Toyota Tundra (2019 year). Instruction - part 24

Using a Bluetooth

phone

To display the screen shown below, press the

switch on the steer-

ing wheel or press the

button.

Several functions are available to operate on each screen that is dis-
played by selecting the 4 tabs.

Device name
Bluetooth

connection status

The hands-free system is a function that allows you to use your
cellular phone without touching it.
This system supports Bluetooth

. Bluetooth

is a wireless data

system that allows the cellular phone to wirelessly connect to
the hands-free system and make/receive calls.

Before making a phone call, check the connection status, battery
charge, call area and signal strength. (

P. 371)

If a Bluetooth

device cannot be connected, check the connection

status on the phone screen. If the device is not connected, either
register or reconnect it. (

P. 360, 365)

Phone screen

371

5-9. Bluetooth

Mu
ltim

■

Microphone
The  vehicle’s  built  in  micro-
phone  is  used  when  talking  on
the phone.
The person you are speaking to
can  be  heard  from  the  front
speakers.

To use the hands-free system, you must register your Bluetooth

phone in the system. (

P. 363)

You can check indicators such as signal strength and battery charge
on any screen.

Connection status
Signal strength
Battery charge

Status display

Indicators

Conditions

Connection status

Good

Poor

Not connected

Battery charge

Full

Empty

Call area

“Rm”: Roaming area

Signal strength

Excellent

Poor

372

Making a call

Display the phone screen. (

Select the “Dial Pad” tab and enter a phone number.

To delete the input phone number, select

For the first digit, you can enter “+” by selecting “

” for a while.

Press the

switch on the steering wheel or select

You can dial a number from the contact data imported from your cellu-
lar phone. The system has one contact for each registered phone. Up
to 2500 contacts may be stored in each contact. (

P. 372)

Display the phone screen. (

Select “Contacts” tab.
Choose the desired contact to call from the list.
Choose the number and then press the

switch on the steering

wheel or select

You can transfer the phone numbers in a Bluetooth

phone to the sys-

tem.
Operation methods differ between PBAP (Phone Book Access Profile)
compatible and PBAP incompatible Bluetooth

phones. If the cellular

phone does not support either PBAP or OPP (Object Push Profile)
service, you cannot transfer contacts.

■

For PBAP compatible Bluetooth

phones



When “Automatic Transfer” is set to on (

P. 386)

Check that a confirmation screen is displayed when the opera-
tion is complete.

Transfer the contact data to the system using a Bluetooth

phone.

Once a Bluetooth

phone is registered, you can make a call

using the following procedure:

Dialing

Dialing from the contacts list

When the contact is empty

373

5-9. Bluetooth

Mu
ltim



When “Automatic Transfer” is set to off

Display the phone screen. (

Select the desired item.

Select to transfer new con-
tacts from a cellular phone,
select  “Always”  and  then
enable  “Automatic  Trans-
fer”.
Select  to  transfer  all  the
contacts from a connected
cellular phone only once.
Select to cancel transferring.

Check that a confirmation screen is displayed when the opera-
tion is complete.

■

For PBAP incompatible but OPP compatible Bluetooth

phones

Display the phone screen. (

Select the desired item.

Select to transfer the con-
tacts  from  the  connected
cellular phone.
Select  to  add  a  new  con-
tact manually.
Select  to  cancel  transfer-
ring.



When “Transfer” is selected

Follow the steps in “For PBAP Incompatible but OPP compatible
Bluetooth

Phones” from step

(

P. 387)



When “Add” is selected

Follow the steps in “Registering a new contact to the contact list”
from step

(

P. 388)

374

You can make a call using numbers registered in the contact.

Display the phone screen. (

Select “Favorites” tab.
Select the desired number to make a call.

You can make a call using the call history, which has the 3 functions
below.

: calls which you missed
: calls which you received
: calls which you made

Display the phone top screen. (

Select “Call History” tab.
Select

or the desired entry from the list.



When

is selected

Check that the “Call” screen is displayed.



When the desired contact is selected
Select the desired number.
Check that the “Call” screen is displayed.

■

Call history list

●

If you make a call to or receive a call from a number registered in the con-
tact, the name is displayed in the call history.

●

If you make multiple calls to the same number, only the last call made is dis-
played in the call history.

■

International calls
You may not be able to make international calls, depending on the mobile
phone in use.

Calling using favorites list

Dialing from call history

375

5-9. Bluetooth

Mu
ltim

Receiving a call

Press the

switch on the steer-

ing wheel or select

Press the

switch on the steering wheel or select

Turn the “PWR·VOL” knob.

■

International calls
Received international calls may not be displayed correctly depending on the
cellular phone in use.

When a call is received, the following screen is displayed
together with a sound.

To answer the phone

To refuse a call

To adjust the incoming call volume

376

Speaking on the phone

Select “-” or “+”. You can also adjust the volume using the volume
knob.

Select “Mute”.

When using phone services such as an answering service or a bank,
you can store phone numbers and code numbers in the contact.

Select “0-9”.
Input the number.

■

Release Tones
“Release Tones” appear when a continuous tone signal(s) contain-
ing a “w” is registered in the contact list.

Select “Release Tones”.

The following screen is displayed when speaking on the phone.

To adjust the call volume

To prevent the other party from hearing your voice

Inputting tones

377

5-9. Bluetooth

Mu
ltim

■

Release Tones

●

A continuous tone signal is a character string that consists of numbers and
the characters “p” or “w”. (e.g.056133w0123p#1

)

●

When the “p” pause tone is used, the tone data up until the next pause tone
will be automatically sent after 2 seconds have elapsed. When the “w”
pause tone is used, the tone data up until the next pause tone will be auto-
matically sent after a user operation is performed.

●

Release tones can be used when automated operation of a phone based
service such as an answering machine or bank phone service is desired. A
phone number with continuous tone signals can be registered in the contact
list.

●

Tone data after a “w” pause tone can be operated on voice command during
a call.

Select “Handset Mode” to change from a hands-free call to a cellular
phone call.
Select “Handset Mode” to off from a cellular phone call to a hands-free
call.

Select “Transmit Volume”.
Select the desired level for the transmit volume.
Select “OK”.

Press the

switch on the steering wheel or select

To transfer a call

Transmit volume setting

To hang up

378

When a call is interrupted by a third party while talking, an incoming
call message will be displayed.
To talk with the other party:
Press the

switch on the steer-

ing wheel or select

To refuse the call:
Press the

switch on the steer-

ing wheel or select

Every time you press the

switch on the steering wheel or select

during call waiting, you will be switched to the other party.

■

Transferring calls

●

If you transfer from the cellular phone to hands-free, the hands-free screen
will be displayed, and you can operate the system using the screen.

●

Transfer method and operation may vary according to the cellular phone
used.

●

For operation of the cellular phone in use, see the phone’s manual.

■

Call waiting operation
Call waiting operation may differ depending on your phone company and cel-
lular phone.

Call waiting

379

5-9. Bluetooth

Mu
ltim

Bluetooth

phone message function

Press the

switch on the steering wheel or press the

button.

Select

on the phone screen.

Check that the “Message
Inbox” screen is displayed.

When an e-mail/SMS/MMS is received, the incoming message screen
pops up with sound and is ready to be operated on the screen.

E-mail: Select to check the
message.
Select to refuse the message.
Select to call the message
sender.

Received messages can be forwarded from the connected
Bluetooth

phone, enabling checking and replying using the

multimedia system.
Depending on the type of Bluetooth

phone connected, received

messages may not be transferred to the message inbox.
If the phone does not support the message function, this func-
tion cannot be used.

Displaying “Message Inbox” screen

Receiving a message

380

■

Receiving a message

●

Depending on the cellular phone used for receiving messages, or its regis-
tration status with the navigation system, some information may not be dis-
played.

●

The pop up screen is separately available for incoming e-mail and SMS/
MMS messages under the following conditions:
E-mail:
• “Incoming E-mail Display” is set to “Full Screen”. (

• “E-mail Notification Popup” is set to on. (

SMS/MMS:
• “Incoming SMS/MMS Display” is set to “Full screen”. (

• “SMS/MMS Notification Popup” is set to on. (

Display the “Message Inbox” screen. (

P. 379)

Select the desired message from the list.
Check that the message is displayed.

E-mails:

Select

“Mark

Unread” or “Mark Read” to
mark mail unread or read on
the “Message Inbox” screen.

This function is available when
“Update Message Read Status
on Phone” is set to on (

Select to make a call to the
sender.
Select to have messages read out. To cancel this function, select
“Stop”.
Select to display the previous or next message.
Select to reply the message.

Checking the messages

381

5-9. Bluetooth

Mu
ltim

■

Check the messages

●

Depending on the type of Bluetooth

phone being connected, it may be nec-

essary to perform additional steps on the phone.

●

Messages are displayed in the appropriate connected Bluetooth

phone’s

registered mail address folder.
Select the tab of the desired folder to be displayed.

●

Only received messages on the connected Bluetooth

phone can be dis-

played.

●

The text of the message is not displayed while driving.

●

When “Automatic Message Readout” is set to on, messages will be auto-
matically read out. (

●

Turn the “PWR

VOL” knob to adjust the message read out volume.

●

The message read out function is available even while driving.

Display the “Message Inbox” screen. (

P. 379)

Select the desired message from the list.
Select “Quick Message”.
Select the desired message.
Select “Send”.

■

Editing quick reply message
This operation cannot be performed while driving.

Select “Quick Message”.
Select

corresponding to the desired message to edit.

Select “OK” when editing is completed.

Replying to a message

382

Calls can be made to an e-mail/SMS/MMS message sender’s phone
number.

Display the “Message Inbox” screen. (

P. 379)

Select the desired message.
Select

Check that the “Call” screen is displayed.

■

Calling from a number within a message
Calls can be made to a number identified in a message’s text area.

Display the “Message Inbox” screen. (

P. 379)

Select the desired message.
Select the text area.
Select

corresponding to the desired number.

Check that the “Call” screen is displayed.

■

Calling from the incoming message screen

P. 378

Calling the message sender

383

5-9. Bluetooth

Mu
ltim

Using the steering wheel switches



Volume switch

• Increase/Decrease the vol-

ume

• Press and hold:

Continuously

increase/

decrease the volume

Off hook switch

• Make a call
• Receive a call
• Display “Phone” screen

On hook switch

• End a call
• Refuse a call



: If equipped

The steering wheel switches can be used to operate a connected
cellular phone.

Operating a telephone using the steering wheel switches

384

Bluetooth

phone settings

To display the screen shown below, press the “SETUP” button, and
select “Phone” on the “Setup” screen.

Set the phone connection
(

P. 365)

Sound Settings (

P. 385)

Contact/Call History Settings
(

P. 386)

Messaging Settings (
