4-6. Using the driving support systems
221
WARNING
■ The ABS does not operate effectively when
●The limits of tire gripping performance have been exceeded (such as
excessively worn tires on a snow covered road).
●The vehicle hydroplanes while driving at high speed on wet or slick roads.
■ Stopping distance when the ABS is operating may exceed that of nor-
mal conditions
The ABS is not designed to shorten the vehicle’s stopping distance. Always
maintain a safe distance from the vehicle in front of you, especially in the
following situations:
● When driving on dirt, gravel or snow-covered roads
●When driving with tire chains
●When driving over bumps in the road
● When driving over roads with potholes or uneven surfaces
■ TRC may not operate effectively when
4
Directional control and power may not be achievable while driving on slip-
pery road surfaces, even if the TRC system is operating.
Drive the vehicle carefully in conditions where stability and power may be
lost.
■ Hill-start assist control does not operate effectively when
●Do not overly rely on hill-start assist control. Hill-start assist control may
not operate effectively on steep inclines and roads covered with ice.
●Unlike the parking brake, hill-start assist control is not intended to hold the
vehicle stationary for an extended period of time. Do not attempt to use
hill-start assist control to hold the vehicle on an incline, as doing so may
lead to an accident.
■ When the VSC is activated
The slip indicator light flashes. Always drive carefully. Reckless driving may
cause an accident. Exercise particular care when the indicator light flashes.
■ When the TRC/VSC systems are turned off
Be especially careful and drive at a speed appropriate to the road condi-
tions. As these are the systems to help ensure vehicle stability and driving
force, do not turn the TRC/VSC systems off unless necessary.
AYGO_OM_Europe_OM99P46E
222
4-6. Using the driving support systems
WARNING
■ Replacing tires
Make sure that all tires are of the specified size, brand, tread pattern and
total load capacity. In addition, make sure that the tires are inflated to the
recommended tire inflation pressure level.
The ABS, TRC and VSC systems will not function correctly if different tires
are installed on the vehicle.
Contact any authorized Toyota dealer or repairer, or another duly qualified
and equipped professional for further information when replacing tires or
wheels.
■ Handling of tires and the suspension
Using tires with any kind of problem or modifying the suspension will affect
the driving assist systems, and may cause a system to malfunction.
AYGO_OM_Europe_OM99P46E
4-7. Driving tips
223
Winter driving tips
Carry out the necessary preparations and inspections before
driving the vehicle in winter. Always drive the vehicle in a man-
ner appropriate to the prevailing weather conditions.
Preparation for winter
● Use fluids that are appropriate to the prevailing outside tempera-
tures.
• Engine oil
• Engine coolant
• Washer fluid
● Have a service technician inspect the condition of the battery.
4
● Have the vehicle fitted with four snow tires or purchase a set of tire
chains* for the front tires.
Ensure that all tires are the same size and brand, and that chains match
the size of the tires.
*: Tire chains cannot be mounted on the 15-inch tires.
Before driving the vehicle
Perform the following according to the driving conditions:
● Do not try to forcibly open a window or move a wiper that is frozen.
Pour warm water over the frozen area to melt the ice. Wipe away
the water immediately to prevent it from freezing.
● To ensure proper operation of the climate control system fan,
remove any snow that has accumulated on the air inlet vents in
front of the windshield.
● Check for and remove any excess ice or snow that may have accu-
mulated on the exterior lights, vehicle’s roof, chassis, around the
tires or on the brakes.
● Remove any snow or mud from the bottom of your shoes before
getting in the vehicle.
AYGO_OM_Europe_OM99P46E
224
4-7. Driving tips
When driving the vehicle
Accelerate the vehicle slowly, keep a safe distance between you and
the vehicle ahead, and drive at a reduced speed suitable to road con-
ditions.
When parking the vehicle (in the winter time or in the cold lati-
tudes)
Park the vehicle and move the shift lever to E, M or R (multi-mode
manual transmission) or 1 or R (manual transmission) without setting
the parking brake. The parking brake may freeze up, preventing it
from being released. If necessary, block the wheels to prevent inad-
vertent sliding or creeping.
Selecting tire chains
Vehicles with 14-inch tires
Use the correct tire chain size when mounting the tire chains.
Chain size is regulated for each tire size.
Side chain:
1
3 mm (0.12 in.) in diameter
2
10 mm (0.39 in.) in width
3
30 mm (1.18 in.) in length
Cross chain:
4
4 mm (0.16 in.) in diameter
5
14 mm (0.55 in.) in width
6
25 mm (0.98 in.) in length
Vehicles with 15-inch tires
Tire chains cannot be mounted on the 15-inch tires.
Snow tires should be use instead.
Regulations on the use of tire chains
Regulations regarding the use of tire chains vary depending on loca-
tion and type of road. Always check local regulations before installing
chains.
AYGO_OM_Europe_OM99P46E
4-7. Driving tips
225
■ Tire chain installation
Observe the following precautions when installing and removing chains:
●Install and remove tire chains in a safe location.
● Install tire chains on the front tires only. Do not install tire chains on the rear
tires.
● Install tire chains on front tires as tightly as possible. Retighten chains after
driving 0.5 1.0 km (1/4 1/2 mile).
● Install tire chains following the instructions provided with the tire chains.
● If wheel ornaments are used, they will be scratched by the chain band, so
remove the ornaments before putting on the chains. (P. 398)
WARNING
■ Driving with snow tires
Observe the following precautions to reduce the risk of accidents.
Failure to do so may result in a loss of vehicle control and cause death or
4
serious injury.
●Use tires of the specified size.
● Maintain the recommended level of air pressure.
●Do not drive at speeds in excess of the speed limit or the speed limit spec-
ified for the snow tires being used.
●Use snow tires on all, not just some wheels.
■ Driving with tire chains (except vehicles with 15-inch tires)
Observe the following precautions to reduce the risk of accidents.
Failure to do so may result in the vehicle being unable to be driven safely,
and may cause death or serious injury.
●Do not drive in excess of the speed limit specified for the tire chains being
used, or 50 km/h (30 mph), whichever is lower.
● Avoid driving on bumpy road surfaces or over potholes.
● Avoid sudden acceleration, abrupt steering, sudden braking and shifting
operations that cause sudden engine braking.
●Slow down sufficiently before entering a curve to ensure that vehicle con-
trol is maintained.
●Do not use LDA (Lane Departure Alert) (if equipped).
AYGO_OM_Europe_OM99P46E
226
4-7. Driving tips
AYGO_OM_Europe_OM99P46E
227
Audio system
5
5-1. Basic Operations
5-5. Using Bluetooth® devices
Audio system types
228
Bluetooth® audio/phone
255
Steering wheel audio
Using the steering
switches
230
wheel switches
261
AUX port/USB port
231
Registering a
Bluetooth® device
262
5-2. Using the audio system
Optimal use of the
5-6.
“SETUP” menu
audio system
232
Using the “SETUP” menu
(“Bluetooth*” menu)
263
5-3. Using the radio
Using the “SETUP” menu
Radio operation
234
(“TEL” menu)
267
5-4. Using an external device
5-7. Bluetooth® Audio
Listening to an iPod
239
Operating a Bluetooth®
Listening USB memory
enabled portable
device
247
player
270
Using the AUX port
254
5-8. Bluetooth® Phone
Making a phone call
272
Receiving a phone call
274
Speaking on the phone
275
5-9. Bluetooth®
Bluetooth®
277
*: Bluetooth is a registered trademark of Bluetooth SIG, Inc.
AYGO_OM_Europe_OM99P46E
228
5-1. Basic Operations
Audio system types
Vehicles with a multimedia system
Refer to the “Multimedia owner’s manual”.
Vehicles without a multimedia system
● Type A (AM/FM radio)
: If equipped
AYGO_OM_Europe_OM99P46E
5-1. Basic Operations
229
● Type B (AM/FM radio with Bluetooth®)
■ Using cellular phones
Interference may be heard through the audio system’s speakers if a cellular
phone is being used inside or close to the vehicle while the audio system is
operating.
5
NOTICE
■ To prevent battery discharge
Do not leave the audio system on longer than necessary with the engine
stopped.
■ To avoid damaging the audio system
Take care not to spill drinks or other fluids over the audio system.
AYGO_OM_Europe_OM99P46E
230
5-1. Basic Operations
Steering wheel audio switches
Some audio features can be controlled using the switches on
the steering wheel.
Operation may differ depending on the type of audio system or
navigation system. For details, refer to the manual provided with
the audio system or navigation system.
Operating the audio system using the steering wheel switches
1
Volume switch
• Increases/decreases volume
• Press and hold: Continuously
increases/decreases volume
2
Radio mode:
• Press: Select a radio station
• Press and hold: Seek up/
down
Bluetooth®, iPod or USB mode:
• Press: Select a track/file/song
• Press and hold: Select a folder or album (Bluetooth® or USB)
3
“MODE” switch
• Turns the power on, selects audio source
• Press and hold this switch to mute or pause the current opera-
tion. To cancel the mute or pause, press and hold the switch
again.
WARNING
■ To reduce the risk of an accident
Exercise care when operating the audio switches on the steering wheel.
: If equipped
AYGO_OM_Europe_OM99P46E
5-1. Basic Operations
231
AUX port/USB port
Connect an iPod, USB memory device or portable audio player
to the AUX port/USB port as indicated below. Press the “MODE”
button to select “iPod”, “USB” or “AUX”.
Connecting using the AUX port/USB port
■ iPod
Connect an iPod using an iPod
cable.
Turn on the power of the iPod if
it is not turned on.
■ USB memory
Connect the USB memory
device.
Turn on the power of the USB
5
memory device if it is not turned
on.
■ Portable audio player
Connect the portable audio player.
Turn on the power of the portable audio player if it is not turned on.
WARNING
■ While driving
Do not connect a device or operate the device controls.
: If equipped
AYGO_OM_Europe_OM99P46E
232
5-2. Using the audio system
Optimal use of the audio system
The sound quality, volume balance, ASL and AUX settings can
be adjusted.
1
Displays the
“SETUP” menu/
Selecting the mode
2
Changes the following settings
• Sound quality and volume bal-
ance
P. 233
The sound quality and balance
setting can be changed to pro-
duce the best sound.
• Automatic Sound Levelizer
P. 233
• AUX setting
P. 233
Using the audio control function
■ Changing sound quality modes
1
Press the “MENU” knob.
2
Turn the knob to select “Sound settings”.
3
Press the knob.
4
Turn the knob as corresponds to the desired mode.
“Bass”, “Treble”, “Balance”, or “ASL” can be selected.
5
Press the knob.
: If equipped
AYGO_OM_Europe_OM99P46E
5-2. Using the audio system
233
■ Adjusting sound quality
Turning the “MENU” knob adjusts the level.
Sound
Mode
Turn to the
Turn to the
Level
quality mode
displayed
left
right
Bass*
“Bass”
-5 to 5
Low
High
Treble*
“Treble”
-5 to 5
Left/right
volume
“Balance”
L7 to R7
Shifts to left
Shifts to right
balance
*: The sound quality level is adjusted individually in each audio mode.
Press the knob or
(Back) to return to the sound setting
menu.
■ Adjusting the Automatic Sound Levelizer (ASL)
When ASL is selected, turn the
“MENU” knob to change the
amount of ASL.
“LOW”, “MID”, “HIGH”, or “OFF” can be selected.
5
ASL automatically adjusts the volume and tone quality according to
vehicle speed.
Press the knob or
(Back) to return to the sound setting
menu.
■ Changing the AUX settings
1
Press the “MENU” knob.
2
Turn the knob to select “AUX Changes”.
3
Press the knob to select “On” or “Off”.
On mode: AUX can be use
Off mode: AUX cannot be use
Press
(Back) to return to the setup menu.
AYGO_OM_Europe_OM99P46E
234
5-3. Using the radio
Radio operation
Press the
“MODE” button until
“AM”,
“FM” or
“DAB” (if
equipped) is displayed.
Type A
1
Power
4
Station selectors
2
Volume
5
Adjusting the frequency or
3
Changing the audio source
selecting items
6
Seeking the frequency
: If equipped
AYGO_OM_Europe_OM99P46E
5-3. Using the radio
235
Type B
1
Power
4
Seeking the frequency
2
Volume
5
Station selectors
3
Changing the audio source
6
Adjusting the frequency or
selecting items
5
Setting station presets
Search for the desired stations by turning the “MENU” knob or
1
pressing the “” or “” on the “SEEK/FILE” button (type A) or “” or
“” button (type B).
2
Press and hold a desired station selector button until you hear a
beep.
AYGO_OM_Europe_OM99P46E
236
5-3. Using the radio
Using the station list (FM mode only)
■ Updating the station list
1
Press
(List).
The station list will be displayed.
2
Press
(Update) to update the list.
“Updating” is displayed while the searching is in process, and then avail-
able stations will be listed on the display.
To cancel the updating process, press
(Back).
■ Selecting a station from the station list
1
Press
(List).
The station list will be displayed.
2
Turn the “MENU” knob to select a station.
3
Press the knob to tune in the station.
To return to the previous display, press
(Back).
RDS (Radio Data System)
This feature allows your radio to receive station.
■ Listening to stations of the same network
1
Press the “MENU” knob.
2
Turn the knob to “Radio” and press the knob.
Turn the knob as corresponds to the desired mode: “FM AF”,
3
“Region code” or “DAB AF” (if equipped).
Press the knob to select “On” or “Off”.
4
FM AF On/DAB AF On (if equipped) mode:
The station among those of the same network with strong recep-
tion is selected.
Region code On mode:
The station among those of the same network with strong recep-
tion and broadcasting the same program is selected.
AYGO_OM_Europe_OM99P46E
5-3. Using the radio
237
■ Traffic information
1
Press the “MENU” knob.
2
Turn the knob to “Radio” and press the knob.
3
Turn the knob to “FM TA” mode.
4
Press the knob to select “On” or “Off”.
TP mode:
The system automatically switches to traffic information when a
broadcast with a traffic information signal is received.
The station returns to the previous one when the traffic information
ends.
TA mode:
The system automatically switches to traffic information when a
broadcast with a traffic information signal is received. In FM
modes, the system will be mute unless traffic information is being
broadcast.
The audio system returns to the previous mode when the traffic informa-
tion ends.
5
■ EON (Enhanced Other Network) system (for traffic announcement func-
tion)
If the RDS station (with EON data) you are listening to is not broadcasting a
traffic information program and the audio system is in the TA
(traffic
announcement) mode, the radio will be switched automatically to a station
broadcasting a traffic information program in the EON AF list when traffic
information begins.
■ When the battery is disconnected
Stations presets are erased.
■ Reception sensitivity
● Maintaining perfect radio reception at all times is difficult due to the continu-
ally changing position of the antenna, differences in signal strength and sur-
rounding objects, such as trains, transmitters, etc.
● The radio antenna is mounted on the roof. The antenna can be removed
from the base by turning it.
■ Digital Audio Broadcast (DAB) radio (if equipped)
The optional radio antenna and tuner are necessary for the use of Digital
Audio Broadcast (DAB) radio.
AYGO_OM_Europe_OM99P46E
