Toyota Aygo (2017 year). Instruction - part 18
6-1. Using the air conditioning system and defogger
289
WARNING
■ To prevent the windshield from fogging up
● Type B only: Do not use
during cool air operation in extremely humid
weather. The difference between the temperature of the outside air and
that of the windshield can cause the outer surface of the windshield to fog
up, blocking your vision.
●Do not place anything on the instrument
panel which may cover the air outlets.
Otherwise, air flow may be obstructed,
preventing the windshield defoggers to
defog.
■ To prevent burns (vehicles with outside rear view mirror defoggers)
Do not touch the rear view mirror surfaces when the outside rear view mirror
defoggers are on.
NOTICE
■ To prevent battery discharge
Do not leave the air conditioning system on longer than necessary when the
6
engine is stopped.
AYGO_OM_Europe_OM99P46E
290
6-1. Using the air conditioning system and defogger
Automatic air conditioning system
Air outlets and fan speed are automatically adjusted according
to the temperature setting.
Air conditioning controls
■ Adjusting the temperature setting
To adjust the temperature setting, press “” on
to increase the
temperature and “” to decrease the temperature.
■ Adjusting the fan speed setting
To adjust the fan speed, press
on
to increase the fan
speed and
to decrease the fan speed.
The fan speed is indicated by the number of fan blades lit.
To turn off the air conditioning system, continually press
until all
the lit blades turn off.
: If equipped
AYGO_OM_Europe_OM99P46E
6-1. Using the air conditioning system and defogger
291
■ Change the airflow mode
To change the airflow, press
Air outlets are adjusted each
time the button is pressed.
1
Air flows to the upper body,
feet and the windshield
2
Air flows to the upper body
3
Air flows to the windshield
4
Air flows to the feet and the
windshield
5
Air flows to the feet
6
Air flows to the upper body and feet
Using by automatic mode
1
Pressing
changes automatic modes in the following order.
“AUTO” mode “FAST” mode*1 “SOFT” mode*2
*1: Operates with the fan speed used effectively
6
*2: Operates with the fan speed controlled quietly
2
Adjust the temperature setting.
3
To stop the operation, continually press
until all the lit blades
turn off.
■ Automatic mode indicator
If the fan speed setting or air flow modes are operated, the auto-
matic mode indicator goes off. However, automatic mode for func-
tions other than that operated is maintained.
AYGO_OM_Europe_OM99P46E
292
6-1. Using the air conditioning system and defogger
Other functions
■ Switching between outside air and recirculated air modes
Press
The mode switches between outside air mode (
not displayed)
and recirculated air mode (
displayed) each time the button is
pressed.
■ Defogging the windshield
Defoggers are used to defog the windshield and front side win-
dows.
Press
Set the outside/recirculated air mode button to outside air mode if the
recirculated air mode is used. (It may switch automatically.)
To defog the windshield and the side windows early, turn the air flow and
temperature up.
To return to the previous mode, press
again when the windshield
is defogged.
If the dehumidification function is not operating, press
to operate
the dehumidification function.
■ Defogging the rear window and outside rear view mirrors
Vehicles without outside rear view mirror defoggers
Defogger is used to defog the rear window.
Vehicles with outside rear view mirror defoggers
Defoggers are used to defog the rear window, and to remove rain-
drops, dew and frost from the outside rear view mirrors.
Press
The defoggers will automatically turn off after approximately 15 minutes.
Vehicles with outside rear view mirror defoggers: Turning the rear win-
dow defogger on will turn the outside rear view mirror defoggers on.
AYGO_OM_Europe_OM99P46E
6-1. Using the air conditioning system and defogger
293
Air outlets
■ Location of air outlets
Air outlets and air volume
changes according to the
selected airflow mode.
*: Some models
*
*
■ Adjusting the position of and opening and closing the air out-
lets
Direct air flow to the left or right,
up or down.
6
1
Open the vent
2
Close the vent
The outlets does not make com-
plete revolutions.
AYGO_OM_Europe_OM99P46E
294
6-1. Using the air conditioning system and defogger
■ Using automatic mode
Fan speed is adjusted automatically according to the temperature setting and
the ambient conditions.
Therefore, the fan may stop for a while until warm or cool air is ready to flow
immediately after
is pressed.
■ Fogging up of the windows
●The windows will easily fog up when the humidity in the vehicle is high.
Turning
on will dehumidify the air from the outlets and defog the wind-
shield effectively.
● If you turn
off, the windows may fog up more easily.
● The windows may fog up if the recirculated air mode is used.
■ Outside/recirculated air mode
● When driving on dusty roads such as tunnels or in heavy traffic, set the out-
side/recirculated air mode button to the recirculated air mode. This is effec-
tive in preventing outside air from entering the vehicle interior. During
cooling operation, setting the recirculated air mode will also cool the vehicle
interior effectively.
● Outside/recirculated air mode may automatically switch depending on the
temperature setting or the inside temperature.
■ When the outside temperature falls to nearly 0C (32F)
The dehumidification function may not operate even when
is selected.
■ Ventilation and air conditioning odors
● To let fresh air in, set the air conditioning system to the outside air mode.
● During use, various odors from inside and outside the vehicle may enter into
and accumulate in the air conditioning system. This may then cause odor to
be emitted from the vents.
● To reduce potential odors from occurring:
• It is recommended that the air conditioning system be set to outside air
mode prior to turning the vehicle off.
• The start timing of the blower may be delayed for a short period of time
immediately after the air conditioning system is started in automatic
mode.
■ An odor comes from the air conditioning system due to the Stop & Start
system operation (vehicles with a Stop & Start system)
When the engine is stopped due to the Stop & Start system, an odor caused
by moisture may be detected. This does not indicate a malfunction.
■ Air conditioning filter
P. 347
AYGO_OM_Europe_OM99P46E
6-1. Using the air conditioning system and defogger
295
WARNING
■ To prevent the windshield from fogging up
●Do not use
during cool air operation in extremely humid weather.
The difference between the temperature of the outside air and that of the
windshield can cause the outer surface of the windshield to fog up, block-
ing your vision.
●Do not place anything on the instrument
panel which may cover the air outlets.
Otherwise, air flow may be obstructed,
preventing the windshield defoggers to
defog.
■ To prevent burns (vehicles with outside rear view mirror defoggers)
Do not touch the rear view mirror surfaces when the outside rear view mirror
defoggers are on.
NOTICE
■ To prevent battery discharge
6
Do not leave the air conditioning system on longer than necessary when the
engine is stopped.
AYGO_OM_Europe_OM99P46E
296
6-1. Using the air conditioning system and defogger
Seat heaters
Turns seat heater on
The indicator light comes on.
■ The seat heaters can be used when
Vehicles without a smart entry & start system
The engine switch is in the “ON” position.
Vehicles with a smart entry & start system
The engine switch is in IGNITION ON mode.
■ When not in use
Turn the seat heater off by pressing the switch. The indicator light turns off.
: If equipped
AYGO_OM_Europe_OM99P46E
6-1. Using the air conditioning system and defogger
297
WARNING
■ Burns
●Use caution when seating the following persons in a seat with the seat
heater on to avoid the possibility of burns:
• Babies, small children, the elderly, the sick and the physically chal-
lenged
• Persons with sensitive skin
• Persons who are fatigued
• Persons who have taken alcohol or drugs that induce sleep (sleeping
drugs, cold remedies, etc.)
●Do not cover the seat with anything when using the seat heater.
Using the seat heater with a blanket or cushion increases the temperature
of the seat and may lead to overheating.
●Do not use the seat heater more than necessary. Doing so may cause
minor burns or overheating.
NOTICE
■ To prevent seat heater damage
Do not put unevenly weighted objects on the seat and do not stick sharp
objects (needles, nails, etc.) into the seat.
■ To prevent battery discharge
6
Turn the seat heaters off when the engine is not running.
AYGO_OM_Europe_OM99P46E
298
6-2. Using the interior lights
Interior lights list
1
Interior light (P. 298)
Interior light
1
On
2
Off
3
Door position
Vehicles without a smart entry &
start system: The interior light
come on when a side door is open.
They turn off when the side doors
are closed.
Vehicles with a smart entry & start
system: The interior light come on
when a door is opened. They turn
off when the doors are closed.
■ To prevent battery discharge
If the interior light is left on when the engine switch is turned to the “LOCK”
position (vehicles without a smart entry & start system) or off (vehicles with a
smart entry & start system), the lights will go off automatically after 20 min-
utes.
AYGO_OM_Europe_OM99P46E
6-3. Using the storage features
299
List of storage features
1
Bottle holders
(P. 301)
3
Glove box
(P. 300)
2
Card holders
(P. 300)
4
Cup holders
(P. 300)
6
WARNING
■ Items that should not be left in the storage spaces
Do not leave glasses, lighters or spray cans in the storage spaces, as this
may cause the following when cabin temperature becomes high:
●Glasses may be deformed by heat or cracked if they come into contact
with other stored items.
● Lighters or spray cans may explode. If they come into contact with other
stored items, the lighter may catch fire or the spray can may release gas,
causing a fire hazard.
■ When driving or when the storage compartments are not in use
Keep the lids closed.
In the event of sudden braking or sudden swerving, an accident may occur
due to an occupant being struck by an open lid or the items stored inside.
AYGO_OM_Europe_OM99P46E
300
6-3. Using the storage features
Glove box
Pull up the lever to open the glove
box.
Card holders
Cup holders
■ Front
AYGO_OM_Europe_OM99P46E
6-3. Using the storage features
301
■ Rear
WARNING
■ Items unsuitable for the cup holders
Do not place anything other than cups, mugs or beverage cans in the cup
holders.
Other items may be thrown out of the holders in the event of an accident or
sudden braking, causing injury. If possible, cover hot drinks to prevent
burns.
Bottle holders
■ Front door
6
■ Rear door (3-door models only)
AYGO_OM_Europe_OM99P46E
302
6-3. Using the storage features
■ Inside the glove box
Pull up the lever to open the
glove box.
WARNING
■ Items unsuitable for the bottle holder
Do not place anything other than a bottle in the bottle holders.
Other items may be thrown out of the holders in the event of an accident or
sudden braking and cause injury.
NOTICE
■ Items that should not be stowed in the bottle holders
Put the cap on before stowing a bottle. Do not place open bottles in the bot-
tle holders, or glasses and paper cups containing liquid. The contents may
spill and glasses may break.
AYGO_OM_Europe_OM99P46E
6-3. Using the storage features
303
Luggage compartment features
Grocery bag hooks
NOTICE
■ Grocery bag hook weight capacity
Do not hang any object heavier than 2 kg (4.4 lb.) on the grocery bag hooks.
Luggage cover (if equipped)
■ Removing the luggage cover
1
6
Unhook the cords and
remove the luggage cover
out of the retainers.
AYGO_OM_Europe_OM99P46E
304
6-3. Using the storage features
2
Lift the luggage cover and
pull it toward you to remove
it.
WARNING
■ Caution for the luggage cover (if equipped)
●Do not place anything on the luggage cover to avoid death or serious
injury.
●Do not allow children to climb on the luggage cover. Climbing on the lug-
gage cover could result in damage to the luggage cover, possibly causing
death or serious injury to the child.
AYGO_OM_Europe_OM99P46E
6-4. Other interior features
305
Other interior features
Sun visors
To set the visor in the forward
1
position, flip it down.
To set the visor in the side posi-
2
tion, flip down, unhook, and
swing it to the side.
Vanity mirrors
Open the cover to use.
6
AYGO_OM_Europe_OM99P46E
