288

6-3. Do-it-yourself maintenance

It is necessary to register the
position of each wheel after per-
forming a tire rotation.
Wheel position registration can
be performed by oneself. Wheel
position registration is per-
formed by driving forward with
moderate left and right turns.
However, depending on the driv-
ing conditions and driving envi-
ronment, registration may take
some time to complete.



4.2-inch display

1

Park the vehicle in a safe
place and turn the engine
switch off, wait for approxi-
mately 20 minutes or more,
and then start the engine.

The wheel position registration pro-

cedure cannot be performed while

the vehicle is moving.

2

Select

 of the multi-infor-

mation display and then

press

.

3

Press

 or

 to select

“Vehicle Settings” and then

press and hold

.

4

Press

 or

 to select

“TPWS setting” and then

press

.

5

Press

 or

 to select

“Tire Rotation” and then

press

.

6

Select “OK” and then press

.

A message indicating that wheel

position registration is being per-

formed will be displayed on the

multi-information display. “---” will

be displayed for the tire inflation

pressure of each tire and wheel

position registration will begin.

7

Drive straight (with occa-
sional left and right turns) at
approximately 25 mph (40
km/h) or more for approxi-
mately 10 to 30 minutes.

When wheel position registration is

complete, a message indicating

that registration has been com-

pleted and the inflation pressure of

each tire will be displayed on the

multi-information display.
Even if it is not possible to drive

continuously at approximately 25

mph (40 km/h) or more, registration

can be completed by driving for a

long time. However, if registration

does not complete after driving for

1 hour or more, park the vehicle in

NOTICE

■

To avoid damage to the tire

pressure warning valves and

transmitters

When a tire is repaired with liquid

sealants, the tire pressure warn-

ing valve and transmitter may not

operate properly. If a liquid seal-

ant is used, contact your Toyota

dealer or other qualified service

shop as soon as possible. Make

sure to replace the tire pressure

warning valve and transmitter

when replacing the tire. (



P.287)

Registration of the posi-
tion of each wheel after
performing a tire rotation

289

6-3. Do-it-yourself maintenance

6

Maintena

nce
 a

nd ca

re

a safe place and leave it with the

engine switch in ON for approxi-

mately 15 minutes or more, and

then perform the driving procedure

again.



7-inch display

1

Park the vehicle in a safe
place and turn the engine
switch off, wait for approxi-
mately 20 minutes or more,
and then start the engine.

The wheel position registration pro-

cedure cannot be performed while

the vehicle is moving.

2

Select

 of the multi-infor-

mation display and then

press

.

3

Press

 or

 to select

“Vehicle Settings” and then

press and hold

.

4

Press

 or

 to select

“TPWS setting” and then

press

.

5

Press

 or

 to select

“Tire Rotation” and then

press

.

6

Select “OK” and then press

.

A message indicating that wheel

position registration is being per-

formed will be displayed on the

multi-information display. “---” will

be displayed for the tire inflation

pressure of each tire and wheel

position registration will begin.

7

Drive straight (with occa-
sional left and right turns) at

approximately 25 mph (40
km/h) or more for approxi-
mately 10 to 30 minutes.

When wheel position registration is

complete, a message indicating

that registration has been com-

pleted and the inflation pressure of

each tire will be displayed on the

multi-information display.
Even if it is not possible to drive

continuously at approximately 25

mph (40 km/h) or more, registration

can be completed by driving for a

long time. However, if registration

does not complete after driving for

1 hour or more, park the vehicle in

a safe place and leave it with the

engine switch in ON for approxi-

mately 15 minutes or more, and

then perform the driving procedure

again.

■

When performing wheel posi-

tion registration

●

Normally, wheel position registra-

tion can be completed within

approximately 30 minutes.

●

Wheel position registration is per-

formed while driving at a vehicle

speed of approximately 25 mph

(40 km/h) or more.

■

Wheel position registration pro-

cedure

●

If the engine switch is turned off

while registering the wheel posi-

tion, the next time the engine

switch is turned to ON, the wheel

position registration will resume

and it will not be necessary to

restart the procedure.

●

While the position of each wheel is

being determined and the inflation

pressures are not being dis-

played, if the inflation pressure of

a tire drops, the tire pressure

warning light will come on.

■

If the wheel position cannot be

registered easily

●

In the following situations, wheel

290

6-3. Do-it-yourself maintenance

position registration may take lon-

ger than usual to be completed or

may not be possible.

• Vehicle is not driven at approxi-

mately 25 mph (40 km/h) or more

• Vehicle is driven on unpaved

roads

• If wheel position registration does

not complete after driving for 1

hour or more, park the vehicle in a

safe place for approximately 15

minutes and then drive the vehicle

again.

●

If the vehicle is reversed during

wheel position registration, all

data collected until then will be

cleared. Perform driving again.

In the following situations, it will
be necessary to perform the tire
inflation pressure setting proce-
dure of the tire pressure warning
system.



When the specified tire infla-
tion pressure has changed,
such as due to carried load,
etc.



When the tire inflation pres-
sure is changed such as
when the tire size is changed.

If the tire inflation pressure has
been adjusted to the specified
level, perform the tire inflation set-
ting procedure by selecting speci-
fied inflation pressure on the
multi-information display.
When the tire inflation pressure is
to be other than specified, such as
when tires other than the specified
size are used, etc., set the tire infla-
tion pressure using the current
pressure. Make sure to adjust the

tire inflation pressure of each tire to
the appropriate level before per-
forming tire pressure setting. The
tire pressure warning system oper-
ates based on this tire inflation
pressure.

■

Setting by selecting a spec-
ified tire inflation pressure



4.2-inch display

1

Park the vehicle in a safe
place and then start the
engine.

The tire inflation pressure cannot

be set while the vehicle is moving.

2

Select

 of the multi-infor-

mation display and then

press

.

3

Press

 or

 to select

“Vehicle Settings” and then

press and hold

.

4

Press

 or

 to select

“TPWS setting” and then

press

.

5

Press

 or

 to select

“Tire Pressure Setting” and

then press

.

6

Press

 or

 to select

“Setting by Specified Pres-

sure” and then press

.

7

Select the desired tire pres-

sures, then press

.

The tire pressure warning light will

slowly blink 3 times.
After setting the tire inflation pres-

Setting the tire pressure

291

6-3. Do-it-yourself maintenance

6

Maintena

nce
 a

nd ca

re

sure, a message indicating that set-

ting has been completed will be

displayed on the multi-information

display.



7-inch display

1

Park the vehicle in a safe
place and then start the
engine.

The tire inflation pressure cannot

be set while the vehicle is moving.

2

Select

 of the multi-infor-

mation display and then

press

.

3

Press

 or

 to select

“Vehicle Settings” and then

press and hold

.

4

Press

 or

 to select

“TPWS setting” and then

press

.

5

Press

 or

 to select

“Tire Pressure Setting” and

then press

.

6

Press

 or

 to select

“Setting by Specified Pres-

sure” and then press

.

7

Select the desired tire pres-

sures, then press

.

The tire pressure warning light will

slowly blink 3 times.
After setting the tire inflation pres-

sure, a message indicating that set-

ting has been completed will be

displayed on the multi-information

display.

■

If the tire inflation pressure can-

not be set easily

●

If the tire pressure warning light

does not blink 3 times when start-

ing the tire inflation pressure set-

ting procedure, the procedure

may not have started. Perform the

procedure again from the begin-

ning.

●

If tire inflation pressure setting

procedure cannot be completed

after performing the above proce-

dure, contact your Toyota dealer.

292

6-3. Do-it-yourself maintenance

■

Setting using the current
tire inflation pressure



4.2-inch display

1

Park the vehicle in a safe
place and then start the
engine.

The tire inflation pressure cannot

be set while the vehicle is moving.

2

Select

 of the multi-infor-

mation display and then

press

.

3

Press

 or

 to select

“Vehicle Settings” and then

press and hold

.

4

Press

 or

 to select

“TPWS setting” and then

press

.

5

Press

 or

 to select

“Tire Pressure Setting” and

then press

.

6

Press

 or

 to select

“Setting by Current Pressure”

and then press

.

The tire pressure warning light will

slowly blink 3 times and a message

indicating that tire inflation pressure

is being set will be displayed on the

multi-information display.
After setting the tire inflation pres-

sure, a message indicating that set-

ting has been completed will be

displayed on the multi-information

display.



7-inch display

1

Park the vehicle in a safe
place and then start the
engine.

The tire inflation pressure cannot

be set while the vehicle is moving.

2

Select

 of the multi-infor-

mation display and then

press

.

3

Press

 or

 to select

“Vehicle Settings” and then

press and hold

.

4

Press

 or

 to select

“TPWS setting” and then

press

.

5

Press

 or

 to select

“Tire Pressure Setting” and

then press

.

WARNING

■

Before performing tire pres-

sure setting

Make sure to adjust the tire infla-

tion pressure of each tire to the

appropriate level before perform-

ing tire pressure setting. Other-

wise, the tire pressure warning

light may not illuminate even if the

tire inflation pressure drops or

may illuminate even though the

tire inflation pressure is normal.

293

6-3. Do-it-yourself maintenance

6

Maintena

nce
 a

nd ca

re

6

Press

 or

 to select

“Setting by Current Pressure”

and then press

.

The tire pressure warning light will

slowly blink 3 times and a message

indicating that tire inflation pressure

is being set will be displayed on the

multi-information display.
After setting the tire inflation pres-

sure, a message indicating that set-

ting has been completed will be

displayed on the multi-information

display.

■

Warning performance of the tire

pressure warning system

●

When performing the tire pressure

setting using the current tire infla-

tion pressure, the warning timing

of the tire pressure warning sys-

tem will vary according to the con-

ditions under which tire pressure

setting was performed. Therefore,

a warning may be output even if

the tire inflation pressure drops

slightly or if the tire inflation pres-

sure increases above that when

the tire inflation pressure was set.

●

Make sure to perform the tire

pressure setting procedure after

adjusting the tire inflation pres-

sure. Also, make sure the tires are

cold before performing the tire

pressure setting procedure or

adjusting the tire inflation pres-

sure.

■

Tire inflation pressure setting

procedure

●

If the engine switch is turned off

while setting the tire inflation pres-

sure, the next time the engine

switch is turned to ON, the setting

procedure will resume and it will

not be necessary to restart the

procedure.

●

If the tire inflation pressure setting

procedure is started unnecessar-

ily, adjust the tire inflation pres-

sure to the specified level with the

tires cold and then perform setting

by selecting a specified tire infla-

tion pressure, or perform the tire

inflation pressure setting proce-

dure with the current tire inflation

pressure.

■

If the tire inflation pressure can-

not be set easily

●

Normally, the tire inflation pres-

sure setting procedure can be

completed in 2 or 3 minutes.

●

If the tire pressure warning light

does not blink 3 times when start-

ing the tire inflation pressure set-

ting procedure, the procedure

may not have started. Perform the

procedure again from the begin-

ning.

●

If tire inflation pressure setting

procedure cannot be completed

after performing the above proce-

dure, contact your Toyota dealer.

The tire pressure warning valve
and transmitter is equipped with
a unique ID code. When new
tire pressure warning valves and
transmitters are installed, new
ID codes must be registered in
the tire pressure warning com-
puter.



ID codes can be registered by

Registering ID codes

294

6-3. Do-it-yourself maintenance

yourself, but depending on
the driving conditions and
driving environment, registra-
tion may take some time to
complete.



When using a wheel set
which all of the ID codes have
already been registered, the
wheel set can be changed in
a short amount of time.

Before performing ID code reg-
istration, make sure that no
wheels with tire pressure warn-
ing valve and transmitters
installed are near the vehicle.



4.2-inch display

1

Park the vehicle in a safe
place and turn the engine
switch off, wait for approxi-
mately 20 minutes or more,
and then start the engine.

The ID code registration procedure

cannot be performed while the

vehicle is moving.

2

Select

 of the multi-infor-

mation display and then

press

.

3

Press

 or

 to select

“Vehicle Settings” and then

press and hold

.

4

Press

 or

 to select

“TPWS setting” and then

press

.

5

Press

 or

 to select

“Tire Set Switching” and then

press

.

6

Press

 or

 to select

“Register New Valve / ID” and

then press

..

7

Press

 or

 to select

“Tire Set 1” or “Tire Set 2”.

Then press

.

ID codes will be registered to the

displayed wheel set.
If ID codes have already been reg-

istered for that wheel set, the tire

pressure warning light will slowly

blink 3 times, and a message indi-

cating that change is occurring will

be displayed on the multi-informa-

tion display.

8

Select “OK” and then press

.

The tire pressure warning light will

slowly blink 3 times and a message

indicating that ID code registration

is being performed will be displayed

on the multi-information display.

Wheel set changing will be can-

celed and registration will begin.
When registration is being per-

formed, the tire pressure warning

light will blink for approximately 1

minute then illuminate and “---” will

be displayed for the inflation pres-

295

6-3. Do-it-yourself maintenance

6

Maintena

nce
 a

nd ca

re

sure of each tire on the multi-infor-

mation display.

9

Drive straight (with occa-
sional left and right turns) at
approximately 25 mph (40
km/h) or more for approxi-
mately 10 to 30 minutes.

When registration is complete, the

tire pressure warning light will turn

off and a message indicating that

registration has been completed

will be displayed on the multi-infor-

mation display.
Registration may take longer than

normal to complete if the vehicle

speed cannot be maintained at

approximately 25 mph (40 km/h) or

more. If registration cannot be com-

pleted after driving for 1 hour or

more, perform the registration pro-

cedure again from the beginning.

10

If the tire inflation pressure of

the wheel set installed differs
from that of the previous set,
it will be necessary to per-
form the tire inflation pres-
sure setting procedure of the
tire pressure warning system.

If the specified tire inflation pres-

sure is the same, it will not be nec-

essary to perform the tire inflation

pressure setting procedure.



7-inch display

1

Park the vehicle in a safe
place and turn the engine
switch off, wait for approxi-
mately 20 minutes or more,
and then start the engine.

The ID code registration procedure

cannot be performed while the

vehicle is moving.

2

Select

 of the multi-infor-

mation display and then

press

.

3

Press

 or

 to select

“Vehicle Settings” and then

press and hold

.

4

Press

 or

 to select

“TPWS setting” and then

press

.

5

Press

 or

 to select

“Tire Set Switching” and then

press

.

6

Press

 or

 to select

“Register New Valve / ID” and

then press

.

7

Press

 or

 to select

“Tire Set 1” or “Tire Set 2”.

Then press

.

ID codes will be registered to the

displayed wheel set.
If ID codes have already been reg-

istered for that wheel set, the tire

pressure warning light will slowly

blink 3 times, and a message indi-

cating that change is occurring will

be displayed on the multi-informa-

tion display.

296

6-3. Do-it-yourself maintenance

8

Select “OK” and then press

.

The tire pressure warning light will

slowly blink 3 times and a message

indicating that ID code registration

is being performed will be displayed

on the multi-information display.

Wheel set changing will be can-

celed and registration will begin.
When registration is being per-

formed, the tire pressure warning

light will blink for approximately 1

minute then illuminate and “---” will

be displayed for the inflation pres-

sure of each tire on the multi-infor-

mation display.

9

Drive straight (with occa-
sional left and right turns) at
approximately 25 mph (40
km/h) or more for approxi-
mately 10 to 30 minutes.

When registration is complete, the

tire pressure warning light will turn

off and a message indicating that

registration has been completed

will be displayed on the multi-infor-

mation display.
Registration may take longer than

normal to complete if the vehicle

speed cannot be maintained at

approximately 25 mph (40 km/h) or

more. If registration cannot be com-

pleted after driving for 1 hour or

more, perform the registration pro-

cedure again from the beginning.

10

If the tire inflation pressure of

the wheel set installed differs
from that of the previous set,
it will be necessary to per-
form the tire inflation pres-
sure setting procedure of the
tire pressure warning system.

If the specified tire inflation pres-

sure is the same, it will not be nec-

essary to perform the tire inflation

pressure setting procedure.

■

When registering ID codes

●

Normally, ID codes registration

can be completed within approxi-

mately 30 minutes.

●

ID code registration is performed

while driving at a vehicle speed of

approximately 25 mph (40 km/h)

or more.

■

If ID codes are not registered

easily

●

In the following situations, ID code

registration may take longer than

usual to be completed or may not

be possible.

• When the vehicle has not been

parked for approximately 20 min-

utes or more before being driven

• Vehicle is not driven at approxi-

mately 25 mph (40 km/h) or more

• Vehicle is driven on unpaved

roads

• Vehicle is driven near other vehi-

cles and system cannot recog-

nize tire pressure warning valve

and transmitters of your vehicle

over those of other vehicles

• Wheel with tire pressure warning

valve and transmitter installed is

inside or near the vehicle

●

If the vehicle is reversed during

registration, all data collected until

then will be cleared. Perform driv-

ing again.

●

If the tire pressure warning light

does not blink 3 times when start-

ing ID code registration proce-

dure to step

8

, the procedure may

not have started. Perform the pro-

cedure again from the beginning.

●

If registration does not complete

after driving for 1 hour or more,

perform the ID code registration

procedure again from the begin-

ning.

●

If the ID codes cannot be regis-

tered even when performing the

above procedure, contact your

Toyota dealer.

297

6-3. Do-it-yourself maintenance

6

Maintena

nce
 a

nd ca

re

■

Canceling ID code registration

To cancel ID code registration after

it has been started, select “Register

Valve / ID” again on the multi-infor-

mation display.
If ID code registration has been can-

celed, the tire pressure warning light

will turn off.
If the warning light does not turn off,

ID code registration may not have

been cancelled correctly. To cancel

registration, select “Register Valve /

ID” on the multi-information display.

Your vehicle is equipped with a
tire pressure warning system
with a function to register two
sets of ID codes. This allows for
registration of a second wheel
set, for example a winter set.
The wheel set can be changed
only if a second wheel set has
been registered to the system. If
a second wheel set has not
been registered, it will not be
possible to change to the
selected wheel set.
ID codes can be registered by
yourself.



Only a change between both
registered wheel set is possi-
ble, mixing between these
wheel sets is not supported.



While registering ID codes, it
may not be possible to
change between wheel sets
normally. Cancel registration
before changing between
wheel sets.



4.2-inch display

1

Install the desired wheel set.

2

Select

 of the multi-infor-

mation display and then

press

.

3

Press

 or

 to select

“Vehicle Settings” and then

press

.

4

Press

 or

 to select

“TPWS setting” and then

press

.

5

Press

 or

 to select

“Tire Set Switching” and then

press

.

6

Press

 or

 to select

“Register Valve / ID” and then

press

.

7

Press

 or

 to select

“Tire Set 1” or “Tire Set 2”.

Then press

.

8

Select “OK” and then press

.

The tire pressure warning light will

slowly blink 3 times, a message

indicating that change is occurring

will be displayed, and the wheel set

change will begin.

Wheel set change will begin and

the tire pressure warning light will

blink for 1 minute and then illumi-

nate.
Also, while the change is being per-

formed, “---” will be displayed for

the tire inflation pressure of each

tire on the multi-information display.

Selecting wheel set

298

6-3. Do-it-yourself maintenance

After approximately 2 minutes, the

wheel set change will complete, the

tire pressure warning light will turn

off, and a completion message will

be displayed on the multi-informa-

tion display.
If changing does not complete after

approximately 4 minutes, a mes-

sage indicating that the change

could not be completed will be dis-

played.
Check which wheel set is installed

and perform the change procedure

again from the beginning.

9

If the specified tire inflation
pressure of the wheel set
installed differs from that of
the previous set, it will be
necessary to perform the tire
inflation pressure setting pro-
cedure of the tire pressure
warning system. (



P.290)

If the specified tire inflation pres-

sure is the same, it will not be nec-

essary to perform the tire inflation

pressure setting procedure.

10

Register the position of each

wheel.



7-inch display

1

Install the desired wheel set.

2

Select

 of the multi-infor-

mation display and then

press

.

3

Press

 or

 to select

“Vehicle Settings” and then

press

.

4

Press

 or

 to select

“TPWS setting” and then

press

.

5

Press

 or

 to select

“Tire Set Switching” and then

press

.

6

Press

 or

 to select

“Register Valve / ID” and then

press

.

7

Press

 or

 to select

“Tire Set 1” or “Tire Set 2”.

Then press

.

8

Select “OK” and then press

.

The tire pressure warning light will

slowly blink 3 times, a message

indicating that change is occurring

will be displayed, and the wheel set

change will begin.

Wheel set change will begin and

the tire pressure warning light will

blink for 1 minute and then illumi-

nate.
Also, while the change is being per-

formed, “---” will be displayed for

the tire inflation pressure of each

tire on the multi-information display.
After approximately 2 minutes, the

wheel set change will complete, the

tire pressure warning light will turn

off, and a completion message will

be displayed on the multi-informa-

tion display.
If changing does not complete after

approximately 4 minutes, a mes-

299

6-3. Do-it-yourself maintenance

6

Maintena

nce
 a

nd ca

re

sage indicating that the change

could not be completed will be dis-

played.
Check which wheel set is installed

and perform the change procedure

again from the beginning.

9

If the specified tire inflation
pressure of the wheel set
installed differs from that of
the previous set, it will be
necessary to perform the tire
inflation pressure setting pro-
cedure of the tire pressure
warning system. (



P.290)

If the specified tire inflation pres-

sure is the same, it will not be nec-

essary to perform the tire inflation

pressure setting procedure.

10

Register the position of each

wheel.

The recommended cold tire
inflation pressure and tire size
are displayed on the tire and
loading information label.
(



P.370)

Tire valve

Tire inflation pressure

Checking the specified
tire inflation pressure

Inspection and adjust-
ment procedure

300

6-3. Do-it-yourself maintenance

Tire pressure gauge

1

Remove the tire valve cap.

2

Press the tip of the tire pres-
sure gauge onto the tire
valve.

3

Read the pressure using the
gauge gradations.

4

If the tire inflation pressure is
not at the recommended
level, adjust the pressure.
If you add too much air, press
the center of the valve to
deflate.

5

After completing the tire infla-
tion pressure measurement
and adjustment, apply soapy
water to the valve and check
for leakage.

6

Put the tire valve cap back
on.

■

Tire inflation pressure check

interval

You should check tire inflation pres-

sure every two weeks, or at least

once a month. Do not forget to

check the spare.

■

Effects of incorrect tire inflation

pressure

Driving with incorrect tire inflation

pressure may result in the following:

●

Reduced fuel economy

●

Reduced driving comfort and poor

handling

●

Reduced tire life due to wear

●

Reduced safety

●

Damage to the drive train

If a tire needs frequent inflating,

have it checked by your Toyota

dealer.

■

Instructions for checking tire

inflation pressure

When checking tire inflation pres-

sure, observe the following:

●

Check only when the tires are

cold.

If your vehicle has been parked for

at least 3 hours or has not been

driven for more than 1 mile or 1.5

km, you will get an accurate cold

tire inflation pressure reading.

●

Always use a tire pressure gauge.

It is difficult to judge if a tire is

properly inflated based only on its

appearance.

●

It is normal for the tire inflation

pressure to be higher after driving

as heat is generated in the tire. Do

not reduce tire inflation pressure

after driving.

●

Never exceed the vehicle capacity

weight.

Passengers and luggage weight

should be placed so that the vehi-

cle is balanced.

WARNING

■

Proper inflation is critical to

save tire performance

Keep your tires properly inflated.

If the tires are not properly

inflated, the following conditions

may occur which could lead to an

accident resulting in death or seri-

ous injury:

●

Excessive wear

●

Uneven wear

●

Poor handling

●

Possibility of blowouts resulting

from overheated tires

●

Air leaking from between tire

and wheel

●

Wheel deformation and/or tire

damage

301

6-3. Do-it-yourself maintenance

6

Maintena

nce
 a

nd ca

re

When replacing wheels, care
should be taken to ensure that
they are equivalent to those
removed in load capacity, diam-
eter, rim width and inset

*

.

Replacement wheels are avail-
able at your Toyota dealer.

*

: Conventionally referred to as off-

set.

Toyota does not recommend
using the following:



Wheels of different sizes or
types



Used wheels



Bent wheels that have been
straightened

■

When replacing wheels

The wheels of your vehicle are

equipped with tire pressure warning

valves and transmitters that allow

the tire pressure warning system to

provide advance warning in the

event of a loss in tire inflation pres-

sure. Whenever wheels are

replaced, the tire pressure warning

valves and transmitters must be

installed. (



P.287)

WARNING

●

Greater possibility of tire dam-

age while driving (due to road

hazards, expansion joints,

sharp edges on the road, etc.)

NOTICE

■

When inspecting and adjust-

ing tire inflation pressure

Be sure to put the tire valve caps

back on.

If a valve cap is not installed, dirt

or moisture may get into the valve

and cause an air leak, resulting in

decreased tire inflation pressure.

Wheels

If a wheel is bent, cracked or
heavily corroded, it should
be replaced. Otherwise, the
tire may separate from the
wheel or cause a loss of
handling control.

Wheel selection

302

6-3. Do-it-yourself maintenance



Use only Toyota wheel nuts
and wheel nut wrenches
designed for use with your
aluminum wheels.



When rotating, repairing or
changing your tires, check
that the wheel nuts are still
tight after driving 1000 miles
(1600 km).



Be careful not to damage the
aluminum wheels when using
tire chains.



Use only Toyota genuine bal-
ance weights or equivalent
and a plastic or rubber ham-
mer when balancing your
wheels.

WARNING

■

When replacing wheels

●

Do not use wheels that are a dif-

ferent size from those recom-

mended in the Owner’s Manual,

as this may result in a loss of

handling control.

●

Never use an inner tube in a

leaking wheel which is designed

for a tubeless tire.

Doing so may result in an acci-

dent, causing death or serious

injury.

■

When installing the wheel

nuts

●

Be sure to install the wheel nuts

with the tapered ends facing

inward. (



P.351) Installing the

nuts with the tapered ends fac-

ing outward can cause the

wheel to break and eventually

cause the wheel to come off

while driving, which could lead

to an accident resulting in death

or serious injury.

●

Never use oil or grease on the

wheel bolts or wheel nuts.

Oil and grease may cause the

wheel nuts to be excessively

tightened, leading to bolt or disc

wheel damage. In addition, the

oil or grease can cause the

wheel nuts to loosen and the

wheel may fall off, causing an

accident and resulting in death

or serious injury. Remove any

oil or grease from the wheel

bolts or wheel nuts.

■

Use of defective wheels pro-

hibited

Do not use cracked or deformed

wheels. Doing so could cause the

tire to leak air during driving, pos-

sibly causing an accident.

NOTICE

■

Replacing tire pressure warn-

ing valves and transmitters

●

Because tire repair or replace-

ment may affect the tire pres-

sure warning valves and

transmitters, make sure to have

tires serviced by your Toyota

dealer or other qualified service

shop. In addition, make sure to

purchase your tire pressure

warning valves and transmit-

ters at your Toyota dealer.

●

Ensure that only genuine Toyota

wheels are used on your vehi-

cle.

Tire pressure warning valves

and transmitters may not work

properly with non-genuine

wheels.

Aluminum wheel precau-
tions

303

6-3. Do-it-yourself maintenance

6

Maintena

nce
 a

nd ca

re

1

Turn the engine switch off.

2

Open the glove box. Slide off
the damper.

3

Push in the glove box on the
vehicle’s outer side to discon-
nect the claws. Then pull out
the glove box and disconnect
the lower claws.

4

Unlock the filter cover ( ),
pull the filter cover out of the

claws ( ), and remove the
filter cover.

5

Remove the filter case.

6

Remove the air conditioning
filter from the filter case and
replace it with a new one.

The “

UP” marks shown on the

filter and the filter case should be

pointing up.

■

Checking interval

Inspect and replace the air condi-

tioning filter according to the mainte-

nance schedule. In dusty areas or

areas with heavy traffic flow, more

Air conditioning filter

The air conditioning filter
must be changed regularly
to maintain air conditioning
efficiency.

Removing the air condi-
tioning filter
