Subaru Ascent (2019 year). Instruction

(387,1)

北米Model "A3200BE-A" EDITED: 2018/ 3/ 5

Snow tires

WARNING

When replacing or installing win-

ter tire(s), all four tires must be
the same for following items.

(a) Size

(b) Circumference

(c) Speed symbol

(d) Load index

(e) Construction

(f) Manufacturer

(g) Brand (tread pattern)

(h) Degrees of wear

For the items (a) to (d), you must
obey the specification that is
printed on the tire placard. The
tire placard is located on the
driver’s door pillar.

If all of four winter tires are not
the same for items (a) to (h),
serious mechanical damage
could occur to the drivetrain of
your car, and affect the following.

– Ride

– Handling

– Braking

– Speedometer/Odometer cali-

bration

– Clearance between the body

and tires

It also may be dangerous and
lead to loss of vehicle control,
and it can lead to an accident.

Do not use a combination of

radial, belted bias or bias tires
since it may cause dangerous
handling characteristics and lead
to an accident.

Your vehicle is equipped with “all season
tires” as original equipment, which are
designed to provide an adequate measure
of traction, handling and braking perfor-
mance in year-round driving. In winter, it
may be possible to enhance performance
through use of tires designed specifically
for winter driving conditions.
When you choose to install winter tires on
your vehicle, be sure to use the correct tire
size and type. You must install four winter
tires that are of the same size, construc-
tion, brand and load range and you should
never mix radial, belted bias or bias tires
since this may result in dangerous hand-
ling characteristics. When you choose a
tire, make sure that there is enough
clearance between the tire and vehicle

body.

Remember to drive with care at all times
regardless of the type of tires on your
vehicle.

Tire chains

CAUTION

Tire chains cannot be used on your
vehicle because of the lack of clear-
ance between the tires and vehicle
body.

NOTE

When tire chains cannot be used, use of
another type of traction device (such as
spring chains) may be acceptable if use
on your vehicle is recommended by the
device manufacturer, taking into ac-
count tire size and road conditions.
Follow the device manufacturer’s in-
structions, especially regarding max-
imum vehicle speed.
To help avoid damage to your vehicle,
drive slowly, readjust or remove the
device if it is contacting your vehicle,
and do not spin your wheels. Damage
caused to your vehicle by use of a
traction device is not covered under
warranty.

– CONTINUED –

Winter driving

385

Driving

tips

(388,1)

北米Model "A3200BE-A" EDITED: 2018/ 3/ 5

Make certain that any traction device
you use is an SAE class S device, and
use it on the front wheels only. Always
use the utmost care when driving with a
traction device. Overconfidence be-
cause you are using a traction device
could easily lead to a serious accident.

Rocking the vehicle

If you must rock the vehicle to free it from
snow, sand, or mud, depress the accel-
erator pedal slightly and move the select
lever back and forth between “D” and “R”
repeatedly. Do not race the engine. For the
best possible traction, avoid spinning the
wheels when trying to free the vehicle.
When the road surface is extremely
slippery, you can obtain better traction by
starting the vehicle with the transmission in
2nd than 1st.

For information about holding the trans-
mission in the 2nd position, refer to
“Selection of manual mode” FP332.

8-10. Loading your vehicle

WARNING

Never allow passengers to ride

on a folded rear seatback in the
cargo area. Doing so may result
in serious injury.

Never stack luggage or other

cargo higher than the top of the
seatback because it could tumble
forward and injure passengers in
the event of a sudden stop or
accident. Keep luggage or cargo
low, as close to the floor as
possible.

WARNING

When you carry something inside

the vehicle, secure it whenever
you can to prevent it from being
thrown around inside the vehicle
during sudden stops, sharp turns
or in an accident.

Do not pile heavy loads on the

roof. These loads raise the vehi-
cle’s center of gravity and make it
more prone to tip over.

Secure lengthy items properly to

prevent them from shooting for-
ward and causing serious injury
during a sudden stop.

Never exceed the maximum load

limit. If you do, some parts on
your vehicle can break, or it can
change the way your vehicle
handles. This could result in loss
of control and cause personal
injury. Also, overloading can
shorten the life of your vehicle.

Do not place anything on the

extended cargo area cover. Such
items could tumble forward in the
event of a sudden stop or a
collision. This could cause ser-
ious injury.

Loading your vehicle

386

(389,1)

北米Model "A3200BE-A" EDITED: 2018/ 3/ 5

CAUTION

Do not carry spray cans, containers
with flammable or corrosive liquids
or any other dangerous items inside
the vehicle.

NOTE

For better fuel economy, do not carry
unneeded cargo.

Vehicle capacity weight

Vehicle placard

The load capacity of your vehicle is
determined by weight, not by available
cargo space. The maximum load you can
carry in your vehicle is shown on the
vehicle placard attached to the driver’s
side door pillar. It includes the total weight
of the driver and all passengers and their
belongings, any optional equipment such
as a trailer hitch, roof rack or bike carrier,
etc., and the tongue load of a trailer.

GVWR and GAWR (Gross Ve-
hicle Weight Rating and
Gross Axle Weight Rating)

Certification label

The certification label attached to the
bottom of driver’s side door pillar shows
GVWR (Gross Vehicle Weight Rating) and
GAWR (Gross Axle Weight Rating).

The GVW (Gross Vehicle Weight) must
never exceed the GVWR. GVW is the
combined total of weight of the vehicle,
fuel, driver, all passengers, luggage, any
optional equipment and trailer tongue
load. Therefore, the GVW changes de-
pending on the situation. The GVWR
equals Curb Weight (actual weight of your
vehicle – including standard equipment,
fluids, emergency tools and spare tire

– CONTINUED –

Loading your vehicle

387

Driving

tips

(390,1)

北米Model "A3200BE-A" EDITED: 2018/ 3/ 5

assembly) plus the vehicle capacity
weight.

In addition, the total weight applied to each
axle (GAW) must never exceed the
GAWR. The front and rear GAWs can be
adjusted by relocating luggage inside the
vehicle.
Even if the total weight of your luggage is
lower than the vehicle capacity weight,
either front or rear GAW may exceed the
GAWR, depending on the distribution of
the luggage.
When possible, the load should be evenly
distributed throughout the vehicle.

If you carry heavy loads in the vehicle, you
should confirm that GVW and front and
rear GAWs are within the GVWR and
GAWR by putting your vehicle on a vehicle
scale, found at a commercial weighing
station.

Do not use replacement tires with a lower
load range than the originals because they
may lower the GVWR and GAWR limita-
tions. Replacement tires with a higher load
range than the originals do not increase
the GVWR and GAWR limitations.

Roof rails

Roof rails

Cargo can be carried on the roof after
securing the roof crossbars to the roof rails
and installing the appropriate carrying
attachments. When installing the roof
crossbars and the carrying attachments,
follow the manufacturer’s instructions. The
roof rail system is designed to carry loads
(cargo, roof crossbars and carrying attach-
ments) of no more than 176 lbs (80 kg). Be
sure not to exceed your vehicle’s GVWR
and GAWR.

CAUTION

When using the carrying attach-

ments, make sure that the total
carrying load of the cargo, roof

crossbars and carrying attach-
ments does not exceed 176 lbs
(80 kg). Overloading may cause
damage to the vehicle. Read the
manufacturer’s instructions and
pay attention to not exceed the
load limit of the parts.

For cargo carrying purposes, the

roof rails must be used together
with the SUBARU recommended
roof crossbars and any appropri-
ate carrying attachment that may
be needed. The roof rails must
never be used alone to carry
cargo. Otherwise, damage to the
roof or paint, or a dangerous road
hazard due to loss of cargo could
result.

NOTE

Remember that the vehicle’s center of
gravity is altered with the weight of the
load on the roof, thus affecting driving
characteristics.
Drive carefully. Avoid rapid starts, hard
cornering and abrupt stops. Crosswind
effects will be increased.

Loading your vehicle

388

(391,1)

北米Model "A3200BE-A" EDITED: 2018/ 3/ 5

Roof tent

WARNING

Adding weight to the vehicle’s roof
can adversely affect handling, brak-
ing, and rollover resistance. The
vehicle must never be driven with a
total roof rail load in excess of 176
lbs (80 kg).

CAUTION

The roof rail load limit for sta-

tionary vehicles (700 lbs (317 kg))
applies only when the vehicle is
parked and the load is evenly
distributed left/right and front/
rear and the roof crossbars and

roof tent are tightly secured to
the vehicle. If these conditions
are not met, the load limit will be
lower.

The maximum load limit of the

roof crossbars must be obtained
from the manufacturer or retailer
of the roof rack. When driving the
vehicle, the maximum roof rail
load is 176 lbs (80 kg) or the
crossbar load limit (whichever is
lower).

Roof tents may be used under certain
conditions at your own risk.

When driving the vehicle

The total weight on the roof rails, including
the roof crossbars and roof tent, must not
exceed the vehicle’s roof rail load of 176
lbs (80 kg), evenly distributed.

Roof rails

Roof crossbars

Roof tent

B + C < 176 lbs (80 kg)

– CONTINUED –

Loading your vehicle

389

Driving

tips

(392,1)

北米Model "A3200BE-A" EDITED: 2018/ 3/ 5

When the vehicle is parked on level
ground

Roof rails

Roof crossbars

Roof tent

Occupants in the roof tent

The total weight on the roof rails –
including the roof crossbars, roof tent,
and all occupants and contents in the roof
tent – must not exceed either the vehicle’s
roof rail load limit (700 lbs (317 kg)), evenly
distributed, or the load limit of the roof
crossbars, whichever is lower.

Load limit of the roof rail (A).
B + C + D < 700 lbs (317 kg)

Exceeding this load limit could cause
damage to the vehicle or racking system.
The vehicle must never be driven with
occupants in the roof tent. Before the
vehicle is driven, occupants and cargo
must be removed from the roof tent and
the roof rail load must be restored to within
the roof rail load limit of 176 lbs (80 kg).
Refer to the user manual that accompa-
nied the roof tent for important safety
information and instructions on the proper
installation and use of the tent.

8-11. Trailer hitch (dealer op-
tion)

WARNING

Never exceed the maximum
weight specified for the trailer
hitch. Exceeding the maximum
weight could cause an accident
resulting in serious personal in-
juries. Permissible trailer weight
changes depending on the situa-
tion. For possible recommenda-
tions and limitations, refer to
“Trailer towing” FP394.

Trailer brakes are required when

the towing load exceeds 1,000 lbs
(453 kg). Be sure your trailer has
safety chains and that each chain
will hold the trailer’s maximum
gross weight. Towing trailers
without safety chains could cre-
ate a traffic safety hazard if the
trailer separates from the hitch
due to coupling damage or hitch
ball damage.

Be sure to check the hitch pin and

safety pin for positive locking
placement before towing a trailer.
If the ball mount comes off the
hitch receiver, the trailer could

Trailer hitch (dealer option)

390

(393,1)

北米Model "A3200BE-A" EDITED: 2018/ 3/ 5

get loose and create a traffic
safety hazard.

Although towing regulations for

trailer or caravan vehicles vary
by state/region, all regulations
agree that specifications such
as the maximum gross trailer
weight must not exceed the les-
ser of the following:

– Maximum gross trailer weight

–

M a x i m u m g r o s s t o n g u e

weight

– GVWR

– GAWR

Failure to comply with the proce-

dures set forth will not only
compromise your safety, but will
also negate your insurance cov-
erage and/or may violate the state
road and traffic acts and regula-
tions.

Use only the ball mount supplied

with this hitch. Use the hitch only
as a weight carrying hitch. Do not
use with any type of weight dis-
tributing hitch.

The standard bumper beam must

be installed after you remove the
trailer hitch. Consult a SUBARU
dealer for purchase of a standard

bumper beam if you do not have
the original.

Safety performance is decreased

and there is increased risk of
injury to passengers in the case
of an accident if the trailer hitch
or a standard bumper beam is not
installed. One of them must al-
ways be installed on the vehicle.

If a trailer hitch is installed, it is

not possible to install the rear
towing hook.

The maximum gross trailer weight and
maximum gross tongue weight are indi-
cated in the following table.

Models with air-cooled continuously variable
transmission fluid cooler

Maximum gross trai-
ler weight

Maximum gross ton-
gue weight

5,000 lbs (2,268 kg)

500 lbs (227 kg)

Models without air-cooled continuously variable
transmission fluid cooler

Maximum gross trai-
ler weight

Maximum gross ton-
gue weight

2,000 lbs (907 kg)

500 lbs (227 kg)

*1: Continuously variable transmission type
TR690SXXXX (To check the model number
label for the continuously variable transmission
type, refer to “Vehicle identification” FP495.)

*2: Continuously variable transmission type
TR690GXXXX (To check the model number
label for the continuously variable transmission
type, refer to “Vehicle identification” FP495.)

When towing a trailer, refer to “Trailer
towing” FP394.

– CONTINUED –

Trailer hitch (dealer option)

391

Driving

tips

(394,1)

北米Model "A3200BE-A" EDITED: 2018/ 3/ 5

Connecting a trailer

1. Remove the 2 clips from the bottom of
the cover.

NOTE

Looking under the cover from bottom,

there are 2 clips fixed under the cover
fastened on each side.
Remove the clips one by one that are
fastened under the vehicle.

2. Remove the cover.

NOTE

Pull the bottom of the cover from where
the triangle mark “

” is located to

remove it.

Ball mount

Hitch pin

Safety clip

Hitch receiver tube

3. Insert the ball mount into the hitch
receiver tube.

Trailer hitch (dealer option)

392

(395,1)

北米Model "A3200BE-A" EDITED: 2018/ 3/ 5

4. Insert the hitch pin into the hole located
on the hitch receiver tube so that the pin
passes through the ball mount.
5. Insert the safety clip to the groove on
the hitch pin securely.
6. Check the ball mount assembly by
pulling on it to make sure it does not come
off the hitch receiver.

Hitch ball installation point

Hooks for safety chains

7. Attach a hitch ball. Use only a hitch ball
that is appropriate for the ball mount and
your trailer. The hitch ball must be securely
installed on the ball mount.
8. Connect your trailer to the hitch ball.
9. Connect the trailer and the hitch with
safety chains that will hold the trailer’s
maximum gross weight. The chains should

cross under the trailer tongue to prevent
the tongue from dropping onto the ground
in case it should disconnect from the hitch
ball. Allow sufficient slack in the chains
taking tight turn situations into account;
however, be careful not to let them drag on
the ground.

WARNING

Do not connect safety chains to any
part of the vehicle other than the
safety chain hooks.

Hitch harness connector (7-pin type)

Hitch harness connector (4-pin type)

10. Connect the hitch wire harness’s black
4-pin or 7-pin wire connector to the towing
trailer’s wire harness.
11. Confirm proper function of the hitch
wire harness by individually activating the
brake, stop and turn signal lights on the
trailer.

NOTE

Always disconnect the trailer wire har-
ness before launching or retrieving a
watercraft.

– CONTINUED –

Trailer hitch (dealer option)

393

Driving

tips

(396,1)

北米Model "A3200BE-A" EDITED: 2018/ 3/ 5

If not towing a trailer

Remove the ball mount from the hitch

receiver tube and insert the receiver cover
onto the hitch receiver tube and/or install
bumper cover.
.

Place the dust cap over the 4-pin or 7-

pin connector of the hitch wire harness to
protect against possible damage.
.

Occasionally lubricate terminals of the

4-pin or 7-pin connector using terminal
grease.

8-12. Trailer towing

Your vehicle is designed and intended to
be used primarily as a passenger-carrying
vehicle. Towing a trailer puts additional
loads on your vehicle’s engine, drivetrain,
brakes, tires and suspension and has an
adverse effect on fuel economy.
If you do decide to tow a trailer, your safety
and satisfaction depend upon proper use
of correct equipment and cautious opera-
tion of your vehicle. Seek the advice of
your SUBARU dealer to assist you in
purchasing a hitch and other necessary
towing equipment appropriate for your
vehicle. Do not use towing equipment
other than genuine SUBARU towing
equipment. In addition, be sure to follow
the instructions for proper installation and
use provided by the trailer or caravan’s
manufacturer.
SUBARU assumes no responsibility for
injuries or vehicle damage that result from
trailer towing equipment, or from any
errors or omissions in the instructions
accompanying such equipment or for your
failure to follow the proper instructions.
Regularly check that the hitch mounting
bolts and nuts are tightened securely.

Warranties and maintenance

SUBARU warranties do not apply to
vehicle damage or malfunction caused by
trailer towing. If you use your vehicle to tow
a trailer, more frequent maintenance will
be required due to the additional load.
(Refer to “Maintenance schedule under
severe driving conditions” in the “Warranty
and Maintenance Booklet”.)
Under no circumstances should a trailer be
towed with a new vehicle or a vehicle with
any new powertrain component (engine,
transmission, differential, wheel bearings,
etc.) for the first 1,000 miles (1,600 km) of
driving.

Trailer towing

394

(397,1)

北米Model "A3200BE-A" EDITED: 2018/ 3/ 5

Maximum load limits

WARNING

Never exceed the maximum load
limits explained in the following.
Exceeding the maximum load limits
could cause personal injury and/or
vehicle damage.

CAUTION

Adequate size trailer brakes are

required when the trailer and its
cargo exceed 1,000 lbs (453 kg)
total weight.

Before towing a trailer, check the

trailer total weight, GVW, GAWs
and tongue load. Make sure the
load and its distribution in your
vehicle and trailer are acceptable.

Total trailer weight

The total trailer weight (trailer weight plus
its cargo load) must never exceed the
maximum total trailer weight in the follow-
ing table.

– CONTINUED –

Trailer towing

395

Driving

tips

(398,1)

北米Model "A3200BE-A" EDITED: 2018/ 3/ 5

Conditions

Maximum total trailer weight

When towing a trailer without brakes.

1,000 lbs (453 kg)

When towing a trailer with brakes.

Models with air-cooled continuously variable

transmission fluid cooler*

5,000 lbs (2,268 kg)

Models without air-cooled continuously variable

transmission fluid cooler*

2,000 lbs (907 kg)

*1: Continuously variable transmission type TR690SXXXX (To check the model number label for the
continuously variable transmission type, refer to “Vehicle identification” FP495.)
*2: Continuously variable transmission type TR690GXXXX (To check the model number label for the
continuously variable transmission type, refer to “Vehicle identification” FP495.)

Gross Vehicle Weight (GVW) and
Gross Vehicle Weight Rating
(GVWR)

Gross Vehicle Weight

The Gross Vehicle Weight (GVW) must
never exceed the Gross Vehicle Weight
Rating (GVWR).
Gross Vehicle Weight (GVW) is the com-
bined total of the weight of the vehicle,
driver, passengers, luggage, trailer hitch,
trailer tongue load and any other optional
equipment installed on your vehicle.
Therefore, the GVW changes depending
on the situation. Determine the GVW each
time before going on a trip by putting your
vehicle and trailer on a vehicle scale.

Trailer towing

396

(399,1)

北米Model "A3200BE-A" EDITED: 2018/ 3/ 5

Certification label

GVWR of your vehicle that is given by
SUBARU is shown on the certification
label located at the bottom of driver’s side
door pillar of your vehicle.

Gross Axle Weight (GAW) and
Gross Axle Weight Rating (GAWR)

Gross Axle Weight

The total weight applied to each axle
(GAW) must never exceed the Gross Axle
Weight Rating (GAWR). The front and rear
GAWs can be adjusted by relocating
passengers and luggage inside the vehi-
cle. The front and rear GAWR of your
vehicle that is given by SUBARU are also
shown on the certification label located at
the bottom of driver’s side door pillar.

To check both GVWR and GAWR and to
confirm that the total weight and weight
distribution are within safe driving limits,
you should have your vehicle and trailer
weighed at a commercial weighing station.
Be sure that all cargo is firmly secured to

prevent a change in weight distribution
while driving.

Tongue load

Ensure that the trailer tongue load is from 8
to 11 percent of the total trailer weight and
does not exceed the maximum value of
500 lbs (227 kg).

– CONTINUED –

Trailer towing

397

Driving

tips

(400,1)

北米Model "A3200BE-A" EDITED: 2018/ 3/ 5

Jack

Bathroom scale

The tongue load can be weighed with a
bathroom scale as shown in the illustration
above. When weighing the tongue load, be
sure to position the towing coupler at the
height at which it would be during actual
towing, using a jack as shown.

Front

The tongue load can be adjusted by proper
distribution of the load in the trailer. Never
load the trailer with more weight in the
back than in the front; approximately 60
percent of the trailer load should be in the
front and approximately 40 percent in the
rear. Also, distribute the load as evenly as
possible on both the left and right sides.
Be sure that all cargo is firmly secured to
prevent a change in weight distribution
while driving.

WARNING

If the trailer is loaded with more
weight in the back of trailer’s axle
than in the front, the load is taken off
the rear axle of the towing vehicle.

This may cause the rear wheels to
skid, especially during braking or
when vehicle speed is reduced dur-
ing cornering, resulting in over-
steer, spin out and/or jackknifing.

Trailer Hitches

WARNING

Never drill the frame or under-body
of your vehicle to install a commer-
cial trailer hitch. If you do, danger-
ous exhaust gas, water or mud may
enter the passenger compartment
through the drilled hole. Exhaust
gas contains carbon monoxide, a
colorless and odorless gas which is
dangerous, or even lethal, if inhaled.
Also, drilling the frame or under-
body of your vehicle could cause
deterioration of strength of your
vehicle and cause corrosion around
the drilled hole.

CAUTION

Do not modify the vehicle ex-

haust system, brake system, or
other systems when installing a
hitch or other trailer towing

Trailer towing

398

(401,1)

北米Model "A3200BE-A" EDITED: 2018/ 3/ 5

equipment.

Do not use axle-mounted hitches

as they can cause damage to the
axle housing, wheel bearings,
wheels or tires.

Do not use a trailer hitch other than a
genuine SUBARU trailer hitch. A genuine
SUBARU trailer hitch is available from
your SUBARU dealer.

When you do not tow a trailer

CAUTION

The housing should be kept dirt

and corrosion-free at the points
of contact. The surfaces only
require cleaning with a cloth.
Grease or other lubricants
should never be used.

If the ball is not installed, the

plastic insert and/or bumper cov-
er should then be installed for
protection and to prevent it from
getting dirty.

When the ball is not used, place the ball
cap and store securely.

Connecting a trailer

Trailer brakes

WARNING

Adequate size trailer brakes are

required when the trailer and its
cargo exceed 1,000 lbs (453 kg)
total weight.

Do not directly connect your

trailer’s hydraulic brake system
to the hydraulic brake system in
your vehicle. Direct connection
would cause the vehicle’s brake
performance to deteriorate and
could lead to an accident.

If your trailer’s total weight (trailer weight
plus its cargo weight) exceeds 1,000 lbs
(453 kg), the trailer is required to be
equipped with its own brake system.
Electric brakes or surge brakes are re-
commended, and must be installed prop-
erly. Check that your trailer’s brakes con-
form with Federal, state/province and/or
other applicable regulations. Your
SUBARU’s brake system is not designed
to be tapped into the trailer’s hydraulic
brake system. Please ask your SUBARU
dealer and professional trailer supplier for
more information about the trailer’s brake
system.

Trailer safety chains

WARNING

Always use safety chains between
your vehicle and the trailer. Towing
trailer without safety chains could
create a traffic safety hazard if the
trailer separates from the hitch due
to coupling damage or hitch ball
damage.

In case the trailer hitch connector or hitch
ball should break or become discon-
nected, the trailer could get loose and
create a traffic safety hazard.
For safety, always connect the towing
vehicle and trailer with trailer safety
chains. Two chains should be used in
total, one to the right side and the other to
the left side trailer tongue. Pass the chains
crossing each other under the trailer
tongue to prevent the trailer from dropping
onto the ground in case the trailer tongue
should disconnect from the hitch ball.
Allow sufficient slack in the chains taking
tight turn situations into account; however,
be careful not to let them drag on the
ground.

– CONTINUED –

Trailer towing

399

Driving

tips

(402,1)

北米Model "A3200BE-A" EDITED: 2018/ 3/ 5

Side mirrors

After hitching a trailer to your vehicle,
check that the standard side mirrors
provide a good rearward field of view
without significant blind spots. If significant
blind spots occur with the vehicle’s stan-
dard side mirrors, use towing mirrors that
conform with Federal, state/province and/
or other applicable regulations.

Trailer lights

CAUTION

Direct splicing or other improper
connection of trailer lights may
damage your vehicle’s electrical
system and cause a malfunction of
your vehicle’s lighting system.

Connection of trailer lights to your vehicle’s
electrical system requires modifications to
the vehicle’s lighting circuit to increase its
capacity and accommodate wiring
changes. To ensure the trailer lights are
connected properly, please consult your
SUBARU dealer. Check for proper opera-
tion of the turn signals and the brake lights
each time you connect a trailer to your
vehicle.

Tires

WARNING

Never tow a trailer when the tempor-
ary spare tire is used. The temporary
spare tire is not designed to sustain
the towing load. Use of the tempor-
ary spare tire when towing can result
in failure of the spare tire and/or less
stability of the vehicle.

Make sure that all the tires on your vehicle
are properly inflated. Refer to “Tires”
FP486.

Trailer tire condition, size, load rating and
proper inflation pressure should be in
accordance with the trailer manufacturer’s
specifications. Also check federal, state,
province and/or other applicable regula-
tions.

In the event your vehicle gets a flat tire
when towing a trailer, ask a commercial
road service representative or profes-
sional to repair the flat tire.

If you carry a regular size spare tire in your
vehicle or trailer as a precaution against
getting a flat tire, be sure that the spare tire
is firmly secured.

Trailer towing tips

CAUTION

For models equipped with the

BSD (Blind Spot Detection) and
RCTA (Rear Cross Traffic Alert)
driving support systems, when
towing a trailer, press the BSD/
RCTA OFF switch to deactivate
the system. The system may not
operate properly due to the
blocked radar waves. For details
about the BSD/RCTA OFF switch,
refer to “BSD/RCTA OFF switch”
FP362.

For models equipped with RAB

(Reverse Automatic Braking)
system, consult your SUBARU
dealer for additional information
about towing a trailer.

Never exceed 45 mph (72 km/h)

Trailer towing

400

Subaru Ascent (2019 year). Instruction - part 25
