Subaru Legacy III (2000-2003 year). Manual - part 1106
WI-378
WIRING SYSTEM
DOOR CORD
56.Door Cord
A: LOCATION
1. LHD MODEL
Connector
Connecting to
No.
Pole
Color
Area
No.
Name
D1
25
★
C-2
B30
Bulkhead wiring harness
D2
2
★
C-3
Front door speaker LH
D3
2
Green
C-3
Front power window motor LH
D4
2
Black
C-3
Front door tweeter LH
D5
6
★
C-3
Remote control rearview mirror LH (Without mirror heater)
8
★
C-3
Remote control rearview mirror LH (With mirror heater)
D7
16
★
C-3
Power window main switch
D10
2
★
C-3
Step light LH
D11
25
★
C-2
B101
Bulkhead wiring harness
D12
2
★
C-2
Front door speaker RH
D13
2
Green
B-2
Front power window motor RH
D14
2
Black
B-2
Front door tweeter RH
D15
6
★
B-2
Remote control rearview mirror RH (Without mirror heater)
8
★
B-2
Remote control rearview mirror RH (With mirror heater)
D17
6
★
B-2
Front power window sub switch RH
D18
4
★
B-2
Front door lock actuator RH
D20
2
★
B-2
Step light RH
D21
8
★
C-3
R11
Rear wiring harness
D23
2
Black
C-4
Rear door speaker LH
D24
2
Green
C-4
Rear power window motor LH
D25
6
★
B-4
Rear power window sub switch LH
D26
4
★
B-4
Rear door lock actuator LH
D27
8
★
B-2
R14
Rear wiring harness
D29
2
Black
B-2
Rear door speaker RH
D30
2
Green
B-2
Rear power window motor RH
D31
6
★
B-2
Rear power window sub switch RH
D32
4
★
B-3
Rear door lock actuator RH
D61
10
★
C-3
Remote control rearview mirror switch
D72
4
Gray
C-3
Front door lock actuator LH
★
: Non-colored
