Toyota 4Runner (2023 year). Manual in english

2. Instrument cluster

Instru

me
nt clu

ster

●

Meter settings (



P. 559)

Select to set the following items.

• Language

Select to change the language on the display.

• Units

Select to change the unit for measure.

•

Eco Driving Indicator Light

Select to activate/deactivate the Eco Driving Indicator Light.
(



P. 98)

•

switch settings

You can register 1 screen as the top screen. To register, press

and hold

while the desired screen is displayed.

• Pop-up display

Select to set the pop-up displays (



P. 99), which may appear

in some situations, on/off.

• Initialization

Select to reset the meter display settings.

2. Instrument cluster

■

Multi-terrain Select display

(if equipped)



P. 315

■

Crawl Control display

(if equipped)



P. 312

■

Outside temperature display

Displays the outside temperature

The temperature range that can be displayed is from -40 °F (-40 °C) to
122 °F (50 °C).
When the outside temperature drops below 37 °F (3 °C),

will

flash approximately 10 seconds, then stay on.

■

Customization

Settings (e.g. available language) can be changed.
(Customizable features:



P. 549)

: Automatically displayed when the system is used

■

Eco Driving Indicator

Other contents

Eco Driving Indicator Light
Eco Driving Indicator Zone Display
Suggests  the  Zone  of  Eco  driving  with
current  Eco  driving  ratio  based  on
acceleration.
Eco driving ratio based on acceleration
If the acceleration exceeds Zone of Eco
driving,  the  right  side  of  Eco  Driving
Indicator Zone Display will illuminate.
Zone of Eco driving
Eco  Driving  Indicator  will  not  operate
under the following conditions:
• The shift lever is in any position other

than D.

• The vehicle speed is approximately

80 mph (130 km/h) or higher.

• The Crawl Control is operating. (if

equipped) (



P. 312)

2. Instrument cluster

Instru

me
nt clu

ster

■

Pop-Up display

The pop-up display is displayed on the multi-information display according to
the operating conditions of the following functions:

●

Route guidance display of the navigation system-linked system (if equipped)

●

Incoming call display of the hands-free phone system

The pop-up display function can be disabled.

■

Tire inflation pressure

●

It may take a few minutes to display the tire inflation pressure after the
engine switch is turned to IGNITION ON mode. It may also take a few min-
utes to display the tire inflation pressure after inflation pressure has been
adjusted.

●

“---” may be displayed if the tire information cannot be determined due to
unfavorable radio wave conditions.

●

Tire inflation pressure changes with temperature. The displayed values may
also be different from the values measured using a tire pressure gauge.

■

Outside temperature display

In the following situations, the correct outside temperature may not be dis-
played, or the display may take longer than normal to change:

●

When the vehicle is stopped, or moving at low speeds (less than 12 mph [20
km/h])

●

When the outside temperature has changed suddenly (at the entrance/exit
of a garage, tunnel, etc.)

●

When “--” or “E” is displayed, the system may be malfunctioning. Take your
vehicle to Toyota dealer.

■

Liquid crystal display

Small spots or light spots may appear on the display. This phenomenon is
characteristic of liquid crystal displays, and there is no problem continuing to
use the display.

100

2. Instrument cluster

WARNING

■

Caution for use while driving

For safety, avoid operating the meter control switches while driving as much
as possible, and do not look continuously at the multi-information display
while driving. Stop the vehicle and operate the meter control switches. Fail-
ure to do so may cause a steering wheel operation error, resulting in an
unexpected accident.

■

Cautions while setting up the display

As the engine needs to be running during setting up the display, ensure that
the vehicle is parked in a place with adequate ventilation. In a closed area
such as a garage, exhaust gases including harmful carbon monoxide (CO)
may collect and enter the vehicle. This may lead to death or a serious
health hazard.

■

The multi-information display at low temperatures

Allow the interior of the vehicle to warm up before using the multi-informa-
tion display. At extremely low temperatures, the multi-information display
monitor may respond slowly, and display changes may be delayed.
For example, there is a lag between the driver’s shifting and the new gear
number appearing on the display. This lag could cause the driver to down-
shift again, causing rapid and excessive engine braking and possibly an
accident resulting in death or serious injury.

NOTICE

■

While setting up the display

To prevent battery discharge, ensure that the engine is running while setting
up the display features.

102

3-1. Key information

The following keys are provided with the vehicle.

Electronic keys

• Operating the smart key system

(



P. 113)

• Operating the wireless remote

control function

Mechanical keys
Key number plate

Locks all the doors (



P. 106)

Unlocks all the doors (



P. 106)

Pressing the button unlocks the
driver’s door. Pressing the button
again within 3 seconds unlocks the
other doors.

Opens the windows and moon
roof (press and hold)

Sounds the alarm
(press and hold) (



P. 103)

: This setting must be customized at your Toyota dealer.

Keys

The keys

Wireless remote control

103

3-1. Key information

Op
eration

f each

compo

nen
t

To take out the mechanical key,
push the release button and take
the key out.

The  mechanical  key  can  only  be
inserted  in  one  direction,  as  the
key only has grooves on one side.
If  the  key  cannot  be  inserted  in  a
lock  cylinder,  turn  it  over  and  re-
attempt to insert it.
After  using  the  mechanical  key,  store  it  in  the  electronic  key.  Carry  the
mechanical key together with the electronic key. If the electronic key bat-
tery  is  depleted  or  the  entry  function  does  not  operate  properly,  you  will
need the mechanical key. (



P. 512)

■

Panic mode

■

When required to leave the vehicle’s key with a parking attendant

Lock the glove box as circumstances demand. (



P. 364)

Remove the mechanical key for your own use and provide the attendant with
the electronic key only.

■

If you lose your mechanical keys

New genuine mechanical keys can be made by your Toyota dealer using the
other mechanical key and the key number stamped on your key number
plate. Keep the plate in a safe place such as your wallet, not in the vehicle.

■

When riding in an aircraft

When bringing a key with wireless remote control function onto an aircraft,
make sure you do not press any buttons on the key while inside the aircraft
cabin. If you are carrying the key in your bag etc., ensure that the buttons are
not likely to be pressed accidentally. Pressing a button may cause the key to
emit radio waves that could interfere with the operation of the aircraft.

■

Conditions affecting operation



P. 117

Using the mechanical key

When

is pressed for longer than

about  one  second,  an  alarm  will  sound
intermittently  and  the  vehicle  lights  will
flash  to  deter  any  person  from  trying  to
break into or damage your vehicle.
To stop the alarm, press any button on the
electronic key.

104

3-1. Key information

■

Key battery depletion

●

The standard battery life is 1 to 2 years.

●

If the battery becomes low, an alarm will sound in the cabin when the engine
stops.

●

As the electronic key always receives radio waves, the battery will become
depleted even if the electronic key is not used. The following symptoms indi-
cate that the electronic key battery may be depleted. Replace the battery
when necessary. (



P. 447)

• The smart key system or the wireless remote control does not operate.
• The detection area becomes smaller.
• The LED indicator on the key surface does not turn on.

●

To avoid serious deterioration, do not leave the electronic key within 3 ft. (1
m) of the following electrical appliances that produce a magnetic field:
• TVs
• Personal computers
• Cellular phones, cordless phones and battery chargers
• Recharging cellular phones or cordless phones
• Table lamps
• Induction cookers

■

Precautions when disconnecting the battery

●

In some cases, it may not be possible to unlock the doors using the smart
key system immediately after the battery has been disconnected. Use the
wireless remote control or the mechanical key to lock or unlock the doors.

●

The engine may not start on the first attempt after reconnecting the battery
but will start normally after the second attempt. This is not a malfunction.

●

The engine switch mode is memorized by the vehicle. When the battery is
reconnected, the system will return to the mode it was in before the battery
was disconnected. Before disconnecting the battery, turn the engine switch
off.

If you are unsure what mode the engine switch was in when the battery was
disconnected, be especially careful when reconnecting the battery.

■

Replacing the battery



P. 447

■

Confirmation of the registered key number

The number of keys already registered to the vehicle can be confirmed. Ask
your Toyota dealer for details.

■

If a wrong key is used

The key cylinder rotates freely to isolate inside mechanism.

105

3-1. Key information

Op
eration

f each

compo

nen
t

NOTICE

■

To prevent key damage

●

Do not drop the keys, subject them to strong shocks or bend them.

●

Do not expose the keys to high temperatures for long periods of time.

●

Do not get the keys wet or wash them in an ultrasonic washer etc.

●

Do not attach metallic or magnetic materials to the keys or place the keys
close to such materials.

●

Do not disassemble the keys.

●

Do not attach a sticker or anything else to the surface of the electronic key.

●

Do not place the keys near objects that produce magnetic fields, such as
TVs, audio systems and induction cookers, or medical electrical equip-
ment, such as low-frequency therapy equipment.

■

Carrying the electronic key on your person

Carry the electronic key 3.9 in. (10 cm) or more away from electric appli-
ances that are turned on. Radio waves emitted from electric appliances
within 3.9 in. (10 cm) of the electronic key may interfere with the key, caus-
ing the key to not function properly.

■

In case of a smart key system malfunction or other key-related prob-
lems

Take your vehicle with all the electronic keys provided with your vehicle to
your Toyota dealer.

■

When an electronic key is lost

If the electronic key remains lost, the risk of vehicle theft increases signifi-
cantly. Visit your Toyota dealer immediately with all remaining electronic
keys that was provided with your vehicle.

106

3-1. Key information

◆

Smart key system

Carry the electronic key to enable this function.

Grip the driver’s door handle
to unlock the door. Grip the
passenger’s door handle to
unlock all the doors.

Make sure to touch the sensor
on the back of the handle.
The doors cannot be unlocked
for 3 seconds after the doors are
locked.

Touch the lock sensor (the indentation on the upper part of the
door handle) to lock the doors.

Check that the door is securely locked.

◆

Wireless remote control

Locks all the doors

Check that the door is securely
locked.

Unlocks all the doors

Pressing the button unlocks the
driver's door. Pressing the but-
ton again within 3 seconds
unlocks the other doors.
Press and hold to open the win-
dows and moon roof.

(



P. 156, 163)

: This setting must be customized at your Toyota dealer.

◆

Key

Turning the key operates the doors as follows:
The doors can also be locked and unlocked with the mechanical
key. (



P. 512)

Side doors

Unlocking and locking the doors from the outside

107

3-1. Key information

Op
eration

f each

compo

nen
t

■

Operation signals

A buzzer sounds and the emergency flashers flash to indicate that the doors
have been locked/unlocked. (Locked: once; Unlocked: twice)

■

Security feature

If a door is not opened within approximately 60 seconds after the vehicle is
unlocked, the security feature automatically locks the vehicle again. (How-
ever, depending on the location of the electronic key, the key may be
detected as being in the vehicle. In this case, vehicle may be unlocked.)

■

When the door cannot be locked by the lock sensor on the upper part of
the door handle

■

Door lock buzzer

If an attempt to lock the doors is made when a door is not fully closed, a
buzzer sounds continuously. Fully close the door to stop the buzzer, and lock
the vehicle once more.

■

Alarm (if equipped)

Locking the doors will set the alarm system. (



P. 79)

■

If the smart key system or the wireless remote control does not operate
properly

Use the mechanical key to lock and unlock the doors. (



P. 512)

Replace the battery with a new one if it is depleted. (



P. 447)

If the door will not lock even when the top-
side sensor area is touched, try touching
both the topside and underside sensor
areas at the same time.

108

3-1. Key information

◆

Door lock switches

Locks all the doors
Unlocks all the doors

◆

Inside lock buttons

Locks the door
Unlocks the door

The  front  doors  can  be  opened
by  pulling  the  inside  handle
even  if  the  lock  buttons  are  in
the lock position.

Move the inside lock button to the lock position.
Close the door.
The door cannot be locked if the engine switch is in ACCESSORY
or IGNITION ON mode, or the electronic key is left inside the vehi-
cle. However, the key may not be detected correctly and the door
may be locked.

Unlocking and locking the doors from the inside

Locking the doors from the outside without a key

109

3-1. Key information

Op
eration

f each

compo

nen
t

The door cannot be opened from
inside the vehicle when the lock is
set.

Unlock
Lock

These locks can be set to prevent
children from opening the rear
doors. Push down on each rear
door switch to lock both rear doors.

The following functions can be set or canceled:

For instructions on customizing, refer to P. 549.

Rear door child-protector lock

Automatic door locking and unlocking systems

Function

Operation

Speed linked door locking function

All doors are automatically locked
when vehicle speed is approxi-
mately 12 mph (20 km/h) or higher.

Shift position linked door locking
function

All doors are automatically locked
when shifting the shift lever to posi-
tion other than P.

Shift position linked door unlocking
function

All doors are automatically unlocked
when shifting the shift lever to P.

Driver's door linked door unlocking
function

All doors are automatically unlocked
when driver's door is opened within
10 seconds after turning the engine
switch off.

110

3-1. Key information

■

Setting and canceling the functions

To switch between setting and canceling, follow the procedure
below:

Close all the doors and turn the engine switch to IGNITION ON
mode. (Perform step 2 within 20 seconds.)
Shift the shift lever to P or N,
and press and hold the
driver's door lock switch
(

)

for

approxi-

mately 5 seconds and then
release.

The  shift  lever  and  switch  posi-
tions  corresponding  to  the
desired  function  to  be  set  are
shown in the following table.
Use the same procedure to can-
cel the function.

When the setting or canceling operation is complete, all the doors are
locked and then unlocked.

Function

Shift lever

position

Driver’s door lock switch

position

Shift position linked
door locking function

Shift position linked
door unlocking function

Speed linked door lock-
ing function

Driver's door linked
door unlocking function

111

3-1. Key information

Op
eration

f each

compo

nen
t

■

Switching the door unlock function

It is possible to set which doors the entry function unlocks using the wireless
remote control.

Turn the power switch off.

When the indicator light on the key surface is not on, press and hold
or

for about 5 seconds while pressing and holding

The setting changes each time an operation is performed, as shown below.
(When changing the setting continuously, release the buttons, wait for at least
5 seconds, and repeat step 2.)

■

Rear seat reminder function

In order to remind you not to forget luggage, etc. in the rear seat, when the
engine switch is turned off after any of the following conditions are met, a
buzzer will sound and a message will be displayed on the multi-information
display for approximately 6 seconds.

●

The engine is started within 10 minutes after opening and closing a rear
door.

●

A rear door has been opened and closed after the engine was started.

However, if a rear door is opened and then closed within approximately 2 sec-
onds, the rear seat reminder function may not operate.
The rear seat reminder function determines that luggage, etc. has been
placed in a rear seat based on opening and closing of a rear door. Therefore,
depending on the situation, the rear seat reminder function may not operate
and you may still forget luggage, etc. in the rear seat, or it may operate
unnecessarily.
The rear seat reminder function can be enabled/disabled. (



P. 559)

■

Customization

Settings (e.g. unlocking function using a key) can be changed.
(Customizable features:



P. 549)

Unlocking doors

Beep

Holding the driver's door handle
unlocks only the driver's door.

Exterior: Beeps 3 times
Interior: Beeps once

Holding the front passenger’s door
handle unlocks all the doors.

Holding either front door handle
unlocks all the doors.

Exterior: Beeps twice
Interior: Beeps once

112

3-1. Key information

WARNING

■

To prevent an accident

Observe the following precautions while driving the vehicle.
Failure to do so may result in a door opening and an occupant throwing out
of the vehicle, resulting in death or serious injury.

●

Ensure that all doors are properly closed and locked.

●

Do not pull the inside handle of the doors while driving.
Be especially careful for the front doors, as the doors may be opened even
if the inside lock buttons are in locked position.

●

Set the rear door child-protector locks when children are seated in the rear
seats.

Toyota 4Runner (2023 year). Manual in english - page 6
