Toyota Auris Hybrid Touring Sports (2017 year). Instruction - part 6

1-3. Theft deterrent system

85

1

AURIS HV Touring

Sports_EE

(OM12L18E)

86

1-3. Theft deterrent system

AURIS HV Touring

Sports_EE

(OM12L18E)

1-3. Theft deterrent system

87

1

AURIS HV Touring

Sports_EE

(OM12L18E)

88

1-3. Theft deterrent system

NOTICE

■ To ensure the system operates correctly

Do not modify or remove the system. If modified or removed, the proper

operation of the system cannot be guaranteed.

AURIS HV Touring

Sports_EE

(OM12L18E)

1-3. Theft deterrent system

89

Alarm

The alarm

The alarm uses light and sound to give an alert when an intrusion is

detected.

1

The alarm is triggered in the following situations when the alarm is

set:

● A locked door is unlocked or opened in any way other than using

the entry function (if equipped) or wireless remote control. (The

doors will lock again automatically.)

● The hood is opened.

● The intrusion sensor detects something moving inside the vehicle.

(An intruder gets in the vehicle.)

● The back door window is tapped or broken.

Setting the alarm system

Close the doors and hood, and

lock all the doors using the entry

function (if equipped) or wireless

remote control. The system will be

set automatically after

30 sec-

onds.

The indicator light changes from

being on to flashing when the sys-

tem is set.

: If equipped

AURIS HV Touring

Sports_EE

(OM12L18E)

1-3. Theft deterrent system

91

■ Triggering of the alarm

The alarm may be triggered in the following situations:

(Stopping the alarm deactivates the alarm system.)

● The doors are unlocked using the key.

1

● A person inside the vehicle opens a door

or the hood.

● The 12-volt battery is disconnected.

■ Alarm-operated door lock

In the following cases, depending on the situation, the door may automatically

lock to prevent improper entry into the vehicle:

● When a person remaining in the vehicle unlocks the door and the alarm is

activated.

● While the alarm is activated, a person remaining in the vehicle unlocks the

door.

● When recharging or replacing the 12-volt battery

NOTICE

■ To ensure the system operates correctly

Do not modify or remove the system. If modified or removed, the proper

operation of the system cannot be guaranteed.

AURIS HV Touring

Sports_EE

(OM12L18E)

92

1-3. Theft deterrent system

Intrusion sensor

The intrusion sensor detects intruders or movement in the vehicle.

When an intruder or movement is detected, the alarm will be trig-

gered.

This system is designed to deter and prevent vehicle theft but does

not guarantee absolute security against all intrusions.

■ Setting the intrusion sensor

The intrusion sensor will be set automatically when the alarm is set.

(P. 89)

■ Canceling the intrusion sensor

If you are leaving pets or other moving things inside the vehicle,

make sure to stop the intrusion sensor before setting the alarm, as

they will respond to movement inside the vehicle.

1

Turn the power switch off.

2

Press the intrusion sensor

cancel switch.

To set the alarm with the intru-

sion sensor disabled, the alarm

must be set within

5 minutes

after canceling the sensor.

The intrusion sensor will revert

to on each time the power

switch is turned to ON mode.

AURIS HV Touring

Sports_EE

(OM12L18E)

1-3. Theft deterrent system

93

■ Canceling and automatic re-enabling of the intrusion sensor

● The alarm will still be set even when the intrusion sensor is canceled.

● After the intrusion sensor is canceled, pressing the power switch or unlock-

ing the doors using the entry function (if equipped) or wireless remote con-

trol will re-enable the intrusion sensor.

● The intrusion sensor will automatically be re-enabled when the alarm sys-

tem is deactivated.

1

● The intrusion sensor will automatically be re-enabled if the alarm system is

not set within 5 minutes after the intrusion sensor is canceled.

■ Intrusion sensor detection considerations

The sensor may trigger the alarm in the following situations:

● Persons or pets are in the vehicle.

● A window is open.

In this case, the sensor may detect the

following:

• Wind or the movement of objects

such as leaves and insects inside the

vehicle

• Ultrasonic waves emitted from

devices such as the intrusion sensors

of other vehicles

• The movement of people outside the

vehicle

● Unstable items, such as dangling acces-

sories or clothes hanging on the coat

hooks, are in the vehicle.

AURIS HV Touring

Sports_EE

(OM12L18E)

94

1-3. Theft deterrent system

● The vehicle is parked in a place where

extreme vibrations or noises occur, such

as in a parking garage.

● Ice or snow is removed from the vehicle,

causing the vehicle to receive repeated

impacts or vibrations.

● The vehicle is inside an automatic or high-pressure car wash.

● The vehicle experiences impacts, such as hail, lightning strikes, and other

kinds of repeated impacts or vibrations.

NOTICE

■ To ensure the intrusion sensor function correctly

● To ensure that the sensors operate

properly, do not touch or cover them.

● Do not spray air fresheners or other

products directly into the sensor holes.

● Installing accessories other than genuine Toyota parts or leaving objects

between the driver’s seat and front passenger’s seat may reduce the

detection performance.

AURIS HV Touring

Sports_EE

(OM12L18E)

1-3. Theft deterrent system

95

Double locking system (right-hand drive

vehicles only)

Unauthorized access to the vehicle is prevented by disabling the

door unlocking function from both the interior and exterior of

the vehicle.

1

Vehicles employing this system

have labels on the window glass

of both front doors.

Setting the double locking system

Turn the power switch off, have all the passengers exit the vehicle

1

and ensure that all the doors are closed.

Using the entry function (if equipped):

2

Touch the sensor area on the outside door handle twice within 5

seconds.

Using the wireless remote control:

Press

twice within 5 seconds.

Canceling the double locking system

Using the entry function (if equipped): Hold the outside door handle.

Using the wireless remote control: Press

WARNING

■ Double locking system precaution

Never activate the double locking system when there are people in the vehi-

cle because all the doors cannot be opened from inside the vehicle.

AURIS HV Touring

Sports_EE

(OM12L18E)

98

2. Instrument cluster

Warning lights and indicators

The warning lights and indicators on the instrument cluster and

center panel inform the driver of the status of the vehicle’s vari-

ous systems.

For the purpose of explanation, the following illustration dis-

plays all warning lights and indicators illuminated.

The units used on the speedometer and some indicators may differ

depending on the target region.

AURIS HV Touring

Sports_EE

(OM12L18E)

2. Instrument cluster

99

Warning lights

Warning lights inform the driver of malfunctions in the indicated vehi-

cle’s systems.

*1

*1

Brake system warning

Slip indicator (P. 505)

light (P. 503)

(Red)

*1

*1, 2

Brake system warning

PCS warning light

2

light (P. 503)

(P. 505)

(Yellow)

(if equipped)

High engine coolant

Low fuel level warning

temperature

warning

light (P. 506)

light (P. 504)

*1

Driver’s and front pas-

Malfunction

indicator

senger’s

seat

belt

lamp (P. 504)

reminder light (P. 506)

*1

*3

Rear passengers’ seat

SRS warning light

belt reminder lights

(P. 504)

(P. 506)

*1

*1

ABS warning light

Tire pressure warning

(P. 504)

light (P. 506)

(if equipped)

*1

Electric power steering

*1

Master warning light

system warning light

(P. 507)

(P. 504)

*

1: These lights turn on when the power switch is turned to ON mode to indi-

cate that a system check is being performed. They will turn off after the

hybrid system is on, or after a few seconds. There may be a malfunction in

a system if a light does not come on, or if the lights do not turn off. Have

the vehicle inspected by any authorized Toyota dealer or repairer, or

another duly qualified and equipped professional.

*2: The light flashes to indicate a malfunction.

*3: This light illuminates on the center panel.

AURIS HV Touring

Sports_EE

(OM12L18E)

100

2. Instrument cluster

Indicators

The indicators inform the driver of the operating state of the vehicle’s

various systems.

Turn signal indicator

Simple-IPA indicator

(P. 232)

(P. 296)

(if equipped)

*1, 2

Tail light indicator

Slip indicator

(P. 234)

(P. 311)

Headlight high beam

*1

VSC OFF indicator

indicator

(P. 311)

(P. 234)

*1

*1

Automatic High Beam

PCS warning light

indicator (P. 275)

(P. 257)

(if equipped)

(if equipped)

Front fog light indicator

EV indicator (P. 222)

(P. 240)

(if equipped)

*3

Rear fog light indicator

Security indicator

(P. 240)

(P. 82, 89)

Cruise control indicator

Power mode indicator

(P. 285)

(P. 227)

(if equipped)

Cruise control “SET”

“ECO MODE” indicator

indicator (P. 285)

(P. 227)

(if equipped)

LDA

(Lane Departure

EV drive mode indicator

Alert) indicator

(P. 222)

(P. 270)

(if equipped)

Toyota parking

“READY” indicator

assist-sensor indicator

(P. 216)

(P. 289)

(if equipped)

AURIS HV Touring

Sports_EE

(OM12L18E)
