Toyota Yaris Cross (2022 year). Manual in english

144

3-3. Adjusting the seats

■

Front seats

Pull the head restraint up.

Down

Push the head restraint down while

pressing the lock release button



Rear center seat without cup
holder

Pull the head restraint up.

Down

Push the head restraint down while

pressing the lock release button



Rear center seat with cup holder

Pull the head restraint up.

Down

Push the head restraint down while

pressing the lock release button

Head restraints

Head restraints are provided
for all seats.

WARNING

■

Head restraint precautions

Observe the following precautions
regarding the head restraints. Failure

to do so may result in death or serious

injury.

●

Use the head restraints designed

for each respective seat.

●

Adjust the head restraints to the

correct position at all times.

●

After adjusting the head restraints,

push down on them and make sure
they are locked in position.

●

Do not drive with the head
restraints removed.

Adjusting a head restraint

145

3-3. Adjusting the seats

Before dri

ving

■

Rear outer seats

Pull the head restraint up.

Down

Push the head restraint down while

pressing the lock release button

■

Adjusting the height of the head

restraints (front seats)

Make sure that the head restraints are

adjusted so that the center of the head

restraint is closest to the top of your
ears.

■

Adjusting the rear center seat head
restraint

Always raise the head restraint one level
from the stowed position when using.

■

Front seats

Pull the head restraint up while
pressing the lock release button

If the head restraint touches the ceiling,
making the removal difficult, adjust the
seatback angle. (



P.141)

■

Rear center seat

Pull the head restraint up while
pressing the lock release button



Rear center seat without cup
holder



Rear center seat with cup holder

Removing the head
restraints

146

3-3. Adjusting the seats

■

Rear outer seats

Pull the seatback lock release

lever

and fold down the

seatback until it reaches the
position where the head
restraints can be removed.

Pull the head restraint up while
pressing the lock release button

■

Front seats

Align the head restraint with the
installation holes and push it down
to the lock position.

Press and hold the lock release button

when lowering the head restraint.

■

Rear center seat

Align the head restraint with the
installation holes and push it down
to the lock position.

Press and hold the lock release button

when lowering the head restraint.



Rear center seat without cup
holder



Rear center seat with cup holder

Installing the head restraints

148

3-4. Adjusting the steering wheel and mirrors

3-4.Adjusting the steering wheel and mirrors

Hold the steering wheel and
push the lever down.

Adjust to the ideal position by
moving the steering wheel hori-
zontally and vertically.

After adjustment, pull the lever up to
secure the steering wheel.

To sound the horn, press on or

close to the

mark.

Steering wheel

Adjustment procedure

WARNING

■

Caution while driving

Do not adjust the steering wheel while

driving.

Doing so may cause the driver to mis-
handle the vehicle and cause an acci-

dent, resulting in death or serious

injury.

■

After adjusting the steering

wheel

Make sure that the steering wheel is
securely locked.

Otherwise, the steering wheel may

move suddenly, possibly causing an
accident, and resulting in death or

serious injury. Also, the horn may not

sound if the steering wheel is not
securely locked.

Horn

149

3-4. Adjusting the steering wheel and mirrors

Before dri

ving

The height of the rear view mirror
can be adjusted to suit your driving
posture.
Adjust the height of the rear view
mirror by moving it up and down.



Manual anti-glare inside rear
view mirror

Reflected light from the headlights
of vehicles behind can be reduced
by operating the lever.

Normal position

Anti-glare position



Auto anti-glare inside rear view
mirror

Responding to the level of bright-
ness of the headlights of vehicles
behind, the reflected light is auto-
matically reduced.
Changing automatic anti-glare
function mode on/off

When the automatic anti-glare function

is in ON mode, the indicator

illumi-

nates. The function will set to ON mode
each time the engine switch is turned to
ON.

Pressing the button turns the function

to off mode. (The indicator

also

turns off.)

Inside rear view mirror

The rear view mirror’s position
can be adjusted to enable suf-
ficient confirmation of the rear
view.

Adjusting the height of rear
view mirror

WARNING

■

Caution while driving

Do not adjust the position of the mir-
ror while driving.

Doing so may lead to mishandling of

the vehicle and cause an accident,
resulting in death or serious injury.

Anti-glare function

150

3-4. Adjusting the steering wheel and mirrors

■

To prevent sensor error (vehicles

with an auto anti-glare inside rear
view mirror)

To ensure that the sensors operate

properly, do not touch or cover them.

To select a mirror to adjust, turn
the switch.

Left

Right

Outside rear view mir-

rors

The rear view mirror’s position
can be adjusted to enable suf-
ficient confirmation of the rear
view.

WARNING

■

Important points while driving

Observe the following precautions

while driving.
Failure to do so may result in loss of

control of the vehicle and cause an

accident, resulting in death or serious
injury.

●

Do not adjust the mirrors while driv-
ing.

●

Do not drive with the mirrors folded.

●

Both the driver and passenger side

mirrors must be extended and prop-
erly adjusted before driving.

Adjustment procedure

151

3-4. Adjusting the steering wheel and mirrors

Before dri

ving

To adjust the mirror, operate the
switch.

Right

Down

Left

■

Mirror angle can be adjusted when

The engine switch is in ACC or ON.

■

When the mirrors are fogged up

The outside rear view mirrors can be

cleared using the mirror defoggers. Turn
on the rear window defogger to turn on

the outside rear view mirror defoggers.

(



P.313, 318)



Manual type

Push the mirror back in the direc-
tion of the vehicle’s rear.



Power type

Folds the mirrors

Extends the mirrors

Putting the outside rear view mirror
folding switch in the neutral position
sets the mirrors to automatic mode.
Automatic mode allows the folding or
extending of the mirrors to be linked to
locking/unlocking of the doors with the
smart entry function or wireless remote
control.

■

Using automatic mode in cold

weather (vehicles with automatic

mode)

When automatic mode is used in cold

weather, the door mirror could freeze up

and automatic stowing and return may
not be possible. In this case, remove

any ice and snow from the door mirror,

then either operate the mirror using
manual mode or move the mirror by

hand.

■

Customization

Some functions can be customized.

WARNING

■

When the mirror defoggers are

operating

Do not touch the rear view mirror sur-
faces, as they can become very hot

and burn you.

Folding and extending the
mirrors

153

3-5. Opening and closing the windows

Before dri

ving

3-5.Opening and closing the windows

: If equipped

The power windows can be opened
and closed using the switches.
Operating the switch moves the
windows as follows:

Closing

One-touch closing

Opening

One-touch opening

: To stop the window partway, operate

the switch in the opposite direction.

■

The power windows can be oper-
ated when

The engine switch is in ON.

■

Operating the power windows after

turning the engine off

The power windows can be operated for

approximately 45 seconds after the

engine switch is turned to ACC or OFF.
They cannot, however, be operated

once either front door is opened.

■

Jam protection function

If an object becomes jammed between
the window and the window frame while

the window is closing, window move-
ment is stopped and the window is

opened slightly.

■

Catch protection function

If an object becomes caught between
the door and window while the window

is opening, window movement is

stopped.

■

When the window cannot be
opened or closed

When the jam protection function or

catch protection function operates
unusually and the side window cannot

be opened or closed, perform the follow-

ing operations with the power window
switch of that door.

●

Stop the vehicle. With the engine
switch in ON, within 4 seconds of the

jam protection function or catch pro-

tection function activating, continu-
ously operate the power window

switch in the one-touch closing direc-

tion or one-touch opening direction so
that the side window can be opened

and closed.

●

If the side window cannot be opened

and closed even when performing the

above operations, perform the follow-
ing procedure for function initializa-

tion.

Turn the engine switch to ON.

Pull and hold the power window

switch in the one-touch closing
direction and completely close the

side window.

Release the power window switch

for a moment, resume pulling the
switch in the one-touch closing

direction, and hold it there for

approximately 6 seconds or more.

Press and hold the power window
switch in the one-touch opening

direction. After the side window is

completely opened, continue holding
the switch for an additional 1 second

or more.

Release the power window switch

for a moment, resume pushing the
switch in the one-touch opening

Power windows

Opening and closing the
power windows

154

3-5. Opening and closing the windows

direction, and hold it there for
approximately 4 seconds or more.

Pull and hold the power window

switch in the one-touch closing

direction again. After the side win-
dow is completely closed, continue

holding the switch for a further 1 sec-

ond or more.

If you release the switch while the win-

dow is moving, start again from the

beginning.
If the window reverses and cannot be

fully closed or opened, have the vehicle

inspected by any authorized Toyota
retailer or Toyota authorized repairer, or

any reliable repairer.

■

Door lock linked window operation

●

The power windows can be opened
and closed using the key (vehicles

without a smart entry & start system)
or mechanical key (vehicles with a
smart entry & start system).

(



P.120,

437)

●

The power windows can be opened
and closed using the wireless remote
control.

(



P.119)

: These settings must be customized at

any authorized Toyota retailer or
Toyota authorized repairer, or any reli-
able repairer.

■

Customization

Some functions can be customized.
(



P.457)

WARNING

Observe the following precautions.

Failure to do so may result in death or
serious injury.

■

Closing the windows

●

The driver is responsible for all the

power window operations, including
the operation for the passengers. In

order to prevent accidental opera-

tion, especially by a child, do not let
a child operate the power windows.

It is possible for children and other

passengers to have body parts
caught in the power window. Also,

when riding with a child, it is recom-

mended to use the window lock
switch. (



P.155)

●

Check to make sure that all passen-
gers do not have any part of their

body in a position where it could be

caught when a window is being
operated.

●

When using the wireless remote
control, key or mechanical key and

operating the power windows, oper-

ate the power window after check-
ing to make sure that there is no

possibility of any passenger having

any of their body parts caught in the
window. Also do not let a child oper-

ate window by the wireless remote

control, key or mechanical key. It is
possible for children and other pas-

sengers to get caught in the power

window.

●

When exiting the vehicle, turn the

engine switch off, carry the key and
exit the vehicle along with the child.

There may be accidental opera-

tion, due to mischief, etc., that may
possibly lead to an accident.

155

3-5. Opening and closing the windows

Before dri

ving

This function can be used to pre-
vent children from accidentally
opening or closing a passenger
window.
Press the switch.

The indicator

will come on and the

passenger windows will be locked.
The passenger windows can still be
opened and closed using the driver’s
switch even if the lock switch is on.

■

The window lock switch can be

operated when

The engine switch is in ON.

■

When the battery is disconnected

The window lock switch is disabled. If

necessary, press the window lock switch
after reconnecting the battery.

WARNING

■

Jam protection function

●

Never use any part of your body to
intentionally activate the jam pro-

tection function.

●

The jam protection function may not

work if something gets jammed just

before the window is fully closed.
Be careful not to get any part of

your body jammed in the window.

■

Catch protection function

●

Never use any part of your body or

clothing to intentionally activate the
catch protection function.

●

The catch protection function may
not work if something gets caught

just before the window is fully

opened. Be careful not to get any
part of your body or clothing caught

in the window.

Preventing accidental opera-
tion (window lock switch)

157

riv

ing

Driving

4-1. Before driving

Driving the vehicle ............

158

Cargo and luggage ...........

165

Trailer towing ....................

167

4-2. Driving procedures

Engine (ignition) switch (vehi-

cles without a smart entry &
start system)...................

173

Engine (ignition) switch (vehi-

cles with a smart entry & start
system)...........................

174

Multidrive ..........................

179

Manual transmission.........

183

Turn signal lever ...............

186

Parking brake ...................

186

Brake Hold........................

190

4-3. Operating the lights and wip-

ers

Headlight switch ...............

192

AHS (Adaptive High-beam

System) ..........................

197

AHB (Automatic High Beam)

.......................................

201

Fog light switch.................

204

Windshield wipers and washer

.......................................

205

Rear window wiper and washer

.......................................

208

4-4. Refueling

Opening the fuel tank cap.

210

4-5. Using the driving support

systems

Toyota Safety Sense.........

212

PCS (Pre-Collision System)

........................................

217

LTA (Lane Tracing Assist) .

228

Dynamic radar cruise control

with full-speed range ......

238

Dynamic radar cruise control

........................................

250

Speed limiter.....................

261

RSA (Road Sign Assist) ....

263

Stop & Start system ..........

267

BSM (Blind Spot Monitor) .

272

Toyota parking assist-sensor

........................................

277

RCTA (Rear Crossing Traffic

Alert) ...............................

284

PKSB (Parking Support Brake)

........................................

289

Parking Support Brake function

(static objects) ................

294

Parking Support Brake function

(rear-crossing vehicles) ..

297

Driving mode select switch

299

GPF (Gasoline Particulate Fil-

ter) system......................

300

Driving assist systems ......

301

4-6. Driving tips

Winter driving tips .............

307

158

4-1. Before driving

4-1.Before driving

■

Starting the engine



P.173, 174

■

Driving



Multidrive

With the brake pedal depressed,
shift the shift lever to D.
(



P.179)

Release the parking brake.
(



P.186)

If the parking brake is in automatic

mode, the parking brake is release
automatically when shifting the shift

lever to any position other than P.

(



P.187)

Gradually release the brake
pedal and gently depress the
accelerator pedal to accelerate
the vehicle.



Manual transmission

While depressing the clutch
pedal, shift the shift lever to 1.
(



P.183)

Release the parking brake.
(



P.186)

If the parking brake is in automatic

mode, the parking brake is released

automatically when depress the accel-
erator pedal. (



P.188)

Gradually release the clutch
pedal. At the same time, gently

depress the accelerator pedal to
accelerate the vehicle.

■

Stopping



Multidrive

With the shift lever in D, depress
the brake pedal.

Vehicles with a Stop & Start system: If

the Stop & Start system is enabled,

depressing the brake pedal will stop the
engine. (



P.267)

If necessary, set the parking
brake.

If the vehicle is to be stopped for an
extended period of time, shift the shift

lever to P. (



P.179)



Manual transmission

While depressing the clutch
pedal, depress the brake pedal.

If necessary, set the parking
brake.

If the vehicle is to be stopped for an

extended period of time, shift the shift
lever to N. (



P.183)

Vehicles with a Stop & Start system: If

the Stop & Start system is enabled,
shifting the shift lever to N and releas-

ing the clutch pedal will stop the engine.

(



P.267)

■

Parking the vehicle



Multidrive

With the shift lever in D, depress
the brake pedal to stop the vehi-
cle completely.

Set the parking brake (



P.186),

and shift the shift lever to P.
(



P.179)

Check the parking brake indicator is

illuminated.

Driving the vehicle

The following procedures
should be observed to ensure
safe driving:

Driving procedure

159

4-1. Before driving

riv

ing

Turn the engine switch to OFF
to stop the engine.

Slowly release the brake pedal.

Lock the door, making sure that
you have the key on your per-
son.

If parking on a hill, block the wheels as

needed.



Manual transmission

While depressing the clutch
pedal, depress the brake pedal.

Set the parking brake. (



P.186)

Check that the parking brake indicator

is illuminated.

Shift the shift lever to N.
(



P.183)

If parking on a hill, shift the shift lever to

1 or R and block the wheels as needed.

Turn the engine switch to OFF
to stop the engine.

Slowly release the brake pedal.

Lock the door, making sure that
you have the key on your per-
son.

■

Starting off on a steep uphill



Multidrive

With the brake pedal depressed,
shift the shift lever to D.

Pull the parking brake switch
and parking brake is set manu-
ally. (



P.186)

Release the brake pedal and
gently depress the accelerator
pedal to accelerate the vehicle.

Press the parking brake switch
and parking brake is released
manually. (



P.186)

Parking brake automatic release func-

tion. (



P.188)



Manual transmission

With the brake pedal depressed,
shift the shift lever to 1.

Pull the parking brake switch
and parking brake is set manu-
ally. (



P.186)

Lightly depress the accelerator
pedal at the same time as grad-
ually releasing the clutch pedal.

Press the parking brake switch
and parking brake is released
manually. (



P.186)

Parking brake automatic release func-
tion. (



P.188)

■

Driving in the rain

●

Drive carefully when it is raining,
because visibility will be reduced, the

windows may become fogged-up, and

the road will be slippery.

●

Drive carefully when it starts to rain,

because the road surface will be
especially slippery.

●

Refrain from high speeds when driv-
ing on an expressway in the rain,

because there may be a layer of water

between the tires and the road sur-
face, preventing the steering and

brakes from operating properly.

■

Engine speed while driving (vehi-

cles with a Multidrive)

In the following conditions, the engine

speed may become high while driving.

This is due to automatic up-shifting con-
trol or down-shifting implementation to

meet driving conditions. It does not indi-

cate sudden acceleration.

160

4-1. Before driving

●

The vehicle is judged to be driving
uphill or downhill

●

When the accelerator pedal is
released

●

When the brake pedal is depressed
while power mode is selected

■

Restraining the engine output

(Brake Override System)

●

When the accelerator and brake ped-

als are depressed at the same time,

the engine output may be restrained.

●

A warning message is displayed on

the multi-information display while the
system is operating.

■

Breaking in your new Toyota

To extend the life of the vehicle, observ-

ing the following precautions is recom-
mended:

●

For the first 300 km (186 miles):

Avoid sudden stops.

●

For the first 800 km (500 miles):

Do not tow a trailer.

●

For the first 1000 km (621 miles):

• Do not drive at extremely high

speeds.

• Avoid sudden acceleration.

• Do not drive continuously in low

gears.

• Do not drive at a constant speed for

extended periods.

■

Operating your vehicle in a foreign

country

Comply with the relevant vehicle regis-

tration laws and confirm the availability

of the correct fuel. (



P.450)

WARNING

Observe the following precautions.

Failure to do so may result in death or

serious injury.

■

When starting the vehicle (vehi-

cles with a Multidrive)

Always keep your foot on the brake
pedal while stopped with the engine

running. This prevents the vehicle

from creeping.

■

When driving the vehicle

●

Do not drive if you are unfamiliar
with the location of the brake and

accelerator pedals to avoid

depressing the wrong pedal.

• Accidentally depressing the accel-

erator pedal instead of the brake
pedal will result in sudden accelera-

tion that may lead to an accident.

• When backing up, you may twist

your body around, leading to a diffi-

culty in operating the pedals. Make
sure to operate the pedals properly.

• Make sure to keep a correct driving

posture even when moving the

vehicle only slightly. This allows you

to depress the brake and accelera-
tor pedals properly.

• Depress the brake pedal using your

right foot. Depressing the brake

pedal using your left foot may delay

response in an emergency, result-
ing in an accident.

●

Do not drive the vehicle over or
stop the vehicle near flammable

materials.

The exhaust system and exhaust
gases can be extremely hot. These

hot parts may cause a fire if there is

any flammable material nearby.

Toyota Yaris Cross (2022 year). Manual in english - page 9
