressure telltale (tire pres-

sure warning light).

Your vehicle has also been

equipped with a TPMS (tire pres-

sure warning system) malfunc-

tion indicator to indicate when the

system is not operating properly.

The TPMS (tire pressure warning

system) malfunction indicator is

combined with the low tire pres-

sure telltale (tire pressure warning

light). When the system detects a

malfunction, the telltale will flash

for approximately one minute and

then remain continuously illumi-

nated. This sequence will con-

tinue upon subsequent vehicle

start-ups as long as the malfunc-

tion exists. When the malfunction

indicator is illuminated, the sys-

tem may not be able to detect or

signal low tire pressure as

intended.

382

7-2. Steps to take in an emergency

■

Warning messages

The warning messages explained

below may differ from the actual

messages according to operation

conditions and vehicle specifica-

tions.

■

Warning buzzer

A buzzer may sound when a mes-

sage is displayed.

The buzzer may not be audible if the

vehicle is in a noisy location or if the

audio system volume is high.

■

If “Engine Oil Level Low Add or

Replace” is displayed

The engine oil level is low. Check

WARNING

TPMS (tire pressure warning sys-

tem) malfunctions may occur for a

variety of reasons, including the

installation of replacement or

alternate tires or wheels on the

vehicle that prevent the TPMS

(tire pressure warning system)

from functioning properly. Always

check the TPMS (tire pressure

warning system) malfunction tell-

tale after replacing one or more

tires or wheels on your vehicle to

ensure that the replacement or

alternate tires and wheels allow

the TPMS (tire pressure warning

system) to continue to function

properly.

NOTICE

■

To ensure the tire pressure

warning system operates

properly

Do not install tires with different

specifications or makers, as the

tire pressure warning system may

not operate properly.

If a warning message

is displayed

The multi-information dis-
play shows warnings for
system malfunctions and
incorrectly performed oper-
ations, and messages that
indicate a need for mainte-
nance. When a message is
displayed, perform the
appropriate corrective
action for the message.

If a warning message is dis-
played again after the
appropriate actions have
been performed, contact
your Toyota dealer.

Additionally, if a warning
light comes on or flashes at
the same time that a warn-
ing message is displayed,
take the appropriate correc-
tive action for the warning
light. (



P.372)

383

7-2. Steps to take in an emergency

Whe

n tr

ouble

ises

the level of the engine oil, and add if

necessary.
This message may appear if the

vehicle is stopped on a slope. Move

the vehicle to a level surface and

check to see if the message disap-

pears.

■

If “Hybrid System Stopped

Steering Power Low” is dis-

played

This message is displayed if the

hybrid system is stopped while driv-

ing.
When steering wheel operations are

heavier than usual, grip the steering

wheel firmly and operate it using

more force than usual.

■

If “Hybrid System Overheated

Output Power Reduced” is dis-

played

This message may be displayed

when driving under severe operat-

ing conditions. (For example, when

driving up a long steep hill.)

Handling method:



P.414

■

If “Traction Battery Needs to be

Protected Refrain from the Use

of N Position” is displayed

This message may be displayed

when the shift lever is in N.
As the hybrid battery (traction bat-

tery) cannot be charged when the

shift lever is in N, shift the shift lever

to P when the vehicle is stopped.

■

If “Traction Battery Needs to be

Protected Shift into P to

Restart” is displayed

This message is displayed when the

hybrid battery (traction battery)

charge has become extremely low

because the shift lever has been left

in N for a certain amount of time.
When operating the vehicle, shift to

P and restart the hybrid system.

■

If “Shift is in N Release Acceler-

ator Before Shifting” is dis-

played

The accelerator pedal has been

depressed when the shift lever is in

N.
Release the accelerator pedal and

shift the shift lever to D or R.

■

If “Press Brake when Vehicle is

Stopped Hybrid System may

Overheat” is displayed

The message may be displayed

when the accelerator pedal is

depressed to hold the vehicle while

the vehicle is stopped on an incline,

etc. The hybrid system may over-

heat. Release the accelerator pedal

and depress the brake pedal.

■

If “Auto Power OFF to Conserve

Battery” is displayed

Power was cut off due to the auto-

matic power off function. Next time

when starting the hybrid system,

operate the hybrid system for

approximately 5 minutes to

recharge the 12-volt battery.

■

If “Headlight System Malfunc-

tion Visit Your Dealer” is dis-

played

The following systems may be mal-

functioning. Have the vehicle

inspected by your Toyota dealer

immediately.

●

The LED headlight system

●

AHB (Automatic High Beam)

■

If “System Malfunction Visi-

tYour Dealer” is displayed

Indicates one of the following sys-

tems is disabled.

●

PCS (Pre-Collision system)

●

LDA (Lane Departure Alert)

●

LTA (Lane Tracing Assist)

●

AHB (Automatic High Beam)

●

Dynamic radar cruise control

●

RSA (Road Sign Assist) (if

equipped)

●

BSM (Blind Spot Monitor) (if

equipped)

384

7-2. Steps to take in an emergency

●

RCTA (Rear Cross Traffic

Alert) (if equipped)

●

SEA (Safe Exit Assist) (if

equipped)

Have the vehicle inspected by your

Toyota dealer immediately.

■

If “System Stopped See

Owner’s Manual” is displayed

Indicates one of the following sys-

tems is disabled.

●

PCS (Pre-Collision system)

●

LDA (Lane Departure Alert)

●

LTA (Lane Tracing Assist)

●

AHB (Automatic High Beam)

●

Dynamic radar cruise control

●

RSA (Road Sign Assist) (if

equipped)

●

BSM (Blind Spot Monitor) (if

equipped)

●

RCTA (Rear Cross Traffic

Alert) (if equipped)

●

SEA (Safe Exit Assist) (if

equipped)

Follow the following correction

methods.
• Check the voltage of the battery
• Check the sensors that the Toyota

Safety Sense 3.0 uses for foreign

matter covering them. Remove

them if any. (



P.202)

Indicates the sensors may not be

operating properly. (



P.205)

When problems are solved and the

sensors are operational, this indica-

tion may disappear by itself.

■

If “System Stopped Front Cam-

era Low Visibility See Owner’s

Manual” is displayed

Indicates one of the following sys-

tems is disabled.

●

PCS (Pre-Collision system)

●

LDA (Lane Departure Alert)

●

LTA (Lane Tracing Assist)

●

AHB (Automatic High Beam)

●

Dynamic radar cruise control

●

RSA (Road Sign Assist) (if

equipped)

Follow the following correction

methods.
• Using the windshield wipers,

remove the dirt or foreign matter

from the windshield.

• Using the air conditioning system,

defog the windshield.

• Close the hood, remove any stick-

ers, etc. to clear the obstruction in

front of the front camera.

■

If “System Stopped Front Cam-

era Out of Temperature Range

Wait until Normal Temperature”

is displayed

Indicates one of the following sys-

tems is disabled.

●

PCS (Pre-Collision system)

●

LDA (Lane Departure Alert)

●

LTA (Lane Tracing Assist)

●

AHB (Automatic High Beam)

●

Dynamic radar cruise control

●

RSA (Road Sign Assist) (if

equipped)

Follow the following correction

methods.
• If the front camera is hot, such as

after the vehicle is parked in the

sun, use the air conditioning sys-

tem to decrease the temperature

around the front camera

• If a sunshade was used when the

vehicle was parked, depending on

its type, the sunlight reflected from

the surface of the sunshade may

cause the temperature of the front

camera to become excessively

high

• If the front camera is cold, such

after the vehicle is parked in an

extremely cold environment, use

385

7-2. Steps to take in an emergency

Whe

n tr

ouble

ises

the air conditioning system to

increase the temperature around

the front camera

■

If “System Stopped Front Radar

Sensor Blocked Clean Radar

Sensor” is displayed

Indicates one of the following sys-

tems is disabled.

●

PCS (Pre-Collision system)

●

LDA (Lane Departure Alert)

●

LTA (Lane Tracing Assist)

●

AHB (Automatic High Beam)

●

Dynamic radar cruise control

Follow the following correction

methods.
• Check if there is any foreign mat-

ter attached to the radar sensor or

radar sensor cover and clean

them if necessary (



P.203)

• This message may be displayed

when driving in an open area with

few nearby vehicles or structures,

such as a desert, grasslands, sub-

urbs, etc.

The message may be cleared by

driving the vehicle in an area with

structures, vehicles, etc., nearby.

■

If “System Stopped Front Radar

Sensor Out of Temperature

Range Wait until Normal Tem-

perature” is displayed

Indicates one of the following sys-

tems is disabled.

●

PCS (Pre-Collision system)

●

LDA (Lane Departure Alert)

●

LTA (Lane Tracing Assist)

●

AHB (Automatic High Beam)

●

Dynamic radar cruise control

Follow the following correction

methods.
The temperature of the radar sensor

is outside of the operating range.

Wait for the temperature to become

appropriate.

■

If “System Stopped Front Radar

In Self Calibration See Owner’s

Manual” is displayed

Indicates one of the following sys-

tems is disabled.

●

PCS (Pre-Collision system)

●

LDA (Lane Departure Alert)

●

LTA (Lane Tracing Assist)

●

AHB (Automatic High Beam)

●

Dynamic radar cruise control

Follow the following correction

methods.
• Check if there is any foreign mat-

ter attached to the radar sensor or

radar sensor cover and clean

them if necessary (



P.203)

• The radar sensor may be mis-

aligned and will be adjusted auto-

matically while driving. Continue

driving for a while.

■

If “Cruise Control Unavailable

See Owner’s Manual” is dis-

played

Indicates one of the following sys-

tems is disabled.

●

Dynamic radar cruise control

●

Cruise control

A message is displayed when the

driving assist switch is pushed

repeatedly.
Press the driving assist switch

quickly and firmly.

■

If “Maintenance Required

Soon” is displayed

Indicates that all maintenance

according to the driven distance on
the maintenance schedule

should

be performed soon.
Comes on approximately 4500

miles (7200 km) after the message

has been reset. If necessary, per-

form maintenance. Please reset the

message after the maintenance is

performed. (



P.309)

: Refer to the separate “Scheduled

Maintenance” or “Owner’s Man-

Content .. 21 22 23 24 ..
