Toyota Sequoia (2005). Manual - part 915

BO1MO–03

BO–96

–

BODY

INSTRUMENT PANEL

3649

REASSEMBLY

Reassembly is in the reverse order of disassembly (See page

BO–95

).

BO43A–02

–

BODY

INSTRUMENT PANEL

BO–97

3650

INSTALLATION

Installation is in the reverse order of removal (See page

BO–89

).

1.

CONNECT CABLE TO NEGATIVE BATTERY TERMINAL

2.

PERFORM INITIALIZATION (See page

IN–20

)

Some systems need initialization when disconnecting the cable from the negative battery terminal.

BO4HM–01

H18897

Assist Grip

w/ Rear A/C:
Rear No. 6 Air Duct

Roof Console Box

Lens

Map Light

w/ Rear No. 2 seat:
Assist Grip

Dome Light

Lens

Rear Trim

Roof Headlining

w/ Rear No. 2 seat:
Rear Trim Cover

w/ Double Sun Visor:

Roof Headlining

Roof Console Box

w/o Rear No. 2 seat:
Service Hole Cover

w/ Rear No. 2 seat:
Assist Grip

w/o Rear No. 2 seat:
Service Hole Cover

Sun Visor

Roof Headlining

w/ Electro chrmic
inner rear view mirror:

Mirror Cover

w/ Sliding roof:

Sun Visor

Sun Visor

Holder

Holder

Assist Grip

Map Light

Lens

Sliding Roof Opening Trim

w/ Rear A/C:
Rear No.5  Air Duct

BO–98

–

BODY

ROOF HEADLINING

3651

ROOF HEADLINING

COMPONENTS

H18896

w/ Rear seat entertainment:

Sliding Roof Opening Trim

Roof Console Box

Roof Headlining

Multi Information Display

Display Panel

Lens

–

BODY

ROOF HEADLINING

BO–99

3652
