PREPARATION  –  AXLE

PP–43

PP

RECOMMENDED TOOLS

09905-00012

Snap Ring No.1 Expander

PP–44

PREPARATION  –  AXLE

PP

EQUIPMENT

Dial indicator with magnetic base

Torque wrench

PREPARATION  –  SUSPENSION

PP–43

PP

PREPARATION

PREPARATION

SUSPENSION

SST

09023-00101

Union Nut Wrench 10 mm

09502-12010

Differential Bearing Replacer

09613-26010

Steering Worm Bearing Cone
Remover

09628-00011

Ball Joint Puller

09628-62011

Boll Joint Puller

09631-12090

Seal Ring Tool

09631-32020

Seal Ring Tool

09710-22021

Front Suspension Bushing Tool
Set

(09710-01031)

Upper Arm Bushing Replacer

(09710-01071)

Lower Arm Bushing Remover

(09710-01081)

Lower Arm Bushing Replacer

PP–44

PREPARATION  –  SUSPENSION

PP

09710-26010

Rear Suspension Bushing Tool Set

(09710-05061)

Replacer

09727-00060

Arm Set C

09727-30021

Coil Spring Compressor

(09727-00010)

Bolt Set

(09727-00031)

Compressor

09950-00020

Bearing Remover

09950-40011

Puller B Set

(09951-04010)

Hanger 150

(09952-04010)

Slide Arm

(09953-04020)

Center Bolt 150

(09954-04010)

Arm 25
