Toyota Auris Hybrid Touring Sports (2017 year). Instruction - part 8

120

3-1. Key information

Keys

The keys

The following keys are provided with the vehicle.

1

Electronic keys

• Operating the smart entry &

start system*1 (P. 134)

• Operating the push button

start*2 (P. 155)

• Operating the wireless remote

control function

2

Mechanical keys

3

Key number plate

*1: Vehicles with a smart entry & start system

*2: Vehicles with a push button start

Wireless remote control

1

Locks all the doors (P. 124)

2

Unlocks all the doors (P. 124)

AURIS HV Touring

Sports_EE

(OM12L18E)

3-1. Key information

121

Using the mechanical key

To take out the mechanical key,

push the release button and take

the key out.

The mechanical key can only be

inserted in one direction, as the

key only has grooves on one side.

If the key cannot be inserted in a

lock cylinder, turn it over and re-

attempt to insert it.

After using the mechanical key, store it in the electronic key. Carry the

mechanical key together with the electronic key. If the electronic key bat-

tery is depleted or the entry function does not operate properly, you will

3

need the mechanical key. (P. 548)

■ If you lose your keys

New genuine keys can be made by any authorized Toyota dealer or repairer,

or another duly qualified and equipped professional using the mechanical key

and the key number stamped on your key number plate. Keep the plate in a

safe place such as your wallet, not in the vehicle.

■ When riding in an aircraft

When bringing an electronic key onto an aircraft, make sure you do not press

any buttons on the electronic key while inside the aircraft cabin. If you are

carrying an electronic key in your bag, etc., ensure that the buttons are not

likely to be pressed accidentally. Pressing a button may cause the electronic

key to emit radio waves that could interfere with the operation of the aircraft.

■ Conditions affecting the operation of the smart entry & start system or

push button start

P. 137, 157

AURIS HV Touring

Sports_EE

(OM12L18E)

3-1. Key information

123

NOTICE

■ To prevent key damage

● Do not drop the keys, subject them to strong shocks or bend them.

● Do not expose the keys to high temperatures for long periods of time.

● Do not get the keys wet or wash them in an ultrasonic washer etc.

● Do not attach metallic or magnetic materials to the keys or place the keys

close to such materials.

● Do not disassemble the keys.

● Do not attach a sticker or anything else to the surface of the electronic key.

● Do not place the keys near objects that produce magnetic fields, such as

TVs, audio systems and induction cookers, or medical electrical equip-

ment, such as low-frequency therapy equipment.

3

■ Carrying the electronic key on your person

Carry the electronic key 10 cm (3.9 in.) or more away from electric appli-

ances that are turned on. Radio waves emitted from electric appliances

within 10 cm (3.9 in.) of the electronic key may interfere with the key, caus-

ing the key to not function properly.

■ In case of a smart entry & start system malfunction or other key-related

problems

Take your vehicle with all the electronic keys provided with your vehicle to

any authorized Toyota dealer or repairer, or another duly qualified and

equipped professional.

■ When an electronic key is lost

If the electronic key remains lost, the risk of vehicle theft increases signifi-

cantly. Visit any authorized Toyota dealer or repairer, or another duly quali-

fied and equipped professional immediately with all remaining electronic

keys that was provided with your vehicle.

AURIS HV Touring

Sports_EE

(OM12L18E)

124

3-2. Opening, closing and locking the doors

Side doors

Unlocking and locking the doors from the outside

◆ Entry function (vehicles with a smart entry & start system)

Carry the electronic key to enable this function.

Grip the front door handle to

1

unlock all the doors.

Make sure to touch the sensor

on the back of the handle.

The doors cannot be unlocked

for 3 seconds after the doors are

locked.

Touch the lock sensor (the

2

indentation on the side of the

door handle) to lock all the

doors.

Check that the door is securely locked.

◆ Wireless remote control

Locks all the doors

1

Check that the door is securely

locked.

Unlocks all the doors

2

■ Operation signals

The emergency flashers flash to indicate that the doors have been locked/

unlocked. (Locked: Once; Unlocked: Twice)

■ Security feature

If a door is not opened within approximately 30 seconds after the vehicle is

unlocked, the security feature automatically locks the vehicle again. (How-

ever, depending on the location of the electronic key, the key may be

detected as being in the vehicle. In this case, vehicle may be unlocked.)

AURIS HV Touring

Sports_EE

(OM12L18E)

3-2. Opening, closing and locking the doors

125

■ When the door cannot be locked by the lock sensor on the surface of the

front door handle

Use your palm to touch the lock sensor.

■ Door lock buzzer

If an attempt to lock the doors is made when a door is not fully closed, a

buzzer will sound continuously for 5 seconds. Fully close the door to stop the

buzzer, and lock the doors again.

3

■ Alarm (if equipped)

Using the entry function or wireless remote control to lock the doors will set

the alarm system. (P. 89)

■ If the smart entry & start system or the wireless remote control does not

operate properly

Use the mechanical key to lock and unlock the doors. (P. 548)

Replace the key battery with a new one if it is depleted. (P. 471)

AURIS HV Touring

Sports_EE

(OM12L18E)

126

3-2. Opening, closing and locking the doors

Unlocking and locking the doors from the inside

◆ Door lock switch

1

Locks all the doors

2

Unlocks all the doors

◆ Inside lock buttons

1

Locks the door

2

Unlocks the door

The front doors can be opened

by pulling the inside handle

even if the lock buttons are in

the lock position.

Locking the front doors from the outside without a key

1

Move the inside lock button to the lock position.

2

Close the door while pulling the door handle.

The door cannot be locked if the power switch is in ACCESSORY or

ON mode, or the electronic key is left inside the vehicle.

The key may not be detected correctly and the door may be locked.

AURIS HV Touring

Sports_EE

(OM12L18E)

3-2. Opening, closing and locking the doors

127

Rear door child-protector lock

The door cannot be opened from

inside the vehicle when the lock is

set.

1

Unlock

2

Lock

These locks can be set to prevent

children from opening the rear

doors. Push down on each rear

door switch to lock both rear doors.

3

■ Using the mechanical key

The doors can also be locked and unlocked with the mechanical key.

(P. 548)

■Open door warning buzzer

If a door or the back door is not fully closed, a buzzer will sound when the

vehicle speed reaches 5 km/h (3 mph).

The open door(s) or back door is indicated on the multi-information display.

■ Conditions affecting the operation of the smart entry & start system

P. 137

AURIS HV Touring

Sports_EE

(OM12L18E)

3-2. Opening, closing and locking the doors

129

Back door

The back door can be locked/unlocked and opened by the fol-

lowing procedures.

Unlocking and locking the back door

■ Door lock switch

P. 126

■ Entry function (vehicles with a smart entry & start system)

Press the button to unlock

1

3

the back door.

The door cannot be unlocked for

3 seconds after the door is

locked.

2

Press the button to lock the

back door.

Check that the door is securely

locked.

■ Wireless remote control

P. 124

AURIS HV Touring

Sports_EE

(OM12L18E)

130

3-2. Opening, closing and locking the doors

Opening the back door

Raise the back door while pushing

up the back door opener switch.

The back door cannot be closed

immediately after the back door

opener switch is pushed.

■ Operation signals

The emergency flashers flash to indicate that the doors have been locked/

unlocked using the entry function or wireless remote control. (Locked: once;

Unlocked: twice)

■Open door warning buzzer

If a door or the back door is not fully closed, a buzzer will sound when the

vehicle speed reaches 5 km/h (3 mph).

The open door(s) or back door is indicated on the multi-information display.

■ When closing the back door

Lower the back door using the back door

handle, and make sure to push the back

door down from the outside to close it.

Be careful not to pull the back door

sideways when closing the back door

with the handle.

AURIS HV Touring

Sports_EE

(OM12L18E)

3-2. Opening, closing and locking the doors

131

■Luggage compartment light

The luggage compartment light turns on when the back door is opened.

■ If the back door opener is inoperative

The back door can be operated from the inside.

Using a screwdriver, remove the cover.

1

To protect the cover, place a rag

between the flathead screwdriver and

the cover as shown in the illustration.

2

Move the lever.

3

WARNING

■ Caution while driving

● Keep the back door closed while driving.

If the back door is left open, it may hit near-by objects while driving or lug-

gage may be unexpectedly thrown out, causing an accident.

In addition, exhaust gases may enter the vehicle, causing death or a seri-

ous health hazard. Make sure to close the back door before driving.

● Before driving the vehicle, make sure that the back door is fully closed. If

the back door is not fully closed, it may open unexpectedly while driving,

causing an accident.

● Never let anyone sit in the luggage compartment. In the event of sudden

braking or a collision, they are susceptible to death or serious injury.

AURIS HV Touring

Sports_EE

(OM12L18E)

132

3-2. Opening, closing and locking the doors

WARNING

■ When children are in the vehicle

Observe the following precautions.

Failure to do so may result in death or serious injury.

● Do not allow children to play in the luggage compartment.

If a child is accidentally locked in the luggage compartment, they could

have heat exhaustion or other injuries.

● Do not allow a child to open or close the back door.

Doing so may cause the back door to move unexpectedly, or cause the

child’s hands, head, or neck to be caught by the closing back door.

■ Operating the back door

Observe the following precautions.

Failure to do so may cause parts of the body to be caught, resulting in death

or serious injury.

● Remove any heavy loads, such as snow and ice, from the back door

before opening it. Failure to do so may cause the back door to suddenly

shut again after it is opened.

● When opening or closing the back door, thoroughly check to make sure

the surrounding area is safe.

● If anyone is in the vicinity, make sure they are safe and let them know that

the back door is about to open or close.

● Use caution when opening or closing the back door in windy weather as it

may move abruptly in strong wind.

● The back door may suddenly shut if it is

not opened fully. It is more difficult to

open or close the back door on an

incline than on a level surface, so

beware of the back door unexpectedly

opening or closing by itself. Make sure

that the back door is fully open and

secure before using the luggage com-

partment.

AURIS HV Touring

Sports_EE

(OM12L18E)

3-2. Opening, closing and locking the doors

133

WARNING

● When closing the back door, take extra

care to prevent your fingers etc. from

being caught.

● When closing the back door, make sure

to press it lightly on its outer surface. If

the back door handle is used to fully

close the back door, it may result in

hands or arms being caught.

● Do not pull on the back door damper stay to close the back door, and do

not hang on the back door damper stay.

Doing so may cause hands to be caught or the back door damper stay to

break, causing an accident.

3

● If a bicycle carrier or similar heavy object is attached to the back door, it

may suddenly shut again after being opened, causing someone’s hands,

head or neck to be caught and injured. When installing an accessory part

to the back door, using a genuine Toyota part is recommended.

NOTICE

■Back door damper stays

The back door is equipped with damper stays that hold the back door in

place.

Observe the following precautions.

Failure to do so may cause damage to the back door damper stay, resulting

in malfunction.

● Do not attach any foreign objects, such

as stickers, plastic sheets, or adhesives

to the damper stay rod.

● Do not touch the damper stay rod with

gloves or other fabric items.

● Do not attach any accessories other

than genuine Toyota parts to the back

door.

● Do not place your hand on the damper

stay or apply lateral forces to it.

AURIS HV Touring

Sports_EE

(OM12L18E)

134

3-2. Opening, closing and locking the doors

Smart entry & start system

The following operations can be performed simply by carrying

the electronic key on your person, for example in your pocket.

The driver should always carry the electronic key.

● Locks and unlocks the doors (P. 124)

● Locks and unlocks the back door (P. 129)

● Starts the hybrid system (P. 216)

■Antenna location

1

Antennas outside the cabin

2

Antennas inside the cabin

3

Antenna inside the luggage compart-

ment

4

Antenna outside the luggage compart-

ment

■ Effective range (areas within which the electronic key is detected)

When locking or unlocking the

doors

The system can be operated when

the electronic key is within about

0.7 m (2.3 ft.) of an outside front

door handle and the back door.

(Only the doors detecting the key

can be operated.)

When starting the hybrid system or changing power switch modes

The system can be operated when the electronic key is inside the

vehicle.

: If equipped

AURIS HV Touring

Sports_EE

(OM12L18E)

3-2. Opening, closing and locking the doors

135

■ Alarms and warning messages

A combination of exterior and interior buzzers as well as warning messages

shown on the multi-information display are used to prevent theft of the vehicle

and accidents resulting from erroneous operation. Take appropriate mea-

sures based on the displayed message. (P. 511)

When only an alarm sounds, circumstances and correction procedures are as

follows.

Alarm

Situation

Correction procedure

An attempt was made

Close all of the doors

Exterior buzzer sounds

to lock the vehicle while

and lock the doors

once for 5 seconds

a door was open.

again.

The power switch was

turned to ACCESSORY

3

mode while the driver’s

Turn the power switch

Interior buzzer sounds

door was open (or the

off

and close the

continuously

driver’s

door was

driver’s door.

opened while the

power switch was in

ACCESSORY mode).

AURIS HV Touring

Sports_EE

(OM12L18E)

Content   ..  6  7  8  9   ..
