Toyota Camry (2023 year). Manual in english

129

2. Instrument cluster

Instru

me
nt clu

ster

Select

on the multi-information display (



P. 117) and then

◆

Enabling/disabling the head-up display

Press

to enable/disable the head-up display.

◆

Changing the head-up display settings

Press and hold

to change the following settings:

■

Eco Driving Indicator/Tachometer

Select to display Eco Driving Indicator/tachometer/no content.

■

Display brightness/position

Select to adjust the brightness and position of the head-up display.

■

Display content

Select to enable/disable the following items:

• Route guidance to destination (if equipped)
• Driving assist system status
• Compass (if equipped)

■

Display angle

Select to adjust the angle of the head-up display.

Using the head-up display

130

2. Instrument cluster

◆

Driving assist system status display

Displays the operational status of the following systems:

• Dynamic radar cruise control with full-speed range (



P. 290)

• LTA (Lane Tracing Assist) (



P. 270)

• RSA (Road Sign Assist) (if equipped) (



P. 285)

• Intuitive parking assist (if equipped) (



P. 336)

◆

Navigation system-linked display area (if equipped)

Displays the following items, which are linked to the navigation sys-
tem:

■

Street name

When the navigation system is performing route guidance, the
name of the next street will be displayed on the top of the display
area.

■

Route guidance to destination

Displayed when the navigation system is performing route guid-
ance. When approaching an intersection, an arrow will be displayed
to indicate the suggested direction of travel.

■

Compass

Displays the direction of travel.

Driving assist system status/navigation system-linked display
area (if equipped)

131

2. Instrument cluster

Instru

me
nt clu

ster

■

Eco Driving Indicator

Eco Driving Indicator Zone
Display
Eco driving ratio based on
acceleration
Zone of Eco driving

Displayed content is the same
as that displayed on the multi-
information display (Eco Driving
Indicator). For details, refer to
P. 126.

■

Tachometer

Displays the engine speed in revolutions per minute.

Displays the following items in the appropriate situation:

■

Warning/Message

●

Alert from the LTA (Lane Tracing Assist)

●

Dynamic radar cruise control with full-speed range

●

Brake Override System/Drive-Start Control

●

message

Displayed when a suggestion/advice pop-up display is displayed on the
multi-information display. (



P. 125)

●

message

Displayed when a warning message is displayed on the multi-informa-
tion display. (



P. 538)

●

Outside temperature

Displayed in the following situations:

• When the engine switch is turned to IGNITION ON mode
• When the low outside temperature indicator is flashing

Displayed content is the same as that displayed on the multi-information
display. For details, refer to the explanation of the outside temperature
display on the multi-information display. (



P. 94)

■

Hands-free system status

Displayed when the hands-free system is operated.

■

Audio system operation status

Displayed when the audio system is operated.

Eco Driving Indicator/Tachometer

Information display area

132

2. Instrument cluster

■

Head-up display

The head-up display may seem dark or hard to see when viewed through
sunglasses, especially polarized sunglasses.
Adjust the brightness of the head-up display or remove your sunglasses.

■

Display brightness

The brightness of the head-up display can be adjusted on

of the multi-

information display. Also, it is automatically adjusted according to the ambient
brightness.

■

Enabling/disabling of the head-up display

If the head-up display is disabled, it will remain disabled when the engine
switch is turned off then back to IGNITION ON mode.

■

Street name display (vehicles with a navigation system)

Only street names which are included in the map data will be displayed.

WARNING

■

Before using the head-up display

●

Check that the position and brightness of the head-up display image does
not interfere with safe driving. Incorrect adjustment of the image’s position
or brightness may obstruct the driver’s view and lead to an accident,
resulting in death or serious injury.

●

Do not continuously look at the head-up display while driving as you may
fail to see pedestrians, objects on the road, etc. ahead of the vehicle.

■

Caution for changing settings of the head-up display

As the engine needs to be running while changing the settings of the head-
up display, ensure that the vehicle is parked in a place with adequate venti-
lation. In a closed area such as a garage, exhaust gases including harmful
carbon monoxide (CO) may collect and enter the vehicle. This may lead to
death or a serious health hazard.

133

2. Instrument cluster

Instru

me
nt clu

ster

NOTICE

■

To prevent damage to components

■

When changing the settings of the head-up display

To prevent battery discharge, ensure that the engine is running while the
changing the settings of the head-up display.

●

Do not place any drinks near the head-
up display projector. If the projector gets
wet, electrical malfunctions may result.

●

Do not place anything on or put stickers
onto the head-up display projector.
Doing so could interrupt head-up dis-
play indications.

●

Do not touch the inside of the head-up
display projector or thrust sharp edges
or the like into the projector.
Doing so could cause mechanical mal-
functions.

135

2. Instrument cluster

Instru

me
nt clu

ster



Audio (vehicles with Data Communication Module), Audio Plus
(vehicles with Data Communication Module) and Premium Audio

Press the “MENU” button.
Select “Info” on the “Menu”
screen.
Select “ECO” on the “Informa-
tion” screen.

If the “History” screen is displayed,
select “Trip Information”.

Resetting the consumption data
Average vehicle speed since
the engine was started
Elapsed time since the engine
was started
Fuel consumption in the past 15
minutes
Cruising range (



P. 137)

Current fuel consumption

Vehicles without a smart key system:
Average fuel consumption for the past 15 minutes is divided by color
into past averages and averages attained since the engine switch was
last turned to the “ON” position. Use the displayed average fuel con-
sumption as a reference.
Vehicles with a smart key system:
Average fuel consumption for the past 15 minutes is divided by color
into past averages and averages attained since the engine switch was
last turned to IGNITION ON mode. Use the displayed average fuel
consumption as a reference.

This image is an example only.

136

2. Instrument cluster



Audio (vehicles without Data Communication Module) or Audio
Plus (vehicles without Data Communication Module)
Press the “MENU” button.
Select “Info” on the “Menu” screen.

If the “Trip Information” screen is displayed, select “History”.



Audio (vehicles with Data Communication Module), Audio Plus
(vehicles with Data Communication Module) and Premium Audio
Press the “MENU” button.
Select “Info” on the “Menu” screen.
Select “ECO” on the “Information” screen.

If the “Trip Information” screen is displayed, select “History”.

Resetting the past record data
Best recorded fuel consumption
Current fuel economy
Previous

fuel

consumption

record



Audio and Audio Plus

Displays the daily average fuel
consumption. (Instead of the date,
“Trip 1” through “Trip 5” will be dis-
played.)



Premium Audio

Displays the daily average fuel consumption.

Updating the average fuel consumption data

The average fuel consumption history is divided by color into past
averages and the average fuel consumption since the last updated.
Use the displayed average fuel consumption as a reference.

This image is an example only.

History

137

2. Instrument cluster

Instru

me
nt clu

ster

■

Updating the past record data

Update the average fuel consumption by selecting “Clip” to measure the cur-
rent fuel consumption again.

■

Resetting the data

The fuel consumption data can be deleted by selecting “Clear”.

■

Cruising range

Displays the estimated maximum distance that can be driven with the quan-
tity of fuel remaining.
This distance is computed based on your average fuel consumption.
As a result, the actual distance that can be driven may differ from that dis-
played.

140

3-1. Key information

The following keys are provided with the vehicle.



Vehicles without a smart key system

Keys

Operating the wireless remote con-
trol function (



P. 141)

Key number plate



Vehicles with a smart key system

Electronic keys

• Operating the smart key system

(



P. 161)

• Operating the wireless remote

control function (



P. 141)

Mechanical keys
Key number plate

Keys

The keys

141

3-1. Key information

Op
eration

f each

compo

nen
t



Vehicles without a smart key system

Locks all the doors (



P. 148)

Unlocks all the doors (



P. 148)

Pressing the button unlocks the
driver’s door. Pressing the button
again within 3 seconds unlocks the
other doors.

Opens the windows

and the

moon roof

1, 2

(



P. 148)

Opens the trunk (



P. 157)

Sounds the alarm (



P. 143)

: This setting must be customized at your Toyota dealer.

: If equipped



Vehicles with a smart key system

Locks all the doors (



P. 148)

Unlocks all the doors (



P. 148)

Pressing the button unlocks the
driver’s door. Pressing the button
again within 3 seconds unlocks the
other doors.

Opens the windows

and the

moon roof

1, 2

or panoramic

moon roof

1, 2

(



P. 148)

Opens the trunk (



P. 157)

Sounds the alarm (



P. 143)

: This setting must be customized at your Toyota dealer.

: If equipped

Wireless remote control

142

3-1. Key information

Releasing

To release the key, press the but-
ton.

Folding

To stow the key, press the button
then fold the key.

To take out the mechanical key,
slide the release lever and take
the key out.

The  mechanical  key  can  only  be
inserted  in  one  direction,  as  the
key only has grooves on one side.
If  the  key  cannot  be  inserted  in  a
lock  cylinder,  turn  it  over  and  re-
attempt to insert it.
After  using  the  mechanical  key,  store  it  in  the  electronic  key.  Carry  the
mechanical key together with the electronic key. If the electronic key bat-
tery  is  depleted  or  the  entry  function  does  not  operate  properly,  you  will
need the mechanical key. (



P. 559)

Using the key (vehicles without a smart key system)

Using the mechanical key (vehicles with a smart key system)

143

3-1. Key information

Op
eration

f each

compo

nen
t

■

Panic mode



Vehicles without a smart key system



Vehicles with a smart key system

When

is pressed for longer than

about  one  second,  an  alarm  will  sound
intermittently  and  the  vehicle  lights  will
flash  to  deter  any  person  from  trying  to
break into or damage your vehicle.
To stop the alarm, press any button on the
wireless remote control.

When

is pressed for longer than

144

3-1. Key information

■

If you lose your keys

New genuine keys can be made by your Toyota dealer using the other key
(vehicles without a smart key system) or the other mechanical key (vehicles
with a smart key system) and the key number stamped on your key number
plate. Keep the plate in a safe place such as your wallet, not in the vehicle.

■

When riding in an aircraft

When bringing a key with wireless remote control function onto an aircraft,
make sure you do not press any button on the key while inside the aircraft
cabin. If you are carrying the key in your bag etc., ensure that the buttons are
not likely to be pressed accidentally. Pressing a button may cause the key to
emit radio waves that could interfere with the operation of the aircraft.

■

Conditions affecting operation



Vehicles without a smart key system

The wireless remote control function may not operate normally in the follow-
ing situations:

●

When the wireless key battery is depleted

●

Near a TV tower, electric power plant, gas station, radio station, large dis-
play, airport or other facility that generates strong radio waves or electrical
noise

●

When carrying a portable radio, cellular phone or other wireless communi-
cation devices

●

When the wireless key is in contact with, or is covered by a metallic object

●

When other wireless key (that emit radio waves) is being used nearby

●

If window tint with a metallic content or metallic objects are attached to the
rear window



Vehicles with a smart key system



P. 163

145

3-1. Key information

Op
eration

f each

compo

nen
t

■

Key battery depletion



Vehicles without a smart key system

●

The standard battery life is 1 to 2 years.

●

Even if the key is not used, the battery may become depleted and the fol-
lowing symptoms may occur. Replace the battery with a new one when nec-
essary. (



P. 494)

• The wireless remote control function does not operate.
• The area in which the wireless remote control function can be operated

becomes smaller.



Vehicles with a smart key system

●

The standard battery life is 1 to 2 years.

●

If the battery becomes low, an alarm will sound in the cabin when the engine
stops.

●

As the electronic key always receives radio waves, the battery will become
depleted even if the electronic key is not used. The following symptoms indi-
cate that the electronic key battery may be depleted. Replace the battery
when necessary. (



P. 494)

• The smart key system or the wireless remote control does not operate.
• The detection area becomes smaller.
• The LED indicator on the key surface does not turn on.

●

To reduce key battery depletion when the electronic key is to not be used for
long periods of time, set the electronic key to the battery-saving mode.
(



P. 163)

●

To avoid serious deterioration, do not leave the electronic key within 3 ft. (1
m) of the following electrical appliances that produce a magnetic field:
• TVs
• Personal computers
• Cellular phones, cordless phones and battery chargers
• Recharging cellular phones or cordless phones
• Table lamps
• Induction cookers

■

Replacing the battery



P. 494

■

Confirmation of the registered key number

The number of keys already registered to the vehicle can be confirmed. Ask
your Toyota dealer for details.

■

If a wrong key is used

The key cylinder rotates freely to isolate inside mechanism.

Toyota Camry (2023 year). Manual in english - page 8
