DI-14

DIFFERENTIALS

GENERAL DESCRIPTION

399703600

PULLER ASSY

Use for removing companion flange.

398177700

INSTALLER

• Used for installing rear bearing cone.
• For T-type.

398457700

ATTACHMENT

• Used for removing side bearing retainer.
• For T-type.

398477703

DRIFT 2

• Used for press-fitting the bearing race (rear) of
differential carrier.
• For T-type.

ILLUSTRATION

TOOL NUMBER

DESCRIPTION

REMARKS

ST-399703600

 ST-398177700

 ST-398457700

 ST-398477703

DI-15

DIFFERENTIALS

GENERAL DESCRIPTION

398437700

DRIFT

• Used for installing side oil seal.
• For T-type.

398507702

DUMMY SHAFT

• Used for adjusting pinion height and preload.
• For T-type.

398507703

DUMMY COLLAR

• Used for adjusting pinion height and preload.
• For T-type.

398517700

REPLACER

• Used for removing rear bearing cone.
• For T-type.

ILLUSTRATION

TOOL NUMBER

DESCRIPTION

REMARKS

 ST-398437700

ST-398507702

ST-398507703

ST-398517700

DI-16

DIFFERENTIALS

GENERAL DESCRIPTION

398487700

DRIFT

• Used for press-fitting the side bearing cone.
• For T-type.

398507701

GAUGE

• Used for adjusting pinion height.
• For T-type.

398527700

PULLEY ASSY

• Used for removing oil seal and side bearing
cup.
• For T-type.

399527700

PULLER SET

• Used for extracting side bearing cone.
(1) BOLT
(2) PULLER
(3) HOLDER
(4) ADAPTER
(5) BOLT
(6) NUT
• For T-type.

ILLUSTRATION

TOOL NUMBER

DESCRIPTION

REMARKS

 ST-398487700

 ST-398507701

ST-398527700

ST-399527700

( 1 )

( 2 )

( 3 )

( 4 )

( 5 )

( 6 )

DI-17

DIFFERENTIALS

GENERAL DESCRIPTION

28099PA090

OIL SEAL PROTEC-
TOR

• Used for installing rear drive shaft into rear dif-
ferential.
• For protecting oil seal.
• For T-type.

398237700

GAUGE

• Used for installing side bearing.
• For T-type.

28099PA100

DRIVE SHAFT
REMOVER

• Used for removing rear drive shaft from rear
differential.
• For T-type.

498175500

INSTALLER

• Used for installing rear bearing cone.
• For VA-type.

ILLUSTRATION

TOOL NUMBER

DESCRIPTION

REMARKS

ST28099PA090

 ST-398237700

ST28099PA100

ST-498175500
