397

5-14. Phone settings

5

Audio

COROLLA_U

2

Enter desired signature with
using keyboard.

3

Select “OK”.

4

Select “OK” on the confirma-
tion screen, or select “Edit
Again” when it needs to
amend.

398

5-15. What to do if... (Bluetooth

®

)

COROLLA_U

5-15.What to do if... (Bluetooth®)

■

When using the hands-free
system with a Bluetooth

®



device

The hands-free system or Blue-
tooth

®

 device does not work.

■

When registering/connect-
ing a cellular phone

A cellular phone cannot be reg-
istered.

Troubleshooting

If there is a problem with the
hands-free system or a
Bluetooth

®

 device, first

check the table below.

Troubleshooting

Likely cause

Solution

The connected
device may not
be a compatible
Bluetooth

®

 cellu-

lar phone.

For a list of spe-
cific devices
which operation
has been con-
firmed on this
system, check
with your Toyota
dealer or the fol-
lowing website:
https://www.
toyota.com/
audio-
multimedia in the
United States,
https://www.
toyota.ca/
connected in
Canada, and
http://www.
toyotapr.com/
audio-
multimedia in
Puerto Rico

The Bluetooth

®



version of the
connected cellu-
lar phone may
be older than the
specified ver-
sion.

Use a cellular
phone with Blue-
tooth

®

 version

2.0 or higher
(recommended:
Ver. 4.1 +EDR or
higher).
(



P.301)

399

5-15. What to do if... (Bluetooth

®

)

5

Audio

COROLLA_U

A Bluetooth

®

 connection can-

not be made.

■

When making/receiving a
call

A call cannot be made/received.

■

When using the phonebook

Phonebook data cannot be
transferred manually/automati-
cally.

Likely cause

Solution

An incorrect
passcode was
entered on the
cellular phone.

Enter the correct
passcode on the
cellular phone.

The registration
operation has
not been com-
pleted on the cel-
lular phone side.

Complete the
registration oper-
ation on the cel-
lular phone
(approve regis-
tration on the
phone).

Old registration
information
remains on
either this sys-
tem or the cellu-
lar phone.

Delete the exist-
ing registration
information from
both this system
and the cellular
phone, then reg-
ister the cellular
phone you wish
to connect to this
system.
(



P.305)

Likely cause

Solution

Another Blue-
tooth

®

 device is

already con-
nected.

Manually con-
nect the cellular
phone you wish
to use to this
system.
(



P.302)

Bluetooth

®

 func-

tion is not
enabled on the
cellular phone.

Enable the Blue-
tooth

®

 function

on the cellular
phone.

Automatic Blue-

tooth

®

 connec-

tion on this

system is set to

off.

Set automatic
Bluetooth

®

 con-

nection on this
system to on
when the engine
switch is in ACC
or ON. (



P.307)

Preferred device
settings function
on this system is
set to on.

Set preferred
device settings
function on this
system to off.
(



P.308)

Set the desired
cellular phone to
the highest auto-
matic connec-
tion priority.
(



P.308)

Likely cause

Solution

Your vehicle is in
a

 area.

Move to where

 no longer

appears on the
display.

Likely cause

Solution

400

5-15. What to do if... (Bluetooth

®

)

COROLLA_U

Phonebook data cannot be

edited.

■

When using the Bluetooth

®



message function

Messages cannot be viewed.

New message notifications are
not displayed.

Likely cause

Solution

The profile ver-
sion of the con-
nected cellular
phone may not
be compatible
with transferring
phonebook data.

For a list of spe-
cific devices
which operation
has been con-
firmed on this
system, check
with your Toyota
dealer or the fol-
lowing website:
https://www.
toyota.com/
audio-
multimedia in the
United States,
https://www.
toyota.ca/
connected in
Canada, and
http://www.
toyotapr.com/
audio-
multimedia in
Puerto Rico

Automatic con-
tact transfer
function on this
system is set to
off.

Set automatic
contact transfer
function on this
system to on.
(



P.391)

Passcode has
not been entered
on the cellular
phone.

Enter the pass-
code on the cel-
lular phone if
requested
(default pass-
code: 1234).

Transfer opera-
tion on the cellu-
lar phone has
not completed.

Complete trans-
fer operation on
the cellular
phone (approve
transfer opera-
tion on the
phone).

Likely cause

Solution

Automatic con-
tact transfer
function on this
system is set to
on.

Set automatic
contact transfer
function on this
system to off.
(



P.391)

Likely cause

Solution

Message trans-
fer is not enabled
on the cellular
phone.

Enable mes-
sage transfer on
the cellular
phone (approve
message trans-
fer on the
phone).

Automatic trans-
fer function on
this system is set
to off.

Set automatic
transfer function
on this system to
on. (



P.391)

Likely cause

Solution

Notification of
SMS/MMS/E-ma
il reception on
this system is set
to off.

Set notification of
SMS/MMS/E-ma
il reception on
this system to
on. (



P.389)

Automatic mes-
sage transfer
function is not
enabled on the
cellular phone.

Enable auto-
matic transfer
function on the
cellular phone.

401

5-15. What to do if... (Bluetooth

®

)

5

Audio

COROLLA_U

■

In other situations

The Bluetooth

®

 connection sta-

tus is displayed at the top of the
screen each time the engine
switch is in ACC or ON.

Even though all conceivable
measures have been taken, the
symptom status does not
change.

For details, refer to the owner’s

manual that came with the cellular

phone.

Likely cause

Solution

Connection con-
firmation display
on this system is
set to on.

To turn off the
display, set con-
nection confir-
mation display
on this system to
off. (



P.308)

Likely cause

Solution

The cellular
phone is not
close enough to
this system.

Bring the cellu-
lar phone closer
to this system.

Radio interfer-
ence has
occurred.

Turn off Wi-Fi

®



devices or other
devices that may
emit radio
waves.

The cellular
phone is the
most likely cause
of the symptom.

Turn the cellular
phone off,
remove and rein-
stall the battery
pack, and then
restart the cellu-
lar phone.

Enable the cellu-
lar phone’s Blue-
tooth

®



connection.

Stop the cellular
phone’s security
software and
close all applica-
tions.

Before using an
application
installed on the
cellular phone,
carefully check
its source and
how its opera-
tion might affect
this system.

Likely cause

Solution

402

5-16. Connected Services Overview

COROLLA_U

5-16.Connected Services Overview



Audio Plus/Premium Audio

Owners of this system should
refer to the “NAVIGATION AND
MULTIMEDIA SYSTEM
OWNER’S MANUAL”.

●

Each function is available in the

following areas:

• Toyota apps is available in the

contiguous United States, Wash-

ington D.C., Alaska, Hawaii,

Puerto Rico and Canada.

• Toyota apps is not available in the

United States Virgin Islands.

• Wi-Fi

®

 Hotspot is available in the

contiguous United States, Wash-

ington D.C.,Alaska and Hawaii.

• Wi-Fi

®

 Hotspot is not available in

Puerto Rico, Canada, and in the

United States Virgin Islands.

• Safety Connect features include:

Automatic Collision Notification,

Emergency Assistance, S.O.S,

Stolen Vehicle Location (available

in the contiguous United States,

Washington D.C., Hawaii, Alaska,

Puerto Rico and Canada) and

Enhanced Roadside Assistance

(available in the contiguous

United States, Washington D.C.,

Alaska, Puerto Rico and Canada).

• Safety Connect is not available in

the United States Virgin Islands.

• Service Connect is available in the

contiguous United States, Wash-

ington D.C., Alaska, Hawaii, the

United States Virgin Islands,

Puerto Rico and Canada.

●

Connected services functionality

is dependent upon network recep-

tion level and signal strength.



The functions included are
classified into the following
four types.

• Type A: Function achieved by

using a smart phone or an
embedded cellular device in the
vehicle (DCM: Data Communica-
tion Module) and the system

• Type B: Function achieved by

using DCM and the system

• Type C: Function achieved by

using DCM

• Type D: Function achieved by

using DCM and a smartphone

Functional overview

Toyota Connected hotspot
includes Toyota apps,
Wi-Fi

®

 Hotspot, Safety Con-

nect and Service Connect.

Functional overview

Function

Type

Toyota apps

Type A

Wi-Fi

®

 Hotspot

Type B

Safety Connect

Type C

Service Connect

Type D

403

5-16. Connected Services Overview

5

Audio

COROLLA_U

*

: If equipped

Content provider

Type A: Function achieved by using a smart
phone or DCM

*

Of the functions included with Connected Services, the Toyota
apps relies on the use of a smart phone or DCM.



Using a smart phone

• Toyota audio multimedia system enables applicable apps

installed on a smart phone to be displayed on and operated from
the screen via a Bluetooth

®

.



Via DCM

• Toyota audio multimedia system enables applicable apps

installed on the system to be displayed on and operated from the
screen.

A few settings must be performed before Toyota apps can be
used. (



P.409)

By using a smart phone or DCM

404

5-16. Connected Services Overview

COROLLA_U

Provides contents to the application server.
Application server
Provides applications to the system or a smart phone.

Smart phone

*

Using the Toyota mobile application, communication is relayed
between the system, application server and contents provider.
The smart phone cannot be operated while communicating.
Applications
Display usable content from the content providers on the screen
using the data connection of the connected smart phone or DCM.
System
Content received, via a smart phone or DCM, from content pro-
vider servers is displayed on the screen. The system is equipped
with an application player to run applications.
Via DCM

*

: For known compatible phones, refer to

https://www.toyota.com/connected-services in the United States,
https://www.toyota.ca/connected in Canada, and
http://www.toyotapr.com/connected-services in Puerto Rico.

The required operations to acti-
vate applications and connect a
smart phone to the system, and
the registration steps for the
connected services are
explained in this section.

■

Subscription



Toyota apps does not require
an activation fee or monthly
recurring fees.



Services requiring a separate
contract can also be used.

*

*

: For details, refer to

https://www.toyota.com/
connected-services
or call 1-800-331-4331 in the

United States,
https://www.toyota.ca/connected
or call 1-888-869-6828 in Can-
ada, and
http://www.toyotapr.com/
connected-services
or call 1-877-855-8377 in Puerto
Rico.

■

Availability of function



Toyota apps is available in the
contiguous United States,
Washington D.C., Alaska,
Hawaii, Puerto Rico and Can-
ada.



Toyota apps is not available in
the United States Virgin
Islands.

●

Data usage fees may apply while

Before using the function

405

5-16. Connected Services Overview

5

Audio

COROLLA_U

using Toyota apps function. Con-

firm data usage fees before using

this function.

●

For details regarding operation of

the Toyota apps, refer to

https://www.toyota.com/

connected-services

in the United States,

https://www.toyota.ca/connected

in Canada, and

http://www.toyotapr.com/

connected-services

in Puerto Rico.

●

These functions are not made

available in some countries or

areas. Availability of functions of

the Toyota apps is dependent on

network reception level.

■

Initializing personal data

The personal data used in appli-
cations can be reset. (



P.324)

The following personal data can
be deleted and returned to their
default settings:



Downloaded contents



Radio stations that were lis-
tened to

Once initialized, the data and set-

tings will be erased. Pay much

attention when initializing the data.

■

Settings required to use
Toyota mobile application

Perform the settings in the fol-
lowing order.

1

Download the Toyota mobile
application to your smart
phone or the system.

2

Open the Toyota mobile
application on your smart
phone and follow instruc-
tions. Bluetooth

®

 Pairing is

required.

In order to use Toyota mobile appli-

cation, the following must first be

performed:



Register a Bluetooth

®

 phone

with the hands-free system.
(



P.298)

●

Applications can only be used

when the Toyota mobile applica-

tion has been downloaded to your

smart phone or the system, and

the application is running.

●

Toyota mobile application opera-

tional procedures can also be con-

firmed by visiting

https://www.toyota.com/

connected-services

in the United States,

https://www.toyota.ca/connected

in Canada, and

http://www.toyotapr.com/

connected-services

in Puerto Rico.

●

If a Toyota mobile application is

used while iPod audio/video is

being played back, system opera-

tion may become unstable.

Preparation before using
Toyota mobile application

406

5-16. Connected Services Overview

COROLLA_U

*

: If equipped

■

Subscription

After you have signed the
Telematics Subscription Service
Agreement and are enrolled,
you can begin receiving ser-
vices. A variety of subscription
terms are available. Contact
your Toyota dealer, or call
1-800-331-4331 in the United
States, 1-888-869-6828 in Can-
ada, and 1-877-855-8377 in
Puerto Rico, for further sub-
scription details. (



P.404)

■

Availability of functions



Wi-Fi

®

 Hotspot is available in

the contiguous United States,
Washington D.C., Alaska and
Hawaii.



Wi-Fi

®

 Hotspot is not avail-

able in Puerto Rico, Canada,
and in the United States Vir-
gin Islands.

Type B: Function

achieved by using

DCM and the system

*

The functionality of Wi-Fi

®



Hotspot is made possible
through the shared work of
the DCM and the system.

This service is available by
subscription and supported
by the Toyota response cen-
ter, which operates 24 hours
a day, 7 days a week.

For details about Wi-Fi

®



Hotspot:



P.310

Before using the function

407

5-16. Connected Services Overview

5

Audio

COROLLA_U

*

: If equipped

*

: If equipped

Service Connect uses DCM to
collect and transmit vehicle data
that allows Toyota to provide:



Vehicle Health Report (VHR)
(Safety Recalls, Service Cam-
paigns, Current Vehicle
Alerts, Required Mainte-
nance, and Vehicle Condition
Status)



Maintenance Notifications



Vehicle Alert Notifications

■

Availability of function



Service Connect is available
in the contiguous United
States, Washington D.C.,
Alaska, Hawaii, the United
States Virgin Islands, Puerto
Rico and Canada.

Type C: Function

achieved by using

DCM

*

The functionality of Safety
Connect is made possible
by the use of a DCM.

For details, (



P.73)

Type D: Function

achieved by using

DCM and a smart-

phone

*

The functionality of Service
Connect is made possible
by the use of a DCM and a
smartphone.

For details about these ser-
vices, refer to
https://www.toyota.com/
connected-services.

Service Connect

408

5-16. Connected Services Overview

COROLLA_U

●

Availability of functions of the Ser-

vice Connect is dependent on net-

work reception level.

409

5-17. Connected Services Operation

5

Audio

COROLLA_U

5-17.Connected Services Operation



From the “MENU” button

1

Press the “MENU” button.

2

Select “Apps”.

3

Follow the steps in “From the
“APPS” button” from step

3

.

(



P.409)



From the “APPS” button

1

Press the “APPS” button.

2

Select “Apps”.

If a specific application screen is

displayed, select “Apps” again.

3

Select the desired application
screen button.

: Select to activate an applica-

tion.
“Update”: Select to update the

applications. (



P.409)

“App Catalog”: Select to change the

order of the applications. (



P.410)

: Displays the number of new

notifications for the application

When the Toyota apps is acti-
vated, an application may need
to be updated. To update an
application, it is necessary to
download update data and
install it.

■

Downloading update

If an update is available,
“Update” can be selected.

Toyota apps

Toyota apps is a function
that enables certain apps
installed on a smart phone
or the system to be dis-
played on and operated
from the system screen.
Before the Toyota apps can
be used, some setup needs
to be performed. (



P.405)

For details about the func-
tions and services provided
by each application, refer to
https://www.toyota.com/
connected-services
in the United States,
https://www.toyota.ca/
connected
in Canada, and
http://www.toyotapr.com/
connected-services
in Puerto Rico.

Using Toyota apps

Updating an application

410

5-17. Connected Services Operation

COROLLA_U

1

Select “Update” on the appli-
cation screen. (



P.409)

2

Check that downloading
starts.

“Download in Background”: Select

to operate other functions while

downloading.
“Cancel”: Select to cancel updating.

3

Check that downloading is
complete.

“Later”: Select to install later. When

this screen button is selected, the

screen will return to the last dis-

played screen. To install the update

data: (



P.410)

“See Detail”: Select to display

detailed information on the update

data.
“Install”: Select to install the update

data. Follow the steps “Installing

the update data” from step

2

.

(



P.410)

■

Installing the update data

After the downloading is com-
plete, “Update” will be changed
to “Install”.

1

Select “Install” on the appli-
cation screen. (



P.409)

2

Select “Continue”.

“Later”: Select to postpone the

installation of the update data and

go back to the previous screen.

3

Check that installing is
started.

“Install in Background”: Select to

operate other functions while

installing.

4

Select “OK” after the install-
ing is complete.

The Toyota apps cannot be oper-

ated while installing.

Order of the applications can be
changed.

1

Display the application
screen. (



P.409)

2

Select “App Catalog”.

3

Select the desired application
to be moved.

4

Select “<<” or “>>” to move
the application, and then
select the done button.

When problems occur with start-
ing the application player, a
message will appear on the
screen. Referring to the follow-
ing items, identify the problem
and take the suggested correc-
tive action.



“When it is safe and legal to
do so, please ensure your
mobile application is running
and logged in on your phone.”

The Toyota mobile application can-
not be connected to Bluetooth

®



SPP.
Refer to
https://www.toyota.com/
connected-services
in the United States,
https://www.toyota.ca/connected
in Canada, and
http://www.toyotapr.com/
connected-services
in Puerto Rico, to confirm if the

Reordering the applica-
tions

If a message appears on
the screen

411

5-17. Connected Services Operation

5

Audio

COROLLA_U

phone is Bluetooth

®

 SPP compati-

ble or not, and then activate the
Toyota mobile application.



“Installation failed, please try
again”

Installation can be attempted again
by changing to the application
screen and pressing the “Install”
switch.



“Application download error.
Please try again later.”

Downloading can be attempted
again by checking the communica-
tion status, changing to the applica-
tion screen and pressing the
“Download” switch again.



“Download error, some mobile
application functions may not
work as expected. Please
reinitiate the download pro-
cess.”

The Toyota mobile application can-
not be connected to Bluetooth

®



SPP.
Refer to
https://www.toyota.com/
connected-services
in the United States,
https://www.toyota.ca/connected
in Canada, and
http://www.toyotapr.com/
connected-services
in Puerto Rico, to confirm if the
phone is Bluetooth

®

 SPP compati-

ble or not, and then activate the
Toyota mobile application.
Please ensure your Toyota mobile
application is running and logged in
on your phone while vehicle is not
moving.



“To use the services, mobile
application needs to be run-
ning on your phone. For more
information, please visit toy-
ota.com or call
1-800-331-4331 in the United
States, 1-888-869-6828 in
Canada, and 1-877-855-8377
in Puerto Rico.”

The Toyota mobile application can-
not be connected to Bluetooth

®



SPP.
Refer to
https://www.toyota.com/
connected-services
in the United States,
https://www.toyota.ca/connected
in Canada, and
http://www.toyotapr.com/
connected-services
in Puerto Rico, to confirm if the
phone is Bluetooth

®

 SPP compati-

ble or not, and then activate the
Toyota mobile application.



“Communication unsuccess-
ful. Please try again.”

Communication was disconnected.
After a few moments, retry the
operation.

A keyword can be entered to an
application by the software key-
board or voice recognition func-
tion. For details about the
functions and services provided
by each application, refer to
https://www.toyota.com/
connected-services

Entering keyword opera-
tion

412

5-17. Connected Services Operation

COROLLA_U

in the United States,
https://www.toyota.ca/connected
in Canada, and
http://www.toyotapr.com/
connected-services
in Puerto Rico.
The keyboard layout can be
changed. (



P.321)

1

Display the application
screen. (



P.409)

2

Select the desired application
screen button.

3

Select the character entering
space.

4

Enter a search term, and
then select “OK”.

5

Entering characters will be
reflected on the character
entering space.

For details on operating the key-

board:



P.293

1

Display the application
screen. (



P.409)

2

Select the desired application
screen button.

3

Press the talk switch.
(



P.364)

4

Say the desired keyword.

Completion of the keyword will be

detected automatically.

5

Search results will be dis-
played on the screen.

Entering a keyword using
the software keyboard

Entering a keyword using
the voice recognition func-
tion

413

5-18. Toyota apps settings

5

Audio

COROLLA_U

5-18.Toyota apps settings

1

Press the “MENU” button.

2

Select “Setup”.

3

Select “Toyota apps”.

4

Select the desired items to
be set.

Select to set the pop up
reminder for smart phone
data usage. (



P.411)

Select to detect iPhone app
automatically on/off.

Select to set the enhanced
mode with connecting USB
device on/off.

When an iPhone is connected while
this setting is set to “On”, communi-
cation with devices connected to
other USB ports may not be possi-
ble. Also, depending on the device,
charging may not be possible.

Select to reset all setup
items.

The data use notification
pop-up, which indicates that the
system will use an internet con-
nection, can be enabled/dis-
abled.

1

Display the Toyota apps set-
tings screen. (



P.413)

2

Select “Data Usage Mes-
sage”.

3

Change the setting as
desired.

Setup

The settings of Toyota apps
can be changed.

Displaying the Toyota
apps settings screen

Toyota apps settings
screen

Data use notification
pop-up settings

414

5-18. Toyota apps settings

COROLLA_U

415

6

6

Interior

 featur

es

COROLLA_U

Interior features

.

6-1. Using the air conditioning

system and defogger

Manual air conditioning sys-

tem ............................

416

Automatic air conditioning

system.......................

421

Heated steering wheel/seat

heaters ......................

426

6-2. Using the interior lights

Interior lights list ..........

428

6-3. Using the storage features

List of storage features

..................................

430

Trunk features .............

433

6-4. Other interior features

Other interior features .

434

Garage door opener....

444

416

6-1. Using the air conditioning system and defogger

COROLLA_U

6-1.Using the air conditioning system and defogger

*

: If equipped

The display and button positions will differ depending on the type of
the system.

Fan speed control switch
Temperature control switch
“MAX A/C” switch
“A/C” switch
Outside air mode switch
Recirculated air mode switch
Airflow mode control switch
Rear window defogger and outside rear view mirror defoggers
switch

*

Windshield defogger switch
On/off switch

Rear window defogger switch

*

*

: If equipped

■

Adjusting the temperature
setting

To adjust the temperature set-
ting, turn the temperature con-
trol switch clockwise (warm) or
counterclockwise (cool).

If “A/C” switch is not pressed, the
system will blow ambient tempera-
ture air or heated air.
For quick cooling, press the “MAX
A/C” switch. The air conditioning
will automatically turn on and, if an

Manual air conditioning system

*

Air conditioning controls

417

6-1. Using the air conditioning system and defogger

6

Interior

 featur

es

COROLLA_U

air outlet position

 or

 is

selected, the system will be set to
recirculated air mode. While “MAX
A/C” is selected, it is not possible to
turn off the air conditioning.

■

Fan speed setting

To adjust the fan speed, turn the
fan speed control switch clock-
wise (increase) or counterclock-
wise (decrease).

Pressing the on/off switch to turns
off the fan.
When the fan is off, pressing the
on/off switch or turning the fan
speed control switch clockwise will
turn on the fan.

■

Change the airflow mode

Press the airflow mode control
switch.

The airflow mode changes as fol-
lows each time the switch is
pressed.

1

Upper body

2

Upper body and feet

3

Feet

4

Feet and the windshield

defogger operates

■

Switching between outside
air and recirculated air
modes



To change to recirculated air
mode, press the recirculated
air mode switch.

The indicator illuminates on the
recirculated air mode switch.



To change to outside air
mode, press the outside air
mode switch.

The indicator illuminates on the out-
side air mode switch.

■

Set cooling and dehumidifi-
cation function

Press the “A/C” switch.

When the function is on, the indica-
tor illuminates on the “A/C” switch.

■

Defogging the windshield

Defoggers are used to defog the
windshield and front side win-
dows.
Press the windshield defogger
switch.

Set the outside/recirculated air
mode switch to outside air mode if
the recirculated air mode is used.
To defog the windshield and the
side windows quickly, turn the air
flow and temperature up.
To return to the previous mode,
press the windshield defogger
switch again when the windshield is
defogged.
When the windshield defogger
switch is on, the indicator illumi-
nates on the windshield defogger

418

6-1. Using the air conditioning system and defogger

COROLLA_U

switch.

■

Defogging the rear window
and outside rear view mir-
rors



Vehicles without outside rear
view mirror defoggers

A defogger is used to defog the
rear window.
Press the rear window defogger
switch.

The defogger will automatically turn
off after a while.
When the rear window defogger
switch is on, the indicator illumi-
nates on the rear window defogger
switch.



Vehicles with outside rear
view mirror defoggers

Defoggers are used to defog the
rear window, and to remove
raindrops, dew and frost from
the outside rear view mirrors.
Press the rear window and out-
side rear view mirror defoggers
switch.

The defoggers will automatically
turn off after a while.
When the rear window and outside
rear view mirror defoggers switch is
on, the indicator illuminates on the
rear window and outside rear view
mirror defoggers switch.

■

Fogging up of the windows

●

The windows will easily fog up

when the humidity in the vehicle is

high. Turning “A/C” switch is on

will dehumidify the air from the

outlets and defog the windshield

effectively.

●

If you turn “A/C” switch is off, the

windows may fog up more easily.

●

The windows may fog up if the

recirculated air mode is used.

■

When driving on dusty roads

Close all windows. If dust thrown up

by the vehicle is still drawn into the

vehicle after closing the windows, it

is recommended that the air intake

mode be set to outside air mode and

the fan speed to any setting except

off.

■

Outside/recirculated air mode

Setting to the recirculated air mode

temporarily is recommended in pre-

venting dirty air from entering the

vehicle interior and helping to cool

the vehicle when the outside air

temperature is high.

■

When the outside temperature

falls to nearly 32°F (0°C)

The dehumidification function may

not operate even when “A/C” switch

is pressed.

■

Ventilation and air conditioning

odors

●

To let fresh air in, set the air condi-

tioning system to the outside air

mode.

●

During use, various odors from

inside and outside the vehicle may

enter into and accumulate in the

air conditioning system. This may

then cause odor to be emitted

from the vents.

●

It is recommended that the air

conditioning system be set to out-

side air mode prior to turning the

vehicle off.

●

When parking, the system auto-

matically switches to outside air

mode to encourage better air cir-

culation throughout the vehicle,

helping to reduce odors that occur

when starting the vehicle.

■

Air conditioning filter



P.487

419

6-1. Using the air conditioning system and defogger

6

Interior

 featur

es

COROLLA_U

■

Air conditioning system refrig-

erant

●

A label regarding the refrigerant of

the air conditioning system is

attached to the hood at the loca-

tion shown in the following illustra-

tion.

●

The meaning of each symbol on

the label are as follows:

■

Location of air outlets

The air outlets and air volume
changes according to the
selected air flow mode.

: If equipped

Caution

Air conditioning sys-
tem

Air conditioning sys-
tem lubricant type

Requires registered
technician to service
air conditioning sys-
tem

Flammable refrigerant

WARNING

■

To prevent the windshield

from fogging up

Do not use the windshield defog-

ger switch during cool air opera-

tion in extremely humid weather.

The difference between the tem-

perature of the outside air and

that of the windshield can cause

the outer surface of the wind-

shield to fog up, blocking your

vision.

■

When the outside rear view

mirror defoggers are operat-

ing (vehicles with outside rear

view mirror defoggers)

Do not touch the outside rear view

mirror surfaces, as they can

become very hot and burn you.

NOTICE

■

To prevent battery discharge

Do not leave the air conditioning

system on longer than necessary

when the engine is off.

■

When repairing/replacing

parts of the air conditioning

system

Have repair/replacement per-

formed by your Toyota dealer.

When a part of the air conditioning

system, such as the evaporator, is

to be replaced, it must be

replaced with a new one.

Air outlet layout and oper-
ations

420

6-1. Using the air conditioning system and defogger

COROLLA_U

■

Adjusting the position of
and opening and closing
the air outlets



Front center

Direct air flow to the left or right, up
or down



Front right-hand side

Direct air flow to the left or right, up
or down



Front left-hand side

Direct air flow to the left or right, up
or down

WARNING

■

To prevent the windshield

defogger from operating

improperly

Do not place anything on the

instrument panel which may cover

the air outlets. Otherwise, air flow

may be obstructed, preventing the

windshield defoggers from defog-

ging.

421

6-1. Using the air conditioning system and defogger

6

Interior

 featur

es

COROLLA_U

*

: If equipped

Temperature control switch
Fan speed control switch
“A/C” switch
Outside air mode switch
Recirculated air mode switch
Eco air conditioning mode switch
Airflow mode control switch
Rear window defogger and outside rear view mirror defoggers
switch
Windshield defogger switch
Off switch
Automatic mode switch

■

Adjusting the temperature
setting

To adjust the temperature set-
ting, turn the temperature con-
trol switch clockwise (warm) or

counterclockwise (cool).

If “A/C” switch is not pressed, the
system will blow ambient tempera-
ture air or heated air.

Automatic air conditioning system

*

Air outlets are automatically selected and fan speed is auto-
matically adjusted according to the set temperature setting.
Also, the display and button positions will differ depending on
the type of the system.

Air conditioning controls

422

6-1. Using the air conditioning system and defogger

COROLLA_U

■

Setting the fan speed

To adjust the fan speed, turn the
fan speed control switch clock-
wise (increase) or counterclock-
wise (decrease).

Pressing the off switch to turns off
the fan.

■

Change the airflow mode

Press the airflow mode control
switch.

The airflow mode changes as fol-
lows each time the switch is
pressed.

1

Upper body

2

Upper body and feet

3

Feet

4

Feet and the windshield
defogger operates

■

Switching between outside
air and recirculated air
modes



To change to recirculated air
mode, press the recirculated
air mode switch.

The indicator illuminates on the

recirculated air mode switch.



To change to outside air
mode, press the outside air
mode switch.

The indicator illuminates on the out-
side air mode switch.

■

Set cooling and dehumidifi-
cation function

Press the “A/C” switch.

When the function is on, the indica-
tor illuminates on the “A/C” switch.

■

Defogging the windshield

Defoggers are used to defog the
windshield and front side win-
dows.
Press the windshield defogger
switch.

Set the outside/recirculated air
mode switch to outside air mode if
the recirculated air mode is used. (It
may switch automatically.)
To defog the windshield and the
side windows quickly, turn the air
flow and temperature up.
To return to the previous mode,
press the windshield defogger
switch again when the windshield is
defogged.
When the windshield defogger
switch is on, the indicator illumi-
nates on the windshield defogger
switch.

■

Defogging the rear window
and outside rear view mir-
rors

Defoggers are used to defog the
rear window, and to remove
raindrops, dew and frost from

423

6-1. Using the air conditioning system and defogger

6

Interior

 featur

es

COROLLA_U

the outside rear view mirrors.
Press the rear window and out-
side rear view mirror defoggers
switch.

The defoggers will automatically
turn off after a while.
When the rear window and outside
rear view mirror defoggers switch is
on, the indicator illuminates on the
rear window and outside rear view
mirror defoggers switch.

■

Eco air conditioning mode

The air conditioning is controlled
with low fuel consumption priori-
tized such as reducing fan
speed, etc.
Press the eco air conditioning
mode switch.

When the eco air conditioning
mode is on, the indicator illumi-
nates on the eco air conditioning
mode switch.

■

When the outside temperature

exceeds 75°F (24°C) and the air

conditioning system is on

●

In order to reduce the air condi-

tioning power consumption, the air

conditioning system may switch to

recirculated air mode automati-

cally. This may also reduce fuel

consumption.

●

Recirculated air mode is selected

as a default mode when the

engine switch is turned to ON.

●

It is possible to switch to outside

air mode at any time by pressing

the outside air mode switch.

■

Fogging up of the windows

●

The windows will easily fog up

when the humidity in the vehicle is

high. Turning “A/C” on will dehu-

midify the air from the outlets and

defog the windshield effectively.

●

If you turn “A/C” off, the windows

may fog up more easily.

●

The windows may fog up if the

recirculated air mode is used.

■

When driving on dusty roads

Close all windows. If dust thrown up

by the vehicle is still drawn into the

vehicle after closing the windows, it

is recommended that the air intake

mode be set to outside air mode and

the fan speed to any setting except

off.

■

Outside/recirculated air mode

●

Setting to the recirculated air

mode temporarily is recom-

mended in preventing dirty air

from entering the vehicle interior

and helping to cool the vehicle

when the outside air temperature

is high.

●

Outside/recirculated air mode may

automatically switch depending on

the temperature setting or the

inside temperature.

■

When the outside temperature

falls to nearly 32°F (0°C)

The dehumidification function may

not operate even when “A/C” switch

is pressed.

■

Ventilation and air conditioning

odors

●

To let fresh air in, set the air condi-

tioning system to the outside air

mode.

●

During use, various odors from

inside and outside the vehicle may

enter into and accumulate in the

air conditioning system. This may

then cause odor to be emitted

from the vents.

●

To reduce potential odors from

occurring:

• It is recommended that the air

conditioning system be set to out-

side air mode prior to turning the

vehicle off.

• The start timing of the blower may

424

6-1. Using the air conditioning system and defogger

COROLLA_U

be delayed for a short period of

time immediately after the air con-

ditioning system is started in auto-

matic mode.

●

When parking, the system auto-

matically switches to outside air

mode to encourage better air cir-

culation throughout the vehicle,

helping to reduce odors that occur

when starting the vehicle.

■

Air conditioning filter



P.487

■

Air conditioning system refrig-

erant

●

A label regarding the refrigerant of

the air conditioning system is

attached to the hood at the loca-

tion shown in the following illustra-

tion.

●

The meaning of each symbol on

the label are as follows:

■

Customization

Some functions can be customized.

(



P.581)

1

Press the automatic mode
switch.

2

Adjust the temperature set-
ting.

Caution

Air conditioning sys-
tem

Air conditioning sys-
tem lubricant type

Requires registered
technician to service
air conditioning sys-
tem

Flammable refrigerant

WARNING

■

To prevent the windshield

from fogging up

Do not use the windshield defog-

ger switch during cool air opera-

tion in extremely humid weather.

The difference between the tem-

perature of the outside air and

that of the windshield can cause

the outer surface of the wind-

shield to fog up, blocking your

vision.

■

When the outside rear view

mirror defoggers are operat-

ing

Do not touch the outside rear view

mirror surfaces, as they can

become very hot and burn you.

NOTICE

■

To prevent battery discharge

Do not leave the air conditioning

system on longer than necessary

when the engine is off.

■

When repairing/replacing

parts of the air conditioning

system

Have repair/replacement per-

formed by your Toyota dealer.

When a part of the air conditioning

system, such as the evaporator, is

to be replaced, it must be

replaced with a new one.

Using automatic mode

425

6-1. Using the air conditioning system and defogger

6

Interior

 featur

es

COROLLA_U

3

To stop the operation, press
the off switch.

If the fan speed setting or air
flow modes are operated, the
automatic mode indicator goes
off. However, automatic mode
for functions other than that
operated is maintained.

■

Using automatic mode

Fan speed is adjusted automati-

cally according to the temperature

setting and the ambient conditions.
Therefore, the fan may stop for a

while until warm or cool air is ready

to flow immediately after the auto-

matic mode switch pressed.

Prevent ice from building up on
the windshield and wiper
blades.

When the windshield wiper de-icer
switch is on, the indicator illumi-
nates on the windshield wiper
de-icer switch.
The windshield wiper de-icer will
automatically turn off after a period
of time.

■

Location of air outlets

The air outlets and air volume
changes according to the
selected air flow mode.

:If equipped

■

Adjusting the position of
and opening and closing
the air outlets



Front center

Direct air flow to the left or right, up
or down

Windshield wiper de-icer
(if equipped)

WARNING

■

To prevent burns

Do not touch the glass at lower

part of the windshield or to the

side of the front pillars when the

windshield wiper de-icer is on.

Air outlet layout and oper-
ations

426

6-1. Using the air conditioning system and defogger

COROLLA_U



Front right-hand side

Direct air flow to the left or right, up
or down



Front left-hand side

Direct air flow to the left or right, up
or down

*

: If equipped

WARNING

■

To prevent the windshield

defogger from operating

improperly

Do not place anything on the

instrument panel which may cover

the air outlets. Otherwise, air flow

may be obstructed, preventing the

windshield defoggers from defog-

ging.

Heated steering

wheel

*

/seat heaters

*



Heated steering wheel

Warms up the grip of the
steering wheel



Seat heaters

Warm up the seat upholstery

WARNING

■

To prevent minor burn inju-

ries

Care should be taken if anyone in

the following categories comes in

contact with the steering wheel or

seats when the heater is on:

●

Babies, small children, the

elderly, the sick and the physi-

cally challenged

●

Persons with sensitive skin

●

Persons who are fatigued

●

Persons who have taken alco-

hol or drugs that induce sleep

(sleeping drugs, cold remedies,

etc.)

NOTICE

■

To prevent damage to the

seat heaters

Do not put heavy objects that

have an uneven surface on the

seat and do not stick sharp

objects (needles, nails, etc.) into

the seat.

■

To prevent battery discharge

Do not use the functions when the

engine is off.

427

6-1. Using the air conditioning system and defogger

6

Interior

 featur

es

COROLLA_U

■

Heated steering wheel

Turns heated steering wheel
on/off

When the heated steering wheel is
on, the indicator illuminates on the
heated steering wheel switch.

■

Seat heaters



Front

Turns seat heaters on/off

1

High temperature

2

Low temperature

When the seat heater is on, the
indicator illuminates on the seat
heater switch.
When not in use, put the switch in
the neutral position. The indicator
will turn off.



Rear

Turns seat heaters on/off

When the seat heater is on, the
indicator illuminates on the seat
heater switch.

■

The heated steering wheel and

seat heaters can be used when

The engine switch is in ON.

Operation instructions

WARNING

■

To prevent overheating and

minor burn injuries

Observe the following precautions

when using the seat heaters.

●

Do not cover the seat with a

blanket or cushion when using

the seat heater.

●

Do not use seat heater more

than necessary.

428

6-2. Using the interior lights

COROLLA_U

6-2.Using the interior lights

Rear interior light (



P.429)

Door trim lights (if equipped)
Front interior/personal lights (



P.428)

Center tray light (if equipped)
Cup holder lights (if equipped)

■

Front

1

Turns the door position on/off

When a door is opened while the
door position is on, the lights turn
on.

Interior lights list

Location of the interior lights

Operating the interior
lights

429

6-2. Using the interior lights

6

Interior

 featur

es

COROLLA_U

2

Turns the lights on/off

■

Rear

1

Turns the door position on

The rear interior light turns on/off
together the front interior lights.
When a door is opened while the
front and rear interior light door
position is on, the lights turn on.

2

Turns the light on

Turns the lights on/off

■

Illuminated entry system

The lights automatically turn on/off

according to the engine switch

mode (position), the presence of the

electronic key (vehicles with a smart

key system), whether the doors are

locked/unlocked, and whether the

doors are opened/closed.

■

To prevent the battery from

being discharged

If the interior lights remain on when

the engine switch is turned off, the

lights will go off automatically after

20 minutes.

■

The interior lights may turn on

automatically when

If any of the SRS airbags deploy

(inflate) or in the event of a strong

rear impact, the interior lights will

turn on automatically.

The interior lights will turn off auto-

matically after approximately 20

minutes.

The interior lights can be turned off

manually. However, in order to help

prevent further collisions, it is rec-

ommended that they be left on until

safety can be ensured.

(The interior lights may not turn on

automatically depending on the

force of the impact and conditions of

the collision.)

■

Customization

Some functions can be customized.

(



P.581)

Operating the personal
lights

NOTICE

■

To prevent battery discharge

Do not leave the lights on longer

than necessary when the engine

is not running.

430

6-3. Using the storage features

COROLLA_U

6-3.Using the storage features

Bottle holders/door pockets (



P.431)

Open trays (if equipped) (



P.432)

Glove box (



P.431)

Cup holders (if equipped) (



P.431)

Console box (



P.432)

List of storage features

Location of the storage features

WARNING

■

Items that should not be left

in the storage spaces

Do not leave glasses, lighters or

spray cans in the storage spaces,

as this may cause the following

when cabin temperature becomes

high:

●

Glasses may be deformed by

heat or cracked if they come

into contact with other stored

items.

●

Lighters or spray cans may

explode. If they come into con-

tact with other stored items, the

lighter may catch fire or the

spray can may release gas,

causing a fire hazard.

431

6-3. Using the storage features

6

Interior

 featur

es

COROLLA_U

Pull up the lever to open the
glove box.

■

Glove box light (if equipped)

The glove box light turns on when

the tail lights are on.



Front



Rear (if equipped)

Pull the armrest down.



Front



Rear

Glove box

WARNING

■

Caution while driving

Keep the glove box closed. In the

event of sudden braking or sud-

den swerving, an accident may

occur due to an occupant being

struck by the open glove box or

the items stored inside.

Cup holders

WARNING

■

Items unsuitable for the cup

holder

Do not place anything other than

cups or beverage cans in the cup

holders.

Other items may be thrown out of

the holders in the event of an

accident or sudden braking and

cause injury. If possible, cover hot

drinks to prevent burns.

Bottle holders

432

6-3. Using the storage features

COROLLA_U

■

Bottle holders

●

When storing a bottle, close the

cap.

●

The bottle may not be stored

depending on its size or shape.

1

Slide the lid to the rear most
position. (vehicles with a
slide function)

2

Lift the lid while pulling up the
knob.

■

Slide function (if equipped)

The console box lid can be slid for-

ward or backward.



Front (if equipped)



Rear

WARNING

■

Items unsuitable for the bottle

holders

Do not place anything other than

a bottle in the bottle holders.

Other items may be thrown out of

the holders in the event of an

accident or sudden braking and

cause injury.

Console box

WARNING

■

Caution while driving

Keep the console box closed.

Injuries may result in the event of

an accident or sudden braking.

Open trays

WARNING

■

Caution while driving

Observe the following precautions

when putting items in the open

tray. Failure to do so may cause

items to be thrown out of the tray

in the event of sudden braking or

steering. In these cases, the items

may interfere with pedal operation

or cause driver distraction, result-

ing in an accident.

433

6-3. Using the storage features

6

Interior

 featur

es

COROLLA_U

Lift the deck mat.



Type A



Type B

WARNING

●

Do not store items in the tray

that can easily shift or roll out.

●

Do not stack items in the tray

higher than the tray’s edge.

●

Do not put items in the tray that

may protrude over the tray’s

edge.

Trunk features

Auxiliary box

434

6-4. Other interior features

COROLLA_U

6-4.Other interior features

The USB charging port are used
to supply 2.1 A of electricity at 5
V to external devices.
The USB charging port are for
charging only. They are not
designed for data transfer or
other purposes.
Depending on the external
device, it may not charge prop-
erly. Refer to the manual
included with the device before
using a USB charging port.

■

Using the USB charging
port

Lift the lid while pulling up the
knob.

■

The USB charging port can be

used when

The engine switch is in ACC or ON.

■

Situations in which the USB

charging port may not operate

correctly

●

If a device which consumes more

than 2.1 A at 5 V is connected

●

If a device designed to communi-

cate with a personal computer,

such as a USB memory device, is

connected

●

If the connected external device is

turned off (depending on device)

●

If the temperature inside the vehi-

cle is high, such as after the vehi-

cle has been parked in the sun

■

About connected external

device

Depending on the connected exter-

nal device, charging may occasion-

ally be suspended and then start

again. This is not a malfunction.

Other interior features

USB charging port (if
equipped)

NOTICE

■

To prevent damage to the

USB charging port

●

Do not insert foreign objects into

the port.

●

Do not spill water or other liq-

uids into the port.

●

Do not apply excessive force to

or impact the USB charging

port.

●

Do not disassemble or modify

the USB charging port.

■

To prevent damage to exter-

nal devices

●

Do not leave external devices in

the vehicle. The temperature

inside the vehicle may become

high, resulting in damage to an

external device.

●

Do not push down on or apply

unnecessary force to an exter-

nal device or the cable of an

external device while it is con-

nected.

■

To prevent battery discharge

Do not use the USB charging port

for a long period of time with the

engine stopped.

435

6-4. Other interior features

6

Interior

 featur

es

COROLLA_U

The power outlet can be used
for 12 V accessories that run on
less than 10 A.
Lift the lid while pulling up the
knob and open the power outlet
lid.

■

The power outlet can be used

when

The engine switch is in ACC or ON.

■

When turning the engine switch

off

Disconnect electrical devices with

charging functions, such as mobile

battery packs.

If such devices are left connected,

the engine switch may not be turned

off normally.

A portable device, such as a
smartphone or mobile battery,
can be charged by just placing it
on the charging area, provided
the device is compatible with the
Qi wireless charging standard
created by the Wireless Power
Consortium.
The wireless charger cannot be
used with a portable device that
is larger than the charging area.
Additionally, depending on the
portable device, the wireless
charger may not operate prop-
erly. Refer to the operation man-
ual of the portable device.

■

The “Qi” symbol

The “Qi” symbol is a trademark
of the Wireless Power Consor-
tium.

Power outlet

NOTICE

■

To prevent the fuse from

being blown

Do not use an accessory that

uses more than 12 V 10 A.

■

To avoid damaging the power

outlet

Close the power outlet lid when

the power outlet is not in use.

Foreign objects or liquids that

enter the power outlet may cause

a short circuit.

■

To prevent the battery from

being discharged

Do not use the power outlet lon-

ger than necessary when the

engine is not running.

Wireless charger (if
equipped)

436

6-4. Other interior features

COROLLA_U

■

Name for all parts

Power supply switch
Operation indicator light
Charge area

■

Using the wireless charger

1

Press the power supply
switch of the wireless char-
ger.

Pressing the switch again turns the

wireless charger off.

When turned on, the operation indi-

cator light (green) comes on.

When the engine switch is turned

off, the on/off state of the wireless

charger will be memorized.

2

Place a portable device on
the charging area with its
charging surface facing
down.

While charging, the operation indi-

cator light (orange) will be illumi-

nated.

If charging does not begin, move

the portable device as close to the

center of the charging area as pos-

sible.

When charging is complete, the

operation indicator light (green) will

illuminate.

■

Recharging function



If a certain amount of time has
elapsed since charging com-
pleted and the portable device
has not been moved, the
wireless charger will restart
charging.



If the portable device is
moved within the charging
area, charging will stop tem-
porarily then restart.

437

6-4. Other interior features

6

Interior

 featur

es

COROLLA_U

■

Operation indicator light status

*

: Depending on the portable device, the operation indicator light may stay

illuminated (orange) after charging has completed.



If the operation indicator light blinks

If an error is detected, the operation indicator light will blink (orange). Take
the appropriate measures according to the table below.

■

The wireless charger can be

operated when

The engine switch is in ACC or ON.

■

Portable devices that can be

charged

●

Portable devices compatible with

the Qi wireless charging standard

can be charged by the wireless

charger. However, compatibility

with all devices which meet the Qi

wireless charging standard is not

guaranteed.

●

The wireless charger is designed

to supply low power electricity (5

W or less) to a cellular phone,

smartphone, or other portable

device.

Operation indicator light

State

Off

The Wireless charger is off

Green (illuminated)

Standby (charging is possible)

Charging is complete

*

Orange (illuminated)

A portable device has been placed on the
charging area (identifying the portable
device)

Charging in progress

Operation indicator light Suspected cause

Measure

Blinks (orange) at a one
second interval continu-
ously

Vehicle to charger com-
munication failure.

Contact your Toyota
dealer.

Blinks (orange) 3 times
repeatedly

A foreign object exists
between the portable
device and charging
area.

Remove the foreign
object.

Portable device is not
positioned properly on
the charging area.

Move the portable
device toward the cen-
ter of the charging area.

Blinks (orange) 4 times
repeatedly

The temperature of the
wireless charger is
excessively high.

Stop charging immedi-
ately and continue
charging after a while.

438

6-4. Other interior features

COROLLA_U

■

If a cover or accessory is

attached to the portable device

Do not charge a portable device if a

cover or accessory which is not Qi

compatible is attached. Depending

on the type of cover and/or acces-

sory attached, it may not be possi-

ble to charge the portable device. If

the portable device is placed on the

charging area and does not charge,

remove the cover and/or accesso-

ries.

■

If interference is heard in AM

radio broadcasts while

charging

Turn off the wireless charger and

check if the noise is reduced. If

noise is reduced, press and hold the

power supply switch of the wireless

charger for 2 seconds. The fre-

quency of the wireless charger is

changed and noise may be

reduced. When the frequency is

changed, the operation indicator

light will blink (orange) 2 times.

■

Charging precautions

●

If the electronic key cannot be

detected in the cabin, charging

cannot be performed. When a

door is opened and closed,

charging may be temporarily sus-

pended.

●

While charging, the wireless char-

ger and the portable device will

become warm.

This is not a malfunction.If a porta-

ble device becomes warm while

charging and charging stops due

to the protection function of the

portable device, wait until the por-

table device cools down and

charge it again.

■

Sound generated during opera-

tion

When the power supply switch is

turned on or while a portable device

is being identified, operation sounds

may be heard. This is not a malfunc-

tion.

■

Cleaning the wireless charger



P.455

■

Certification for the wireless charger

439

6-4. Other interior features

6

Interior

 featur

es

COROLLA_U

440

6-4. Other interior features

COROLLA_U

441

6-4. Other interior features

6

Interior

 featur

es

COROLLA_U

WARNING

■

Caution while driving

When charging a portable device

while driving, for safety reasons,

the driver should not operate the

portable device.

■

Caution regarding interfer-

ence with electronic devices

People with implantable cardiac

pacemakers, cardiac resynchroni-

zation therapy pacemakers or

implantable cardioverter defibrilla-

tors, as well as any other electri-

cal medical device, should consult

their physician about the usage of

the wireless charger.

Operations of the wireless char-

ger may have an affect on medi-

cal devices.

■

To prevent damage or burns

Observe the following precau-

tions.

Failure to do so may result in the

possibility of fire, equipment fail-

ure or damage, or burns due to

heat.

●

Do not put any metallic objects

between the charging area and

the portable device while

charging.

●

Do not attach metallic objects,

such as aluminum stickers, to

the charging area.

●

Do not cover the wireless char-

ger with a cloth or other object

while charging.

●

Do not attempt to charge porta-

ble devices which are not com-

patible with the Qi wireless

charging standard.

●

Do not disassemble, modify or

remove the wireless charger.

●

Do not apply force or impact to

the wireless charger.

NOTICE

■

Conditions in which the wire-

less charger may not operate

correctly

In the following situations, the

wireless charger may not operate

correctly:

●

When a portable device is fully

charged

●

When there is a foreign object

between the charging area and

portable device

●

When a portable device

becomes hot while charging

●

When a portable device is

placed on the wireless area with

its charging surface facing up

●

When a portable device is not

centered on the charging area

●

When the vehicle is near a TV

tower, electric power plant, gas

station, radio station, large dis-

play, airport or other facility that

generates strong radio waves or

electrical noise

●

When the portable device is in

contact with, or is covered by

any of the following metallic

objects:

• Cards to which aluminum foil is

attached

• Cigarette boxes that have alu-

minum foil inside

• Metallic wallets or bags

• Coins

• Metal hand warmers

• Media such as CDs and DVDs

442

6-4. Other interior features

COROLLA_U

1

To set the visor in the forward
position, flip it down.

2

To set the visor in the side
position, flip down, unhook,
and swing it to the side.

3

To use the side extender,
place the visor in the side
position, then slide it back-
ward. (if equipped)

Slide the cover to open.

The vanity light turns on. (if
equipped)

■

To prevent battery discharge

(vehicles with vanity lights)

If the vanity lights remain on when

the engine switch is OFF, the lights

will go off automatically after 20 min-

utes.

NOTICE

●

When wireless keys (that emit

radio waves) other than those of

your vehicle are being used

nearby.

If in situations other than above
the wireless charger does not
operate properly or the operation
indicator light is blinking, the wire-
less charger may be malfunction-
ing. Contact your Toyota dealer.

■

To prevent failure or damage

to data

●

Do not bring magnetic cards,

such as a credit card, or mag-

netic recording media, close to

the wireless charger while

charging. Otherwise, data may

be erased due to the influence

of magnetism.

Additionally, do not bring preci-

sion instruments such as wrist

watches, close to the wireless

charger, as such objects may

malfunction.

●

Do not leave portable devices in

the cabin. The temperature

inside the cabin may become

high when parked in the sun,

and cause damage to the

device.

■

To prevent battery discharge

Do not use the wireless charger

for a long period of time with the

engine stopped.

Sun visors

Vanity mirrors

443

6-4. Other interior features

6

Interior

 featur

es

COROLLA_U

Fold down the armrest for use.

An assist grip installed on the
ceiling can be used to support
your body while sitting on the
seat.

The coat hooks are provided
with the rear assist grips.

NOTICE

■

To prevent the battery from

being discharged (vehicles

with vanity lights)

Do not leave the vanity lights on

for extended periods while the

engine is stopped.

Armrest (if equipped)

NOTICE

■

To prevent damage to the

armrest

Do not apply too much load on the

armrest.

Assist grips

WARNING

■

Assist grip

Do not use the assist grip when

getting in or out of the vehicle or

rising from your seat.

NOTICE

■

To prevent damage to the

assist grip

Do not hang any heavy object or

put a heavy load on the assist

grip.

Coat hooks

WARNING

■

Items that cannot be hung on

the coat hook

Do not hang coat hangers or

other hard or sharp objects on the

hook. If the SRS curtain shield air-

bags deploy, these items may

become projectiles, causing death

or serious injury.

444

6-4. Other interior features

COROLLA_U

*

: If equipped

The HomeLink

®

 wireless control

system in your vehicle has 3
buttons which can be pro-
grammed to operate 3 different
devices. Refer to the program-
ming methods on the following
pages to determine the method
which is appropriate for the
device.

HomeLink

®

 indicator light

Garage door operation indi-
cators

HomeLink

®

 icon

Illuminates while HomeLink

®

 is

operating.

Buttons

■

Codes stored in the Home-
Link

®

 memory

●

The registered codes are not

erased even if the battery cable is

disconnected.

●

If learning failed when registering
a different code to a HomeLink

®



button that already has a code

registered to it, the already regis-

tered code will not be erased.

■

Certification for the garage door opener



Except for vehicles sold in Canada

Garage door opener

*

The garage door opener can
be programmed using the
HomeLink

®

 to operate

garage doors, gates, entry
doors, door locks, home
lighting systems, security
systems, and other devices.

System components

445

6-4. Other interior features

6

Interior

 featur

es

COROLLA_U



For vehicles sold in Canada

■

When support is necessary

Visit on the web at www.

homelink.com/toyota or call

1-800-355-3515.

■

Before programming Home-
Link

®



During programming, it is pos-
sible that garage doors,
gates, or other devices may
operate. For this reason,
make sure that people and
objects are clear of the
garage door or other devices
to prevent injury or other
potential harm.



It is recommended that a new
battery be placed in the
remote control transmitter for
more accurate programming.

WARNING

■

When programming a garage

door or other remote control

device

The garage door or other device

may operate, so ensure people

and objects are out of danger to

prevent potential harm.

■

Conforming to federal safety

standards

Do not use the HomeLink

®

 com-

patible transceiver with any

garage door opener or device that

lacks safety stop and reverse fea-

tures as required by federal safety

standards.
This includes any garage door

that cannot detect an interfering

object. A door or device without

these features increases the risk

of death or serious injury.

■

When operating or program-
ming HomeLink

®

Never allow a child to operate or
play with the HomeLink

®

 buttons.

Programming the Home-
Link

®

446

6-4. Other interior features

COROLLA_U



Garage door opener motors
manufactured after 1995 may
be equipped with rolling code
protection. If this is the case,
you may need a stepladder or
other sturdy, safe device to
reach the “Learn” or “Smart”
button on the garage door
opener motor.

■

Programming HomeLink

®

Steps

1

 through

3

 must be per-

formed within 60 seconds, oth-
erwise the indicator light will
stop flashing and programming
will not be able to be completed.

1

Press and release the Home-
Link

®

 button you want to pro-

gram and check that the
HomeLink

®

 indicator light

flashes (orange).

2

Point the remote control
transmitter for the device at
the rear view mirror, 1 to 3 in.
(25 to 75 mm) from the
HomeLink

®

 buttons.

Keep the HomeLink

®

 indicator light

in view while programming.

3

Program a device.



Programming a device other
than an entry gate (for U.S.A.
owners)

Press and hold the handheld
transmitter button until the
HomeLink

®

 indicator light

changes from slowly flashing
orange to rapidly flashing green
(rolling code) or continuously lit
green (fixed code), then release
the button.



Programming an entry gate
(for U.S.A. owners)/Program-
ming a device in the Cana-
dian market

Press and release the remote
control transmitter button at 2
second intervals, repeatedly,
until the HomeLink

®

 indicator

light changes from slowly flash-
ing (orange) to rapidly flashing
(green) (rolling code) or continu-
ously lit (green) (fixed code).

4

Test the HomeLink

®

 opera-

tion by pressing the newly
programmed button and
observing the indicator light:



Indicator light illuminates:
Programming of a fixed code
device has completed. The

447

6-4. Other interior features

6

Interior

 featur

es

COROLLA_U

garage door or other device
should operate when a Home-
Link

®

 button is pressed and

released.



Indicator light flashes rapidly:
The garage door opener
motor or other device is
equipped with a rolling code.
To complete programming,
firmly press and hold the
HomeLink

®

 button for 2 sec-

onds then release it.



If the garage door or other
device does not operate, pro-
ceed to “Programming a roll-
ing code system”.

5

Repeat the steps above to
program another device for
any of the remaining Home-
Link

®

 buttons.

■

Programming a rolling code
system

2 or more people may be neces-
sary to complete rolling code
programming.

1

Locate the “Learn” or “Smart”
button on the garage door
opener motor in the garage.

This button can usually be found

where the hanging antenna wire is

attached to the unit. The name and

color of the button may vary by

manufacturer. Refer to the owner’s

manual supplied with the garage

door opener motor for details.

2

Press and release the
“Learn” or “Smart” button.

Perform

3

 within 30 seconds after

performing

2

.

3

Press and hold the desired
HomeLink

®

 button (inside the

vehicle) for 2 seconds and
release it. Repeat this
sequence
(press/hold/release) up to 3
times to complete program-
ming.
If the garage door opener
motor operates when the
HomeLink

®

 button is

pressed, the garage door

448

6-4. Other interior features

COROLLA_U

opener motor recognizes the
HomeLink

®

 signal.

■

Enabling 2-way communi-
cation with a garage door
(only available for compati-
ble devices)

When enabled, 2-way communi-
cation allows you to check the
status of the opening and clos-
ing of a garage door through
indicators in your vehicle.
2-way communication is only
available if the garage door
opener motor used is a compati-
ble device. (To check device
compatibility, refer to
www.homelink.com.)

1

Within 5 seconds after pro-
gramming the garage door
opener has been completed,
if the garage door opener
motor is trained to Home-
Link

®

, both garage door

operation indicators will flash
rapidly (green) and the light
on the garage door opener
motor will blink twice, indicat-
ing that 2-way communica-
tion is enabled.

If the indicators do not flash, per-

form

2

 and

3

 within the first 10

presses of the HomeLink

®

 button

after programming has been com-

pleted.

2

Press a programmed Home-
Link

®

 button to operate a

garage door.

3

Within 1 minute of pressing
the HomeLink

®

 button, after

the garage door operation
has stopped, press the
“Learn” or “Smart” button on
the garage door opener
motor. Within 5 seconds of
the establishment of 2-way
communication with the
garage door opener, both
garage door operation indica-
tors in the vehicle will flash
rapidly (green) and the light
on the garage door opener
motor will blink twice, indicat-
ing that 2-way communica-
tion is enabled.

■

Reprogramming a single
HomeLink

®

 button

When the following procedure is
performed, buttons which
already have devices registered
to them can be overwritten:

1

With one hand, press and
hold the desired HomeLink

®



button.

2

When the HomeLink

®

 indica-

tor starts flashing (orange),
continue to hold the Home-
Link

®

 button and perform

“Programming HomeLink

®

”

1



449

6-4. Other interior features

6

Interior

 featur

es

COROLLA_U

(it takes 20 seconds for the
HomeLink

®

 indicator to start

flashing).

■

Before programming

●

Install a new battery in the trans-

mitter.

●

The battery side of the transmitter

must be pointed away from the
HomeLink

®

.

Press the appropriate Home-
Link

®

 button. The HomeLink

®



indicator light should turn on.
The status of the opening and
closing of a garage door is
shown by the indicators.

Opening
Closing

This function is only available if the
garage door opener motor used is a
compatible device. (To check
device compatibility, refer to
www.homelink.com.)

The indicators can operate
within approximately 820 ft. (250
m) of the garage door. However,
if there are obstructions
between the garage door and
the vehicle, such as houses and
trees, feedback signals from the
garage door may not be
received.
To recall the previous door oper-
ation status, press and release
either HomeLink

®

 buttons



and

 or

 and



simultaneously. The last
recorded status will be dis-
played for 3 seconds.

Press and hold the 2 outside
buttons for 10 seconds until the
HomeLink

®

 indicator light

changes from continuously lit
(orange) to rapidly flashing
(green).

If you sell your vehicle, be sure to
erase the programs stored in the

Operating HomeLink

®

Color

Status

Orange (flash-

ing)

Currently open-

ing/closing

Green

Opening/closing

has completed

Red (flashing)

Feedback sig-

nals cannot be

received

Erasing the entire Home-
Link

®

 memory (all three

codes)

450

6-4. Other interior features

COROLLA_U

HomeLink

®

 memory.

451

7

7

Maintena

nce
 a

nd ca

re

COROLLA_U

Maintenance and care

.

7-1. Maintenance and care

Cleaning and protecting the

vehicle exterior ..........

452

Cleaning and protecting the

vehicle interior ...........

454

7-2. Maintenance

Maintenance requirements

..................................

457

General maintenance..

458

Emission inspection and

maintenance (I/M) pro-
grams ........................

461

7-3. Do-it-yourself mainte-

nance

Do-it-yourself service pre-

cautions.....................

462

Hood ...........................

464

Positioning a floor jack

..................................

465

Engine compartment...

466

Tires ............................

475

Tire inflation pressure..

484

Wheels ........................

486

Air conditioning filter....

487

Wireless remote con-

trol/electronic key battery

..................................

489

Checking and replacing

fuses..........................

492

Light bulbs...................

495

452

7-1. Maintenance and care

COROLLA_U

7-1.Maintenance and care



Working from top to bottom,
liberally apply water to the
vehicle body, wheel wells and
underside of the vehicle to
remove any dirt and dust.



Wash the vehicle body using
a sponge or soft cloth, such
as a chamois.



For hard-to-remove marks,
use car wash soap and rinse
thoroughly with water.



Wipe away any water.



Wax the vehicle when the
waterproof coating deterio-
rates.

If water does not bead on a clean
surface, apply wax when the vehi-
cle body is cool.

■

Automatic car washes

●

Fold the mirrors before washing

the vehicle. Start washing from the

front of the vehicle. Make sure to

extend the mirrors before driving.

●

Brushes used in automatic car

washes may scratch the vehicle

surface, parts (wheel, etc.) and

harm your vehicle’s paint.

●

Vehicles with a rear spoiler: In cer-

tain automatic car washes, the

rear spoiler may interfere with

machine operation. This may pre-

vent the vehicle from being

cleaned properly or result in dam-

age to the rear spoiler.

■

High pressure car washes

As water may enter the cabin, do

not bring the nozzle tip near the

gaps around the doors or perimeter

of the windows, or spray these

areas continuously.

■

When using a car wash (vehi-

cles with a smart key system)

If the door handle becomes wet

while the electronic key is within the

effective range, the door may lock

and unlock repeatedly. In that case,

follow the following correction pro-

cedures to wash the vehicle:

●

Place the key in a position 6 ft. (2

m) or more separate from the

vehicle while the vehicle is being

washed. (Take care to ensure that

the key is not stolen.)

●

Set the electronic key to bat-

tery-saving mode to disable the

smart key system. (



P.126)

■

Wheels and wheel ornaments

●

Remove any dirt immediately by

using a neutral detergent.

●

Wash detergent off with water

immediately after use.

●

To protect the paint from damage,

make sure to observe the follow-

ing precautions.

• Do not use acidic, alkaline or

abrasive detergent

• Do not use hard brushes

• Do not use detergent on the

wheels when they are hot, such

as after driving or parking in hot

weather

■

Bumpers and side moldings

Do not scrub with abrasive cleaners.

■

Plated portions

If dirt cannot be removed, clean the

parts as follows:

Cleaning and protect-

ing the vehicle exte-

rior

Perform cleaning in a man-
ner appropriate to each
component and its material.

Cleaning instructions

453

7-1. Maintenance and care

7

Maintena

nce
 a

nd ca

re

COROLLA_U

●

Use a soft cloth dampened with an

approximately 5% solution of neu-

tral detergent and water to clean

the dirt off.

●

Wipe the surface with a dry, soft

cloth to remove any remaining

moisture.

●

To remove oily deposits, use alco-

hol wet wipes or a similar product.

WARNING

■

When washing the vehicle

Do not apply water to the inside of

the engine compartment. Doing

so may cause the electrical com-

ponents, etc. to catch fire.

■

Precautions regarding the

exhaust pipe

Exhaust gasses cause the

exhaust pipe to become quite hot.

When washing the vehicle, be

careful not to touch the pipe until it

has cooled sufficiently, as touch-

ing a hot exhaust pipe can cause

burns.

■

Precaution regarding the rear

bumper with Blind Spot Moni-

tor (if equipped)

If the paint of the rear bumper is

chipped or scratched, the system

may malfunction. If this occurs,

consult your Toyota dealer.

NOTICE

■

To prevent paint deteriora-

tion and corrosion on the

body and components (alumi-

num wheels, etc.)

●

Wash the vehicle immediately in

the following cases:

• After driving near the sea coast

• After driving on salted roads

• If coal tar or tree sap is present

on the paint surface

• If dead insects, insect droppings

or bird droppings are present on

the paint surface

• After driving in an area contami-

nated with soot, oily smoke,

mine dust, iron powder or chem-

ical substances

• If the vehicle becomes heavily

soiled with dust or mud

• If liquids such as benzene and

gasoline are spilled on the paint

surface

●

If the paint is chipped or

scratched, have it repaired

immediately.

●

To prevent the wheels from cor-

roding, remove any dirt and

store in a place with low humid-

ity when storing the wheels.

■

Cleaning the exterior lights

●

Wash carefully. Do not use

organic substances or scrub

with a hard brush.

This may damage the surfaces

of the lights.

●

Do not apply wax to the sur-

faces of the lights.

Wax may cause damage to the

lenses.

■

To prevent damage to the

windshield wiper arms

When lifting the wiper arms away

from the windshield, pull the driver

side wiper arm upward first, and

repeat for the passenger side.

When returning the wipers to their

original position, do so from the

passenger side first.

454

7-1. Maintenance and care

COROLLA_U



Remove dirt and dust using a
vacuum cleaner. Wipe dirty
surfaces with a cloth damp-
ened with lukewarm water.



If dirt cannot be removed,
wipe it off with a soft cloth
dampened with neutral deter-
gent diluted to approximately
1%.
Wring out any excess water
from the cloth and thoroughly
wipe off remaining traces of
detergent and water.

■

Shampooing the carpets

There are several commercial foam-

ing-type cleaners available. Use a

sponge or brush to apply the foam.

Rub in overlapping circles. Do not

use water. Wipe dirty surfaces and

let them dry. Excellent results are

obtained by keeping the carpet as

dry as possible.

■

Handling the seat belts

Clean with mild soap and lukewarm

water using a cloth or sponge. Also

check the belts periodically for

excessive wear, fraying or cuts.

NOTICE

■

When using a high pressure

car wash

●

When washing the vehicle, do

not spray the camera or its sur-

rounding area directly with a

high pressure washer. Shock

applied from high pressure

water may cause the device to

not operate normally.

●

Do not bring the nozzle tip close

to boots (rubber or resin manu-

factured cover), connectors or

the following parts. The parts

may be damaged if they come

into contact with high-pressure

water.

• Traction related parts

• Steering parts

• Suspension parts

• Brake parts

●

Keep the cleaning nozzle at

least 11.9 in. (30 cm) away from

the vehicles body. Otherwise

resin section, such as moldings

and bumpers, may be deformed

and damaged. Also, do not con-

tinuously hold the nozzle in the

same place.

●

Do not spray the lower part of

the windshield continuously. If

water enters the air conditioning

system intake located near the

lower part of the windshield, the

air conditioning system may not

operate correctly.

●

Do not wash the underside of

the vehicle using a high pres-

sure car washer.

Cleaning and protect-

ing the vehicle interior

Perform cleaning in a man-
ner appropriate to each
component and its material.

Protecting the vehicle
interior

455

7-1. Maintenance and care

7

Maintena

nce
 a

nd ca

re

COROLLA_U

WARNING

■

Water in the vehicle

●

Do not splash or spill liquid in

the vehicle.

Doing so may cause electrical

components, etc. to malfunc-

tion or catch fire.

●

Do not get any of the SRS com-

ponents or wiring in the vehicle

interior wet.

(



P.31)

An electrical malfunction may

cause the airbags to deploy or

not function properly, resulting

in death or serious injury.

●

Vehicles with wireless charger:

Do not let the wireless charger

(



P.435) get wet. Failure to do

so may cause the charger to

become hot and cause burns or

could cause electric shock

resulting in death or serious

injury.

■

Cleaning the interior (espe-

cially instrument panel)

Do not use polish wax or polish

cleaner. The instrument panel

may reflect off the windshield,

obstructing the driver’s view and

leading to an accident, resulting in

death or serious injury.

NOTICE

■

Cleaning detergents

●

Do not use the following types

of detergent, as they may dis-

color the vehicle interior or

cause streaks or damage to

painted surfaces:

• Areas other than the seats and

steering wheel: Organic sub-

stances such as benzene or

gasoline, alkaline or acidic solu-

tions, dye, and bleach

• Seats: Alkaline or acidic solu-

tions, such as thinner, benzene,

and alcohol

• Steering wheel: Organic sub-

stances, such as thinner, and

cleaner that contains alcohol

●

Do not use polish wax or polish

cleaner. The instrument panel’s

or other interior part’s painted

surface may be damaged.

■

Preventing damage to leather

surfaces

Observe the following precautions

to avoid damage to and deteriora-

tion of leather surfaces:

●

Remove any dust or dirt from

leather surfaces immediately.

●

Do not expose the vehicle to

direct sunlight for extended peri-

ods of time. Park the vehicle in

the shade, especially during

summer.

●

Do not place items made of

vinyl, plastic, or containing wax

on the upholstery, as they may

stick to the leather surface if the

vehicle interior heats up signifi-

cantly.

■

Water on the floor

Do not wash the vehicle floor with

water.

Vehicle systems such as the

audio system may be damaged if

water comes into contact with

electrical components such as the

audio system above or under the

floor of the vehicle. Water may

also cause the body to rust.

■

When cleaning the inside of

the windshield

Do not allow glass cleaner to con-

tact the lens. Also, do not touch

the lens. (



P.196)

456

7-1. Maintenance and care

COROLLA_U



Remove dirt using a
water-dampened soft cloth or
synthetic chamois.



Wipe the surface with a dry,
soft cloth to remove any
remaining moisture.

■

Cleaning the areas with

satin-finish metal accents

The metal areas use a layer of real

metal for the surface. It is necessary

to clean them regularly. If dirty areas

are left uncleaned for long periods

of time, they may be difficult to

clean.



Remove dirt and dust using a
vacuum cleaner.



Wipe off any excess dirt and
dust with a soft cloth damp-
ened with diluted detergent.

Use a diluted water solution of
approximately 5% neutral wool
detergent.



Wring out any excess water
from the cloth and thoroughly
wipe off all remaining traces
of detergent.



Wipe the surface with a dry,
soft cloth to remove any
remaining moisture. Allow the
leather to dry in a shaded and
ventilated area.

■

Caring for leather areas

Toyota recommends cleaning the

interior of the vehicle at least twice a

year to maintain the quality of the

vehicle’s interior.



Remove dirt and dust using a
vacuum cleaner.



Wipe it off with a soft cloth
dampened with neutral deter-
gent diluted to approximately
1%.



Wring out any excess water
from the cloth and thoroughly
wipe off remaining traces of
detergent and water.

NOTICE

■

Cleaning the inside of the rear

window

●

Do not use glass cleaner to

clean the rear window, as this

may cause damage to the rear

window defogger heater wires

or antenna. Use a cloth damp-

ened with lukewarm water to

gently wipe the window clean.

Wipe the window in strokes run-

ning parallel to the heater wires

or antenna.

●

Be careful not to scratch or

damage the heater wires or

antenna.

Cleaning the areas with
satin-finish metal accents

Cleaning the leather areas

Cleaning the synthetic
leather areas

457

7-2. Maintenance

7

Maintena

nce
 a

nd ca

re

COROLLA_U

7-2.Maintenance

■

Repair and replacement

It is recommended that genuine

Toyota parts be used for repairs to

ensure performance of each sys-

tem. If non-Toyota parts are used in

replacement or if a repair shop other

than a Toyota dealer performs

repairs, confirm the warranty cover-

age.

■

Allow inspection and repairs to

be performed by a Toyota

dealer

●

Toyota technicians are

well-trained specialists and are

kept up to date with the latest ser-

vice information. They are well

informed about the operation of all

systems on your vehicle.

●

Keep a copy of the repair order. It

proves that the maintenance that

has been performed is under war-

ranty coverage. If any problem

should arise while your vehicle is

under warranty, your Toyota

dealer will promptly take care of it.

General maintenance should be
performed on a daily basis. This
can be done by yourself or by a
Toyota dealer.

Scheduled maintenance should
be performed at specified inter-
vals according to the mainte-
nance schedule.

For details about maintenance
items and schedules, refer to the
“Scheduled Maintenance Guide” or
“Owner’s Manual Supplement”.

Maintenance require-

ments

To ensure safe and econom-
ical driving, day-to-day care
and regular maintenance
are essential. It is the
owner’s responsibility to
perform regular checks.
Toyota recommends the
maintenance below.

WARNING

■

If your vehicle is not properly

maintained

Improper maintenance could

result in serious damage to the

vehicle and possible death or seri-

ous injury.

■

Handling of the battery

●

Engine exhaust, some of its

constituents, and a wide variety

of automobile components con-

tain or emit chemicals known to

the State of California to cause

cancer and birth defects and

other reproductive harm. Work

in a well ventilated area.

●

Oils, fuels and fluids contained

in vehicles as well as waste pro-

duced by component wear con-

tain or emit chemicals known to

the State of California to cause

cancer and birth defects or

other reproductive harm. Avoid

exposure and wash any

affected area immediately.

●

Battery posts, terminals and

related accessories contain lead

and lead compounds which are

known to cause brain damage.

Wash your hands after han-

dling. (



P.472)

General maintenance

Scheduled maintenance

458

7-2. Maintenance

COROLLA_U

■

Resetting the message indicat-

ing maintenance is required

After the required maintenance is

performed according to the mainte-

nance schedule, please reset the

message.

To reset the message, follow the

procedure described below:

1

Press

 or

 of the meter

control switch to select

.

2

Press

 or

 to select “Vehi-

cle Settings” and then press and
hold

.

3

Press

 or

 to select

“Scheduled Maintenance” and
then press

.

4

Press

 or

 to select “Yes”

and then press

.

A message will be displayed on the

multi-information display when the

reset procedure has been com-

pleted.

You can perform some mainte-
nance procedures by yourself.
Please be aware that do-it-your-
self maintenance may affect
warranty coverage.

The use of Toyota repair manuals is
recommended.
For details about warranty cover-
age, refer to the separate “Owner’s
Warranty Information Booklet” or
“Owner’s Manual Supplement”.

Do-it-yourself mainte-
nance

General maintenance

Listed below are the general
maintenance items that
should be performed at the
intervals specified in the
“Owner’s Warranty Informa-
tion Booklet” or “Owner’s
Manual Supplement/Sched-
uled Maintenance Guide”. It
is recommended that any
problem you notice should
be brought to the attention
of your Toyota dealer or
qualified service shop for
advice.

WARNING

■

If the engine is running

Turn the engine off and ensure

that there is adequate ventilation

before performing maintenance

checks.

Engine compartment

Items

Check points

Battery

Check the connec-
tions. (



P.472)

Brake fluid

Is the brake fluid at
the correct level?
(



P.471)

Engine coolant

Is the engine cool-
ant at the correct
level? (



P.470)

Engine oil

Is the engine oil at
the correct level?
(



P.467)

459

7-2. Maintenance

7

Maintena

nce
 a

nd ca

re

COROLLA_U

Exhaust sys-
tem

There should not
be any fumes or
strange sounds.

Radiator/con-
denser

The radiator and
condenser should
be free from for-
eign objects.
(



P.471)

Washer fluid

Is there sufficient
washer fluid?
(



P.474)

Vehicle interior

Items

Check points

Accelerator
pedal

The accelerator
pedal should move
smoothly (without
uneven pedal effort
or catching).

Continuously
variable trans-
mission “Park”
mechanism

When parked on a
slope and the shift
lever is in P, is the
vehicle securely
stopped?

Brake pedal

• Does the brake

pedal move
smoothly?

• Does the brake

pedal have
appropriate
clearance from
the floor?
(



P.563)

• Does the brake

pedal have the
correct amount
of free play?
(



P.563)

Items

Check points

Clutch pedal

• Does the clutch

pedal move
smoothly?

• Does the clutch

pedal have
appropriate
clearance from
the floor?
(



P.563)

• Does the clutch

pedal have the
correct amount
of free play?
(



P.563)

Brakes

• The vehicle

should not pull to
one side when
the brakes are
applied.

• The brakes

should work
effectively.

• The brake pedal

should not feel
spongy.

• The brake pedal

should not get
too close to the
floor when the
brakes are
applied.

Head
restraints

Do the head
restraints move
smoothly and lock
securely?

Indica-
tors/buzzers

Do the indicators
and buzzers func-
tion properly?

Lights

Do all the lights
come on?

Items

Check points

460

7-2. Maintenance

COROLLA_U

Parking brake

• Does the park-

ing brake oper-
ate normally?

• When parked on

a slope and the
parking brake is
on, is the vehicle
securely
stopped?

Seat belts

• Do the seat belts

operate
smoothly?

• The seat belts

should not be
damaged.

Seats

Do the seat con-
trols operate prop-
erly?

Steering wheel

• Does the steer-

ing wheel rotate
smoothly?

• Does the steer-

ing wheel have
the correct
amount of free
play?

• There should not

be any strange
sounds coming
from the steer-
ing wheel.

Vehicle exterior

Items

Check points

Doors/trunk

Do the doors/trunk
operate smoothly?

Engine hood

Does the engine
hood lock system
work properly?

Items

Check points

Fluid leaks

There should not
be any signs of
fluid leakage after
the vehicle has
been parked.

Tires

• Is the tire infla-

tion pressure
correct?

• The tires should

not be damaged
or excessively
worn.

• Have the tires

been rotated
according to the
maintenance
schedule?

• The wheel nuts

should not be
loose.

Windshield
wipers

• The wiper blades

should not show
any signs of
cracking, split-
ting, wear, con-
tamination or
deformation.

• The wiper blades

should clear the
windshield with-
out streaking or
skipping.

Items

Check points
