Toyota 4Runner (2023 year). Manual in english - page 30

484

7-2. Steps to take in an emergency

■

When the tire pressure warning light comes on

Inspect the appearance of the tire to check that the tire is not punctured.
If the tire is punctured:



P. 493

If the tire is not punctured:

Carry out the following procedure after the tire temperature has lowered

sufficiently.

●

Check the tire inflation pressure and adjust to the appropriate level.

●

If the warning light does not go out even after several minutes, check

that the tire inflation pressure is at the specified level and carry out ini-

tialization. (



P. 429)

The warning light may come on again if the above operations are con-

ducted without first allowing the tire temperature to lower sufficiently.

■

The tire pressure warning light may come on due to natural causes

The tire pressure warning light may come on due to natural causes such

as natural air leaks and tire inflation pressure changes caused by tem-

perature. In this case, adjusting the tire inflation pressure will turn off the

warning light (after a few minutes).

■

When a tire is replaced with a spare tire



Vehicles without P245/60R20 tires

The spare tire is not equipped with a tire pressure warning valve and

transmitter. If a tire goes flat, the tire pressure warning light will not turn off

even though the flat tire has been replaced with the spare tire. Replace

the spare tire with the repaired tire and adjust the tire inflation pressure.

The tire pressure warning light will go off after a few minutes.



Vehicles with P245/60R20 tires

The spare tire is also equipped with a tire pressure warning valve and

transmitter. The tire pressure warning light will turn on if the tire inflation

pressure of the spare tire is low. If a tire goes flat, the tire pressure warn-

ing light will not turn off even though the flat tire has been replaced with

the spare tire. Replace the spare tire with the repaired tire and adjust the

tire inflation pressure. The tire pressure warning light will go off after a few

minutes.

485

7-2. Steps to take in an emergency

Wh
en tro

uble

ris

■

If the tire pressure warning system is not functioning

The tire pressure warning system will be disabled in the following condi-

tions:
(When the condition becomes normal, the system will work properly.)

●

If tires not equipped with tire pressure warning valves and transmitters

are used

●

If the ID code on the tire pressure warning valves and transmitters is not

registered in the tire pressure warning computer

●

If the tire inflation pressure is 73 psi (500 kPa, 5.1 kgf/cm

or bar) or

higher

The tire pressure warning system may be disabled in the following condi-

tions:
(When the condition becomes normal, the system will work properly.)

●

If electronic devices or facilities using similar radio wave frequencies are

nearby

●

If a radio set at a similar frequency is in use in the vehicle

●

If a window tint that affects the radio wave signals is installed

●

If there is a lot of snow or ice on the vehicle, particularly around the

wheels or wheel housings

●

If non-genuine Toyota wheels are used (Even if you use Toyota wheels,

the tire pressure warning system may not work properly with some types

of tires.)

●

If tire chains are used

●

Vehicles with P245/60R20 tires: If the spare tire is in a location subject

to poor radio wave signal reception

●

Vehicles with P245/60R20 tires: If a large metallic object which can

interfere with signal reception is put in the luggage compartment

■

If the tire pressure warning light frequently comes on after blinking

for 1 minute

If the tire pressure warning light frequently comes on after blinking for 1

minute when the engine switch is turned on, have it checked by your

Toyota dealer.

■

Customization that can be configured at Toyota dealer

The vehicle speed linked seat belt reminder buzzer can be disabled.
(Customizable features



P. 549) However, Toyota recommends that the seat

belt reminder buzzer be operational to alert the driver and front passenger
when seat belts are not fastened.

486

7-2. Steps to take in an emergency

WARNING

■

If the tire pressure warning light comes on

Be sure to observe the following precautions. Failure to do so could

cause a loss of vehicle control and result in death or serious injury.

●

Stop your vehicle in a safe place as soon as possible. Adjust the tire

inflation pressure immediately.

●

If the tire pressure warning light comes on even after tire inflation pres-

sure adjustment, it is probable that you have a flat tire. Check the tires.

If a tire is flat, change it with the spare tire and have the flat tire

repaired by the nearest Toyota dealer.

●

Avoid abrupt maneuvering and braking. If the vehicle tires deteriorate,

you could lose control of the steering wheel or the brakes.

■

If a blowout or sudden air leakage should occur

The tire pressure warning system may not activate immediately.

■

Maintenance of the tires

Each tire, including the spare (if provided), should be checked monthly

when cold and inflated to the inflation pressure recommended by the

vehicle manufacturer on the vehicle placard or tire inflation pressure

label (tire and load information label). (If your vehicle has tires of a dif-

ferent size than the size indicated on the vehicle placard or tire inflation

pressure label [tire and load information label], you should determine

the proper tire inflation pressure for those tires.)
As an added safety feature, your vehicle has been equipped with a tire

pressure monitoring system (TPMS-tire pressure warning system) that

illuminates a low tire pressure telltale (tire pressure warning light) when

one or more of your tires is significantly under-inflated. Accordingly,

when the low tire pressure telltale (tire pressure warning light) illumi-

nates, you should stop and check your tires as soon as possible, and

inflate them to the proper pressure. Driving on a significantly under-

inflated tire causes the tire to overheat and can lead to tire failure.

Under-inflation also reduces fuel efficiency and tire tread life, and may

affect the vehicle’s handling and stopping ability.
Please note that the TPMS (tire pressure warning system) is not a sub-

stitute for proper tire maintenance, and it is the driver’s responsibility to

maintain correct tire pressure, even if under-inflation has not reached

the level to trigger illumination of the TPMS low tire pressure telltale (tire

pressure warning light).

487

7-2. Steps to take in an emergency

Wh
en tro

uble

ris

WARNING

Your vehicle has also been equipped with a TPMS (tire pressure warn-

ing system) malfunction indicator to indicate when the system is not

operating properly. The TPMS (tire pressure warning system) malfunc-

tion indicator is combined with the low tire pressure telltale (tire pressure

warning light). When the system detects a malfunction, the telltale will

flash for approximately one minute and then remain continuously illumi-

nated. This sequence will continue upon subsequent vehicle start-ups

as long as the malfunction exists. When the malfunction indicator is illu-

minated, the system may not be able to detect or signal low tire pres-

sure as intended.
TPMS (tire pressure warning system) malfunctions may occur for a vari-

ety of reasons, including the installation of replacement or alternate tires

or wheels on the vehicle that prevent the TPMS (tire pressure warning

system) from functioning properly. Always check the TPMS (tire pres-

sure warning system) malfunction telltale after replacing one or more

tires or wheels on your vehicle to ensure that the replacement or alter-

nate tires and wheels allow the TPMS (tire pressure warning system) to

continue to function properly.

NOTICE

■

To ensure the tire pressure warning system operates properly

Do not install tires with different specifications or makers, as the tire

pressure warning system may not operate properly.

488

7-2. Steps to take in an emergency

Master warning light

The  master  warning  light  also
comes  on  or  flashes  in  order  to
indicate  that  a  message  is  cur-
rently being displayed on the multi-
information display.

Multi-information display
Handling method

Follow the instructions of the mes-
sage on the multi-information dis-
play.

If any of the warning messages are shown again after the following
actions have been performed, contact your Toyota dealer.

If a warning message is displayed

The multi-information display shows warnings of system mal-
functions, incorrectly performed operations, and messages that
indicate a need for maintenance. When a message is shown,
perform the correction procedure appropriate to the message.

489

7-2. Steps to take in an emergency

Wh
en tro

uble

ris

The warning lights and warning buzzers operate as follows depending
on the content of the message. If a message indicates the need for
inspection by a dealer, have the vehicle inspected by your Toyota
dealer immediately.

The operation of the warning lights and warning buzzers may differ
from those stated. in this case, perform the correction procedure
according to the displayed message.

: A buzzer sounds the first time a message is shown on the multi-informa-

tion display.

Messages and warnings

System

warning

light

Warning

buzzer

Warning

Comes on Comes on

Sounds

Indicates an important situation, such
as when a system related to driving is
malfunctioning or that danger may
result if the correction procedure is not
performed

Comes on



Sounds



Comes on

or flashes

Sounds

Indicates  an  important  situation,  such
as  when  the  systems  shown  on  the
multi-information  display  may  be  mal-
functioning

Flashes



Sounds

Indicates a situation, such as when
damage to the vehicle or danger may
result

Comes on



Does not

sound

Indicates a condition, such as mal-
function of electrical components, their
condition, or indicates the need for
maintenance

Flashes



Does not

sound

Indicates a situation, such as when an
operation has been performed incor-
rectly, or indicates how to perform an
operation correctly

490

7-2. Steps to take in an emergency

■

Warning messages

The warning messages explained below may differ from the actual messages
according to operation conditions and vehicle specifications.

■

System warning lights

The master warning light does not come on or flash in the following cases.
Instead, a separate system warning light will come on along with a message
or image shown on the multi-information display.

●

Malfunction in the ABS
The ABS warning light comes on. (



P. 478)

●

Indicates that the PCS (Pre-Collision System) is not currently functional
The PCS warning light comes on or flashes. (



P. 481)

●

Malfunction in the tire pressure warning system
The tire pressure warning light comes on. (



P. 481)

■

If a message instructing to refer to the Owner’s Manual is displayed

●

If the following message is shown, there may be a malfunction.
Immediately stop the vehicle in a safe place and contact your Toyota dealer.
Continuing to drive the vehicle may be dangerous.
• “Braking Power Low Stop in a Safe Place See Owner’s Manual”
• “Oil Pressure Low Stop in a Safe Place See Owner’s Manual”

●

If “Engine Coolant Temp High Stop in a Safe Place See Owner’s Manual” is
displayed, follow the instructions accordingly. (



P. 519)

●

If “Front Camera Unavailable See Owner’s Manual” is displayed, follow the
instructions accordingly. (



P. 237, 488)

●

If the following message is shown, there may be a malfunction.
Immediately have the vehicle inspected by your Toyota dealer.
• “Smart Key System Malfunction See Owner’s Manual”

■

If “High transmission fluid temperature” is shown, it indicates that the
automatic transmission fluid temperature is too high.

Immediately stop the vehicle in a safe place, shift the shift lever to P and wait
until the warning message and light go off. If the warning message and light
go off, you may start the vehicle again. If the warning message and light do
not go off, contact your Toyota dealer.

491

7-2. Steps to take in an emergency

Wh
en tro

uble

ris

■

If “Auto power off to conserve battery” is shown

Power was turned off due to the automatic power off function.
Next time when starting the engine, increase the engine speed slightly and
maintain that level for approximately 5 minutes to recharge the battery.

■

When a message that indicates the need for the shift lever operation is
shown

To prevent the shift lever from being operated incorrectly or the vehicle from
moving unexpectedly, a message that requires shifting the shift lever may be
shown on the multi-information display. In that case, follow the instruction of
the message and shift the shift lever.

■

When “Headlight System Malfunction Visit Your Dealer” is displayed on
the multi-information display

The following system may be malfunctioning. Have the vehicle inspected by
your Toyota dealer.

●

Automatic High Beam

■

If a message that indicates the malfunction of front camera is displayed

The following systems may be suspended until the problem shown in the
message is resolved. (



P. 237, 488)

●

PCS (Pre-Collision System)

●

LDA (Lane Departure Alert)

●

Dynamic radar cruise control

●

Automatic High Beam

■

If a message that indicates the malfunction of radar sensor is displayed

The following systems may be suspended until the problem shown in the
message is resolved. (



P. 237, 488)

●

PCS (Pre-Collision System)

●

LDA (Lane Departure Alert)

●

Dynamic radar cruise control

■

If a following message is shown, take appropriate action and confirm
that the message has disappeared.

●

“Crawl Not Available Select L4 and Shift to [D] or [R] Position”

●

“Crawl Not Available Check System Operation Conditions”

: Refer to the “Off-road Driving Owner’s Manual”.

■

If “Oil Maintenance Required Soon” is displayed (U.S.A. only)

Indicates that all maintenance according to the driven distance on the mainte-
nance schedule

should be performed soon.

Comes on approximately 4500 miles (7200 km) after the message has been
reset.
If necessary, perform maintenance. Please reset the message after the main-
tenance is performed. (



P. 404)

: Refer to the separate “Scheduled Maintenance Guide” or “Owner’s Manual

Supplement” for the maintenance interval applicable to your vehicle.

492

7-2. Steps to take in an emergency

■

If “Oil Maintenance Required” is displayed (U.S.A. only)

Indicates that all maintenance is required to correspond to the driven distance
on the maintenance schedule

Comes on approximately 5000 miles (8000 km) after the message has been
reset.
(The indicator will not work properly unless the message has been reset.)
Perform the necessary maintenance. Please reset the message after the
maintenance is performed. (



P. 404)

: Refer to the separate “Scheduled Maintenance Guide” or “Owner’s Manual

Supplement” for the maintenance interval applicable to your vehicle.

■

If “Visit Your Dealer” is shown

The system or part shown on the multi-information display is malfunctioning.
Have the vehicle inspected by your Toyota dealer immediately.

■

Warning buzzer

In some cases, the buzzer may not be heard due to being in a noisy location
or audio sound.

NOTICE

■

While the engine oil level warning is displayed

Continued engine operation with low engine oil will damage the engine.

493

7-2. Steps to take in an emergency

Wh
en tro

uble

ris

●

Phillips screwdriver

●

Stop the vehicle in a safe place on a hard, flat surface.

●

Set the parking brake.

●

Shift the shift lever to P.

●

Stop the engine.

●

Turn on the emergency flashers. (



P. 466)

If you have a flat tire

Your vehicle is equipped with a spare tire. The flat tire can be
replaced with the spare tire.
For details about tires:



P. 427

WARNING

■

If you have a flat tire

Do not continue driving with a flat tire.
Driving even a short distance with a flat tire can damage the tire and the

wheel beyond repair, which could result in an accident.

You will need the following item:

Before jacking up the vehicle

494

7-2. Steps to take in an emergency

Spare tire
Jack
Tool bag

Location of the spare tire, jack and tools

495

7-2. Steps to take in an emergency

Wh
en tro

uble

ris

WARNING

■

Using the tire jack

Improper use of the tire jack may cause the vehicle to suddenly fall off

the jack, leading to death or serious injury.

●

Do not use the tire jack for any purpose other than replacing tires or

installing and removing tire chains.

●

Only use the tire jack that comes with this vehicle for replacing a flat

tire.

Do not use it on other vehicles, and do not use other tire jacks for

replacing tires on this vehicle.

●

Always check that the tire jack is securely set to the jack point.

●

Do not put any part of your body under the vehicle while it is supported

by the jack.

●

Do not start or run the engine while your vehicle is supported by the

jack.

●

Do not raise the vehicle while someone is inside.

●

When raising the vehicle, do not put an object on or under the jack.

●

Do not raise the vehicle to a height greater than that required to

replace the tire.

●

Use a jack stand if it is necessary to get under the vehicle.



Vehicles with Automatic running boards

●

Observe the following precautions. Failure to do so may result in seri-

ous injury:
• When jacking up the vehicle, always turn the Automatic running

boards switch off.

• When jacking up the vehicle, do not use an Automatic running board

as a jack point. The Automatic running board may break, causing

injuries.

Take particular care when lowering the vehicle to ensure that no one

working on or near the vehicle may be injured.

■

Using the jack handle/wheel nut wrench (used with jack handle)

Tighten all the jack handle bolts securely to prevent the extension parts

from coming apart unexpectedly.

496

7-2. Steps to take in an emergency

Remove the cover.

Unhook and take out the tool
bag.

Take out the jack.

For loosening
For tightening

Taking out the jack and tool bag

497

7-2. Steps to take in an emergency

Wh
en tro

uble

ris

Vehicles without Jack handle: Assembling the wheel nut wrench
(used with jack handle).

Remove the wheel nut wrench and the jack handle extension bar from

the tool bag and assemble by following these steps.

Loosen the bolt using a
wheel nut wrench.

Assemble the jack handle
extension bar and wheel nut
wrench and tighten the bolt.

Check that the bolts are firmly

tightened.

Taking out the spare tire

498

7-2. Steps to take in an emergency

Vehicles with Jack handle: Assembling the jack handle.

Remove the jack handle and the jack handle extension bar from the

tool bag and assembly by following these steps.

Loosen the bolt and the
screw using either the jack
handle or a screwdriver.

Assemble the jack handle
extension bars and tighten
the bolt.

Check that the bolt is firmly

tightened.

Assemble  the  jack  handle
and  the  jack  handle  exten-
sion  bar  and  tighten  the
screw.

Check that the screw is firmly

tightened.

499

7-2. Steps to take in an emergency

Wh
en tro

uble

ris

Insert  the  end  of  the  jack  han-
dle  extension  into  the  lowering
screw  and  turn  it  counterclock-
wise.

Lower the spare tire completely

to the ground.

Pull out the spare tire and
remove the holding bracket.

Content .. 28 29 30 31 ..
