Toyota Prius Prime (2018 year). Instruction - part 2

FEATURES & OPERATIONS

Auto lock/unlock

Automatic door locks can be programmed to operate in different modes, or turned

OFF.

Shift position linked door locking/unlocking function

-Doors lock when shifting from Park.

-Doors unlock when shifting into Park.

Speed linked door locking function

-Doors lock when the vehicle speed is approximately 12 mph or higher.

'ULYHU·V GRRU OLQNHG GRRU XQORFNLQJ IXQFWLRQ

-Doors unlock when the engine switch is set to OFF and driver’s door is opened

within approximately 45 seconds.

Refer to the Owner’s Manual for more details.

Hybrid Synergy Drive System

The Hybrid Synergy Drive System utilizes a computer-controlled gasoline engine

and electric motor to provide the most efficient combination of power for the

vehicle. To conserve energy, when the brakes are applied the braking force

generates electricity which is then sent to the traction battery. In addition, the

engine shuts off when the vehicle is stopped. The benefits are better fuel economy,

reduced vehicle emissions and improved performance.

NOTE: Fuel consumption and energy information of the Hybrid System are

shown on the Multi-Information Display.

TIPS FOR IMPROVED FUEL ECONOMY

-Ensure tire pressures are maintained at levels specified in the Owner’s Manual.

-When possible, link trips to reduce engine cold starts.

-Avoid driving at speeds that are higher than necessary, especially on the highway.

-When possible, avoid sudden stops to maximize regenerative braking energy.

-Minimize use of the air conditioning.

STARTING YOUR VEHICLE

(1) Depress the brake pedal, and press the

“POWER” switch briefly and firmly.

(2) The “READY” light will blink. After a few

Push

seconds, when the light remains steady

and a beep sounds, you may begin

driving.

Hybrid transmission

Park button

Reverse

Neutral

Drive

Engine brake*

* The engine brake is the equivalent of downshifting. Shift to “B” when engine

braking is desired (i.e.

downhill driving, coasting to a stop, etc.) While vehicle is

stopped, push “P” button to park.

Driving mode select

Normal - Suitable for normal

driving.

Power mode - Use when a

higher level of response is

desired, such as when driving

in mountainous regions.

ECO drive mode -

Helps achieve lower fuel

consumption during trips that

involve frequent accelerating

and braking.

Refer to the Owner’s Manual for more details.

EV/HV drive mode

EV Mode allows the electric motor (traction motor), powered by the hybrid battery

(traction battery), to be used to drive the vehicle under certain driving conditions.

EV Mode is the default Mode upon starting the vehicle if the battery has sufficient

charge. You can use the EV/HV button at any time to toggle between EV Mode and

hybrid mode.

Refer to the Owner’s Manual for more details.

FEATURES & OPERATIONS

EV Auto drive mode

Push

EV Auto Mode intelligently selects between EV and hybrid driving based on

demand and driving conditions to optimize your efficiency.

Refer to the Owner’s Manual for more details.

Vehicle Stability Control (VSC)/TRAC OFF Switch

Push

The VSC OFF switch can be used to help free a stuck

vehicle in surroundings like

mud, dirt or snow. While car is stopped, press switch to disable the TRAC system.

To disable both VSC and TRAC systems, press the switch for at least 3 seconds.

Refer to the Owner’s Manual for more details.

Tilt & telescopic steering wheel

Lock release lever

Angle

Length

Hold

wheel, push lever down, set angle and length, and return lever.

NOTE: Do not attempt to adjust while the vehicle is in motion.

Parking brake

Set: Depress

Release: Depress again

Door locks

Lock

Unlock

Windows-Power

Window lock switch

Down

Automatic operation Push the switch completely down or pull it completely up and

release to fully open or close. To stop the window partway, operate the switch in

the opposite direction.

Window lock switch Deactivates all passenger windows. Driver’s window remains

operable.

FEATURES & OPERATIONS

Seat adjustments-Front

MANUAL SEAT

POWER SEAT (IF EQUIPPED)*

Seat position

Seatback angle

Lumbar support

(forward/backward)

Seat cushion

(front) angle

Height crank

Seatback angle

Seat position

Height crank

(forward/backward)

(driver’s side only)

*Driver’s side only

Seats-Head restraints

Front

Rear outboard

Lock

release button

Lock release button

Seats-Folding down rear seats

(1) Press down

(2) Fold down

Lights & turn signals

HEADLIGHTS

Type A

Type B

Headlights

Parking lights

DRL ON

AUTO*

OFF

*if equipped

Low beam

High beam

High beam flasher

Auto High Beam**

Daytime Running Light system (DRL) Automatically turns on the headlights at a

reduced intensity

Automatic light cutoff system Automatically turns lights off after a delay of 30

seconds, or when lock switch on remote is pushed after all doors are locked.

Automatic High Beam (AHB) system Automatically switches between high

and low beams as appropriate to provide the most light possible and enhance

forward visibility. Refer to Toyota Safety Sense™ P (TSS-P) in this guide or the

Owner’s Manual for more details on the Automatic High Beam feature.

** Operating conditions must be met. Refer to Owner’s Manual for details.

FRONT FOG LIGHTS (IF EQUIPPED)

Type A

Type B

OFF

Front fog lights come on only when the headlights are on low beam.

TURN SIGNALS

Right turn

Lane change

Left turn

FEATURES & OPERATIONS

Windshield wipers & washers

FRONT-INTERMITTENT (IF EQUIPPED)

Type A

Type B

Single mist

Adjustment frequency1

& wipe

Single wipe

Off

Interval

wipe

Slow

Fast

Pull to wash and wipe

1 Intermittent windshield wiper frequency adjustment Rotate to increase/

decrease wipe frequency.

FRONT-AUTO (RAIN-SENSING) (IF EQUIPPED)

Type A

Type B

Adjust sensitivity2

Single mist

Single wipe

& wipe

Off

Rain-sensing

(AUTO)

Low

High

Pull to wash and wipe

2 Rain-sensing windshield wipers Rotate to increase/decrease sensor sensitivity.

Refer to the Owner’s Manual for more details on customizing AUTO mode

operation.

Seat heaters

Front

Driver seat

passenger seat

NOTE: Turn system off

Push

when not in use.

Steering wheel-Heater (if equipped)

Push

Steering wheel switches &

telephone controls (Bluetooth®)

STEERING WHEEL AUDIO AND TELEPHONE CONTROLS

“MODE”

Volume control

Push to turn audio ON and select

an audio mode. Push and hold to

mute/unmute or pause/resume the

current operation.

“

” Use to search within the

selected audio medium (radio,

CD, etc.).

Start call/

Mobile Assistant access*

End call

Voice command switch

MICROPHONE

Type A (7” display)

Type B (7” display/11.6” display)

Bluetooth® technology allows dialing or receipt of calls without taking hands from

the steering wheel or using a cable to connect the compatible telephone and the

system.

Push and hold to access Mobile Assistant. Once you connect a compatible,

registered mobile phone, you can access Siri® Eyes Free using Mobile Assistant

access switch.

Refer to “Bluetooth® Device Pairing Section,” in this guide, for more information

about phone connections and compatibility.

Refer to the “Navigation System Owner’s manual for more datails.

NOTE: Concentrating on the road should always be your first priority while

driving. Do not use the hands-free phone system if it will distract you.

FEATURES & OPERATIONS

Air conditioning/heating

AIR CONDITIONING REMOTE

(1) Press twice to de-activate. System also

automatically shuts off after 10 minutes or

when a door is opened.

(2) The Remote Air Conditioning System will

operate in accordance with the temperature

settings of the air conditioning system.

Push and hold

NOTE: Remote Climate system can also

be activated via smartphone using Entune

Prime Apps (if equipped).

Refer to the Owner’s Manual for more details.

AUTOMATIC AIR CONDITIONING - 7” DISPLAY

Automatic climate control ON

Smart-flow (S-Flow) mode gives airflow

Adjusting the temperature setting will

priority to the front seats, reducing the

cause the airflow vents, air intake and

airflow and air conditioning effect on rear

fan to adjust automatically.

seats when there are no passengers.

Climate control that minimizes fuel

consumption. This option may

Climate control OFF

reduce fan speed.

Temperature

Airflow vent

setting display

mode display

Fan speed display

Fan speed control

Windshield

Air conditioning

defogger

Temperature selector

ON/OFF

Airflow vent mode

Outside rearview mirror/

Recirculate cabin air

Rear defogger

(outside air when OFF)

AUTOMATIC AIR CONDITIONING - 11.6” DISPLAY (IF EQUIPPED)

Controls

Air conditioning

temperature control

Windshield defogger

Rear window and outside

rear view mirrors defogger

Touch area to display

air conditioning control

screen (See below)

Air conditioning control screen

Fan speed setting

Automatic mode setting

Airflow mode setting

Temperature setting

Outside/recirculated

Air conditioning

S-FLOW mode setting

air mode setting

A/C setting

ECO mode setting

FEATURES & OPERATIONS

Color Dual Multi-Information Display (MID)

Main display

MID

MAIN DISPLAY

Simple screen

Split screen

Fuel gauge

Outside temperature

Hybrid system indicator and

current fuel consumption

Mileage display

Average fuel

Speedometer

(odometer/trip meters/

consumption

driving range)

display

The default split screen mode can also be viewed in simple screen mode shown

above. The main display shows basic drive information. Push “

” to view more

info for mileage and average fuel consumption display.

For more details, see Owner’s Manual.

MULTI-INFORMATION DISPLAY (MID)

Drive information

Navigation system-linked display

Audio system-linked display

Air conditioning system

settings screen

Driving assist system information

Warning message display

Settings display

Push “

” to change between the following information screens, “

” to select,

“

” to switch contents and “

” to go back:

For more details, see Owner’s Manual.

Color Head-up display (HUD) (if equipped)

Vehicle speed display

Hybrid system current driving and

energy regeneration status

Insert display driving support

system information

Route guidance display

Head-up display (HUD) switch

Meter control switches adjust

activates or switches between items

position and brightness of HUD

The color head-up display can display the current vehicle speed and hybrid system

indicator in front of the driver. Also, it can display various types of information to

assist the driver.

FEATURES & OPERATIONS

Audio

ENTUNE™ PREMIUM AUDIO WITH INTEGRATED NAVIGATION & APP SUITE

7” Display

Eject CD

Touch to pause or

AUDIO Button

resume playing

Access to audio

functions.

Seek station/

CD track select

APPS Button

Access to

Entune® App

Button

Suite, sports,

Access telephone

stocks, news,

option screen.

TRAFlC AND

weather.

Turn to tune radio

stations manually

HOME Button

or select tracks

or files

Access to

Home screen.

Map card

Push to turn ON/OFF.

Touch screen display

insert

HOME SCREEN - the home screen offers a two panel and a three panel layout. Information and

layout will vary depending on selected set up.

Refer to the “Navigation System Owner’s Manual” for more details.

NOTE: Concentrating on the road should always be your first priority while

driving. Do not use the Entune system if it will distract you.

ENTUNE™ PREMIUM (JBL®) AUDIO

WITH INTEGRATED NAVIGATION & APP SUITE

11.6” Display (if equipped)

Touch screen display

Access audio and

navigation functions.

Home button

Access to Home

screen.

Menu button

Access to Menu

screen.

Volume button

Push to turn

ON/OFF.

Audio information

display area

Refer to the “Navigation System Owner’s Manual” for more details.

NOTE: Concentrating on the road should always be your first priority while

driving. Do not use the Entune system if it will distract you.

USB/AUX port

By inserting a USB or an auxilary cable plug into the USB/AUX port, you can listen

to music from a portable audio device through the vehicle’s speaker system while in

USB/AUX mode.

Refer to the “Navigation System Owner’s Manual” for instructions and more

information.

FEATURES & OPERATIONS

Power outlets

Front

Rear

Power switch must

be set at “ACCESSORY” or “ON” mode to be used.

Qi-compatible wireless charging (if equipped)

(1)

(2)

Operation

indicator light

Charge

area

Push power supply charging button.

Place charging side of device on the charge area.

Orange light - detecting device and/or device is charging.

Green light - device charging complete.

The power switch must be in ACCESSORY or ON mode.

A portable device can be charged by just placing Qi standard wireless charge

compatible portable devices according to the Wireless Power Consortium, such as

smart phones and mobile batteries, etc., on the charge area.

This function cannot be used with portable devices that are larger than the charging

area. Also, depending on the portable device, it may not operate normally.

See Owner’s Manual for compatible portable devices.

Clock

Multi-Information Display

Multi-Information Display (MID)

Clock display

Meter

control switches

To adjust the time, use meter control switches to go to the

screen on the MID

for vehicles with the 7” display. Then, select the

option to access the

clock setting.

11.6” display (if equipped)

To adjust the time, press

to select

. Then select

to access

General Settings screen. From here, select “System Time” to access clock setting.

FEATURES & OPERATIONS

Intelligent Parking Assist (IPA) (if equipped)

Front

center sensor

Corner sensors

(front and rear)

Side

sensors

(front and

rear)

Corner sensors

(front and rear)

Rear

(front and rear)

center sensor

If the sensors detect an obstacle, the buzzer and MID display informs the driver of

the approximate position and distance of the obstacle by illuminating continuously

(far) or blinking (near).

Note: Use

in the Multi-Information Display (MID) to change settings. The

system will continue in the last state it was in (ON or OFF) when the engine is

started again.

Refer to section S-APGS (Simple Advanced Parking Guidance System) in the

Owner’s Manual for limitations and more details.

Content .. 1 2 3 ..
