Subaru Impreza (2019 year). Instruction

(53,1)

北米Model "A1350BE-A" EDITED: 2018/ 4/ 20

Seatbelt maintenance

To clean the seatbelts, use a mild soap and
lukewarm water. Never bleach or dye the
belts because this could seriously affect
their strength.

Inspect the seatbelts and attachments
including the webbing and all hardware
periodically for cracks, cuts, gashes, tears,
damage, loose bolts or worn areas. Re-
place the seatbelts even if only minor
damage is found.

CAUTION

Keep the belts free of polishes,

oils, chemicals and particularly
battery acid.

Never attempt to make modifica-

tions or changes that will prevent
the seatbelt from operating prop-
erly.

Seatbelt pretensioners

The following seatbelts have a seatbelt
pretensioner.
.

Driver’s seatbelt

Front passenger’s seatbelt

The seatbelt pretensioners are designed
to be activated in the event of an accident
involving a moderate to severe frontal and
side collision and rollover accident.

WARNING

To obtain maximum protection,

the occupants should sit in an
upright position with their seat-
belts properly fastened. Refer to
“Seatbelts” F1-12.

Do not modify, remove or strike

the seatbelt retractor assemblies
equipped with seatbelt preten-
sioners or surrounding area. This
could result in accidental activa-
tion of the seatbelt pretensioners
or could make the system inop-
erative, possibly resulting in ser-
ious injury. Seatbelt preten-
sioners have no user-serviceable
parts. For required servicing of
seatbelt retractors equipped with
seatbelt pretensioners, consult

your SUBARU dealer.

When discarding seatbelt retrac-

tor assemblies equipped with
seatbelt pretensioners or scrap-
ping the entire vehicle due to
collision damage or for other
reasons, consult your SUBARU
dealer.

NOTE

Seatbelt pretensioners are not de-

signed to activate in minor impacts or
in rear impacts.
.

Pretensioners are designed to func-

tion on a one-time-only basis. In the
event that a pretensioner is activated,
both the driver’s and front passenger’s
seatbelt retractor assemblies should
be replaced only by an authorized
SUBARU dealer. When replacing seat-
belt retractor assemblies, use only
genuine SUBARU parts.
.

If a seatbelt that has a seatbelt

pretensioner does not retract or cannot
be pulled out due to a malfunction or
activation of the pretensioner, contact
your SUBARU dealer as soon as pos-
sible.

– CONTINUED –

Seat, seatbelt and SRS airbags/Seatbelt pretensioners

1-21

(54,1)

北米Model "A1350BE-A" EDITED: 2018/ 4/ 20

If the seatbelt retractor assembly or

surrounding area has been damaged,
contact your SUBARU dealer as soon
as possible.
.

When you sell your vehicle, we urge

you to inform the buyer that the vehicle
is equipped with seatbelt preten-
sioners. Also, notify the buyer of the
contents of this section.

Driver’s seatbelt

The driver’s seatbelt has a shoulder belt
pretensioner.

Front seatbelt pretensioner

The pretensioner sensor also serves as
follows.
.

SRS frontal airbag sensor

Side impact sensor

Front door impact sensor

Rollover sensor

If the sensor detects a certain predeter-
mined amount of force during frontal or
side collisions or rollover accidents, any
seatbelt that has a seatbelt pretensioner is
quickly drawn back in by the retractor to
take up the slack so that the belt more
effectively restrains the seat occupant.

The driver’s seatbelt pretensioner includes
a tension reducing device which limits the
peak forces exerted by the seatbelt on the
occupant in the event of a collision.

When a seatbelt pretensioner is activated,
an operating noise will be heard and a
small amount of smoke will be released.
These occurrences are normal and not
harmful. This smoke does not indicate a
fire in the vehicle.

Once the seatbelt pretensioner has been
activated, the seatbelt retractor remains
locked. Consequently, the seatbelt cannot
be pulled out and retracted and therefore
must be replaced.

In cases of rollover accident, frontal
collisions or side collisions, the
following components will operate
simultaneously

For details, refer to “In cases of rollover
accident, frontal collisions or side colli-
sions, the following components will oper-
ate simultaneously” F1-24.

Seat, seatbelt and SRS airbags/Seatbelt pretensioners

1-22

(55,1)

北米Model "A1350BE-A" EDITED: 2018/ 4/ 20

Front passenger’s seatbelt

The front passenger’s seatbelt has a
shoulder belt and a lap belt pretensioner.

Seatbelt retractor assembly (shoulder
belt pretensioner and adaptive force
limiter)

Lap belt pretensioner

On the front passenger’s side, the
shoulder belt pretensioner is supplemen-
ted by a lap belt pretensioner, which is
located at the base of the center pillar. Like
the shoulder belt pretensioner, the lap belt
pretensioner instantaneously pulls in the
belt to eliminate slack if a certain level of
frontal collision force is detected. As a
result, the seatbelt restrains the front seat
occupant more effectively.
The front passenger’s seatbelt preten-
sioner includes a tension reducing device

which limits the peak forces exerted by the
seatbelt on the occupant in the event of a
collision.
The adaptive force limiter will select a
reducing load to the suit body size of
occupant as detected by the occupant
detection sensor.

Once the seatbelt pretensioner has been
activated, the seatbelt pretensioner re-
mains locked. Consequently, the seatbelt
cannot be pulled out and retracted and
therefore must be replaced.

– CONTINUED –

Seat, seatbelt and SRS airbags/Seatbelt pretensioners

1-23

(56,1)

北米Model "A1350BE-A" EDITED: 2018/ 4/ 20

In cases of rollover accident, frontal collisions or side collisions, the following components will operate simultaneously

Driver’s side
seatbelt pre-

tensioner

Front passen-

ger’s side

shoulder belt

pretensioner

Front passen-

ger’s side lap

belt preten-

sioner

SRS frontal

airbag for dri-

ver

SRS frontal

airbag for front

passenger

SRS curtain

airbags

SRS side air-

bags

Rollover accidents

–

both sides

–

Frontal collisions

–

Offset frontal
collisions

both sides

–

Side collisions

–

impacted side

Rear impact

–

Minor impact

–

: Activated

–: Not activated

*1: This does not operate if the occupant detection system deactivates airbag operation.
*2: When both the satellite safing sensor and any of the center pillar impact sensors/front door impact sensors sense an impact force.
*3: When both the satellite safing sensor and the driver’s side front door impact sensor sense an impact force.
However, when a center pillar impact sensor detects a signal faster than the front door impact sensor, or both sensors detect signals simultaneously, the
seatbelt pretensioner does not activate.
*4: When both the satellite safing sensor and the front passenger’s side front door impact sensor sense an impact force.
However, when a center pillar impact sensor detects a signal faster than the front door impact sensor, or both sensors detect signals simultaneously, the
seatbelt pretensioner does not activate.

Seat, seatbelt and SRS airbags/Seatbelt pretensioners

1-24

(57,1)

北米Model "A1350BE-A" EDITED: 2018/ 4/ 20

System monitors

A diagnostic system continually monitors
the readiness of the seatbelt pretensioner
with the ignition switch in the “ON” position.
The seatbelt pretensioners share the
control module with the SRS airbag
system. Therefore, if any malfunction
occurs in a seatbelt pretensioner, the
SRS airbag system warning light will
illuminate. For details, refer to “SRS airbag
system monitors” F1-70.

System servicing

WARNING

When discarding a seatbelt re-

tractor assembly or scrapping
the entire vehicle damaged by a
collision, consult your SUBARU
dealer.

Tampering with or disconnecting

the system’s wiring could result
in accidental activation of the
seatbelt pretensioner and/or
SRS airbag or could make the
system inoperative, which may
result in serious injury. Do not
use electrical test equipment on
any circuit related to the seatbelt
pretensioner and SRS airbag sys-
tems. For required servicing of

the seatbelt pretensioner, con-
sult your nearest SUBARU deal-
er.

CAUTION

For the locations of the sensors and
SRS airbag control module, refer to
“Components” F1-49.

If you need service or repair in the
areas where the sensors and SRS
airbag modules are stored, or near
the front seatbelt retractors, have
the work performed by your author-
ized SUBARU dealer.

NOTE

If the front or side part of the vehicle is
damaged in an accident to the extent
that the seatbelt pretensioner does not
operate, contact your SUBARU dealer
as soon as possible.

Precautions against vehicle
modification

Always consult your SUBARU dealer if you
want to install any accessory parts to your
vehicle.

CAUTION

Do not perform any of the following
modifications. Such modifications
can interfere with proper operation
of the seatbelt pretensioners.

Attachment of any equipment

(bush bar, winches, snow plow,
skid plate, etc.) other than genu-
ine SUBARU accessory parts to
the front end.

Modification of the suspension

system or front end structure.

Installation of a tire of different

size and construction from the
tires specified on the vehicle
placard attached to the driver’s
door pillar or specified for indivi-
dual vehicle models in this Own-
er’s Manual.

Seat, seatbelt and SRS airbags/Seatbelt pretensioners

1-25

(58,1)

北米Model "A1350BE-A" EDITED: 2018/ 4/ 20

Child restraint systems

Infants and small children should always
be placed in an infant or child restraint
system in the rear seat while riding in the
vehicle.

You should use an infant or child restraint
system that meets Federal Motor Vehicle
Safety Standards or Canada Motor Vehi-
cle Safety Standards, is compatible with
your vehicle and is appropriate for the
child’s age and size.

All child restraint systems are designed to
be secured in vehicle seats by lap belts or
the lap belt portion of a lap/shoulder belt
(except those described in “Installation of
child restraint systems by use of lower and
tether anchorages (LATCH)” F1-35).

Children could be endangered in an
accident if their child restraints are not
properly secured in the vehicle. When
installing the child restraint system, care-
fully follow the manufacturer’s instructions.

According to accident statistics, children
are safer when properly restrained in the
rear seating positions than in the front
seating positions.

All U.S. states and Canadian provinces
require that infants and small children be
restrained in an approved child restraint
system at all times while the vehicle is
moving.

Lock release knob
1)

Unlocked

Locked

Unlocking marker in red

WARNING

Before installing a child restraint
system, be sure to confirm that the
seatback is securely locked into
place. Otherwise, in an accident,
serious injury or death could result.

WARNING

Never let a passenger hold a child on
his or her lap or in his or her arms
while the vehicle is moving. The
passenger cannot protect the child
from injury in a collision, because
the child will be caught between the
passenger and objects inside the
vehicle.

Seat, seatbelt and SRS airbags/Child restraint systems

1-26

(59,1)

北米Model "A1350BE-A" EDITED: 2018/ 4/ 20

Additionally, holding a child in your
lap or arms in the front seat exposes
that child to another serious danger.
Since the SRS airbag deploys with
considerable speed and force, the
child could be injured or even killed.

WARNING

Children should be properly re-
strained at all times. Never allow a
child to stand up, or to kneel on any
seat. Unrestrained children will be
thrown forward during sudden stop
or in an accident and can be injured
seriously.

Additionally, children standing up or
kneeling on or in front of the front

seat are exposed another serious
danger. Since the SRS airbag de-
ploys with considerable speed and
force, the child could be injured or
even killed.

Safety tips for installing child
restraint systems

WARNING

Do not use a seat belt extender. If

a seat belt extender is used when
installing a child restraint sys-
tem, the seat belt will not se-
curely hold the child restraint
system. Use of a seat belt exten-
der could cause death or serious
injury to children or other pas-
sengers in sudden braking, swer-
ving, or accidents.

Child restraint systems and seat-

belts can become hot in a vehicle
that has been closed up in sunny
weather; they could burn a small
child. Check the child restraint
system before you place a child
in it.

Do not leave an unsecured child

restraint system in your vehicle.
Unsecured child restraint sys-

tems can be thrown around in-
side of the vehicle in a sudden
stop, turn or accident; they can
strike and injure vehicle occu-
pants as well as result in serious
injuries or death to the child.

– CONTINUED –

Seat, seatbelt and SRS airbags/Child restraint systems

1-27

(60,1)

北米Model "A1350BE-A" EDITED: 2018/ 4/ 20

CAUTION

When you install a child restraint
system, follow the manufacturer’s
instructions supplied with it. After
installing the child restraint system,
check to ensure that it is held
securely in position. If it is not held
tight and secure, the danger of your
child suffering personal injury in the
event of an accident may be in-
creased.

Where to place a child re-
straint system

The following are SUBARU’s recommen-
dations on where to place a child restraint
system in your vehicle.

A: Front passenger’s seat
You should not install a child restraint
system (including a booster seat) due to
the hazard to children posed by the
passenger’s airbag.

B: Rear seat, window-side seating
positions
Recommended positions for all types of
child restraint systems.
In these positions, the following equipment
is provided for installing a child restraint
system.

Automatic Locking Retractor/Emer-

gency Locking Retractor (ALR/ELR) seat-
belts
.

Lower anchorages (bars)

Upper anchorages (tether anchorages)

Some types of child restraints might not be
able to be secured firmly due to projection
of the seat cushion.
In this seating position, you should use
only a child restraint system that has a
bottom base that fits snugly against the
contours of the seat cushion and can be
securely retained using the seatbelt.

C: Rear seat, center seating position
The ALR/ELR seatbelt and an upper
anchorage (tether anchorage) are pro-
vided in this position.
Some types of child restraints might not be
able to be secured firmly due to projection
of the seat cushion.
In this seating position, you should use
only a child restraint system that has a
bottom base that fits snugly against the
contours of the seat cushion and can be
securely retained using the seatbelt.
When you install a child restraint system in
the rear seat’s center seating position,
raise the center head restraint.
Lower anchorages (bars) for window-side
seating positions may be used for a seat in

Seat, seatbelt and SRS airbags/Child restraint systems

1-28

(61,1)

北米Model "A1350BE-A" EDITED: 2018/ 4/ 20

the center seating position if a child
restraint system manufacturer’s instruc-
tions permit and specify using anchors as
far apart as those in this vehicle.
If a child restraint system is not correctly
fixed in place (for example, if a child
restraint system can be moved more than
1 inch (2.5 cm) from side to side), you
should install the child restraint system in a
rear seat, window-side seating position.

WARNING

Even with advanced airbags, chil-

dren can be seriously injured by
the airbag. Place children in the
rear seat properly restrained at
all times. The SRS airbag deploys
with considerable speed and
force and can injure or even kill
children, especially if they are not
restrained or improperly re-
strained. Because children are
lighter and weaker than adults,
their risk of being injured from
deployment is greater.

For that reason, be sure to secure
ALL types of child restraint de-
vices (including forward facing
child seats) in the REAR seats at
all times. You should choose a
restraint device which is appro-

priate for the child’s age, height
and weight. According to acci-
dent statistics, children are safer
when properly restrained in the
rear seating positions than in the
front seating positions.

Do not use lower anchorages

(bars) for a seat in the center
seating position unless a child
restraint system manufacturer’s
instructions permit and specify
using anchors spaced as far
apart as those in this vehicle.

Do not connect two or more lower

hooks onto the same anchorage
(bar).

WARNING

S I N C E Y O U R V E H I C L E I S

EQUIPPED WITH A PASSEN-
GER’S SRS AIRBAG, NEVER IN-
STALL A CHILD SAFETY SEAT IN
THE FRONT SEAT. DOING SO
RISKS SERIOUS INJURY OR
DEATH TO THE CHILD BY PLA-
CING THE CHILD’S HEAD TOO
CLOSE TO THE SRS AIRBAG.

Do not allow children to lean their

heads or other body parts against
the door of the vehicle, or the
areas around the door. Deploy-
ment of the SRS side and curtain
airbags could impact the child
resulting in death or serious
injury.

To secure the child restraint sys-

tem, be sure to comply with all
installation instructions provided
by the child restraint manufac-
turer. Not doing so could result in
death or serious injury to chil-
dren in a sudden stop or acci-
dent.

– CONTINUED –

Seat, seatbelt and SRS airbags/Child restraint systems

1-29

(62,1)

北米Model "A1350BE-A" EDITED: 2018/ 4/ 20

Choosing a child restraint
system

Choose a child restraint system that is
appropriate for the child’s age and size
(weight and height) in order to provide the
child with proper protection. The child
restraint system should meet all applicable
requirements of Federal Motor Vehicle
Safety Standards for the United States or
of Canada Motor Vehicle Safety Standards
for Canada. It can be identified by looking
for the label on the child restraint system or
the manufacturer’s statement of compli-
ance in the document attached to the
system.
Also it is important for you to make sure
that the child restraint system is compa-
tible with the vehicle in which it will be
used.

Installing child restraint sys-
tems with ALR/ELR seatbelt

CAUTION

When you install a child restraint

system, follow the manufac-
turer’s instructions supplied with
it. After installing the child re-
straint system, check to ensure
that it is held securely in position.
If it is not held tight and secure,
the danger of your child suffering
personal injury in the event of an
accident may be increased.

When installing a child restraint

system in the rear center seating
position, set both seatbacks to
the original position. Otherwise,
the child restraint system cannot
be securely restrained, which
may result in death or serious
injuries in the event of sudden
stop, sudden steering maneuver
or an accident.

Installing a rearward facing child
restraint

WARNING

NEVER INSTALL A CHILD SEAT

IN THE FRONT SEAT. DOING SO
RISKS SERIOUS INJURY OR
DEATH TO THE CHILD BY PLA-
CING THE CHILD’S HEAD TOO
CLOSE TO THE SRS AIRBAG.

Before installing a child restraint

system, be sure to confirm that
the seatback is securely locked
into place. Otherwise, in an acci-
dent, serious injury or death
could result.

1. Move the seatback back and forth to

Seat, seatbelt and SRS airbags/Child restraint systems

1-30

(63,1)

北米Model "A1350BE-A" EDITED: 2018/ 4/ 20

confirm that it is securely locked into place.

– Check that the red colored unlock-
ing marker which is attached to the
bottom of the lock release knob is not
visible. For details, refer to “Folding
down the rear seatback” F1-6.

2. Place the child restraint system in the
rear seating position.

WARNING

When you intend to install a child
restraint system in the rear center
seating position, if the child restraint
system does not fit snugly against
the contours of the rear center seat
cushion, install the child restraint
system in the window-side seating
position to be safe. For details, refer
to “Where to place a child restraint
system” F1-28.

3. Run the lap and shoulder belt through
or around the child restraint system follow-
ing the instructions provided by its manu-
facturer.
4. Insert the tongue plate into the buckle
until you hear a click.

5. Take up the slack in the lap belt.
6. If using the seatbelt in the ALR mode is
recommended by the manufacturer’s in-
structions supplied with the child restraint
system, perform the following procedure.
(1) Pull out the seatbelt fully from the
retractor to change the retractor over from
the Emergency Locking Retractor (ELR) to
the Automatic Locking Retractor (ALR)
mode.
(2) Allow the belt to rewind into the
retractor. As the belt is rewinding, clicks
will be heard which indicate the retractor
functions as ALR.

7. Push and pull the child restraint system
forward and from side to side to check if it
is firmly secured. Sometimes a child
restraint can be more firmly secured by
pushing it down into the seat cushion and
then tightening the seatbelt.
8. If the seatbelt has been set to the ALR
mode in step 5, pull at the shoulder portion
of the belt to confirm that it cannot be
pulled out (ALR properly functioning).

– CONTINUED –

Seat, seatbelt and SRS airbags/Child restraint systems

1-31

(64,1)

北米Model "A1350BE-A" EDITED: 2018/ 4/ 20

9. To remove the child restraint system,
press the release button on the seatbelt
buckle and allow the belt to retract
completely. The belt will return to the
ELR mode.

NOTE

When the child restraint system is no
longer in use, remove it and restore the
ELR function of the retractor. That
function is restored by allowing the
seatbelt to retract fully.

Installing forward facing child re-
straint

WARNING

NEVER INSTALL A CHILD SEAT

IN THE FRONT SEAT. DOING SO
RISKS SERIOUS INJURY OR
DEATH TO THE CHILD BY PLA-
CING THE CHILD’S HEAD TOO
CLOSE TO THE SRS AIRBAG.

Before installing a child restraint

system, be sure to confirm that
the seatback is securely locked
into place. Otherwise, in an acci-
dent, serious injury or death
could result.

1. Move the seatback back and forth to
confirm that it is securely locked into place.

– Check that the red colored unlock-
ing marker which is attached to the
bottom of the lock release knob is
invisible. For details, refer to “Folding
down the rear seatback” F1-6.

2. Prepare the rear seat head restraint
where a child restraint system is intended
to be installed in the following way.

– When a child restraint system is
installed on the window-side seating
position or the rear center seating
position of a sedan, remove the rear
seat head restraint. For details, refer to
“Rear seats” F1-9.
Store the head restraint in the trunk
(sedan) or cargo area (5-door models).
Avoid placing the head restraint in the
passenger compartment to prevent it
from being thrown around in the
passenger compartment in a sudden
stop or a sharp turn.

– When a child restraint system is
installed on the rear center seating
position of a 5-door model, raise the
rear seat head restraint to the ex-
tended position. Do not remove the
head restraint. For details, refer to
“Rear seats” F1-9.

3. Place the child restraint system in the
rear seating position.

WARNING

When you intend to install a child
restraint system on the rear center
seating position, if the child restraint
system does not fit snugly against
the contours of the rear center seat
cushion, install the child restraint
system on the window-side seating

Seat, seatbelt and SRS airbags/Child restraint systems

1-32

(65,1)

北米Model "A1350BE-A" EDITED: 2018/ 4/ 20

position to be safe. For details, refer
to “Where to place a child restraint
system” F1-28.

4. Run the lap and shoulder belt through
or around the child restraint system follow-
ing the instructions provided by its manu-
facturer.

– When a child restraint system is
installed on the rear center seating
position of a 5-door model, pass the
rear center seatbelt through the belt
guide properly. For details, refer to
“Rear center seatbelt on 5-door mod-
els” F1-17.

5. Insert the tongue plate into the buckle
until you hear a click.

6. Take up the slack in the lap belt.
7. Pull out the seatbelt fully from the
retractor to change the retractor over from
the Emergency Locking Retractor (ELR) to
the Automatic Locking Retractor (ALR)
function. Then, allow the belt to rewind into
the retractor. As the belt is rewinding,
clicks will be heard which indicate the
retractor functions as ALR.

8. Before having a child sit in the child
restraint system, try to move it back and
forth and right and left to check if it is firmly
secured. Sometimes a child restraint
system can be more firmly secured by
pushing it down into the seat cushion and
then tightening the seatbelt.
9. Pull at the shoulder portion of the belt
to confirm that it cannot be pulled out (ALR
properly functioning).

– CONTINUED –

Seat, seatbelt and SRS airbags/Child restraint systems

1-33

(66,1)

北米Model "A1350BE-A" EDITED: 2018/ 4/ 20

Sedan

5-door models

10. Latch the top tether hook onto the
tether anchorage that is located behind the
rear seat and tighten the top tether firmly.
For additional instructions, refer to “Top

tether anchorages” F1-39.

11. To remove the child restraint system,
press the release button on the seatbelt
buckle and allow the belt to retract
completely. The belt will return to the
ELR mode.

If you have installed a child restraint
system for the rear center seating posi-
tion on a 5-door model, when you
remove the child restraint system, the
seatbelt may not be restored to the ELR
mode even if the seatbelt is retracted. In
this case, lower the head restraint to the
retracted position to allow the seatbelt to
retract moreover. The seatbelt will return to
the ELR mode.

Remember that the head restraint is not
intended to be used at the lowest position
(retracted position). Therefore, when the
rear center seat is occupied (including
when a child restraint system is installed)
next time, be sure to raise the head
restraint to the extended position.

NOTE

When the child restraint system is no
longer in use, remove it and restore the
ELR function of the retractor. That
function is restored by allowing the
seatbelt to retract fully.

Installing a booster seat

1. Place the booster seat in the rear
seating position and sit the child on it.
The child should sit well back on the

Seat, seatbelt and SRS airbags/Child restraint systems

1-34

(67,1)

北米Model "A1350BE-A" EDITED: 2018/ 4/ 20

booster seat.
2. Run the lap and shoulder belt through
or around the booster seat and the child
following the instructions provided by its
manufacturer.
3. Insert the tongue plate into the buckle
until you hear a click. Take care not to twist
the seatbelt.
Make sure the shoulder belt is positioned
across the center of child’s shoulder and
that the lap belt is positioned as low as
possible on the child’s hips.

4. To remove the booster seat, press the
release button on the seatbelt buckle and
allow the belt to retract.

WARNING

Never use a belt that is twisted or

reversed. In an accident, this can
increase the risk or severity of
injury to the child.

Never place the shoulder belt

under the child’s arm or behind
the child’s back. If an accident
occurs, this can increase the risk
or severity of injury to the child.

The seatbelt should fit snugly in

order to provide full restraint.
Loose fitting belts are not as
effective in preventing or redu-
cing injury.

Place the lap belt as low as

possible on the child’s hips. A
high-positioned lap belt will in-
crease the risk of sliding under
the lap belt and of the lap belt
sliding up over the abdomen, and
both can result in serious internal
injury or death.

Make sure the shoulder belt is

positioned across the center of
child’s shoulder. Placing the
shoulder belt over the neck may
result in neck injury during sud-
den braking or in a collision.

Installation of child restraint
systems by use of lower and
tether anchorages (LATCH)

Lower and tether anchorages

Sedan

– CONTINUED –

Seat, seatbelt and SRS airbags/Child restraint systems

1-35

(68,1)

北米Model "A1350BE-A" EDITED: 2018/ 4/ 20

5-door models

WARNING

Attach the child restraint system to
the anchors properly. When using
the LATCH anchors, be sure that
there are no foreign objects around
the anchors. Also, the seat belts
should not be caught behind the
child restraint system. Make sure
the child restraint system is se-
curely attached. Otherwise it may
cause death or serious injury to
children or other passengers in
sudden braking, swerving, or acci-
dents.

Some types of child restraint systems can
be installed on the rear seat of your vehicle

without use of the seatbelts. Such child
restraint systems are secured to the
designated anchorages provided on the
vehicle body. The lower and tether an-
chorages are sometimes referred to as the
LATCH system (Lower Anchors and
Tethers for CHildren).

Your vehicle is equipped with four lower
anchorages (bars) and three upper an-
chorages (tether anchorages) for accom-
modating such child restraint systems.

Lower anchorages

The lower anchorages (bars) are used for
installing a child restraint system only on
the rear seat window-side seating posi-
tions. For each window-side seating posi-
tion, two lower anchorages are provided.
Each lower anchorage is located where
the seat cushion meets the seatback.

Seat, seatbelt and SRS airbags/Child restraint systems

1-36

Subaru Impreza (2019 year). Instruction - part 4
