DI1OE–19

Inspector’s name:

Customer’s Name

VIN

Licence Plate No.

Production Data

Odometer Reading

             /               /

km
mile

Weather Conditions
When Problem
Occurred

Frequency Problem Occurs

Weather

                              /                                /

 Once only

Brought in

Malfunction
System

Outdoor Temperature

 Fine



 Cloudy



Rainy



Snowy

 Various/Others

 Hot



Warm         Cool

 Cold (Approx.

°

F (

°

C))

 Constant          Sometimes (    times per     day, month)

 Key Unlock Warning System

Headlight and Taillight System (Light Auto Turn–off system, Daytime Running
Light System

 Stop Light System

 Automatic Light Control System



Illuminated Entry System

 Foglight System

 Wiper and Washer System

 Power Window Control System



Power Door Lock Control System

 Theft Deterrent System

 Wireless Door Lock Control System

 Others (Buzzer etc.)

 Auto Lock/Unlock System

BODY CONTROL SYSTEM Check Sheet

Remote Control Mirror System (w/ Driving Position Memory)

–

DIAGNOSTICS

BODY CONTROL SYSTEM

DI–1683

1877

CUSTOMER PROBLEM ANALYSIS CHECK

DID9A–01

DI–1684

–

DIAGNOSTICS

BODY CONTROL SYSTEM

1878

CUSTOMIZE PARAMETERS

HINT:
The following items can be customized.
NOTICE:

When the customer requests a change in a function, first make sure that customization of the
function(s) is/are possible.

Be sure to make a note of the current setting before customizing.

When troubleshooting a function, first make sure that the function is not set to OFF.

WIRELESS DOOR LOCK:

DISPLAY (ITEM)

DEFAULT

CONTENTS

SETTING

WIRELESS OPER

ON

Turns wireless door lock function ON/OFF.

ON/OFF

OPEN DOOR WARN

ON

Sounds buzzer for 10 seconds when door is not completely

closed and transmitter LOCK switch is pressed.

ON/OFF

AUTO LOCK DELAY

30S

Controls amount of time from when doors are unlocked until

they are locked by automatic lock function.

60S/30S

UNLOCK/2OPER

ON

When UNLOCK switch is pressed once, this function un–

locks only the designated door. When unlock switch is

pressed again within 3 seconds, all doors unlock. If setting is

OFF, pressing UNLOCK switch once unlocks all doors.

ON/OFF

LNT/LGT ON/UNLK

ON

Turns on room light when wireless door lock system is oper-

ated.

ON/OFF

ALARM FUNCTION

ON

Operates theft deterrent system when transmitter LOCK

(PANIC) switch is held for 3 seconds.

ON/OFF

AUTO LOCK

OFF

Locks doors when the vehicle speed reaches a certain level.

ON/OFF

UNLK/KEY TWICE

ON

Unlocks only driver’s door when driver’s door key cylinder is

turned to unlock once, and unlocks all doors when it is turned

to unlock twice. In OFF setting, unlocks all doors when the

cylinder is turned to unlock once.

ON/OFF

ALL UNLK/OPN–CL

OFF

Function that unlocks all doors when the driver door is

opened after turning the ignition switch off.

ON/OFF

UNLOCK/PARK

OFF

Unlocks doors when shift lever is moved to P position from

any position other than P while the ignition switch is ON.

ON/OFF

THEFT:

DISPLAY (ITEM)

DEFAULT

CONTENTS

SETTING

WARNING TIME

15S

Changes warning time for PASSIVE MODE.

5S/15S/27.5S/60S

PASSIVE MODE

OFF

Switches theft deterrent system from arming preparation

state to armed state 30 seconds after key is removed from

ignition key cylinder and driver side door is closed, even if

doors are not locked by wireless or door key lock operation.

ON/OFF

WARN BY GLS SEN

ON

Function that switches the alarm warning on/off when glass

breakage is detected.

ON/OFF

DOOR LOCK:

DISPLAY (ITEM)

DEFAULT

CONTENTS

SETTING

AUTO LOCK/SHIFT

ON

Locks doors when shift lever is moved from P to another

position.

ON/OFF

–

DIAGNOSTICS

BODY CONTROL SYSTEM

DI–1685

1879

ILLUMINATED ENTRY:

DISPLAY (ITEM)

DEFAULT

CONTENTS

SETTING

I/L ON/UNLOCK

ON

Illuminates interior light when ignition switch is turned from

ACC to LOCK position.

ON/OFF

LIGHTING TIME

15S

Changes lighting time after closing doors (light quickly fades

out when ignition switch is turned on).

15S/7.5S/30S

LIGHT CONTROL:

DISPLAY (ITEM)

DEFAULT

CONTENTS

SETTING

SENSITIVITY

NORMAL

Sensitivity adjustment is difficult to confirm. Check by driving

the customer’s vehicle.

NORMAL/DARK2/DARK1/

LIGHT1/LIGHT2

LIGHT OFF DELAY

30S

Keeps headlights on for a certain period of time after closing

all doors with ignition switch on, light control switch in HEAD

or AUTO position, and headlights on.

OFF/30S/60S/90S

DISP EX ON SEN

NORMAL

Changes brightness of lights such as combination meter

indicator light, A/C indicator lamp, and clock lamp.

NORMAL/DARK2/DARK1/

LIGHT1/LIGHT2

DISP OFF SEN

NORMAL

Changes brightness of lights such as combination meter

indicator light, A/C indicator lamp, and clock lamp.

NORMAL/DARK2/DARK1/

LIGHT1/LIGHT2

DI1OH–18

DI–1686

–

DIAGNOSTICS

BODY CONTROL SYSTEM

1880

PROBLEM SYMPTOMS TABLE

DOOR LOCK CONTROL

Symptom

Suspected Area

See page

Lock or unlock cannot be operated with door lock control switch.

1. Door lock control switch (Power source circuit)

                                                                  (Driver’s)

                                                           (Passenger’s)

2. Body ECU

DI–1788

DI–1826

IN–35

Door key linked function does not operate.

1. Door key lock and unlock switch circuit (Driver’s)

                                                         (Passenger’s)

2. Body ECU

DI–1794

DI–1832

IN–35

Key confinement prevention function does not operate.

1. Key unlock warning switch circuit

2. Body ECU

DI–1715

IN–35

Door lock function does not operate.

1. Door lock motor circuit

2. Body ECU

DI–1720

IN–35

THEFT DETERRENT SYSTEM

Symptom

Suspected Area

See page

No alerting condition is operated. (The system cannot be set.)

1. Security indicator circuit

2. Key unlock warning switch circuit

3. Courtesy light switch circuit

4. Door unlock detection switch circuit (Driver’s)

                                                    (Passenger’s)

5. Engine hood courtesy light switch circuit

6. Back door courtesy light switch circuit

7. Back door ECU

8. Body ECU

DI–1731

DI–1715

DI–1728

DI–1791

DI–1829

DI–1725

DI–1864

IN–35

IN–35

Cannot be canceled when IG is turned ON with a key.

1. Key unlock warning switch circuit

2. Ignition switch

3. Body ECU

DI–1715

BE–24

IN–35

Cannot be canceled when unlocking the back door with a key.

1. Back door ECU

2. Body ECU

IN–35

IN–35

Headlights do not light up as an alert function.

1. Headlight relay circuit

2. Body ECU

DI–1708

IN–35

Taillights do not light up as an alert function.

1. Taillight relay circuit

2. Body ECU

DI–1706

IN–35

Theft deterrent horn or vehicle horn does not sound.

1. Security horn circuit

2. Horn circuit

3. Body ECU

DI–1734

DI–1764

IN–35

During warning condition, cannot be canceled by unlocking the

door with a key.

1. Door key lock and unlock switch circuit (Driver’s)

                                                         (Passenger’s)

2. Body ECU

DI–1794

DI–1832

IN–35

During warning condition, cannot be canceled by unlocking the

door with a key. (transmitter)

1. Transmitter

2. Body ECU

BE–99

IN–35

During warning condition, cannot be canceled by turning the igni-

tion ON with a key.

1. Ignition switch

2. Key unlock warning switch circuit

3. Body ECU

BE–24

DI–1715

IN–35

The system operated for more than 60 seconds.

Body ECU

IN–35

Glass breakage sensor does not operate.

1. Glass breakage sensor circuit

2. Body ECU

DI–1774

IN–35
