Toyota 4Runner (2021 year). Manual in english - part 6





334

4-6. Driving tips

4RUNNER (U)

WARNING

Off-road vehicle precautions

Always observe the following precautions to minimize the risk of death, seri-
ous injury or damage to your vehicle:

In  a  rollover  crash,  an  unbelted  person  is  significantly  more  likely  to  die
than a person wearing a seat belt. Therefore, the driver and all passengers
should always fasten their seat belts.

Avoid sharp turns or abrupt maneuvers, if at all possible.
Failure  to  operate  this  vehicle  correctly  may  result  in  loss  of  control  or
vehicle rollover causing death or serious injury.

Loading cargo on the roof luggage carrier will make the center of the vehi-
cle gravity higher. Avoid high speeds, sudden starts, sharp turns, sudden
braking or abrupt maneuvers, otherwise it may result in loss of control or
vehicle rollover due to failure to operate this vehicle correctly.

Always slow down in gusty crosswinds. Because of its profile and higher
center of gravity, your vehicle is more sensitive to side winds than an ordi-
nary passenger car. Slowing down will allow you to have better control.

When  driving  off-road  or  in  rugged  terrain,  do  not  drive  at  excessive
speeds, jump, make sharp turns, strike objects, etc. This may cause loss
of control or vehicle rollover causing death or serious injury. You are also
risking expensive damage to your vehicle’s suspension and chassis.

Do  not  drive  horizontally  across  steep  slopes.  Driving  straight  up  or
straight  down  is  preferred.  Your  vehicle  (or  any  similar  off-road  vehicle)
can tip over sideways much more easily than forward or backward.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

335

4-6. Driving tips

4

Drivin

g

4RUNNER (U)

When driving your vehicle off-road, please observe the following pre-
cautions to ensure your driving enjoyment and to help prevent the clo-
sure of areas to off-road vehicles:

Drive your vehicle only in areas where off-road vehicles are permit-
ted to travel.

Respect  private  property.  Get  owner’s  permission  before  entering
private property.

Do not enter areas that are closed. Honor gates, barriers and signs
that restrict travel.

Stay on established roads. When conditions are wet, driving tech-
niques should be changed or travel delayed to prevent damage to
roads.

Additional information for off-road driving

For owners in U.S. mainland, Hawaii and Puerto Rico:
To  obtain  additional  information  pertaining  to  driving  your  vehicle  off-road,
consult the following organizations.

State and Local Parks and Recreation Departments

State Motor Vehicle Bureau

Recreational Vehicle Clubs

U.S. Forest Service and Bureau of Land Management

Off-road driving

-------------------------------------------------------------------------------------------------------------------------------------------------------------

336

4-6. Driving tips

4RUNNER (U)

WARNING

Off-road driving precautions

Always observe the following precautions to minimize the risk of death, seri-
ous injury or damage to your vehicle:

Drive carefully when off the road. Do not take unnecessary risks by driving
in dangerous places.

Do not grip the steering wheel spokes when driving off-road. A bad bump
could jerk the wheel and injure your hands. Keep both hands and espe-
cially your thumbs on the outside of the rim.

Always  check  your  brakes  for  effectiveness  immediately  after  driving  in
sand, mud, water or snow.

After  driving  through  tall  grass,  mud,  rock,  sand,  rivers,  etc.,  check  that
there is no grass, bush, paper, rags, stone, sand, etc. adhering or trapped
on  the  underbody.  Clear  off  any  such  matter  from  the  underbody.  If  the
vehicle is used with these materials trapped or adhering to the underbody,
a breakdown or fire could occur.

In  a  rollover  crash,  an  unbelted  person  is  significantly  more  likely  to  die
than a person wearing a seat belt. Therefore, the driver and all passengers
should fasten their seat belts whenever the vehicle is moving.

When  driving  off-road  or  in  rugged  terrain,  do  not  drive  at  excessive
speeds, jump, make sharp turns, strike objects, etc. This may cause loss
of control or vehicle rollover causing death or serious injury. You are also
risking expensive damage to your vehicle’s suspension and chassis.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

337

4-6. Driving tips

4

Drivin

g

4RUNNER (U)

NOTICE

To prevent water damage

Take  all  necessary  safety  measures  to  ensure  that  water  damage  to  the
engine or other components does not occur.

Water entering the engine air intake will cause severe engine damage.

Water entering the automatic transmission will cause deterioration in shift
quality, locking up of your transmission accompanied by vibration, and ulti-
mately damage.

Water can wash the grease from wheel bearings, causing rusting and pre-
mature  failure,  and  may  also  enter  the  differentials,  transmission  and
transfer case, reducing the gear oil’s lubricating qualities.

When you drive through water

If driving through water, such as when crossing shallow streams, first check
the  depth  of  the  water  and  the  bottom  of  the  riverbed  for  firmness.  Drive
slowly and avoid deep water.

Inspection after off-road driving

Sand  and  mud  that  has  accumulated  in  brake  drums  and  around  brake
discs may affect braking efficiency and may damage brake system compo-
nents.

Always perform a maintenance inspection after each day of off-road driv-
ing  that  has  taken  you  through  rough  terrain,  sand,  mud,  or  water.  For
scheduled maintenance information, refer to the “Scheduled Maintenance
Guide” or “Owner’s Manual Supplement”.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

338

4-6. Driving tips

4RUNNER (U)

-------------------------------------------------------------------------------------------------------------------------------------------------------------

-------------------------------------------------------------------------------------------------------------------------------------------------------------

340

4RUNNER (U)

5-1. Using the air conditioning system and defogger

Adjusting the temperature setting

To adjust the temperature setting, turn

 clockwise (warm) or

counterclockwise (cool).

If



 is not pressed, the system will blow ambient temperature air or

heated air.
For quick cooling, turn the temperature control knob to “MAX A/C”. The
air  conditioning  will  automatically  turn  on  and,  if  an  air  outlet  position
other than

 or

 is selected, the system will be set to recircu-

lated air mode. While “MAX A/C” is selected, it is not possible to turn off
the air conditioning.

Manual air conditioning system

: If equipped

Air conditioning controls

-------------------------------------------------------------------------------------------------------------------------------------------------------------

341

5-1. Using the air conditioning system and defogger

5

In

te

rior

fe

at

ures

4RUNNER (U)

Fan speed setting

To adjust the fan speed, turn

 clockwise (increase) or coun-

terclockwise (decrease).

Turning the knob to “OFF” turns off the fan.

Change the airflow mode

To select the air outlets, set

 to the desired position.

The positions between the air outlet selections shown below can also be
selected for more delicate adjustment.

Other functions

Switching between outside air and recirculated air modes

Defogging the windshield (

P. 342)

Defogging the rear window and outside rear view mirrors
(

P. 342)

Windshield wiper de-icer (if equipped) (

P. 342)

Switching between outside air and recirculated air modes

Press

 .

The mode switches between outside air mode (introduces air from out-
side  the vehicle)  (indicator  off) and  recirculated  air  mode (recycles air
inside the vehicle) (indicator on) each time the button is pressed.

Other functions

-------------------------------------------------------------------------------------------------------------------------------------------------------------

342

5-1. Using the air conditioning system and defogger

4RUNNER (U)

Defogging the windshield

Defoggers  are  used  to  defog  the  windshield  and  front  side  win-
dows.
Set the air outlet selector dial to

 position.

If the recirculated air mode is used, it will automatically switch to outside
air mode.
To  defog  the  windshield  and  the  side  windows  early,  increase  the  air
flow and temperature.

If  the  dehumidification  function  is  not  operating,  press

  to

operate the dehumidification function.

Defogging the rear window and outside rear view mirrors

Defoggers are used to defog the rear window, and to remove rain-
drops, dew and frost from the outside rear view mirrors.
Before  operating  the  defoggers,  make  sure  the  back  window  is
completely closed. (

P. 166)

Press

The defoggers will automatically turn off after their operation time. The
operation time varies depending on the ambient temperature and vehi-
cle speed.

Windshield wiper de-icer (if equipped)

This  feature  is  used  to  prevent  ice  from  building  up  on  the  wind-
shield and wiper blades.
Turns  the  windshield  wiper  de-
icer on/off

The windshield wiper de-icer will
automatically  turn  off  after
approximately 15 minutes.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

343

5-1. Using the air conditioning system and defogger

5

In

te

rior

fe

at

ures

4RUNNER (U)

Location of air outlets

The  air  outlets  and  air  volume
changes  according  to  the
selected airflow mode.

Adjusting the position of and opening and closing the air out-
lets

Air outlets

Front center outlets

Front side outlets

Rear outlets

Direct air flow to the left or right, up or down.
Turn the knob to open or close the vent.

1

2

-------------------------------------------------------------------------------------------------------------------------------------------------------------

344

5-1. Using the air conditioning system and defogger

4RUNNER (U)

Fogging up of the windows

The  windows  will  easily  fog  up  when  the  humidity  in  the  vehicle  is  high.

Turning

 on will dehumidify the air from the outlets and defog the wind-

shield effectively.

If you turn

 off, the windows may fog up more easily.

The windows may fog up if the recirculated air mode is used.

When driving on dusty roads

Close all windows. If dust thrown up by the vehicle is still drawn into the vehi-
cle after closing the windows, it is recommended that the air intake mode be
set to outside air mode and the fan speed to any setting except off.

Outside/recirculated air mode

Setting to the recirculated air mode temporarily is recommended in prevent-
ing dirty air from entering the vehicle interior and helping to cool the vehicle
when the outside air temperature is high.

When the outside temperature exceeds 75°F (24°C) and the air condition-
ing system is on

In order to reduce the air conditioning power consumption, the air condition-
ing system may switch to recirculated air mode automatically. This may also
reduce fuel consumption.

Recirculated air mode is selected as a default mode when the engine switch
is turned to the “ON” position (vehicles without a smart key system) or the
engine switch is turned to IGNITION ON mode (vehicles with a smart key
system).

It is possible to switch to outside air mode at any time by pressing





.

When the indicator light on

 flashes

Press



to turn off the cooling and dehumidification function and turn it on

again. There may be a problem in the air conditioning system if the indicator
light  continues  to  flash.  Turn  the  air  conditioning  system  off  and  have  it
inspected by your Toyota dealer.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

345

5-1. Using the air conditioning system and defogger

5

In

te

rior

fe

at

ures

4RUNNER (U)

When the outside temperature falls to nearly 32

F (0

C)

The dehumidification function may not operate even when

 is pressed.

Ventilation and air conditioning odors

To let fresh air in, set the air conditioning system to the outside air mode.

During use, various odors from inside and outside the vehicle may enter into
and accumulate in the air conditioning system. This may then cause odor to
be emitted from the vents.

To reduce potential odors from occurring:
It  is  recommended  that  the  air  conditioning  system  be  set  to  outside  air
mode prior to turning the vehicle off.

Air conditioning system refrigerant

The meaning of each symbol on the label are as follows:

A  label  regarding  the  refrigerant  of  the
air conditioning system is attached to the
hood at the location shown in the follow-
ing illustration.

Caution

Air conditioning system

Air conditioning system lubricant type

Requires  registered  technician  to  service  air  conditioning
system

Flammable refrigerant

-------------------------------------------------------------------------------------------------------------------------------------------------------------

346

5-1. Using the air conditioning system and defogger

4RUNNER (U)

WARNING

To prevent the windshield from fogging up

Do  not  use

  during  cool  air operation in extremely humid  weather.

The difference between the temperature of the outside air and that of the
windshield can cause the outer surface of the windshield to fog up, block-
ing your vision.

To prevent burns

Do not touch the rear view mirror surfaces when the outside rear view mir-
ror defoggers are on.

Do not touch the glass at lower part of the windshield or to the side of the
front pillars when the windshield wiper de-icer is on.

NOTICE

To prevent battery discharge

Do not leave the air conditioning system on longer than necessary when the
engine is stopped.

When repairing/replacing parts of the air conditioning system

Have repair/replacement performed by your Toyota dealer.
When a part of the air conditioning system, such as the evaporator, is to be
replaced, it must be replaced with a new one.

Do not place anything on the instrument
panel  which  may  cover  the  air  outlets.
Otherwise,  air  flow  may  be  obstructed,
preventing  the  windshield  defoggers
from defogging.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

347

5-1. Using the air conditioning system and defogger

5

In

te

rior

fe

at

ures

4RUNNER (U)

Adjusting the temperature setting

To  adjust  the  temperature  setting,  turn

  clockwise  to

increases  the  temperature  and  turn

  counterclockwise  to

decreases the temperature.

If

 is not pressed, the system will blow ambient temperature air or

heated air.

Fan speed setting

To adjust the fan speed, press “

” on

 to increase the fan

speed and “

” to decrease the fan speed.

Press

 to turn the fan off.

Automatic air conditioning system

: If equipped

Air outlets and fan speed are automatically adjusted according
to the temperature setting.

Air conditioning controls

-------------------------------------------------------------------------------------------------------------------------------------------------------------

348

5-1. Using the air conditioning system and defogger

4RUNNER (U)

Change the airflow mode

To change the air outlets, press

 or

.

Other functions

Switching between outside air and recirculated air modes
(

P. 349)

Defogging the windshield (

P. 349)

Defogging the rear window and outside rear view mirrors
(

P. 349)

Windshield wiper de-icer (if equipped) (

P. 350)

Press

.

The air conditioning system begins to operate. Air outlets and fan speed
are automatically adjusted according to the temperature setting.

Adjust the temperature setting.
To stop the operation, press

.

Automatic mode indicator

If the fan speed setting or air flow modes are operated, the auto-
matic mode indicator goes off. However, automatic mode for func-
tions other than that operated is maintained.

Adjusting the temperature for driver and passenger seats sep-
arately (“DUAL” mode)

Perform the following procedures to turn on the “DUAL” mode:

Press

.

Adjust the passenger’s side temperature setting.
The indicator comes on when the “DUAL” mode is on.
While in “DUAL” mode, the temperature of the rear air outlets is
set at the right-hand side temperature setting.

Using automatic mode

1

2

3

-------------------------------------------------------------------------------------------------------------------------------------------------------------

349

5-1. Using the air conditioning system and defogger

5

In

te

rior

fe

at

ures

4RUNNER (U)

Switching between outside air and recirculated air modes

Press

.

The mode switches between outside air mode (the indicator is off) and
recirculated  air  mode  (the  indicator  is  on)  each  time  the  button  is
pressed.

Defogging the windshield

Defoggers  are  used  to  defog  the  windshield  and  front  side  win-
dows.

Press

.

The dehumidification function operates and fan speed increases.
Set the outside/recirculated air mode button to the outside air mode if
the recirculated air mode is used. (It may switch automatically.)
To defog the windshield and the side windows early, turn the air flow and
temperature up.

To return to the previous mode, press

 again when the windshield

is defogged.

Defogging the rear window and outside rear view mirrors

Defoggers are used to defog the rear window, and to remove rain-
drops, dew and frost from the outside rear view mirrors.
Before  operating  the  defoggers,  make  sure  the  back  window  is
completely closed. (

P. 166)

Press

The defoggers will automatically turn off after their operation time. The
operation time varies depending on the ambient temperature and vehi-
cle speed.

Other functions

-------------------------------------------------------------------------------------------------------------------------------------------------------------

350

5-1. Using the air conditioning system and defogger

4RUNNER (U)

Windshield wiper de-icer (if equipped)

This  feature  is  used  to  prevent  ice  from  building  up  on  the  wind-
shield and wiper blades.
Turns  the  windshield  wiper  de-
icer on/off

The windshield wiper de-icer will
automatically  turn  off  after
approximately 15 minutes.

Location of air outlets

The  air  outlets  and  air  volume
changes  according  to  the
selected airflow mode.

Air outlets

-------------------------------------------------------------------------------------------------------------------------------------------------------------

351

5-1. Using the air conditioning system and defogger

5

In

te

rior

fe

at

ures

4RUNNER (U)

Adjusting the position of and opening and closing the air out-
lets

Using automatic mode

Fan speed is adjusted automatically according to the temperature setting and
the ambient conditions.
Therefore, the fan may stop for a while until warm or cool air is ready to flow

immediately after

 is pressed.

Front center outlets

Front side outlets

Rear outlets

Direct air flow to the left or right, up or down.
Turn the knob to open or close the vent.

1

2

-------------------------------------------------------------------------------------------------------------------------------------------------------------

352

5-1. Using the air conditioning system and defogger

4RUNNER (U)

Fogging up of the windows

The  windows  will  easily  fog  up  when  the  humidity  in  the  vehicle  is  high.

Turning

 on will dehumidify the air from the outlets and defog the wind-

shield effectively.

If you turn

 off, the windows may fog up more easily.

The windows may fog up if the recirculated air mode is used.

When driving on dusty roads

Close all windows. If dust thrown up by the vehicle is still drawn into the vehi-
cle after closing the windows, it is recommended that the air intake mode be
set to outside air mode and the fan speed to any setting except off.

Outside/recirculated air mode

Setting to the recirculated air mode temporarily is recommended in prevent-
ing dirty air from entering the vehicle interior and helping to cool the vehicle
when the outside air temperature is high.

Outside/recirculated  air  mode  may  automatically  switch  depending  on  the
temperature  setting,  outside  temperature,  pressure,  engine  coolant  tem-
perature or inside temperature.

When the outside temperature exceeds 75°F (24°C) and the air condition-
ing system is on

In order to reduce the air conditioning power consumption, the air condition-
ing system may switch to recirculated air mode automatically. This may also
reduce fuel consumption.

Recirculated air mode is selected as a default mode when the engine switch
is turned to the “ON” position (vehicles without a smart key system) or the
engine switch is turned to IGNITION ON mode (vehicles with a smart key
system).

It is possible to switch to outside air mode at any time by pressing



 .

When the outside temperature falls to nearly 32

F (0

C)

The dehumidification function may not operate even when

 is pressed.

When driving on dusty roads

Close all windows. If dust thrown up by the vehicle is still drawn into the vehi-
cle after closing the windows, it is recommended that the air intake mode be
set to outside air mode and the fan speed to any setting except off.

When the indicator light on

 flashes

Press



to turn off the cooling and dehumidification function and turn it on

again. There may be a problem in the air conditioning system if the indicator
light  continues  to  flash.  Turn  the  air  conditioning  system  off  and  have  it
inspected by your Toyota dealer.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

353

5-1. Using the air conditioning system and defogger

5

In

te

rior

fe

at

ures

4RUNNER (U)

Ventilation and air conditioning odors

To let fresh air in, set the air conditioning system to the outside air mode.

During use, various odors from inside and outside the vehicle may enter into
and accumulate in the air conditioning system. This may then cause odor to
be emitted from the vents.

To reduce potential odors from occurring:
• It is recommended that the air conditioning system be set to outside air

mode prior to turning the vehicle off.

• The start timing of the blower may be delayed for a short period of time

immediately  after  the  air  conditioning  system  is  started  in  automatic
mode.

Air conditioning filter

P. 441

Air conditioning system refrigerant

The meaning of each symbol on the label are as follows:

A  label  regarding  the  refrigerant  of  the
air conditioning system is attached to the
hood at the location shown in the follow-
ing illustration.

Caution

Air conditioning system

Air conditioning system lubricant type

Requires  registered  technician  to  service  air  conditioning
system

Flammable refrigerant

-------------------------------------------------------------------------------------------------------------------------------------------------------------

354

5-1. Using the air conditioning system and defogger

4RUNNER (U)

WARNING

To prevent the windshield from fogging up

Do  not  use

  during  cool  air operation in extremely humid  weather.

The difference between the temperature of the outside air and that of the
windshield can cause the outer surface of the windshield to fog up, block-
ing your vision.

To prevent burns

Do not touch the rear view mirror surfaces when the outside rear view mir-
ror defoggers are on.

Do not touch the glass at lower part of the windshield or to the side of the
front pillars when the windshield wiper de-icer is on.

NOTICE

To prevent battery discharge

Do not leave the air conditioning system on longer than necessary when the
engine is stopped.

When repairing/replacing parts of the air conditioning system

Have repair/replacement performed by your Toyota dealer.
When a part of the air conditioning system, such as the evaporator, is to be
replaced, it must be replaced with a new one.

Do not place anything on the instrument
panel  which  may  cover  the  air  outlets.
Otherwise,  air  flow  may  be  obstructed,
preventing  the  windshield  defoggers
from defogging.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

355

5-1. Using the air conditioning system and defogger

5

In

te

rior

fe

at

ures

4RUNNER (U)

Seat heaters

/seat ventilators

: If equipped

The seat heaters warm the seats and the seat ventilators main-
tain good airflow by blowing air through the seats.

WARNING

Care should be taken to prevent injury if anyone in the following categories
comes in contact with the seats when the heater is on:
• Babies,  small  children,  the  elderly,  the  sick  and  the  physically  chal-

lenged

• Persons with sensitive skin
• Persons who are fatigued
• Persons who have taken alcohol or drugs that induce sleep (sleeping

drugs, cold remedies, etc.)

Observe the following precautions to prevent the minor burns or overheat-
ing
• Do  not  cover  the  seat  with  a  blanket  or  cushion  when  using  the  seat

heater.

• Do not use seat heater more than necessary.

NOTICE

Do not put heavy objects that have an uneven surface on the seat and do
not stick sharp objects (needles, nails, etc.) into the seat.

To prevent battery discharge, do not use the functions when the engine is
off.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

356

5-1. Using the air conditioning system and defogger

4RUNNER (U)

Vehicles with ventilator

Press  the  knob  to  release  it,
and turn the knob to the desired
temperature setting.
OFF

Press the knob to lock it when not
in use.

Ventilation
Heat

Vehicles without ventilator

On

The indicator light comes on.

Adjusts the seat temperature

The  further  you  move  the  dial  for-
ward,  the  warmer  the  seat
becomes.

Off

Move  the  dial  fully  backward.  The
indicator light turns off.

The seat heaters/seat ventilators can be used when

Vehicles without a smart key system

The engine switch is in the “ON” position.

Vehicles with a smart key system

The engine switch is in IGNITION ON mode.

Seat heaters/ventilators

1

2

3

4

1

2

3

-------------------------------------------------------------------------------------------------------------------------------------------------------------

357

5

In

te

rior

fe

at

ures

4RUNNER (U)

5-2. Using the interior lights

Rear interior light (

P. 358)

Front interior light/front personal lights (

P. 358)

Shift  lever  light  (when  the  engine  switch  is  in  the  “ACC”  or  “ON”
position  [without  a  smart  key  system]  or  the  engine  switch  is  in
ACCESSORY or IGNITION ON mode [with a smart key system])
Inside door handle lights (if equipped)
Outer foot lights (if equipped)
Engine switch light (vehicles without a smart key system)
Footwell lights (if equipped)
Door courtesy lights

Turning the instrument panel light control dial fully downward disables
the inside door handle lights, footwell lights and shift lever light.
(

P. 89)

Interior lights list

1

2

3

4

5

6

7

8

-------------------------------------------------------------------------------------------------------------------------------------------------------------

358

5-2. Using the interior lights

4RUNNER (U)

Front

Turns the lights off
Turns the door position on

Rear

Turns the door position on
Turns the light off
Turns the light on

Turns the lights on/off

Interior lights

1

2

1

2

3

Personal lights

-------------------------------------------------------------------------------------------------------------------------------------------------------------

359

5-2. Using the interior lights

5

In

te

rior

fe

at

ures

4RUNNER (U)

Illuminated entry system

Vehicles without a smart key system

The lights  automatically turn on/off  according to the  engine switch position,
whether  the  doors  are  locked/unlocked,  and  whether  the  doors  are  open/
closed.

Vehicles with a smart key system

The  lights  automatically  turn  on/off  according  to  engine  switch  mode,  the
presence of the electronic key, whether the doors are locked/unlocked, and
whether the doors are opened/closed.

To prevent battery discharge

If  the  following  lights  remain  on,  the  lights  will  go  off  automatically  after  20
minutes:

Engine switch light

Front interior light

Rear interior light

Personal lights

Footwell lights

Inside door handle lights

Door courtesy lights

Customization

Setting (e.g. the time elapsed before lights turn off) can be changed.
(Customizable features:

P. 545)

NOTICE

To prevent battery discharge

Do  not  leave  the  lights  on  longer  than  necessary  when  the  engine  is  not
running.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

360

4RUNNER (U)

5-3. Using the storage features

List of storage features

Auxiliary box (

P. 364)

Glove box (

P. 361)

Bottle holders (

P. 366)

Tissue pocket (

P. 365)

Cup holders (

P. 362)

Pen holder (

P. 365)

Console box (

P. 361)

Coin holder (

P. 365)

WARNING

Do not leave glasses, lighters or spray cans in the storage spaces, as this
may cause the following when cabin temperature becomes high:
• Glasses may be deformed by heat or cracked if they come into contact

with other stored items.

• Lighters or spray cans may explode. If they come into contact with other

stored  items,  the  lighter  may  catch  fire  or  the  spray  can  may  release
gas, causing a fire hazard.

When driving or when the storage compartments are not in use, keep the
lids closed. In the event of sudden braking or sudden swerving, an acci-
dent  may  occur  due  to  an  occupant  being  struck  by  an  open  lid  or  the
items stored inside.

1

2

3

4

5

6

7

8

-------------------------------------------------------------------------------------------------------------------------------------------------------------

361

5-3. Using the storage features

5

In

te

rior

fe

at

ures

4RUNNER (U)

The glove box can be opened by pressing the lock release button and
can be locked and unlocked by using the master key (vehicles without
a smart key system) or the mechanical key (vehicles with a smart key
system).

Open
Unlock
Lock

Lift  the  lid  while  pulling  up  the
knob to release the lock.

The separator can be used in either of the positions shown in the illus-
tration

Glove box

1

2

3

Console box

Change the separator position.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

362

5-3. Using the storage features

4RUNNER (U)

Cup holders

Front seats

Rear  seats  (without  third  row
seats)

Pull down the rear seat center
armrest.

Second  row  seats  (with  third
row seats)

Third row seats (if equipped)

Pull down the second row seat
center armrest and press down
the button on the armrest.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

363

5-3. Using the storage features

5

In

te

rior

fe

at

ures

4RUNNER (U)

Adjusting the size of the cup holders

Front seats

Rear seats (without third row seats)

Remove the adapter.

Remove the adapter.

WARNING

Items unsuitable for the cup holders

Do not place anything other than cups or aluminum cans in the cup holders.
Other items may be thrown out of the holders in the event of an accident or
sudden  braking,  causing  injury.  If  possible,  cover  hot  drinks  to  prevent
burns.

When not in use (second row seat cup holders only)

Keep the cup holders closed. In the event of sudden braking, an accident
may occur due to an occupant being struck by the open cup holders or the
items stored inside.

NOTICE

To prevent damage to the rear cup holders (second row seats only)

Stow the cup holders before stowing the armrest.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

364

5-3. Using the storage features

4RUNNER (U)

Push the lid.

Auxiliary box (if equipped)

WARNING

Items unsuitable for storing

Do not store items heavier than 0.4 lb. (0.2 kg).
Doing so may cause the auxiliary box to open and the items inside may fall
out, resulting in an accident.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

365

5-3. Using the storage features

5

In

te

rior

fe

at

ures

4RUNNER (U)

Lift the lid while pulling up the knob to release the lock.

Coin holder
Tissue pocket
Pen holder

Coin holder/tissue pocket/pen holder

1

2

3

-------------------------------------------------------------------------------------------------------------------------------------------------------------

366

5-3. Using the storage features

4RUNNER (U)

When using the bottle holder

When storing a bottle, close the cap.

The bottle may not be stored depending on its size or shape.

Bottle holders

Front seats

Rear  seats  (without  third  row
seats)/second row seats (with
third row seats)

WARNING

Items unsuitable for the bottle holder

Do not place anything other than a bottle in the bottle holders.
Other items may be thrown out of the holders in the event of an accident or
sudden braking and cause injury.

NOTICE

Items that should not be stowed in the bottle holders

Put the cap on before stowing a bottle. Do not place open bottles in the bot-
tle holders, or glasses and paper cups containing liquid. The contents may
spill and glasses may break.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

367

5-3. Using the storage features

5

In

te

rior

fe

at

ures

4RUNNER (U)

Cargo hooks

Vehicles with third seats
Fold down the third seats. (

P. 145)

Raise the hook to use.

The  cargo  hooks  are  provided
for securing loose items.

Vehicles without third seats

Raise the hook to use.

The  cargo  hooks  are  provided
for securing loose items.

Luggage compartment features

1

2

-------------------------------------------------------------------------------------------------------------------------------------------------------------

368

5-3. Using the storage features

4RUNNER (U)

Cargo net hooks

The cargo net itself is not included as original equipment.

Vehicles with third seats (pattern 1)

Raise  the  rear  cargo  hook  to
use.

Vehicles with third seats (pattern 2)
Fold down the third seats. (

P. 145)

Raise the cargo hook to use.

Vehicles without third seats (pattern 1)

Raise  the  rear  cargo  hook  to
use.

1

2

-------------------------------------------------------------------------------------------------------------------------------------------------------------

369

5-3. Using the storage features

5

In

te

rior

fe

at

ures

4RUNNER (U)

Vehicles without third seats (pattern 2)

Raise the cargo hook to use.

Storage compartment

Open the storage compartment as shown.

Type A (if equipped)

Type B (if equipped)

-------------------------------------------------------------------------------------------------------------------------------------------------------------

370

5-3. Using the storage features

4RUNNER (U)

Slide deck (if equipped)

Slide the deck while turning the
lock  release  lever,  and  then
release  the  lever  after  sliding
the deck to the lock position.

Half-slide locked position
Full-slide locked position

Grocery bag hooks

Type B only: To use the grocery bag hooks, slide the slide deck to
the full-slide locked position.

1

2

Type A

Type B (if equipped)

-------------------------------------------------------------------------------------------------------------------------------------------------------------

371

5-3. Using the storage features

5

In

te

rior

fe

at

ures

4RUNNER (U)

WARNING

When the cargo hooks are not in use

To avoid injury, always return the cargo hooks to their stowed positions.

Slide deck operating precaution (if equipped)

Be careful not to get hands or feet pinched by the slide deck.

Be careful not to allow the slide deck to hit any persons or luggage while
sliding the deck.

Do not operate the slide deck while someone is on it.
Doing so may cause an accident.

If operating the slide deck when the vehicle is stopped on an incline, the
slide deck may move faster. Be careful not to allow the slide deck to hit
you or pinch your fingers etc.

After sliding the deck, make sure it is securely locked in position.

Do not close the back door while any person is sitting on the slide deck or
any person is between the slide deck and back door.

Do not stow any objects into the space between the slide deck rails.

NOTICE

To prevent damage to the cargo net hooks

Avoid hanging things other than a cargo net on them.

Slide deck weight capacity (if equipped)

Do not load anything heavier than 440 lb. (200 kg) on the sliding deck.

Grocery bag hook weight capacity

Do not hang any object heavier than 8.8 lb. (4 kg) on the grocery bag hooks.

When using the slide deck (if equipped)

Do  not  close  the  back  door  while  the  slide  deck  is  sliding  out.  Doing  so
may cause the back door or slide deck to break.

If operating the slide deck when the vehicle is stopped on an incline, the
slide deck may move faster. Be careful as luggage may become damaged
or fly out and damage the cabin.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

372

4RUNNER (U)

5-4. Other interior features

To  set  the  visor  in  the  forward
position, flip it down.
To set the visor in the side posi-
tion,  flip  down,  unhook,  and
swing it to the side.
To use the side extender, place
the  visor  in  the  side  position,
then slide it backward.

Slide the cover to open.

The  light  turns  on  when  the  cover
is opened.

Other interior features

Sun visors

1

2

3

Vanity mirrors

NOTICE

To prevent battery discharge

Do not leave the vanity lights on for extended periods while the engine is off.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

373

5-4. Other interior features

5

In

te

rior

fe

at

ures

4RUNNER (U)

The clock can be adjusted by pressing the buttons.

Adjusts the hours
Adjusts the minutes

The clock is displayed when

Vehicles without a smart key system

The engine switch is in the “ACC” or “ON” position.

Vehicles with a smart key system

The engine switch is in ACCESSORY or IGNITION ON mode.

When disconnecting and reconnecting battery terminals

The clock data will be reset.

Clock

1

2

-------------------------------------------------------------------------------------------------------------------------------------------------------------

374

5-4. Other interior features

4RUNNER (U)

The power outlet can be used for electrical appliances.

Main switch

To  use  the  power  outlet,  turn  on
the main switch.

The power supply starts a few sec-
onds  after  the  main  switch  is
pressed.

Power outlet socket (luggage compartment)

Open the lid.

Maximum available capacity of the power outlet

While the vehicle is being driven
The maximum capacity of the power outlet is always 120 V AC/
100 W.

When the vehicle is stationary
The maximum capacity of the power outlet varies depending on
the position of the shift lever.

• The  maximum  capacity  is  120  V  AC/100  W  when  the  shift

lever is in any position other than P or N.

• The  maximum  capacity  is  120  V  AC/400  W  when  the  shift

lever is in P or N.

The maximum capacity of 400 W can only be restored by turning the
power outlet main switch off and then on again with the shift lever in
P or N.

Power outlets (120 V AC) (if equipped)

-------------------------------------------------------------------------------------------------------------------------------------------------------------

375

5-4. Other interior features

5

In

te

rior

fe

at

ures

4RUNNER (U)

The power outlet can be used when

The engine is running.

The indicator light changes according to the maximum available capac-
ity as follows:

When the power outlet is in operation

The sound of the cooling fan may be heard from the right side of the luggage
compartment. This is normal and does not indicate a malfunction.

If the engine is started with the power outlet main switch on

The maximum capacity of the power supply may decrease to below the stan-
dard, or may be cut off completely, even when the vehicle is stationary.

The protection circuit may be activated to cut the power supply if any of
the following conditions apply:

The engine is started with the power outlet main switch on.

Use of electrical appliances exceeding the maximum capacity is attempted.
A sound may be heard when the protection circuit is activated. This is nor-
mal and does not indicate a malfunction.

Electrical appliances, which consume power exceeding 100 W, have been
used continuously for a long time period.

The total power usage by all electrical features (headlights, air conditioning,
etc.)  has  exceeded  the  total  vehicle  maximum  for  an  extended  period  of
time.

If the protection circuit is activated and the power supply is cut, conduct
the following procedure:

Park the vehicle in a safe place, and then securely apply the parking brake.
Check and ensure that the shift lever is in P or N.
Make  sure  that  the  power  consumption  of  the  electric  appliance  is  within
the maximum capacity of the power outlet and the appliance is not broken.
Press the power outlet main switch again.

When the cabin temperature is high, open the windows to cool the tempera-
ture  down.  Once  it  reaches  the  normal  temperature,  turn  the  power  outlet
main switch on again.
If  the  power  supply  does  not  resume  even  after  the  above  procedure  has
been performed, have the vehicle inspected by your Toyota dealer.

120 V AC/400 W
120 V AC/100 W

1

2

1

2

3

4

-------------------------------------------------------------------------------------------------------------------------------------------------------------

376

5-4. Other interior features

4RUNNER (U)

WARNING

Using a power outlet

Observe the following precautions to reduce the risk of injury.

Use  of the  power outlet  when it  is wet with  water or snow may result  in
electrical shocks and is extremely dangerous. The power outlet must be
thoroughly dried before use.

Do not allow children to use or play with the power outlet.

Be careful not to get any part of your body caught in the power outlet lid.

When using electrical appliances, strictly follow any cautions and notices
written on their labels and in the manufacturers' instruction manuals.

Do not modify, disassemble or repair the power outlet or its inverter in any
way. Doing so may result in unexpected malfunctions or accidents, which
could  cause  serious  damage  or  injuries.  Contact  your  Toyota  dealer  for
any necessary repairs.

To prevent injuries and accidents, secure all electric appliances before
use and do not use any appliances that may do any of the following:

Distract the driver while driving, or hamper safe driving.

Result in a fire or burn injuries due to the appliance rolling, falling or over-
heating while driving.

Emit steam while the windows of the cabin are closed.

To prevent unexpected accidents, such as electric shocks, do not per-
form any of the following actions:

Using the power outlet for electric heaters while sleeping.

Contaminating the power outlet with liquid substances or mud.

Handling electrical appliance plugs at the power outlet with wet hands or
feet.

Inserting foreign objects into the power outlet.

Using malfunctioning electric appliances.

Inserting inappropriate or badly fitting plugs into the power outlet.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

377

5-4. Other interior features

5

In

te

rior

fe

at

ures

4RUNNER (U)

NOTICE

To avoid damaging the power outlet and the plug

Close the power outlet lid when not in use.

Do  not  allow  foreign  objects  or  liquids  to  enter  the  power  outlet,  as  this
may cause a short circuit.

Do not use plug adaptors to connect too many plugs to the power outlet.

After removing a plug, gently close the power outlet lid.

To prevent the fuse from being blown

Do  not  use  a  120  V AC  appliance  that  requires  more  than  the  maximum
capacity of the power outlet. If a 120 V AC appliance that consumes more
than the maximum capacity is used, the protection circuit will cut the power
supply.

Appliances that may not operate properly (120 V AC)

The following 120 V AC appliances may not operate even if their power con-
sumption is under maximum capacity.

Appliances with high initial peak wattage

Measuring devices that process precise data.

Other appliances that require an extremely stable power supply

To prevent battery discharge

Turn off all the vehicle's electronic equipment and accessories, such as the
headlights and air conditioning, when electrical appliances that consume in
excess of 100 W are used continuously for long periods of time.

To prevent any damage caused by heat

Do  not  use  any  electrical  appliances  that  give  off  intense  heat,  such  as
toasters, in any locations including the internal or external trim, seats and
deck.

Do not use any electrical appliances that are easily affected by vibration or
heat inside the vehicle. Vibration while driving, or the heat of the sun while
parking, may result in damage to those electrical appliances.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

378

5-4. Other interior features

4RUNNER (U)

Please use as a power supply for electronic goods that use less than
12 VDC / 10 A (power consumption of 120 W).
When using electronic goods, make sure that the power consumption
of all the connected power outlets is less than 120 W.

Center panel

Open the lid.

NOTICE

If any electrical appliances are to be used while driving

Securely fasten both the appliances and their cables to prevent them from
falling or getting caught in any of the power train components.

If  the  power  outlet is  loose  when  an  electrical appliance  plug is  con-
nected

Replace the outlet. Contact your Toyota dealer for any necessary replace-
ments.

If the power outlet gets dirty

Turn the main switch off and use a soft, clean cloth to wipe it gently. Do not
use any cleansing materials, such as organic solvents, wax, or compound
cleaners, as these may damage the power outlet or cause it to malfunction.

Power outlets

-------------------------------------------------------------------------------------------------------------------------------------------------------------

379

5-4. Other interior features

5

In

te

rior

fe

at

ures

4RUNNER (U)

Console box (inside)

Lift  the  lid  while  pulling  up  the
knob to release the lock.

Open the lid.

1

2

Luggage  compartment  (vehi-
cles without the 120 V AC)

Luggage  compartment  (vehi-
cles with the 120 V AC)

Open the lid.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

380

5-4. Other interior features

4RUNNER (U)

The power outlets can be used when

Vehicles without a smart key system

The engine switch is in the “ACC” or “ON” position.

Vehicles with a smart key system

The engine switch is in ACCESSORY or IGNITION ON mode.

When turning the engine switch off

Disconnect electrical devices with charging functions, such as mobile battery
packs.
If such devices are left connected, the engine switch may not be turned off
normally.

NOTICE

To avoid damaging the power outlets

Close the power outlet lids when the power outlets are not in use.
Foreign objects or liquids that enter the power outlets may cause a short cir-
cuit.

To prevent battery discharge

Do not use the power outlets longer than necessary when the engine is off.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

381

5-4. Other interior features

5

In

te

rior

fe

at

ures

4RUNNER (U)

The USB charging ports are used to supply 2.1 A of electricity at 5 V
to external devices (power consumption of 10.5 W).
The USB charging ports are for charging only. They are not designed
for data transfer or other purposes.
Depending on the external device, it may not charge properly. Refer to
the  manual  included  with  the  device  before  using  a  USB  charging
port.

Using the USB charging ports

Open the lid.

The USB charging ports can be used when

The engine switch is in ACCESSORY or IGNITION ON mode.

Situations in which the USB charging ports may not operate correctly

If a device which consumes more than 2.1 A at 5 V (10.5 W) is connected

If a device designed to communicate with a personal computer, such as a
USB memory device, is connected

If the connected external device is turned off (depending on device)

If the temperature inside the vehicle is high, such as after the vehicle has
been parked in the sun

About connected external devices

Depending on the connected external device, charging may occasionally be
suspended and then start again. This is not a malfunction.

USB charging ports

-------------------------------------------------------------------------------------------------------------------------------------------------------------

382

5-4. Other interior features

4RUNNER (U)

NOTICE

To prevent damage to the USB charging ports

Do not insert foreign objects into the ports.

Do not spill water or other liquids into the ports.

When  the USB  charging ports are not  in use,  close the  lids. If  a foreign
object or liquid enters a port may cause a short circuit.

Do not apply excessive force to or impact the USB charging ports.

Do not disassemble or modify the USB charging ports.

To prevent damage to external devices

Do not leave external devices in the vehicle. The temperature inside the
vehicle may become high, resulting in damage to an external device.

Do not push down on or apply unnecessary force to an external device or
the cable of an external device while it is connected.

To prevent battery discharge

Do not use the USB charging ports for a long period of time with the engine
stopped.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

383

5-4. Other interior features

5

In

te

rior

fe

at

ures

4RUNNER (U)

Pull down the armrest for use.

An assist grip (type A) installed on
the ceiling can be used to support
your  body  while  sitting  on  the
seat.
An assist grip (type B) installed on
the  pillar  can  be  used  when  get-
ting  in  or  out  of  the  vehicle  and
others.

Assist grip (type A)
Assist grip (type B)

Armrest

NOTICE

Do not apply too much load on the armrest.

Assist grips

1

2

WARNING

Assist grip (type A)

Do not use the assist grip (type A) when getting in or out of the vehicle or
rising from your seat.

NOTICE

Do not hang any heavy object or put a heavy load on the assist grip.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

384

5-4. Other interior features

4RUNNER (U)

The garage door opener (HomeLink

®

 Universal Transceiver) is manu-

factured under license from HomeLink

®

.

The HomeLink

®

 compatible transceiver in your vehicle has 3 buttons

which can be programmed to operate 3 different devices. Refer to the
programming method below appropriate for the device.

HomeLink

®

 Indicator light

Garage  door  operation  indica-
tors (

P. 388)

Buttons

Before programming HomeLink

®

During programming, it is possible that garage doors, gates, or
other devices may operate. For this reason, make sure that peo-
ple and objects are clear of the garage door or other devices to
prevent injury or other potential harm.

It  is  recommended  that  a  new  battery  be  placed  in  the  remote
control transmitter for more accurate programming.

Garage door openers manufactured after 1995 may be equipped
with  rolling  code  protection.  If  this  is  the  case,  you  will  need  a
stepladder  or  other  sturdy,  safe  device  to  reach  the  “learn”  or
“smart” button on the garage door opener motor.

Garage door opener

: If equipped

The garage door opener can be programmed to operate garage
doors,  gates,  entry  doors,  door  locks,  home  lighting  systems,
security systems, and other devices.

Programming the HomeLink

®

1

2

3

-------------------------------------------------------------------------------------------------------------------------------------------------------------

385

5-4. Other interior features

5

In

te

rior

fe

at

ures

4RUNNER (U)

Programming HomeLink

®

Steps

 through

 must be performed within 60 seconds, other-

wise the indicator light will stop flashing and programming will not
be able to be completed.

Press  and  release  the  HomeLink

®

  button  you  want  to  program

and check that the HomeLink

®

 indicator light flashes orange.

Point  the  remote  control
transmitter for the device 1 to
3 in. (25 to 75 mm) from the
HomeLink

®

 buttons.

Keep  the  HomeLink

®

  indicator

light in view while programming.

Program a device.

Programming a device other than an entry gate (for U.S.A. own-
ers)

Press and hold the HomeLink

®

 button you want to program and the

remote control transmitter button simultaneously. When the Home-
Link

®

 indicator light changes from slowly flashing orange to rapidly

flashing green (rolling code) or continuously lit green (fixed code),
release both buttons.

Programming an entry gate (for U.S.A. owners)/Programming a
device in the Canadian market

With one hand, press and hold the HomeLink

®

 button you want to

program. With your other hand, press and release the remote con-
trol  transmitter  button every  2  seconds  and  repeat  this cycle until
the HomeLink

®

 indicator light starts to flash rapidly. Then, release

the buttons.

1

3

1

2

3

-------------------------------------------------------------------------------------------------------------------------------------------------------------

386

5-4. Other interior features

4RUNNER (U)

Test  the  HomeLink

®

  operation  by  pressing  the  newly  pro-

grammed button and observing the indicator light:

If the indicator light is solid/continuous, programming has been
completed  and  your  device  should  activate  when  the  Home-
Link

®

 button is pressed and released.

If the indicator light blinks rapidly for 2 seconds and then turns
into a solid/continuous light, proceed to the heading “Program-
ming a rolling code system”.

Repeat the steps above to program another device for any of
the remaining HomeLink

®

 buttons.

Programming a rolling code system

2 or more people may be necessary to complete rolling code pro-
gramming.

Locate  the  “learn”  or  “smart”
button  on  the  garage  door
opener motor in the garage.

This button can usually be found
where the hanging antenna wire
is  attached  to  the  unit.  The
name  and  color  of  the  button
may  vary  by  manufacturer.
Please refer to the owner’s man-
ual  supplied  with  the  garage
door opener motor for details.

Press and release the “learn”
or “smart” button.
Perform

  within  30  sec-

onds after performing

.

4

5

1

2

3

2

-------------------------------------------------------------------------------------------------------------------------------------------------------------

387

5-4. Other interior features

5

In

te

rior

fe

at

ures

4RUNNER (U)

Press  and  hold  the  pro-
grammed  HomeLink

®

  button

(located  inside  the  vehicle)
for 2 seconds and release it.
Repeat this sequence (press/
hold/release) up to 3 times to
complete programming.
If  the  garage  door  opener
motor  activates  when  the
HomeLink

®



button

is

pressed,  the  garage  door
opener motor recognizes the
HomeLink

®

 signal.

Enabling 2-way communication with a garage door (only avail-
able for compatible devices)

When enabled, 2-way communication allows you to check the sta-
tus of the opening and closing of the garage door through indicators
in your vehicle.
2-way  communication  is  only  available  if  the  garage  door  opener
motor used is a compatible device. (To check device compatibility,
refer to the owner’s manual supplied with the garage door opener
motor.)

Press  a  programmed  HomeLink

®

  button  to  operate  a  garage

door.
Within  1  minute  of  pressing  the  HomeLink

®

  button,  after  the

garage door operation has stopped, press the “learn” or “smart”
button on the garage door opener motor. Within 5 seconds of the
establishment  of  2-way  communication  with  the  garage  door
opener, both garage door operation indicators in the vehicle will
flash rapidly (green).

Reprogramming a single HomeLink

®

 button

When the following procedure is performed, buttons which already
have devices registered to them can be overwritten:

With one hand, press and hold the desired HomeLink

®

 button.

When the HomeLink

®

 indicator starts flashing, continue to hold

the  HomeLink

®

  button  and  perform  “Programming  HomeLink

®

from

 (it takes 20 seconds for the HomeLink

®

 indicator to start

flashing).

3

1

2

1

2

1

-------------------------------------------------------------------------------------------------------------------------------------------------------------

388

5-4. Other interior features

4RUNNER (U)

Press  the  appropriate  HomeLink

®

  button.  The  HomeLink

®

  indicator

light should turn on.

The  status  of  the  opening  and
closing of a garage door is shown
by the indicators.

Opening
Closing

This function is only available if the
garage door opener motor used is
a  compatible  device.  (To  check
device  compatibility,  refer  to  the
owner’s  manual  supplied  with  the
garage door opener motor.)

The indicators can operate within approximately 820 ft. (250 m) of the
garage door. However, if there are obstacles between the garage door
and the vehicle, such as houses and trees, feedback signals from the
garage door may not be received.
To recall the previous door operation status, press and release either
HomeLink

®

 buttons “1” and “2” or “2” and “3” simultaneously for 2 sec-

onds. The last recorded status will be displayed for 5 seconds.

Operating HomeLink

®

Garage door operation indicators

1

2

Color

Status

Orange (flashing)

Currently opening/closing

Green

Opening/closing has completed

Red (flashing)

Feedback signals cannot be received

-------------------------------------------------------------------------------------------------------------------------------------------------------------

389

5-4. Other interior features

5

In

te

rior

fe

at

ures

4RUNNER (U)

Press and hold the 2 outside but-
tons  for  10  seconds  until  the
HomeLink

®



indicator

light

changes  from  continuously  lit
(orange)  to  rapidly  flashing
(green).

If you sell your vehicle, be sure to
erase  the  programs  stored  in  the
HomeLink

®

 memory.

Programs stored in the HomeLink

®

 memory

The registered codes are not erased even if the 12-volt battery cable is dis-
connected.

If  learning  failed  when  registering  a  different  code  to  a  HomeLink

®

  button

that already has a code registered to it, the already registered code is not
erased.

Before programming

Install a new battery in the transmitter.

The battery side of the transmitter must be pointed away from the Home-
Link

®

.

Certification for the garage door opener

For vehicles sold in the U.S.A.

Erasing the entire HomeLink

®

 memory (all three programs)

-------------------------------------------------------------------------------------------------------------------------------------------------------------

390

5-4. Other interior features

4RUNNER (U)

For vehicles sold in Canada

For additional programming assistance with your HomeLink

®

 Universal

Transceiver

Visit on the web at www.homelink.com/toyota or call 1-800-355-3515.

WARNING

When programming a garage door or other remote control device

The garage door may operate, so ensure people and objects are out of dan-
ger to prevent potential harm.

Conforming to federal safety standards

Do not use the HomeLink

®

 Compatible Transceiver with any garage door

opener or device that lacks safety stop and reverse features as required by
federal safety standards.
This includes any garage door that cannot detect an obstruction object. A
door or device without these features increases the risk of death or serious
injury.

When operating or programming HomeLink

®

Never allow a child to operate or play with the HomeLink

®

 buttons.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

-------------------------------------------------------------------------------------------------------------------------------------------------------------

392

4RUNNER (U)

6-1. Maintenance and care

Working  from  top  to  bottom,  liberally  apply  water  to  the  vehicle
body, wheel wells and underside of the vehicle to remove any dirt
and dust.

Wash  the  vehicle  body  using  a  sponge  or  soft  cloth,  such  as  a
chamois.

For hard-to-remove marks, use car wash soap and rinse thoroughly
with water.

Wipe away any water.

Wax the vehicle when the waterproof coating deteriorates.

If  water  does  not  bead  on  a  clean  surface,  apply  wax  when  the  vehicle
body is cool.

Automatic car washes

Fold the mirrors before washing the vehicle. Start washing from the front of
the vehicle. Make sure to extend the mirrors before driving.

Brushes  used  in  automatic  car  washes  may  scratch  the  vehicle  surface,
parts (wheel, etc.) and harm your vehicle’s paint.

In  certain  automatic  car  washes,  the  roof  antenna  (if  equipped)  or  rear
spoiler may interfere with machine operation. This may prevent the vehicle
from  being  cleaned  properly  or  result  in  damage  to  the  antenna  or  rear
spoiler.

High pressure car washes

As  water  may  enter  the  cabin,  do  not  bring  the  nozzle  tip  near  the  gaps
around the doors or perimeter of the windows, or spray these areas continu-
ously.

Cleaning and protecting the vehicle

exterior

Perform  the  following  to  protect  the  vehicle  and  maintain  it  in
prime condition:

-------------------------------------------------------------------------------------------------------------------------------------------------------------

393

6-1. Maintenance and care

6

Mainten

ance an

d ca

re

4RUNNER (U)

Wheels and wheel ornaments

Remove any dirt immediately by using a neutral detergent.

Wash detergent off with water immediately after use.

To protect the paint from damage, make sure to observe the following pre-
cautions.
• Do not use acidic, alkaline or abrasive detergent
• Do not use hard brushes
• Do not use detergent on the wheels when they are hot, such as after driv-

ing or parking in hot weather

Bumpers and side moldings

Do not scrub with abrasive cleaners.

Plated portions

If dirt cannot be remove, clean the parts as follows:

Use  a  soft  cloth  dampened  with  an  approximately  5%  solution  of  neutral
detergent and water to clean the dirt off.

Wipe the surface with a dry, soft cloth to remove any remaining moisture.

To remove oily deposits, use alcohol wet wipes or a similar product.

Notes for a smart key system (if equipped)

If the door handle becomes wet while the electronic key is within the effective
range, the door may lock and unlock repeatedly. In this case, follow the fol-
lowing correction procedures to wash the vehicle:
• Place the electronic key in a location 6 ft. (2 m) or more away from the vehi-

cle. (Take care to ensure that the key is not stolen.)

• Set the electronic key to battery-saving mode to disable the smart key sys-

tem. (

P. 121)

WARNING

When washing the vehicle

Do not apply water to the inside of the engine compartment. Doing so may
cause the electrical components etc. to catch fire.

Precautions regarding the exhaust pipe

Exhaust gases cause the exhaust pipe to become quite hot.
When  washing  the  vehicle,  be  careful  not  to  touch  the  pipe  until  it  has
cooled sufficiently, as touching hot exhaust pipe can cause burns.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

394

6-1. Maintenance and care

4RUNNER (U)

NOTICE

To prevent paint deterioration and corrosion on the body and compo-
nents (aluminum wheels etc.)

Wash the vehicle immediately in the following cases:
• After driving near the sea coast
• After driving on salted roads
• If coal tar or tree sap is present on the paint surface
• If dead insects, insect droppings or bird droppings are present on the

paint surface

• After driving in an area contaminated with soot, oily smoke, mine dust,

iron powder or chemical substances

• If the vehicle becomes heavily soiled with dust or mud
• If liquids such as benzene and gasoline are spilled on the paint surface

If the paint is chipped or scratched, have it repaired immediately.

To prevent the wheels from corroding, remove any dirt and store in a place
with low humidity when storing the wheels.

Cleaning the exterior lights

Wash carefully. Do not use organic substances or scrub with a hard brush.
This may damage the surfaces of the lights.

Do not apply wax to the surfaces of the lights.
Wax may cause damage to the lenses.

High pressure car washes

Vehicles with rear view monitor system: When washing the vehicle, do not
apply  intensive bursts  of water to  the camera or camera area. Doing  so
may result in the camera malfunctioning.

Do  not  spray  water  directly  on  the  radar  which  is  equipped  behind  the
emblem. Otherwise it may cause the device to be damaged.

Do not bring the nozzle tip close to boots (rubber or resin manufactured
cover),  connectors  or  the  following  parts. The  parts  may  be  damaged  if
they come into contact with high-pressure water.
• Traction related parts
• Steering parts
• Suspension parts
• Brake parts

Keep the cleaning nozzle at least 11.9 in. (30 cm) away from the vehicle
body.  Otherwise  resin  section,  such  as  moldings  and  bumpers,  may  be
deformed and damaged. Also, do not continuously hold the nozzle in the
same place.

Do not spray the lower part of the windshield continuously. If water enters
the air conditioning system intake located near the lower part of the wind-
shield, the air conditioning system may not operate correctly.

Do  not  wash  the  underside  of  the  vehicle  using  a  high  pressure  car
washer.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

395

6-1. Maintenance and care

6

Mainten

ance an

d ca

re

4RUNNER (U)

Remove dirt and dust using a vacuum cleaner. Wipe dirty surfaces
with a cloth dampened with lukewarm water.

If dirt cannot be removed, wipe it off with a soft cloth dampened with
neutral detergent diluted to approximately 1%.
Wring out any excess water from the cloth and thoroughly wipe off
remaining traces of detergent and water.

Remove dirt and dust using a vacuum cleaner.

Wipe off any excess dirt and dust with a soft cloth dampened with
diluted detergent.

Use a diluted water solution of approximately 5% neutral wool detergent.

Wring out any excess water from the cloth and thoroughly wipe off
all remaining traces of detergent.

Wipe  the  surface  with  a  dry,  soft  cloth  to  remove  any  remaining
moisture. Allow the leather to dry in a shaded and ventilated area.

Remove dirt and dust using a vacuum cleaner.

Wipe it off with a soft cloth dampened with neutral detergent diluted
to approximately 1%.

Wring out any excess water from the cloth and thoroughly wipe off
remaining traces of detergent and water.

Cleaning and protecting the vehicle interior

The following procedures will help protect your vehicle’s interior
and keep it in top condition:

Protecting the vehicle interior

Cleaning the leather areas

Cleaning the synthetic leather areas

-------------------------------------------------------------------------------------------------------------------------------------------------------------

396

6-1. Maintenance and care

4RUNNER (U)

Caring for leather areas

Toyota recommends cleaning the interior of the vehicle at least twice a year to
maintain the quality of the vehicle’s interior.

Shampooing the carpets

There are several commercial foaming-type cleaners available. Use a sponge
or  brush  to  apply  the  foam.  Rub  in  overlapping  circles.  Do  not  use  water.
Wipe dirty surfaces and let them dry. Excellent results are obtained by keep-
ing the carpet as dry as possible.

Seat belts

Clean  with  mild  soap  and  lukewarm  water  using  a  cloth  or  sponge.  Also
check the belts periodically for excessive wear, fraying or cuts.

WARNING

Water in the vehicle

Do not splash or spill liquid in the vehicle.
Doing  so  may  cause  electrical  components  etc.  to  malfunction  or  catch
fire.

Do not get any of the SRS components or wiring in the vehicle interior wet.
(

P. 36)

An electrical malfunction may cause the airbags to deploy or not function
properly, resulting in death or serious injury.

Cleaning the interior (especially instrument panel)

Do not use polish wax or polish cleaner. The instrument panel may reflect
off the windshield, obstructing the driver’s view and leading to an accident,
resulting in death or serious injury.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

397

6-1. Maintenance and care

6

Mainten

ance an

d ca

re

4RUNNER (U)

NOTICE

Cleaning detergents

Do not use the following types of detergent, as they may discolor the vehi-
cle interior or cause streaks or damage to painted surfaces:
• Non-seat  portions:  Organic  substances  such  as  benzene  or  gasoline,

alkaline or acidic solutions, dye, and bleach

• Seats: Alkaline or acidic solutions, such as thinner, benzene, and alco-

hol

Do not use polish wax or polish cleaner. The instrument panel’s or other
interior part’s painted surface may be damaged.

Preventing damage to leather surfaces

Observe the following precautions to avoid damage to and deterioration of
leather surfaces:

Remove any dust or dirt from leather surfaces immediately.

Do not expose the vehicle to direct sunlight for extended periods of time.
Park the vehicle in the shade, especially during summer.

Do not place items made of vinyl, plastic, or containing wax on the uphol-
stery, as they may stick to the leather surface if the vehicle interior heats
up significantly.

Water on the floor

Do not wash the vehicle floor with water.
Vehicle systems such as the audio system may be damaged if water comes
into contact with electrical components such as the audio system above or
under the floor of the vehicle. Water may also cause the body to rust.

When cleaning the inside of the windshield

Do not allow glass cleaner to contact the lens. Also, do not touch the lens.
(

P. 246)

Cleaning the inside of the rear quarter windows and back window

Do not use glass cleaner to clean the rear quarter windows and back win-
dow, as this may cause damage to the rear window defogger heater wires
or antenna. Use a cloth dampened with lukewarm water to gently wipe the
window clean. Wipe the window in strokes running parallel to the heater
wires or antenna.

Be careful not to scratch or damage the heater wires or antenna.

-------------------------------------------------------------------------------------------------------------------------------------------------------------















Content      ..     4      5      6      7     ..
