PREPARATION – DIFFERENTIAL
PP–41
PP
LUBRICANT
Front differential
Rear differential
Item
Capacity
Oil grade
Classification
w/ A.D.D.
1.45 to 1.55 liters (1.53 to 1.63
US qts, 1.27 to 1.36 Imp. qts.)
Hypoid gear oil APL GL-4 and
GL-5
Above-18
°C (0°F): SAE 90)
Below-18
°C (0°F): SAE 75W-90
w/o A.D.D.
1.35 to 1.45 liters (1.42 to 1.53
US qts, 1.18 to 1.27 Imp. qts.)
Hypoid gear oil APL GL-4 and
GL-5
Above-18
°C (0°F): SAE 90)
Below-18
°C (0°F): SAE 85W-90
Item
Capacity
Oil grade
Classification
w/ Differential lock
2.85 to 2.95 liters (3.01 to 3.12
US qts, 2.51 to 2.60 Imp. qts.)
Hypoid gear oil APL GL-5
Above-18
°C (0°F): SAE 90)
Below-18
°C (0°F): SAE 85W-90
w/o Differential lock
2.95 to 3.05 liters (3.12 to 3.22
US qts, 2.60 to 2.68 Imp. qts.)
Hypoid gear oil APL GL-5
Above-18
°C (0°F): SAE 90)
Below-18
°C (0°F): SAE 85W-90
