84

1-2. Theft deterrent system

■

Triggering of the alarm
The alarm may be triggered in the following situations:
(Stopping the alarm deactivates the alarm system.)

■

Alarm-operated door lock
In the following cases, depending on the situation, the door may automatically
lock to prevent improper entry into the vehicle:

●

When a person remaining in the vehicle unlocks the door and the alarm is
activated.

●

While the alarm is activated, a person remaining in the vehicle unlocks the
door.

●

When recharging or replacing the battery.

●

A person inside the vehicle opens a door
or hood, or unlocks the vehicle using a
inside lock button.

●

The battery is recharged or replaced
when the vehicle is locked. (

→P. 642)

NOTICE

■

To ensure the system operates correctly
Do not modify or remove the system. If modified or removed, the proper
operation of the system cannot be guaranteed.

85

Instrument cluster

2

2. Instrument

cluster

Warning lights and

indicators .......................... 86

Gauge and meters .............. 92

Multi-information

display............................... 95

Eco Driving Indicator......... 102

Fuel consumption

information ...................... 103

86

2. Instrument cluster

The units used on the meters and some indicators may differ depending on
the target region.

Warning lights and indicators

The warning lights and indicators on the instrument cluster and
center panel inform the driver of the status of the vehicle’s vari-
ous systems.

For the purpose of explanation, the following illustration dis-
plays all warning lights and indicators illuminated.

87

2. Instrument cluster

2

Instrum

e

nt clus

ter

Warning lights inform the driver of malfunctions in the indicated vehi-
cle’s systems.

Warning lights

*

1

(U.S.A.)

Brake system warning
light (

→P. 581)

(Amber)

LDA (Lane Departure
Alert with steering con-
trol) indicator
(

→P. 583)

*

1

(Canada)

Brake system warning
light (

→P. 581)

*

1

Slip indicator (

→P. 582)

*

1

(U.S.A.)

Malfunction indicator
lamp (

→P. 581)

Low fuel level warning
light (

→P. 582)

*

1

(Canada)

Malfunction indicator
lamp (

→P. 581)

Driver’s and front pas-
senger’s seat belt
reminder light (

→P. 582)

*

1

SRS warning light
(

→P. 581)

*

4

Rear seat seat belt
reminder lights
(

→P. 582)

*

1

(U.S.A.)

ABS warning light
(

→P. 581)

*

2, 5

Stop & Start cancel indi-
cator



(

→P. 583)

*

1

(Canada)

ABS warning light
(

→P. 581)

*

1

Master warning light
(

→P. 584)

*

1

Electric power steering
system warning light
(

→P. 582)

*

1

Tire pressure warning
light (

→P. 584)

*

1, 3

PCS (Pre-Collision Sys-
tem) warning light
(

→P. 583)

*

1

(U.S.A)

Parking brake warning
light (

→P. 582)
