Subaru Legacy III (2000-2003 year). Manual - part 254
ME(H6DO)-4
MECHANICAL
GENERAL DESCRIPTION
Connecting rod
bushing
Clearance between piston pin
and bushing
STD
0 — 0.022 mm (0 — 0.0009 in)
Limit
0.030 mm (0.0012 in)
Crankshaft
Bend limit
0.035 mm (0.0014 in)
Crank pin and
crank journal
Out-of-roundness
0.020 mm (0.0008 in) or less
Grinding limit
0.250 mm (0.0098 in)
Crank pin outer diameter
STD
51.984 — 52.000 mm (2.0466 — 2.0472 in)
0.03 mm (0.0012 in) US
51.954 — 51.970 mm (2.0454 — 2.0461 in)
0.05 mm (0.0020 in) US
51.934 — 51.950 mm (2.0446 — 2.0453 in)
0.25 mm (0.0098 in) US
51.734 — 51.750 mm (2.0368 — 2.0374 in)
Crank journal
outer diameter
#1, #3, #5, #7
STD
63.992 — 64.008 mm (2.5194 — 2.5200 in)
0.03 mm (0.0012 in) US
63.962 — 63.978 mm (2.5182 — 2.5188 in)
0.05 mm (0.0020 in) US
63.942 — 63.958 mm (2.5174 — 2.5180 in)
0.25 mm (0.0098 in) US
63.742 — 63.758 mm (2.5095 — 2.5102 in)
#2, #4, #6
STD
63.992 — 64.008 mm (2.5194 — 2.5200 in)
0.03 mm (0.0012 in) US
63.962 — 63.978 mm (2.5182 — 2.5188 in)
0.05 mm (0.0020 in) US
63.942 — 63.958 mm (2.5174 — 2.5180 in)
0.25 mm (0.0098 in) US
63.742 — 63.758 mm (2.5095 — 2.5102 in)
Thrust clearance
STD
0.030 — 0.115 mm (0.0012 — 0.0045 in)
Limit
0.25 mm (0.0098 in)
Oil clearance
STD
0.015 — 0.030 mm (0.0006 — 0.0012 in)
Limit
0.050 mm (0.0020 in)
Crankshaft
bearing
Crankshaft
bearing thick-
ness
#1, #3, #5, #7
STD
1.992 — 2.005 mm (0.0784 — 0.0789 in)
0.03 mm (0.0012 in) US
2.017 — 2.020 mm (0.0794 — 0.0795 in)
0.05 mm (0.0020 in) US
2.027 — 2.030 mm (0.0798 — 0.0799 in)
0.25 mm (0.0098 in) US
2.127 — 2.130 mm (0.0837 — 0.0839 in)
#2, #4, #5
STD
1.996 — 2.000 mm (0.0786 — 0.0787 in)
0.03 mm (0.0012 in) US
2.019 — 2.020 mm (0.0795 — 0.0795 in)
0.05 mm (0.0020 in) US
2.029 — 2.032 mm (0.0799 — 0.0800 in)
0.25 mm (0.0098 in) US
2.129 — 2.132 mm (0.0838 — 0.0839 in)
