ED–6
ENGINE HOOD / DOOR – HOOD SUPPORT
ED
DISPOSAL
HINT:
•
Use the same procedure for both the RH and LH sides.
•
The procedure described below is for the LH side.
1.
DISPOSE OF HOOD SUPPORT
(a) Horizontally fix the hood support in a vise with the
piston-rod pulled out.
(b) Wearing protective glasses, using a metal saw
gradually cut the shaded part between A and B,
shown in the illustration, to gradually release the
gas.
Specification
CAUTION:
•
Cover the area that is being cut with a shop
rag or a piece of cloth because there is a
possibility that metal shards may be
dispersed by the gas.
•
The gas is colorless, odorless and harmless.
a
b
A
B
B135983E01
Area
Measurement
a
80 mm (3.15 in.)
b
20 mm (0.80 in.)
