Toyota Sequoia (2005). Manual - part 789

SA17E–04

F14301

Stabilizer Bar

Bushing

Bracket

N·m (kgf·cm, ft·lbf) : Specified torque

Stabilizer Bar Link

37 (377, 27)

37 (377, 27)

Bushing

Bracket

Stabilizer Bar Link

69 (704, 51)

69 (704, 51)

69 (704, 51)

69 (704, 51)

–

SUSPENSION AND AXLE

REAR STABILIZER BAR

SA–149

3145

REAR STABILIZER BAR

COMPONENTS

SA17F–04

F14302

F14303

SA–150

–

SUSPENSION AND AXLE

REAR STABILIZER BAR

3146

REMOVAL

1.

REMOVE REAR WHEELS
Torque: 110 N·m (1,150 kgf·cm, 83 ft·lbf)

2.

SUPPORT REAR AXLE HOUSING WITH JACK

3.

REMOVE STABILIZER BAR LINKS

(a)

Remove the 2 nuts and stabilizer bar link.
Torque: 69 N·m (704 kgf·cm, 51 ft·lbf)

HINT:
If the ball joint stud turns together with the nut, use a hexagon
wrench to hold the stud.
(b)

Use the same procedure described above to the other
side.

4.

REMOVE STABILIZER BAR FROM REAR AXLE
HOUSING

(a)

Remove the 4 bolts and stabilizer bar with the bushings
and brackets.
Torque: 37 N·m (377 kgf·cm, 27 ft·lbf)

(b)

Remove the 2 brackets and 2 bushings from the stabilizer
bar.

SA24K–02

F14304

–

SUSPENSION AND AXLE

REAR STABILIZER BAR

SA–151

3147

INSPECTION

INSPECT STABILIZER BAR LINK
Rotate the ball joint stud in all directions.
If it does not move smoothly and freely, replace the stabilizer
link.

SA17G–03

SA–152

–

SUSPENSION AND AXLE

REAR STABILIZER BAR

3148

INSTALLATION

Installation is in the reverse order of removal (See page

SA–150

).
