SB–52

SEAT BELT  –  REAR SEAT OUTER BELT ASSEMBLY

SB

REAR FLOOR BOARD

REAR FLOOR MAT
ASSEMBLY

REAR FLOOR MAT
SUPPORT PLATE

LUGGAGE HOLD BELT
STRIKER ASSEMBLY

LUGGAGE HOLD BELT
STRIKER ASSEMBLY

x2

x5

LUGGAGE HOLD BELT
STRIKER ASSEMBLY

B130655E01

SEAT BELT  –  REAR SEAT OUTER BELT ASSEMBLY

SB–53

SB

FRONT DOOR OPENING
TRIM WEATHERSTRIP

FRONT DOOR
SCUFF PLATE

ACCESS DOOR
SCUFF PLATE

B138381E01

SB–54

SEAT BELT  –  REAR SEAT OUTER BELT ASSEMBLY

SB

x4

w/ Woofer:

AMPLIFIER BOX
SPEAKER ASSEMBLY

DECK SIDE GARNISH

QUARTER TRIM POCKET

QUARTER TRIM POCKET TRAY

SIDE TRIM COVER

SPEAKER MOUNTING COVER

N*m (kgf*cm, ft*lbf)  : Specified torque

8.1 (85, 72 in.*lbf)

REAR DECK
TRIM COVER

POWER OUTLET
CONNECTOR

w/ Power Outlet Socket:

for RH Side:

SPEAKER CONNECTOR

B138473E01

SEAT BELT  –  REAR SEAT OUTER BELT ASSEMBLY

SB–55

SB

42 (430, 31)

REAR SEAT OUTER
BELT ASSEMBLY

ROOF SIDE
INNER GARNISH

CLIP

PACKAGE HOLDER
NET HOOK

42 (430, 31)

8.5 (85, 75 in.*lbf)

42 (430, 31)

LAP BELT OUTER
ANCHOR COVER

DECK TRIM SIDE
PANEL ASSEMBLY

N*m (kgf*cm, ft.*lbf) : Specified torque

x3

w/o Woofer:

for RH Side:

B134993E01
