F–23

TABLE OF REPAIR WIRE, TERMINAL PACKING, HOLE PLUG AND PRESS SLEEVE

Wire Harness Repair Manual

437

Repair Wire (Non–waterproof Type)

Type

SL

Male

Female

Sleeve : Large (Yellow)

P/N

82998–12130*

Type

SP

Female (Power)

Female (Signal)

Sleeve : Medium (Blue)

Sleeve : Medium (Blue)

P/N

82998–12520

82998–12530

Type

TLC

Male

Female

Sleeve : Medium (Blue)

Sleeve : Medium (Blue)

P/N

82998–12220

82998–12230

TABLE OF REPAIR WIRE, TERMINAL PACKING, HOLE PLUG AND PRESS SLEEVE

F–24

438

Wire Harness Repair Manual

Repair Wire (Non–waterproof Type)

Type

TNS

Male

Female

Sleeve : Medium (Blue)

Sleeve : Medium (Blue)

P/N

82998–12240

82998–12250

Type

TODC

Male

Female

Sleeve : Large (Yellow)

Sleeve : Large (Yellow)

P/N

82998–12080

82998–12090

F–25

TABLE OF REPAIR WIRE, TERMINAL PACKING, HOLE PLUG AND PRESS SLEEVE

Wire Harness Repair Manual

439

Terminal Packing

Type

6.3

Cav.

No.

1

3

P/N

90980–09210

90980–09211

Type

7.7

Cav.

No.

1

P/N

90980–09380

Type

TODC

Cav.

No.

1

3

P/N

90980–09378

90980–09379

TABLE OF REPAIR WIRE, TERMINAL PACKING, HOLE PLUG AND PRESS SLEEVE

F–26

440

Wire Harness Repair Manual

Hole Plug

Type

6.3, 7.7, TODC

4.8

P/N

90950–01730

90980–09325

Type

8.0

2.3II

P/N

90980–09353

90980–09152

(6mm)

90980–09229

(5mm)

Type

TLC

1.3

P/N

90980–09162

90980–09414

F–27

TABLE OF REPAIR WIRE, TERMINAL PACKING, HOLE PLUG AND PRESS SLEEVE

Wire Harness Repair Manual

441

Hole Plug

Type

1.0III

0.64

P/N

90980–09717

90980–09871

Type

P/N

Type

P/N

TABLE OF REPAIR WIRE, TERMINAL PACKING, HOLE PLUG AND PRESS SLEEVE

F–28

442

Wire Harness Repair Manual

Press Sleeve

Color

YELLOW

BLUE

P/N

82999–12030

82999–12020

Color

RED

P/N

82999–12010

Wire Harness Repair Manual

443

APPENDIX

WIRE HARNESS REPAIR KIT WITH CASE

G–1

. . .

REPORTING OF WIRE HARNESS
PROBLEM

G–2

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

G
