Subaru Outback (2019 year). Instruction

(218,1)

北米Model "A2550BE-A" EDITED: 2018/ 5/ 9

Indicator light

The indicator light located on the combina-
tion meter will illuminate when the front fog
lights are on.

Wiper and washer

WARNING

In freezing weather, do not use the
windshield washer until the wind-
shield is sufficiently warmed by the
defroster.

Otherwise the washer fluid can
freeze on the windshield, blocking
your view.

CAUTION

Do not operate the washer con-

tinuously for more than 10 sec-
onds, or when the washer fluid
tank is empty. This may cause
overheating of the washer motor.
Check the washer fluid level fre-
quently, such as at fuel stops.

Do not operate the wipers when

the windshield or rear window is
dry. This may scratch the glass,
damage the blade rubbers and
might cause the wiper motor to
fail. Before operating the wiper
on a dry windshield or rear win-
dow, always use the windshield
washer.

In freezing weather, be sure that

the blade rubbers are not frozen
to the windshield or rear window
before switching on the wipers.
Attempting to operate the wiper
with the blade rubbers frozen to
the window glass could cause
not only the blade rubbers to be
damaged but also might cause
the wiper motor to fail. If the blade
rubbers are frozen to the window
glass, be sure to operate the
defroster, windshield wiper dei-
cer (if equipped) or rear window
defogger before turning on the
wiper.

If the wipers stop during opera-

tion because of ice or some other
obstruction on the window, this
might cause the wiper motor to
fail even if the wiper switch is
t u r n e d o f f . I f t h i s o c c u r s ,
promptly stop the vehicle in a
safe location, turn the ignition
switch to the “LOCK”/“OFF” po-
sition and clean the window glass
to allow proper wiper operation.

Use clean water if windshield

washer fluid is unavailable. In
areas where water freezes in
winter, use SUBARU Windshield
Washer Fluid or the equivalent.

Instruments and controls/Wiper and washer

3-60

(219,1)

北米Model "A2550BE-A" EDITED: 2018/ 5/ 9

Refer to “Windshield washer
fluid” F11-31.

Also, when driving the vehicle
when there are freezing tempera-
tures, use non-freezing type wi-
per blades.

Do not clean the wiper blades

with gasoline or a solvent, such
as paint thinner or benzine. This
will cause deterioration of the
wiper blades.

NOTE

The windshield wiper motor is pro-

tected against overloads by a circuit
breaker. If the motor operates continu-
ously under an unusually heavy load,
the circuit breaker may trip to stop the
motor temporarily. If this happens, park
your vehicle in a safe location, turn off
the wiper switch, and wait for approxi-
mately 10 minutes. The circuit breaker
will reset itself, and the wipers will
again operate normally.
.

Clean your blade rubbers and win-

dow glass periodically with a washer
solution to prevent streaking, and to
remove accumulations of road salt or
road film. Operate the windshield
washer for at least 1 second so that
washer solution will be sprinkled all

over the windshield or rear window.
.

Grease, wax, insects or other mate-

rial on the windshield or the blade
rubbers results in jerky wiper operation
and streaking on the glass. If you
cannot remove those streaks after
operating the washer or if the wiper
operation is jerky, clean the outer sur-
face of the windshield or rear window
and the blade rubbers using a sponge
or soft cloth with a neutral detergent or
mild abrasive cleaner. After cleaning,
rinse the window glass and blade
rubbers with clean water. The glass is
clean if no beads form on the glass
when you rinse with water.
.

If you cannot eliminate the streaking

even after following this procedure,
replace the wiper blades (or blade
rubbers) with new ones. For replace-
ment instructions, refer to “Replace-
ment of wiper blades” F11-32.

Windshield wiper and washer
switches

The wiper operates only when the ignition
switch is in the “ON” position.

Windshield wipers

: Mist (for a single wipe)

: Off

: Intermittent

: Low speed

: High speed

To turn the wipers on, push the wiper
control lever down.

To turn the wipers off, return the lever to
the “ ” position.

– CONTINUED –

Instruments and controls/Wiper and washer

3-61

(220,1)

北米Model "A2550BE-A" EDITED: 2018/ 5/ 9

For a single wipe of the wipers, push the
lever up. The wipers operate until you
release the lever.

Wiper intermittent time control

When the wiper switch is in the “

”

position, turn the dial to adjust the operat-
ing interval of the wiper. The operating
interval can be adjusted in several steps
from the shortest interval to the longest.

Windshield washer

To wash the windshield, pull the wiper
control lever toward you. The washer fluid
sprays until you release the lever. The
wipers operate while you pull the lever.

Windshield washer fluid warning light

NOTE

The windshield washer fluid warning
light appears when the washer fluid
level in the tank has dropped to the
lower limit. If the warning light appears,
refill the tank with fluid. For the tank
refilling method, refer to “Windshield
washer fluid” F11-31.

Instruments and controls/Wiper and washer

3-62

(221,1)

北米Model "A2550BE-A" EDITED: 2018/ 5/ 9

Rear window wiper and
washer switch (Outback)

Washer (accompanied by wiper op-
eration)

: Continuous

: Intermittent

: Off

Washer (accompanied by wiper op-
eration)

Rear wiper

To turn the rear wiper on, turn the knob
switch upward.
To turn the wiper off, return the knob switch
to the “ ” position.

With the switch turned to the “

” position,

the rear wiper will operate intermittently at
intervals corresponding to the vehicle
speed. In this position, when you move
the select lever to the “R” position, the rear
wiper will switch to continuous operation.
When you move the select lever from the
“R” (reverse) position to another position,
the rear wiper will return to intermittent
operation.

Reverse gear interlocked rear wiper:
Even if the rear wiper switch is in the off
“ ” position, if the front windshield wiper is
operating continuously, the rear wiper will
operate intermittently when you move the
select lever to the “R” (reverse) position.

The factory setting (default setting) of the
reverse gear interlocked rear wiper is as
follows.
.

U.S.-spec. models: Non-operational

Other models: Operational

This setting can be changed by a SUBARU
dealer. Consult your SUBARU dealer for
details.

CAUTION

Do not attach anything that disturbs
the rear wiper operation on the rear
gate. Doing so may damage the rear
wiper when it operates.

Washer

To wash the rear window while the rear
wiper is operating, turn the knob switch
upward to the “

” position. The washer

fluid sprays until you release the knob.

To wash the rear window when the rear
wiper is not in use, turn the knob switch
downward to the “

” position. The washer

fluid sprays and the wiper operates until
you release the knob.

NOTE

When the amount of washer fluid is
getting low, the rear washer fluid will
first be stopped. This means that the
amount of washer fluid is low, and it
should be added immediately.

Instruments and controls/Wiper and washer

3-63

(222,1)

北米Model "A2550BE-A" EDITED: 2018/ 5/ 9

Defogger and deicer

Rear window defogger

Outside mirror defogger (if equipped)

Windshield wiper deicer (if equipped)

The defogger and deicer system is acti-

vated only when the ignition switch is in the
“ON” position.

Control switch (type A)
1)

Rear window defogger button

Control switch (type B)
1)

Rear window and outside mirror defogger
button

To activate the defogger and deicer sys-
tem, press the control switch. The rear
window defogger, outside mirror defogger
and windshield wiper deicer are activated
simultaneously. The indicator light on the
control switch illuminates while the defog-
ger and deicer system is activated.
To turn them off, press the control switch
again. They also turn off when the ignition
switch is turned to the “ACC” or “LOCK”/
“OFF” position.

The defogger and deicer system will
automatically shut off after approximately
15 minutes. If the rear window and outside
mirrors have been cleared and the wind-
shield wiper blade rubbers have been

Instruments and controls/Defogger and deicer

3-64

(223,1)

北米Model "A2550BE-A" EDITED: 2018/ 5/ 9

deiced completely before that time, press
the control switch to turn them off. If
defrosting, defogging or deicing is not
complete, you have to press the control
switch to turn them on again.

It is possible to set the defogger and deicer
system for the continuous operation mode
by operating the combination meter dis-
play. For details, refer to “Defogger” F3-
47.

CAUTION

To prevent the battery from being

discharged, do not operate the
defogger and deicer system con-
tinuously for any longer than
necessary.

Do not use sharp instruments or

window cleaner containing abra-
sives to clean the inner surface of
the rear window. They may da-
mage the conductors printed on
the window.

NOTE

Turn on the defogger and deicer

system if the wipers are frozen to the
windshield.
.

If the windshield is covered with

snow, remove the snow so that the

windshield wiper deicer works effec-
tively.
.

While the defogger and deicer sys-

tem is in the continuous operation
mode:

– If the vehicle speed remains at 9
mph (15 km/h) or lower for 15
minutes, the windshield wiper dei-
cer system automatically stops op-
erating. However, the rear window
defogger system and outside mirror
defogger system maintain continu-
ous operation in this condition.
– If the vehicle battery voltage
drops below the permissible level,
continuous operation of the defog-
ger system and deicer system is
canceled and the system stops
operating.

Mirrors

Always check that the inside and outside
mirrors are properly adjusted before you
start driving.

Inside mirror (without auto-
dimming function) (if
equipped)

Normal position

Anti-glare position

Push the tab on the mirror for normal use.
To reduce glare from the headlights of the
vehicle behind you, pull the tab to the anti-
glare position.

– CONTINUED –

Instruments and controls/Mirrors

3-65

(224,1)

北米Model "A2550BE-A" EDITED: 2018/ 5/ 9

Auto-dimming mirror/com-
pass with HomeLink

(U.S.-

spec. models without
EyeSight system - if
equipped)

HomeLink

button 1

HomeLink

button 2

LED

HomeLink

button 3

Sensor

Automatic dimming on/off button

Compass display button

Compass display

The auto-dimming mirror has an anti-glare
feature which automatically reduces glare
coming from headlights of vehicles behind
you. It also contains a built-in compass and
HomeLink

wireless control system.

By pressing the automatic dimming on/

off button, the automatic dimming function
is toggled on or off. When the automatic
dimming function is on, the LED indicator
will illuminate.
Even with the mirror in the automatic
dimming mode, the mirror surface turns
bright if the transmission is shifted into
reverse. This is to ensure good rearward
visibility during reversing.
.

By pressing the compass display but-

ton, the compass display is toggled on or
off. When the compass is on, an illumi-
nated compass reading will appear in the
upper right corner of the mirror.

When cleaning the mirror, use a paper
towel or similar material dampened with
glass cleaner. Do not spray glass cleaner
directly on the mirror as that may cause the
liquid cleaner to enter the mirror housing
and damage the mirror.

Photosensors

The mirror has a photosensor attached on
both the front and back sides. During
nighttime driving, these sensors detect
distracting glare from vehicle headlights
behind you and automatically dim the
mirror to eliminate glare and preserve your
vision. For this reason, use care not to
cover the sensors with stickers, or other
similar items. Periodically wipe the sen-
sors clean using a piece of dry soft cotton
cloth or an applicator.

Instruments and controls/Mirrors

3-66

(225,1)

北米Model "A2550BE-A" EDITED: 2018/ 5/ 9

Compass zone adjustment

Compass calibration zones

1. Refer to the “Compass calibration
zones” map shown above to verify that
the compass zone setting is correct for
your geographical location.
2. Press and hold the compass display
button for 3 seconds until the zone selec-
tion comes up (a number will be displayed
in the mirror compass window).
3. Press the compass display button
repeatedly until the correct zone setting
for your location is displayed.
4. Releasing the button for 5 seconds will
exit the zone setting mode.

Compass calibration

1. If a “C” is displayed in the compass
window, the compass needs to be cali-
brated.
2. Drive the vehicle in a circle at 5 mph (8
km/h) or less until the display reads a
direction.
3. You can also calibrate the compass by
driving your vehicle on your everyday
routine. The compass will be calibrated
once it has tracked a complete circle.
4. To recalibrate your compass, push and
hold the compass display button for 9
seconds until a “C” appears in the com-
pass window.
5. Calibrate the compass according to
step 2 or step 3.

HomeLink

Wireless Control Sys-

tem

The HomeLink

Wireless Control System

can be used to activate remote control
devices such as gate operators, garage
door openers, door locks, home lighting
and security systems.

There are three HomeLink

buttons on the

mirror, each of which can be programmed
for operation of one desired device. For
details on the device types which can be
operated by this system, consult the
HomeLink

website at:

www.homelink.com or call 1-800-355-
3515.

U.S.-spec. models

CAUTION

FCC WARNING

Changes or modifications not ex-
pressly approved by the party re-
sponsible for compliance could void
the user’s authority to operate the
equipment.

This device complies with part 15 of the
FCC Rules. Operation is subject to the
following two conditions: (1) This de-
vice may not cause harmful interfer-
ence, and (2) this device must accept
any interference received, including
interference that may cause undesired
operation.

– CONTINUED –

Instruments and controls/Mirrors

3-67

(226,1)

北米Model "A2550BE-A" EDITED: 2018/ 5/ 9

Canada-spec. models

HomeLink

and the HomeLink

house are

registered trademarks of Gentex Corpora-
tion.

WARNING

W h e n

p r o g r a m m i n g

t h e

HomeLink

Wireless Control Sys-

tem, you may be operating a
garage door opener or other
device. Make sure that people
and objects are out of the way of
the garage door or other device
to prevent potential harm or da-
mage.

Do not use the HomeLink

Wire-

less Control System with a gar-
age door opener that lacks the
safety stop and reverse feature
as required by applicable safety
standards. A garage door opener
which cannot detect an object,
signaling the door to stop and
reverse, does not meet these
safety standards. Using a garage
door opener without these fea-
tures increases risk of serious
injury or death. For more infor-
mation, consult the HomeLink

website at www.homelink.com or
call 1-800-355-3515.

CAUTION

When programming the HomeLink

Wireless Control System to operate
a garage door opener or an entrance
gate, unplug the device’s motor from
the outlet during programming to
prevent motor burnout.

NOTE

After programming your HomeLink

Wireless Control System for the de-
sired devices, retain the hand-held
transmitters for further programming
or device testing in the event of a
problem.
.

It is recommended that you insert a

new battery in the hand-held transmit-
ter of a device to ensure correct
programming.

Garage door opener program-
ming in the U.S.A.

NOTE

When programming the HomeLink

Wireless Control System for a garage
door opener, it is suggested that you
park the vehicle outside the garage.

1. Unplug the motor of the garage door
opener from the outlet.

Instruments and controls/Mirrors

3-68

(227,1)

北米Model "A2550BE-A" EDITED: 2018/ 5/ 9

NOTE

If any of the HomeLink

buttons are

already programmed for other devices,
skip step 2 because it clears the
memory of all three buttons.

HomeLink

button 1

HomeLink

button 2

HomeLink

button 3

2. Press and hold the two outer
HomeLink

buttons (button 1 and button

3) until the indicator light begins to flash
(after approximately 10 seconds). Then
release both buttons.
3. Hold the end of the garage door open-
er’s hand-held transmitter between 1 and
3 inches (25 and 76 mm) away from the
HomeLink

button you wish to program.

4. Simultaneously press and hold both

the hand-held transmitter button and the
desired HomeLink

button. DO NOT re-

lease the buttons until step 5 has been
completed.

NOTE

Some gate operators and garage door
openers may require you to replace this
programming step 4 with procedures in
“Programming for entrance gates and
garage door openers in Canada” F3-
70.

5. Hold down both buttons until the
HomeLink

indicator light flashes, first

slowly then rapidly. When the indicator
light flashes rapidly, both buttons may be
released. (The rapidly flashing light indi-
cates successful programming of the new
frequency signal.)
6. Press and hold the programmed button
and check the HomeLink

indicator light. If

the indicator light stays on continuously,
your garage door should activate and the
programming is completed.

If the indicator light flashes rapidly for 2
seconds and then stays on continuously,
your garage door opener may be protected
by a rolling code feature. In this case you
need to perform the additional steps that
are described in “Programming rolling-
code-protected garage door openers in

the U.S.A.” F3-69.

Programming rolling-code-pro-
tected garage door openers in
the U.S.A.

If your garage door opener has a rolling
code feature, program the HomeLink

Wireless Control System for it by following
steps 1 through 5 in “Garage door opener
programming in the U.S.A.” F3-68. Then
continue with the following steps.

NOTE

The assistance of a second person may
make the programming quicker and
easier.

1. Locate the training button on the
garage door opener motor head unit. The
exact location and color of the button may

– CONTINUED –

Instruments and controls/Mirrors

3-69

(228,1)

北米Model "A2550BE-A" EDITED: 2018/ 5/ 9

vary by brand of garage door opener. If it is
difficult to locate the training button, refer
to your garage door opener’s instruction
manual.

Training button

2. Press the training button on the garage
door opener motor head unit (which
activates the “training light” on the unit).
Proceed to step 3 within 30 seconds.
3. Inside the vehicle, firmly press, hold for
2 seconds and release the HomeLink

button that was programmed in the pre-
vious section. Press and release the
button a second time to complete the
programming procedure.

NOTE

Some garage door openers may require
you to do the above press-hold-release
sequence a third time to complete the
programming.

4. The garage door opener should now
recognize the HomeLink

Wireless Control

System and your garage door opener
should activate when the HomeLink

button is pressed.

Programming for entrance gates
and garage door openers in
Canada

1. Unplug the motor of the entrance gate
or garage door opener from the outlet.

NOTE

If any of the HomeLink

buttons are

already programmed for other devices,
skip step 2 because it clears the
memory of all three buttons.

HomeLink

button 1

HomeLink

button 2

HomeLink

button 3

2. Press and hold the two outer
HomeLink

buttons (button 1 and button

3) until the HomeLink

indicator light

begins to flash (after approximately 10
seconds). Then release both buttons.
3. Hold the end of the entrance gate’s/
garage door opener’s hand-held transmit-
ter between 1 and 3 inches (25 and 76
mm) away from the HomeLink

button you

wish to program.
4. Press and hold the desired HomeLink

button.
5. Press and release (“cycle”) the hand-
held transmitter button every 2 seconds
until step 6 is complete.

Instruments and controls/Mirrors

3-70

(229,1)

北米Model "A2550BE-A" EDITED: 2018/ 5/ 9

6. When the indicator light flashes slowly
and then rapidly after several seconds,
release both buttons.
7. Plug the motor of the entrance gate/
garage door opener to the outlet.
8. Test your entrance gate/garage door
opener by pressing the programmed
HomeLink

button.

Operating the HomeLink

Wire-

less Control System

Once programmed, the HomeLink

Wire-

less Control System can be used to
remote-control the devices to which its
buttons are programmed. To activate a
device, simply press the appropriate but-
ton. The indicator light illuminates, indicat-
ing that the signal is being transmitted.

Programming other devices

To program other devices such as door
locks, home lighting and security systems,
contact HomeLink

at www.homelink.com

or call 1-800-355-3515.

R e p r o g r a m m i n g a s i n g l e
HomeLink

button

1. Press and hold the HomeLink

button

you wish to reprogram. DO NOT release
the button until step 4 has been completed.
2. When the HomeLink

indicator light

begins to flash slowly (after approximately

20 seconds), position the hand-held trans-
mitter of the device between 1 to 3 inches
(25 to 76 mm) away from the HomeLink

button you wish to program.
3. Press and hold the hand-held trans-
mitter button. The HomeLink

indicator

light will flash, first slowly and then rapidly.
4. When the indicator light begins to flash
rapidly, release both buttons.

The programming for the previous device
is now erased and the new device can be
operated by pressing the HomeLink

button.

Erasing HomeLink

button mem-

ory

NOTE

Performing this procedure erases

the memory of all the preprogrammed
buttons simultaneously. The memory
of individual buttons cannot be erased.
.

It is recommended that upon the sale

of the vehicle, the memory of all
programmed HomeLink

buttons be

erased for security purposes.

HomeLink

button 1

HomeLink

button 2

HomeLink

button 3

1. Press and hold the two outer buttons
(button 1 and button 3) until the indicator
light begins to flash (after approximately
20 seconds).
2. Release both buttons.

In case a problem occurs

If you cannot activate a device using
the corresponding HomeLink

button

after programming, contact HomeLink

at www.homelink.com or call 1-800-355-
3515 for assistance.

– CONTINUED –

Instruments and controls/Mirrors

3-71

(230,1)

北米Model "A2550BE-A" EDITED: 2018/ 5/ 9

Auto-dimming mirror with
HomeLink

(except U.S.-

spec. models - if equipped)

HomeLink

button 1

HomeLink

button 2

LED

HomeLink

button 3

Sensor

Automatic dimming on button

Automatic dimming off button

The auto-dimming mirror has an anti-glare
feature which automatically reduces glare
coming from headlights of vehicles behind
you. It also contains a HomeLink

wireless

control system.

By pressing the automatic dimming on/off
button, the automatic dimming function is
turned on or off. When the automatic

dimming function is on, the LED indicator
will illuminate.
Even with the mirror in the automatic
dimming mode, the mirror surface turns
bright if the select lever is shifted into the
“R” (reverse) position. This is to ensure
good rearward visibility during reversing.

Photosensors

The mirror has a photosensor attached on
both the front and back sides. During
nighttime driving, these sensors detect
distracting glare from vehicle headlights

behind you and automatically dim the
mirror to eliminate glare and preserve your
vision. For this reason, use care not to
cover the sensors with stickers, or other
similar items. Periodically wipe the sen-
sors clean using a piece of dry soft cotton
cloth or an applicator.

HomeLink

Wireless Control Sys-

tem

The HomeLink

Wireless Control System

can be used to activate remote control
devices such as gate operators, garage
door openers, door locks, home lighting
and security systems.

There are three HomeLink

buttons on the

mirror, each of which can be programmed
for operation of one desired device. For
details on the device types which can be
operated by this system, consult the
HomeLink

website at:

www.homelink.com or call 1-800-355-
3515.

Instruments and controls/Mirrors

3-72

(231,1)

北米Model "A2550BE-A" EDITED: 2018/ 5/ 9

U.S.-spec. models

CAUTION

FCC WARNING

Changes or modifications not ex-
pressly approved by the party re-
sponsible for compliance could void
the user’s authority to operate the
equipment.

Canada-spec. models

HomeLink

and the HomeLink

house are

registered trademarks of Gentex Corpora-
tion.

WARNING

W h e n

p r o g r a m m i n g

t h e

HomeLink

Wireless Control Sys-

tem, you may be operating a
garage door opener or other
device. Make sure that people
and objects are out of the way of
the garage door or other device
to prevent potential harm or da-
mage.

Do not use the HomeLink

Wire-

website at www.homelink.com or
call 1-800-355-3515.

– CONTINUED –

Instruments and controls/Mirrors

3-73

(232,1)

北米Model "A2550BE-A" EDITED: 2018/ 5/ 9

CAUTION

When programming the HomeLink

Wireless Control System to operate
a garage door opener or an entrance
gate, unplug the device’s motor from
the outlet during programming to
prevent motor burnout.

NOTE

After programming your HomeLink

Wireless Control System for the de-
sired devices, retain the hand-held
transmitters for further programming
or device testing in the event of a
problem.
.

It is recommended that you insert a

new battery in the hand-held transmit-
ter of a device to ensure correct
programming.

Garage door opener program-
ming in the U.S.A.

NOTE

When programming the HomeLink

Wireless Control System for a garage
door opener, it is suggested that you
park the vehicle outside the garage.

1. Unplug the motor of the garage door
opener from the outlet.

NOTE

If any of the HomeLink

buttons are

already programmed for other devices,
skip step 2 because it clears the
memory of all three buttons.

HomeLink

button 1

HomeLink

button 2

HomeLink

button 3

2. Press and hold the two outer
HomeLink

buttons (button 1 and button

3) until the indicator light begins to flash
(after approximately 20 seconds). Then
release both buttons.
3. Hold the end of the garage door open-
er’s hand-held transmitter between 1 and
3 inches (25 and 76 mm) away from the
HomeLink

button you wish to program.

4. Simultaneously press and hold both

the hand-held transmitter button and the
desired HomeLink

button. DO NOT re-

lease the buttons until step 5 has been
completed.

NOTE

Some gate operators and garage door
openers may require you to replace this
programming step 4 with procedures in
“Programming for entrance gates and
garage door openers in Canada” F3-
75.

5. Hold down both buttons until the
HomeLink

indicator light flashes, first

indicator light. If

the indicator light stays on continuously,
your garage door should activate and the
programming is completed.

Instruments and controls/Mirrors

3-74

(233,1)

北米Model "A2550BE-A" EDITED: 2018/ 5/ 9

the U.S.A.” F3-75.

Programming rolling-code-pro-
tected garage door openers in
the U.S.A.

If your garage door opener has a rolling
code feature, program the HomeLink

Wireless Control System for it by following
steps 1 through 5 in “Garage door opener
programming in the U.S.A.” F3-74. Then
continue with the following steps.

NOTE

The assistance of a second person may
make the programming quicker and
easier.

1. Locate the training button on the
garage door opener motor head unit. The
exact location and color of the button may

vary by brand of garage door opener. If it is
difficult to locate the training button, refer
to your garage door opener’s instruction
manual.

Training button

button that was programmed in the pre-
vious section. Press and release the
button a second time to complete the
programming procedure.

NOTE

Some garage door openers may require
you to do the above press-hold-release
sequence a third time to complete the
programming.

4. The garage door opener should now
recognize the HomeLink

Wireless Control

System and your garage door opener
should activate when the HomeLink

button is pressed.

Programming for entrance gates
and garage door openers in
Canada

1. Unplug the motor of the entrance gate
or garage door opener from the outlet.

NOTE

If any of the HomeLink

buttons are

already programmed for other devices,
skip step 2 because it clears the
memory of all three buttons.

– CONTINUED –

Instruments and controls/Mirrors

3-75

Subaru Outback (2019 year). Instruction - part 14
