92

2. Instrument cluster

Tachometer

Displays the engine speed in revolutions per minute.

Multi-information display

Presents the driver with a variety of driving-related data.

Speedometer

Fuel gauge

Trip meter reset knob

Switches the trip information.

Outside temperature

Odometer/trip meter/Stop & Start system operation time display*

Shift position and shift range

Displays the selected shift position or selected shift range. (

→P. 227)

Instrument panel light control button

Engine coolant temperature gauge

Displays the engine coolant temperature.

*

: If equipped

Gauge and meters

The displayed content may differ depending on the type of
meter.

1

2

3
4
5

6
7
8

9

10

93

2. Instrument cluster

2

Instrum

e

nt clus

ter

Switches between the trip meter
“A” and “B” displays. When the trip
meter is displayed, pressing and
holding the knob will reset the trip
meter.

The brightness of the instrument panel lights can be adjusted.

Pressing the button will adjust the
brightness of the instrument panel
lights.

The brightness level of the meters
when the surroundings are bright
(day mode) and dark (night mode)
can be adjusted individually. How-
ever, when in day mode, adjusting
the brightness level will also
change the brightness level of
night mode.

■

The meters and display illuminate when



Vehicles without a smart key system

The engine switch is in the “ON” position.



Vehicles with a smart key system

The engine switch is in IGNITION ON mode.

■

Outside temperature display
In the following situations, the correct outside temperature may not be dis-
played, or the display may take longer than normal to change:

●

When stopped, or driving at low speeds (less than 12 mph [20 km/h])

●

When the outside temperature has changed suddenly (at the entrance/exit
of a garage, tunnel, etc.)

■

Stop & Start system operation time (current) (if equipped)
This display will be displayed when the engine is stopped due to the opera-
tion of the Stop & Start system.

Changing the trip meter display

Instrument panel light control

94

2. Instrument cluster

NOTICE

■

To prevent damage to the engine and its components

●

Do not let the indicator needle of the tachometer enter the red zone, which
indicates the maximum engine speed.

●

The engine may be overheating if the engine coolant temperature gauge is
in the red zone (H). In this case, immediately stop the vehicle in a safe
place, and check the engine after it has cooled completely. (

→P. 644)

95

2. Instrument cluster

2

Instrum

e

nt clus

ter

Drive information

Select to display various drive
data. (

→P. 97)

Navigation system-

linked display (if
equipped)

Select to display the following navigation system-linked information.

• Route guidance
• Compass display (north-up display/heading-up display)

Audio system-linked display (if equipped)

Select to enable selection of an audio source or track on the meter
using the meter control switches.

Driving assist system information

Select to display the operational status of the following systems:

• Dynamic radar cruise control (

→P. 285)

• LDA (Lane Departure Alert with steering control) (

→P. 275)

Stop & Start system information (if equipped)

Select to display the operational status of the Stop & Start system.
(

→P. 297)

Warning message display

Select to display warning messages and measures to be taken if a
malfunction is detected. (

→P. 591)

Settings display

Select to change the meter display settings. (

→P. 99)

Multi-information display

Display contents
