If a birthday or anniversary is approaching,
a message will be shown when the ignition
switch is turned to the “ON” position. This
function can be set to on or off by
“Reminder Screen”. For details, refer to
“General settings”

�

P221.

1. Touch

(HOME).

(Settings)

“General”

“Birthday List”

“Add”

6. Enter the name.
7.

“Next”

8. Enter the date.
9.

“OK”

Center Information Display (CID)

232

(235,1)

NOTE

A maximum of 5 birthdays can be
stored.

Anniversary List

The procedure for setting an anniversary is
the same as “Birthday List”

�

P232, except

that in step 4 “Anniversary List” is selected.

Driver Monitoring System (if
equipped)

The Driver Monitoring System settings can
be changed.
For setting method for the following menu
on the Driver Monitoring System, refer to
“ON/OFF setting”

�

P231.

Driver Monitoring System

User Recognition

Automatically Retract Seat on Entry

Repeat Facial Scan:

1. Touch

(HOME).

(Settings)

“Car”

“Driver Monitoring System”

“Repeat Facial Scan”

“OK”

7. While seated in the driver’s seat, face
forward and wait for a few moments. When
the scan is completed, the completion
screen is displayed on the combination
meter (color LCD).

Register User:

1. Adjust the seat position, outside mirror
angle, and reverse tilt-down outside mirror
angle so that you are seated in the correct
driving posture.

NOTE

Start the user registration after ad-

justing the seat position, outside mirror
angle, and reverse tilt-down outside
mirror angle. If they are adjusted during
user registration, it may be disrupted.

Refer to “Power Seat”

P32 or “Out-

If the ignition switch is turned to the

“OFF” position before user registration
is complete, the information of the
adjusted seat position, outside mirror
angles, and reverse tilt-down outside
mirror angle will not be saved.

2. Touch

(HOME).

(Settings)

“Car”

“Driver Monitoring System”

“Register User”

7. Select the preferred user from the list.

– CONTINUED –

Center Information Display (CID)

233

Instruments

and

Controls

(236,1)

“Set”

9. While seated in the driver’s seat, face
forward and wait for a few moments.

When the screen changes, the registration
of the facial scan is completed.

Forward direction

Display direction

Face forward.

Do not lower your chin.

Face the display.

*: Display

NOTE

If user registration cannot be per-

formed, turn your face forward as
shown in the illustration, then turn to
the display.

There are some cases where user

registration cannot be registered prop-
erly. In those cases, refer to “Driver
Monitoring System”

�

P427.

If “Unable to register. Try again.”

appears, repeat the procedure begin-
ning from step 5.

10. Enter the name.
11.

“Next”

Center Information Display (CID)

234

(237,1)

12. Select the preferred icon.
13.

“Set”

NOTE

An existing user can be overwritten

by selecting a registered number. When
a user is registered by overwriting, the
individual fuel economy data is reset.

When “User Recognition” is set to

OFF, user registration cannot be se-
lected.

Update Seat and Mirror Position:

1. Touch

(HOME).

(Settings)

“Car”

“Driver Monitoring System”

“Update Seat and Mirror Position”

“Set”

NOTE

Start the user registration after ad-

justing the seat position, outside mirror
angle, and reverse tilt-down outside
mirror angle. If they are adjusted during
user registration, it may be disrupted.
Refer to “Power Seat”

P32 or “Out-

If the ignition switch is turned to the

“OFF” position before user registration

is complete, the information of the
adjusted seat position, outside mirror
angles, and reverse tilt-down outside
mirror angle will not be saved.

Delete Driver Position:

1. Touch

(HOME).

(Settings)

“Car”

“Driver Monitoring System”

“Delete Driver Position”

“Yes”

– CONTINUED –

Center Information Display (CID)

235

Instruments

and

Controls

(238,1)

Delete User:

1. Touch

(HOME).

(Settings)

“Car”

“Driver Monitoring System”

“Delete User”

6. Select the preferred user from the list.

“Yes”

Delete All Users:

1. Touch

(HOME).

(Settings)

“Car”

“Driver Monitoring System”

“Delete All Users”

“Yes”

Center Information Display (CID)

236

(239,1)

Car information screen

1. Touch

(HOME) to display the top

menu.

(Car Info)

Driving Statistics screen

Driving Statistics

Steering angle

Running condition

Vehicle posture

Telltale screen

This screen displays the driving status of
the vehicle and the operation status func-
tions. For functions that are operating, the
indicator will illuminate or flash.

NOTE

The vehicle posture indication may

differ from the actual vehicle posture.

F o r O u t b a c k / S u b a r u O u t b a c k

Wilderness, when X-MODE has been
turned on, the screen of the center
information display will be changed to
the X-MODE screen.

The vehicle posture angle varies not

only due to the angle of the road
surface, but also due to the vehicle tilt
caused by the occupants, cargo, and
acceleration or deceleration.

Maintenance screen

Maintenance reminders can be set.

Engine Oil change reminder:

1. Touch “Maintenance” from the 2nd
menu in the car info screen.
2.

(Engine Oil)

3. Select “Notification Date” or “Notifica-
tion Distance” of the reminder.
4.

“Set”

– CONTINUED –

Center Information Display (CID)

237

Instruments

and

Controls

(240,1)

Oil Filter change reminder:

The setting procedure is the same as the
“Engine Oil” reminder, but touch the “Oil
Filter” item in step 2.

Tires rotation reminder:

The setting procedure is the same as the
“Engine Oil” reminder, but touch the “Tires”
item in step 2.

Maintenance Schedule setting:

The setting procedure is the same as the
“Engine Oil” reminder, but touch the
“Maintenance Schedule” item in step 2.

NOTE

Touch “Reset” to reset each setting.

Touch “Update” to revert to the

default value.

Dual 7.0-Inch Display Models
(If Equipped)

NOTE

For 11.6-inch display models, refer to
“11.6-Inch Display Models”

�

P214.

Main screens

Upper display

Lower display

HOME button (Refer to “HOME button”

�

P238.)

Status bar (Refer to “Status bar”

�

P238.)

Upper main screen (Refer to “Setting of
the upper display”

�

P239.)

Lower main screen (Refer to “Setting of
the lower display”

�

P243.)

Climate control screen (Refer to “Climate
control screen”

�

P239.)

While the ignition switch is in the “ACC” or
“ON” position, the touch panel will activate.

HOME button

Press

(HOME) to display the top menu.

Status bar

The driver profiles icon, outside tempera-
ture and clock are shown on the display.

NOTE

The outside temperature indicator

shows the temperature around the
sensor. However, the temperature may
not be indicated correctly or the update
may be delayed in the following condi-
tions.

– While parking or driving at low
speeds
– When the outside temperature
changes suddenly (example: when
going in and out of an underground
parking area or when passing
through a tunnel)
– When starting the engine after
being parked for a certain period of
time

Center Information Display (CID)

238

(241,1)

You can set the temperature units to

be displayed in Celsius (

C) or Fahren-

heit (

F). For details, refer to “Vehicle

setting icons”

�

P246.

The clock can be shown in either 12-

hour display or 24-hour display. For
details about the setting, refer to
“Clock”

�

P252.

Touch the clock on the status bar to

display the clock setting screen. Refer
to “Clock”

�

P252.

Upper display

For details about items, refer to “Setting of
the upper display”

�

P239.

For details about the following menu, refer
to the separate navigation/audio Owner’s
Manual.

Radio

Media

Phone

Apps

SUBARU STARLINK

Add Shortcut

Lower display

For details about the setting items, refer to
“Setting of the lower display”

�

P243.

If this screen changes to the climate
control screen, refer to “Dual 7.0-Inch
Display Models”

�

P304.

Climate control screen

Driver’s seat heater icon (if equipped)

Set temperature indicator

Climate control mode

Airflow mode

Air inlet selection

Front passenger’s seat heater icon (if
equipped)

Customizable icon

Fan speed indicator

Climate control On/Off icon

When operating the climate control sys-
tem, the main screen switches to the
climate control screen. For details about
climate control operation, refer to “Climate
Control Panel”

�

P303.

Setting of the upper display

In this Owner’s Manual, the settings of the
“General” menu will be explained. For
details about other items, refer to the
separate navigation/audio Owner’s Man-
ual.

General settings

The “General” menu is used to set the
display, language and time.
1. Press

(HOME).

2. Touch

(Settings).

“General”

4. Select the preferred menu.

– CONTINUED –

Center Information Display (CID)

239

Instruments

and

Controls

(242,1)

The setting adjustments to the following items can be manually changed to meet your personal requirements.

Item

Available settings

Page reference

for the vehicle

system opera-

tion

Page reference

for the setting

procedure

1st menu

2nd menu

3rd menu

General

Clock

Time Setting

Sync With Phone/Manual

252

Clock Format

12H/24H

253

Display

Display Off

Turn the screen off.

—

249

Brightness Dial

ON/OFF

—

249

Brightness/Contrast

Set and adjust the brightness
and contrast of the screen dis-
play and camera display.

—

249

Reminder Screen

Maintenance

ON/OFF

213

249

Birthday

ON/OFF

249

Anniversary

ON/OFF

249

Valet Mode

Passcode Setting*

Keyboard: Enter New Pass-
code

255

231

Activate Valet Mode

Keyboard: Enter Your Pass-
code

Change Passcode

Keyboard: Change Passcode

Meter Screen

Gauge Initial Movement

ON/OFF

175

249

Meter Information Screen

Eco Gauge/OUT TEMP/Clock/
Gas Range

205

249

Center Information Display (CID)

240

(243,1)

Item

Available settings

Page reference

for the vehicle

system opera-

tion

Page reference

for the setting

procedure

1st menu

2nd menu

3rd menu

General

Camera

Rear Camera Delay Control

ON/OFF

403

249

Steering Angle Lines

ON/OFF

405

249

Climate Control

Customize Climate Button

A/C/MAX A/C/AUTO/Recircu-
lation

310

249

Temperature Unit

—

238

249

Language

—

English/Français/Español

203 and 212

249

Tire Pressure Units*

—

kPa/PSi

208

249

Home Screen Shortcuts

—

ON/OFF

249

Welcome Screen

—

ON/OFF

205

249

Goodbye Screen

—

ON/OFF

205

249

Birthday List

—

Set a birthday.

213

250

Anniversary List

—

Set an anniversary day.

213

250

SUBARU STARLINK Apps Re-
covery

—

OK/Cancel

—

SUBARU STARLINK Auto
Connect

—

ON/OFF

Factory Data Reset

—

Reset/Cancel

– CONTINUED –

Center Information Display (CID)

241

Instruments

and

Controls

(244,1)

Item

Available settings

Page reference

for the vehicle

system opera-

tion

Page reference

for the setting

procedure

1st menu

2nd menu

3rd menu

General

System Information

—

Free/Open Source Software
Information

—

*1: Displayed until valet mode is set.
*2: If equipped
*3: For details about the audio and navigation system, refer to the Owner’s Manual supplement for the audio and navigation system.

NOTE

Touch

to display the explanation of the items.

Center Information Display (CID)

242
