Fig. 174: Identifying Rear Differential Carrier Assembly Nuts And Washers 2. INSTALL REAR AXLE SHAFT LH a. Install the rear axle shaft LH (see INSTALLATION ). 3. INSTALL REAR AXLE SHAFT RH HINT: Use the same procedures described for the LH side. 4. INSTALL PROPELLER SHAFT ASSEMBLY a. Install the propeller shaft for 2WD (see INSTALLATION ). b. Install the propeller shaft for 4WD (see INSTALLATION ). 5. ADD DIFFERENTIAL OIL (see REPLACEMENT ) 6. INSTALL REAR WHEEL a. Install the rear wheels. Torque: for aluminum wheel 131 N*m (1336 kgf*cm, 97 ft.*lbf) for steel wheel 209 N*m (2131 kgf*cm, 154 ft.*lbf) FRONT DIFFERENTIAL CARRIER ASSEMBLY (FOR 4WD) COMPONENTS NOTE: Be careful not to damage the contact surfaces of the differential
2009 Toyota Tundra 2009 DRIVELINE/AXLES Differential - Tundra
|
