Toyota Aygo (2017 year). Instruction - part 8
3-2. Opening, closing and locking the doors
119
3
AYGO_OM_Europe_OM99P46E
120
3-2. Opening, closing and locking the doors
WARNING
■ Caution regarding interference with electronic devices
●People with implantable cardiac pacemakers, cardiac resynchronization
therapy-pacemakers or implantable cardioverter defibrillators should main-
tain a reasonable distance between themselves and the smart entry &
start system antennas. (P. 113)
The radio waves may affect the operation of such devices. If necessary,
the entry function can be disabled. Ask any authorized Toyota dealer or
repairer, or another duly qualified and equipped professional for details,
such as the frequency of radio waves and timing of the emitted radio
waves. Then, consult your doctor to see if you should disable the entry
function.
●Users of any electrical medical device other than implantable cardiac
pacemakers, cardiac resynchronization therapy-pacemakers or implant-
able cardioverter defibrillators should consult the manufacturer of the
device for information about its operation under the influence of radio
waves.
Radio waves could have unexpected effects on the operation of such
medical devices.
Ask any authorized Toyota dealer or repairer, or another duly qualified and
equipped professional for details on disabling the entry function.
AYGO_OM_Europe_OM99P46E
3-3. Adjusting the seats
121
Front seats
Adjustment procedure
1
Seat position adjustment lever
2
Seatback angle adjustment dial
3
Vertical height adjustment lever
(driver’s side only) (if equipped)
Seatback lock release lever
4
(3-door models)
3
Moving front seat for rear seat entry (3-door models)
■ Getting in and out of the vehicle
For easy access to the rear seat, use the seatback lock release
lever. When the seatback lock release lever is used, the seat’s orig-
inal position is memorized, so the seat may be returned to that orig-
inal position.
Lift the seatback lock release
lever.
The seatback will fold forward,
and the seat’s slide lock will be
released.
Move the seat all the way for-
ward.
AYGO_OM_Europe_OM99P46E
122
3-3. Adjusting the seats
■ After passengers have entered the vehicle (3-door models)
Slide the seat backward and then lift the seatback. The seat will be set and
locked to its previous position automatically. If the seat cannot be slid back to
the previous position due to the rear passenger or luggage, the seat will be
locked in that position, disabling the seat position memory system.
To recall the previous position, lift the seatback lock release lever after remov-
ing the luggage, or after having the passenger get out or sit properly so that
the seat can be slid back to the previous position. However, if you slide the
seat further backwards than previous position using the seat position adjust-
ment lever, the memory of previous position will be overwritten.
WARNING
■ When adjusting the seat position
● Take care when adjusting the seat position to ensure that other passen-
gers are not injured by the moving seat.
●Do not put your hands under the seat or near the moving parts to avoid
injury.
Fingers or hands may become jammed in the seat mechanism.
■ Seat adjustment
● To reduce the risk of sliding under the lap belt during a collision, do not
recline the seat more than necessary.
If the seat is too reclined, the lap belt may slide past the hips and apply
restraint forces directly to the abdomen, or your neck may contact the
shoulder belt, increasing the risk of death or serious injury in the event of
an accident.
Adjustments should not be made while driving as the seat may unexpect-
edly move and cause the driver to lose control of the vehicle.
●After adjusting the seat, make sure that the seat is locked in position.
● 3-door models: Never allow anyone to touch seatback lock release levers
while the vehicle is moving.
AYGO_OM_Europe_OM99P46E
3-3. Adjusting the seats
123
Rear seats
The seatbacks of the rear seats can be folded down.
Folding down the rear seatbacks
Stow the seat belts using the seat belt hangers.
1
Insert the tab of the rear seat belt as shown in the illustration.
3-door models
5-door models
3
2
Lower the head restraints to the
lowest position.
Vehicles with a non-split rear seat
Pull both seatback lock release
3
straps at the same time and
fold the seatback down.
AYGO_OM_Europe_OM99P46E
124
3-3. Adjusting the seats
Vehicles with a split rear seats
Pull the seatback lock release
3
strap and fold the seatback
down.
Each seatback may be folded sep-
arately.
■ After returning the rear seatback
Remove the rear seat belts from the seat belt hangers.
WARNING
■ When folding the rear seatbacks down
Observe the following precautions. Failure to do so may result in death or
serious injury.
●Do not fold the seatbacks down while driving.
● Stop the vehicle on level ground, set the parking brake and shift the shift
lever to E, M or R (multi-mode manual transmission) or N (manual trans-
mission).
●Do not allow anyone to sit on a folded seatback or in the luggage compart-
ment while driving.
●Do not allow children to enter the luggage compartment.
● Be careful not to get your hands caught when folding the rear seatbacks.
● Adjust the position of the front seat before folding down the rear seatbacks
so that the front seat does not interfere with the rear seatbacks when fold-
ing down the rear seatbacks.
■ After returning the rear seatback to the upright position
Observe the following precautions. Failure to do so may result in death or
serious injury.
● Make sure the seatback is securely locked by pushing it forward and rear-
ward on the top.
●Check that the seat belts are not twisted or caught in the seatback.
NOTICE
■ Stowing the seat belts
The seat belts must be stowed before you fold down the rear seatback.
AYGO_OM_Europe_OM99P46E
3-3. Adjusting the seats
125
Head restraints
Head restraints are provided for all seats.
Rear head restraints
1
Up
Pull the head restraints up.
2
Down
Push the head restraint down while
pressing the lock release button.
Lock release
3
button
■ Removing the rear head restraints
Pull the head restraint up while pressing
the lock release button.
Lock release button
■ Adjusting the rear seat head restraints
Always raise the head restraint one level from the stowed position when
using.
■ Front head restraints
The front head restraints do not have adjusted function.
WARNING
■ Head restraint precautions
Observe the following precautions regarding the head restraints. Failure to
do so may result in death or serious injury.
●Use the head restraints designed for each respective seat.
● Adjust the head restraints to the correct position at all times.
● After adjusting the head restraints, push down on them and make sure
they are locked in position.
●Do not drive with the head restraints removed.
AYGO_OM_Europe_OM99P46E
126
3-4. Adjusting the steering wheel and mirrors
Steering wheel
Adjustment procedure
The steering wheel can be adjusted to a comfortable position.
Hold the steering wheel and
1
push the lever down.
Adjust to the ideal position by
2
moving the steering wheel verti-
cally.
After adjustment, pull the lever up
to secure the steering wheel.
Horn
To sound the horn, press on or
close to the
mark.
■ After adjusting the steering wheel
Make sure that the steering wheel is securely locked.
The horn may not sound if the steering wheel is not securely locked.
AYGO_OM_Europe_OM99P46E
3-4. Adjusting the steering wheel and mirrors
127
WARNING
■ Caution while driving
Do not adjust the steering wheel while driving.
Doing so may cause the driver to mishandle the vehicle and cause an acci-
dent, resulting in death or serious injury.
■ After adjusting the steering wheel
Make sure that the steering wheel is securely locked.
Otherwise, the steering wheel may move suddenly, possibly causing an
accident and resulting in death or serious injury.
3
AYGO_OM_Europe_OM99P46E
128
3-4. Adjusting the steering wheel and mirrors
Inside rear view mirror
The rear view mirror’s position can be adjusted to enable suffi-
cient confirmation of the rear view.
Adjusting the height of rear view mirror (if equipped)
The height of the rear view mirror can be adjusted to suit your driving
posture.
Adjust the height of the rear view
mirror by moving it up and down.
Anti-glare function
Reflected light from the headlights of vehicles behind can be reduced
by operating the lever.
1
Normal position
2
Anti-glare position
WARNING
Do not adjust the position of the mirror while driving.
Doing so may lead to mishandling of the vehicle and cause an accident,
resulting in death or serious injury.
AYGO_OM_Europe_OM99P46E
3-4. Adjusting the steering wheel and mirrors
129
Outside rear view mirrors
Adjustment procedure
Manual-adjustable type
Adjust the mirror up, down, in or
out using the lever.
3
Power-adjustable type
1
To select a mirror to adjust,
press the switch.
1
Left
2
Right
2
To adjust the mirror, press the
switch.
1
Up
2
Right
3
Down
4
Left
AYGO_OM_Europe_OM99P46E
130
3-4. Adjusting the steering wheel and mirrors
Folding the mirrors
Push the mirror back in the direc-
tion of the vehicle’s rear.
■ Mirror angle can be adjusted when (power-adjustable type)
Vehicles without a smart entry & start system
The engine switch is in the “ACC” or “ON” position.
Vehicles with a smart entry & start system
The engine switch is in ACCESSORY or IGNITION ON mode.
■ When the mirrors are fogged up (power-adjustable type)
The outside rear view mirrors can be cleared using the mirror defoggers. Turn
on the rear window defogger to turn on the outside rear view mirror defog-
gers. (P. 286, 292)
WARNING
■ Important points while driving
Observe the following precautions while driving.
Failure to do so may result in loss of control of the vehicle and cause an
accident, resulting in death or serious injury.
●Do not adjust the mirrors while driving.
●Do not drive with the mirrors folded.
● Both the driver and passenger side mirrors must be extended and properly
adjusted before driving.
■ When a mirror is moving
To avoid personal injury and mirror malfunction, be careful not to get your
hand caught by the moving mirror.
■ When the mirror defoggers are operating (power-adjustable type)
Do not touch the rear view mirror surfaces, as they can become very hot
and burn you.
AYGO_OM_Europe_OM99P46E
3-5. Opening, closing the windows and canvas top
131
Power windows
Opening and closing procedures
The power windows can be opened and closed using the switches.
Operating the switch moves the windows as follows:
1
Closing
2
Opening
3
■ The power windows can be operated when
Vehicles without a smart entry & start system
The engine switch is in the “ON” position.
Vehicles with a smart entry & start system
The engine switch is in IGNITION ON mode.
WARNING
Observe the following precautions.
Failure to do so may result in death or serious injury.
■ Closing the windows
●The driver is responsible for all the power window operations, including the
operation for the passengers. In order to prevent accidental operation,
especially by a child, do not let a child operate the power windows. It is
possible for children and other passengers to have body parts caught in
the power window.
●Check to make sure that all passengers do not have any part of their body
in a position where it could be caught when a window is being operated.
●When exiting the vehicle, turn the engine switch to the “LOCK” position
(vehicles without a smart entry & start system) or off (vehicles with a smart
entry & start system), carry the key and exit the vehicle along with the
child. There may be accidental operation, due to mischief, etc., that may
possibly lead to an accident.
: If equipped
AYGO_OM_Europe_OM99P46E
132
3-5. Opening, closing the windows and canvas top
Rear side windows (5-door models)
The rear side windows can be opened and closed.
Opening the rear side windows
Pull the latch handle toward you
1
and swing it fully out.
Push the latch handle to
2
securely lock the latch as
shown in the illustration.
Closing the rear side windows
Close the rear side window as
shown in the illustration.
When closing the window, make
sure it is completely closed.
AYGO_OM_Europe_OM99P46E
3-5. Opening, closing the windows and canvas top
133
WARNING
■ When driving the vehicle
Be sure not to put any body parts, such as hands, out of the rear side win-
dows while the driving. Doing so could be very dangerous because serious
injury may result from collisions or when the brakes are suddenly applied.
■ When closing the rear side windows
Take care to prevent hands or fingers
from being caught in the latch handle.
Failure to do so may result in serious
injury.
3
AYGO_OM_Europe_OM99P46E
134
3-5. Opening, closing the windows and canvas top
Canvas top
Use the overhead switches to open and close the canvas top.
Opening and closing
1
Opens the canvas top*
2
Closes the canvas top*
The canvas top stops slightly
before the fully close position.
Press the switch again to fully
close the canvas top.
*: Lightly press either end of the can-
vas top switch to stop the canvas
top partway.
■ The canvas top can be operated when
Vehicles without a smart entry & start system
The engine switch is in the “ON” position.
Vehicles with a smart entry & start system
The engine switch is in IGNITION ON mode.
■ System safeguard
When the canvas top repeatedly opening and closing, it may stop temporarily
for system protection. With the engine switch in the “ON” position (vehicles
without a smart entry & start system) or IGNITION ON mode (vehicles with a
smart entry & start system) normal operations can be resumed after several
minutes.
■ When the canvas top auto operation is not available
Perform the following procedure:
1
Vehicles without a smart entry & start system: Turn the engine switch to
the “ON” (engine running) position.
Vehicles with a smart entry & start system: Turn the engine switch to IGNI-
TION ON (engine running) mode.
Press and hold the close switch until the following operations finishes.
2
Canvas top closes canvas top opens canvas top closes again
Check to make sure that the canvas top is completely closed and then
3
release the switch.
If the auto operation is available, the initialization is finished correctly.
If the auto operation is not available, perform the initialization method again.
: If equipped
AYGO_OM_Europe_OM99P46E
3-5. Opening, closing the windows and canvas top
135
WARNING
Observe the following precautions.
Failure to do so may cause death or serious injury.
■ Opening and closing the canvas top
●Do not allow any passengers to put their hands or heads outside the vehi-
cle while it is moving.
●Do not sit on top of the canvas top.
●The driver is responsible for canvas top opening and closing operations.
In order to prevent accidental operation, especially by a child, do not let a
child operate the canvas top. It is possible for children and other passen-
gers to have body parts caught in the canvas top.
●Check to make sure that all passengers do not have any part of their body
in a position where it could be caught when the canvas top is being oper-
3
ated.
●When exiting the vehicle, turn the engine switch to the “LOCK” position
(vehicles without a smart entry & start system) or off (vehicles with a smart
entry & start system), carry the key and exit the vehicle along with the
child. There may be accidental operation, due to mischief, etc., that may
possibly lead to an accident.
AYGO_OM_Europe_OM99P46E
