PREPARATION  –  DIFFERENTIAL

PP–33

PP

PREPARATION

PREPARATION

DIFFERENTIAL

SST

09223-00010

Cover & Seal Replacer

09223-15020

Oil Seal & Bearing Replacer

09308-00010

Oil Seal Puller

09308-10010

Oil Seal Puller

09316-60011

Transmission & Transfer Bearing
Replacer

(09316-00011)

Replacer Pipe

(09316-00021)

Replacer A

(09316-00041)

Replacer C

09330-00021

Companion Flange Holding Tool

(09330-00030)

Pin

09350-20015

TOYOTA Automatic Transmission
Tool Set

PP–34

PREPARATION  –  DIFFERENTIAL

PP

(09369-20040)

Piston Spring Compressor Set

09502-12010

Differential Bearing Replacer

09504-00011

Differential Side Bearing
Adjusting Nut Wrench

09506-30012

Differential Drive Pinion Rear
Bearing Cone Replacer

09550-00032

Replacer

09554-22010

Differential Oil Seal Replacer

09554-30011

Differential Oil Seal Replacer

09556-22010

Drive Pinion Front Bearing
Remover

09564-32011

Differential Preload Adaptor

09608-32010

Steering Knuckle Oil Seal
Replacer

09612-65014

Steering Worm Bearing Puller

(09612-01020)

Claw B

PREPARATION  –  DIFFERENTIAL

PP–35

PP

(09612-01050)

Hanger Pin with Nut

09636-20010

Upper Ball Joint Dust Cover
Replacer

09930-00010

Drive Shaft Nut Chisel

09950-00020

Bearing Remover

(09951-00680)

Replacer 68

(09951-00890)

Replacer 89

09950-30012

Puller A Set

(09951-03010)

Upper Plate

(09953-03010)

Center Bolt

(09954-03010)

Arm

(09955-03030)

Lower Plate 130

(09956-03020)

Adapter 18

PP–36

PREPARATION  –  DIFFERENTIAL

PP

(09956-03030)

Adaptor 20

09950-40011

Puller B Set

(09951-04010)

Hanger 150

(09951-04020)

Hanger 200

(09952-04010)

Slide Arm

(09953-04020)

Center Bolt 150

(09953-04030)

Center Bolt 200

(09954-04010)

Arm 25

(09955-04011)

Claw No.1

(09955-04061)

Claw No.6

(09957-04010)

Attachment

(09958-04011)

Holder
