Subaru Impreza (2019 year). Instruction

If your vehicle is equipped with a combination meter display (color LCD), setting adjustments to the following items can be manually
changed within the display to meet your personal requirements.

NOTE

If your vehicle is not equipped with a combination meter display (color LCD), setting changes to the following items will need
to be performed by a SUBARU dealer. Refer to“Function settings and adjustments performed by a dealer” F28.

Item

Available settings

Factory default setting

Page reference

for the vehicle

system opera-

tion

1st menu/vehicle sys-
tem

2nd menu/adjustable
vehicle system setting

3rd menu/selectable ve-
hicle system setting

Screen Settings

Welcome Screen

—

On/Off

3-35

Good-bye Screen

—

On/Off

3-35

Gauge Initial Movement

—

On/Off

3-39

Units

—

km, km/h, Liter/mile,
MPH, Gallon

U.S.-spec models: mile,
MPH, Gallon
Other models: km, km/h,
Liter

3-40

Tire Pressure Units (if
equipped)

—

kPa/PSi

PSi

3-40

Languages

—

English/Español/Fran-
çais

U.S.-spec models: Eng-
lish
Other models: Français

3-40

– CONTINUED –

(28,1)

北米Model "A1350BE-A" EDITED: 2018/ 4/ 20

Item

Available settings

Factory default setting

Page reference

for the vehicle

system opera-

tion

1st menu/vehicle sys-
tem

2nd menu/adjustable
vehicle system setting

3rd menu/selectable ve-
hicle system setting

Warning Volume*

—

Max/Mid/Min

Mid

7-54 and 7-67

For details about

EyeSight sys-

tem, refer to the

Owner’s Manual

supplement for

the EyeSight

system.

EyeSight (models with
EyeSight system)

Lead Vehicle Acquisition
Sound

—

On/Off

Refer to the

Owner’s Manual

supplement for

the EyeSight

system.

Lead Vehicle Moving
Monitor Function

—

On/Off

Cruise Control Accel-
eration Characteristics*

—

Lv.4 (Dynamic)/Lv.3
(Standard)/Lv.2 (Com-
fort)/Lv.1 (ECO)

Lv.3 (Standard)

RAB (if equipped)

Sonar Audible Alarm

—

On/Off

7-67

(29,1)

北米Model "A1350BE-A" EDITED: 2018/ 4/ 20

Item

Available settings

Factory default setting

Page reference

for the vehicle

system opera-

tion

1st menu/vehicle sys-
tem

2nd menu/adjustable
vehicle system setting

3rd menu/selectable ve-
hicle system setting

Vehicle Setting

Keyless Entry System

Audible Signal (if
equipped)

On/Off

2-16

Hazard Warning Flasher On/Off

3-40

Security Relocking (if
equipped)

20 seconds/30 seconds/
40 seconds/50 seconds/
60 seconds/Off

30 seconds

3-40

Driver Door Unlock (if
equipped)

Driver’s Door Only/All

Driver’s Door Only

2-11

Rear Gate/Trunk Unlock
(if equipped)

Rear Gate Only/All

Rear Gate/Trunk Only

3-40

Defogger

—

15 minutes/Continuous

15 minutes

3-88

Interior Light

—

10 seconds/20 seconds/
30 seconds/Off

30 seconds

6-3

Auto Light Sensor (if
equipped)

—

Low/Normal/High/Very
high

High

3-66

Welcome Lighting (if
equipped)

Approaching Time Set

30 seconds/60 seconds/
90 seconds/Off

30 seconds

3-66

Leaving Time Set

30 seconds/60 seconds/
90 seconds/Off

30 seconds

3-66

One-touch lane changer

—

On/Off

3-75

Default Settings

—

No/Yes

—

3-41

*: You can also set this while driving.

– CONTINUED –

(30,1)

北米Model "A1350BE-A" EDITED: 2018/ 4/ 20

Individual settings and adjustments excluding combination meter display (color LCD)

Item

Function

Available settings

Factory default setting

Page

Remote keyless entry system

Audible signal

Operation/Non-operation

Operation

2-22

Alarm system

Operation/Non-operation

Operation

2-29

Function settings and adjustments performed by a dealer

A SUBARU dealer can change the setting adjustments of the following items to meet your personal requirements. Contact the nearest
SUBARU dealer for details.

Item

Function

Available settings

Factory default setting

Keyless Access (if equipped)

Hazard warning flasher

Operation/Non-operation

Operation

Audible signal volume

Level 1 to 7

Level 5

Door unlock selection function (dri-
ver’s door unlock)

Driver’s door only/All doors

Driver’s door only

Door unlock selection function (rear
gate unlock) (5-door models)

Rear gate only/All doors

Rear gate only

Audible signal

Operation/Non-operation

Operation

Remote keyless entry system

Hazard warning flasher

Operation/Non-operation

Operation

Audible signal volume

Level 1 to 7

Level 5

Audible signal

Operation/Non-operation

Operation

Key lock-in prevention

Operation/Non-operation

Operation

Remote trunk open function (sedan) Trunk lid opener function with ac-

cess key fob/remote transmitter

Operation/Non-operation

Operation

Battery drainage prevention func-
tion

Operation/Non-operation

Operation

(31,1)

北米Model "A1350BE-A" EDITED: 2018/ 4/ 20

Item

Function

Available settings

Factory default setting

Alarm system

Dome light, cargo area light, and
map lights illumination

ON/OFF

OFF

Monitoring start delay time (after
closure of doors)

0 seconds/30 seconds

30 seconds

Alarm system

Operation/Non-operation

Operation

Auto dimmer cancel (if equipped)

Sensitivity of the operation of the
auto dimmer cancel

OFF/Min/Low/Mid/Hi/Max

Mid

Seatbelt warning

Sounds a chime while driving

Operation/Non-operation

Operation

Auto on/off headlights (if equipped)

Sensitivity of the operation of the
auto on/off headlights

Low/Normal/High/Very high

High

Auto on/off wiper-linked headlights
(if equipped)

Auto-on/off wiper-linked

Operation/Non-operation

Operation

High beam assist function (if
equipped)

High beam assist function

Operation/Non-operation

Operation

One-touch lane changer

Operation of the one-touch lane
changer

Operation/Non-operation

Operation

Reverse gear interlocked rear wiper
(5-door models)

Reverse gear interlocked rear wiper Operation/Non-operation

U.S.-spec models: Non-operation
Other models: Operation

Defogger and deicer system for
models with the automatic climate
control system

Rear window defogger, outside mir-
ror defogger and windshield wiper
deicer

Operation for 15 minutes/Continu-
ous operation

Operation for 15 minutes

Dome light/Map lights/Cargo area
light (5-door models)

Operation of dome light/map light/
cargo area light OFF delay timer

OFF/10 seconds/20 seconds/30
seconds

30 seconds

(33,1)

北米Model "A1350BE-A" EDITED: 2018/ 4/ 20

Seats ........................................................................ 1-2

Safety tips ............................................................. 1-2
Front seats ............................................................ 1-5
Rear seats ............................................................. 1-6
Head restraint ........................................................ 1-8

Seat heater (if equipped) ...................................... 1-10

Safety precautions ................................................ 1-10
Operation.............................................................. 1-11

Seatbelts ................................................................ 1-12

Seatbelt safety tips ............................................... 1-12
Emergency Locking Retractor (ELR)...................... 1-14
Automatic Locking Retractor/Emergency Locking

Retractor (ALR/ELR)............................................ 1-14

Seatbelt warning light and chime .......................... 1-14
Fastening the seatbelt........................................... 1-14
Seatbelt maintenance ............................................ 1-21

Seatbelt pretensioners ......................................... 1-21

Driver’s seatbelt.................................................... 1-22
Front passenger’s seatbelt .................................... 1-23
System monitors................................................... 1-25
System servicing .................................................. 1-25
Precautions against vehicle modification............... 1-25

Child restraint systems ........................................ 1-26

Safety tips for installing child restraint systems .... 1-27
Where to place a child restraint system................. 1-28

Choosing a child restraint system......................... 1-30
Installing child restraint systems with ALR/ELR

seatbelt ............................................................. 1-30

Installing a booster seat ....................................... 1-34
Installation of child restraint systems by use of

lower and tether anchorages (LATCH) ................ 1-35

Top tether anchorages .......................................... 1-39

SRS airbag (Supplemental Restraint System

airbag) ................................................................ 1-41

General precautions regarding SRS airbag

system .............................................................. 1-41

General precautions regarding SRS airbag

system for accessories and any objects............. 1-43

General precautions regarding SRS airbag

system and children .......................................... 1-46

Components ......................................................... 1-49
SUBARU advanced frontal airbag system.............. 1-51
SRS side airbag and SRS curtain airbag ............... 1-62
SRS airbag system monitors................................. 1-70
SRS airbag system servicing ................................ 1-71
Precautions against vehicle modification .............. 1-72
How to contact the vehicle manufacturer

concerning modifications for persons with
disabilities that may affect the advanced
airbag system.................................................... 1-73

Seat, seatbelt and SRS airbags

(34,1)

北米Model "A1350BE-A" EDITED: 2018/ 4/ 20

Seats

Safety tips

Safety tips for seat

WARNING

Never adjust the seat while driv-

ing to avoid loss of vehicle con-
trol and personal injury.

Before adjusting the seat, make

sure the hands and feet of rear
seat passengers and cargo are
clear of the adjusting mechan-
ism.

After adjusting the seat, move it

back and forth to make sure it is
securely locked. If the seat is not
securely locked, it may move or
the seatbelt may not operate
properly.

Do not put objects under the front

seats. They may interfere with
front seat locking and cause an
accident.

Seatbelts provide maximum re-

straint when the occupant sits
well back and upright in the seat.
To reduce the risk of sliding
under the seatbelt in a collision,
the front seatbacks should be

always used in the upright posi-
tion while the vehicle is running.
If the front seatbacks are not
used in the upright position in a
collision, the risk of sliding under
the lap belt and of the lap belt
sliding up over the abdomen will
increase, and both can result in
serious internal injury or death.

The SRS airbags deploy with

considerable speed and force.
Occupants who are out of proper
position when the SRS airbag
deploys could suffer very serious
injuries. Because the SRS airbag
needs enough space for deploy-
ment, the driver should always sit
upright and well back in the seat
as far from the steering wheel as
practical while still maintaining
full vehicle control and the front
passenger should move the seat
as far back as possible and sit
upright and well back in the seat.

WARNING

Place children in the rear seat prop-
erly restrained at all times. The SRS
airbag deploys with considerable
speed and force and can injure or
even kill children, especially if they
are not restrained or improperly
restrained. Because children are
lighter and weaker than adults, their
risk of being injured from deploy-
ment is greater. For that reason, we
strongly recommend that ALL chil-
dren (including those in child seats
and those that have outgrown child
restraint devices) sit in the REAR
seat properly restrained at all times
in a child restraint device or in a
seatbelt, whichever is appropriate

Seat, seatbelt and SRS airbags/Seats

1-2

(35,1)

北米Model "A1350BE-A" EDITED: 2018/ 4/ 20

for the child’s age, height and
weight. Secure ALL types of child
restraint devices (including forward
facing child seat) in the REAR seats
at all times.

NEVER INSTALL A CHILD SEAT IN
THE FRONT SEAT. DOING SO RISKS
SERIOUS INJURY OR DEATH TO
THE CHILD BY PLACING THE
CHILD’S HEAD TOO CLOSE TO
THE SRS AIRBAG.

According to accident statistics,
children are safer when properly
restrained in the rear seating posi-
tions than in the front seating posi-
tions. For instructions and precau-
tions concerning child restraint sys-
tems, refer to “Child restraint sys-
tems” F1-26.

WARNING

To prevent the passenger from slid-
ing under the seatbelt in the event of
a collision, always put the seatback
in the upright position while the
vehicle is in motion. Also, do not
place objects such as cushions
between the passenger and the seat-
back. If you do so, the risk of sliding
under the lap belt and of the lap belt
sliding up over the abdomen will
increase, and both can result in
serious internal injury or death.

WARNING

Do not let rear passengers rest their
feet between the front seatback and
seat cushion. Doing so may lead to
defective operation of the following
systems and could result in serious
injury.

Occupant detection system

SRS side airbag

Seat heater (if equipped)

Power seat (if equipped)

– CONTINUED –

Seat, seatbelt and SRS airbags/Seats

1-3

(36,1)

北米Model "A1350BE-A" EDITED: 2018/ 4/ 20

WARNING

Seatbelts provide maximum re-
straint when the occupant sits well
back and upright in the seat. Do not
put cushions or any other materials
between occupants and seatbacks
or seat cushions. If you do so, the
risk of sliding under the lap belt and
of the lap belt sliding up over the
abdomen will increase, and both can
result in serious internal injury or
death.

WARNING

Never stack luggage or other cargo
higher than the top of the seatback
because it could tumble forward and
injure passengers in the event of a
sudden stop or accident.

Safety tips for head restraint

WARNING

Never drive the vehicle with the

head restraints removed because
they are designed to reduce the
risk of serious neck injury in the
event that the vehicle is struck
from the rear. Also, never install
the head restraints the opposite
way round. Doing so will prevent
the head restraints from function-
ing as intended. Therefore, when
you remove the head restraints,
you must reinstall all head re-
straints correctly to protect vehi-
cle occupants.

All occupants, including the dri-

ver, should not operate a vehicle
or sit in a vehicle’s seat until the
head restraints are placed in their
proper positions in order to mini-
mize the risk of neck injury in the
event of a crash.

Seat, seatbelt and SRS airbags/Seats

1-4

Subaru Impreza (2019 year). Instruction - part 2
