WI-342

WIRING SYSTEM

BULKHEAD WIRING HARNESS (IN ENGINE ROOM)

3. RHD 4-CYLINDER ENGINE MODEL

Connector

Connecting to

No.

Pole

Color

Area

No.

Name

B3

5

★

B-2

Air flow sensor (Turbo engine model)

B6

2

Brown

B-2

Front ABS sensor RH (Outback model)

2

Gray

B-2

Front ABS sensor RH (Other models)

B7

6

Black

B-3

Cruise control actuator

B8

5

★

B-3

Front wiper motor

B11

20

Black

B-3

T4

Transmission (AT)

B12

12

★

B-3

T3

Black

B-3

T3

Transmission (Turbo engine AT model)

B14

1

Black

B-3

Starter (Magnet)

B15

2

Brown

B-3

Front ABS sensor LH (Outback model)

2

Gray

B-3

Front ABS sensor LH (Other models)

B16

2

Gray

B-2

Brake fluid level switch

B17

3

★

B-2

Vehicle speed sensor (MT)

B18

4

★

B-2

Oxygen sensor

B19

4

★

B-2

T5

Rear oxygen sensor cord (With OBD model)

B20

16

★

B-2

E1

Engine wiring harness (Turbo engine model)

B21

20

★

B-2

E2

Engine wiring harness

B22

16

Brown

B-2

E3

B24

2

Gray

B-3

T1

Back-up light switch (MT)

B25

2

Brown

B-3

T2

Neutral position switch (MT)

B29

2

Black

B-3

T8

Lo (AWD) indicator light switch (MT)

B128

4

★

B-3

T9

Transmission (MT)

B143

3

★

B-4

Main fuse box (M/B)

B144

6

Black

C-3

B145

1

★

B-3

B146

2

Green

C-2

Front washer motor

B147

2

★

B-3

Rear washer motor

B148

2

Black

B-4

Side turn signal light LH

B155

3

★

B-2

CO resistor (Without OBD model)

B186

4

Black

C-4

Main fuse box (M/B)

B212

1

Gray

C-3

F86

Front wiring harness (Turbo engine model)

B220

12

★

B-2

Engine wiring harness (Turbo engine model)

B221

3

★

B-3

Differential pressure sensor

B328

6

Black

B-3

E58

Engine wiring harness

★

: Non-colored

WI-343

WIRING SYSTEM

BULKHEAD WIRING HARNESS (IN ENGINE ROOM)

WI-01034

1

2

3

4

5

1

2

3

4

5

A

B

C

D

A

B

C

D

B155

B20

B6

B18

B16

B19

B128

B220

B3

B17

B22

B21

B328

B18

B146

B147

B22

B21

B212

B15

B144

B186

B143

B145

B7

B148

B14

*1

B25

*1

B24

*2

B11

*4

B12

*5

B29

*3

*2

*3 *4

*5

B221

GB-4

GB-3

B8

TURBO ENGINE MODEL

NON-TURBO ENGINE MODEL

:

TB

TB

TB

NA

NA

NA

TB

:

NA

WI-344

WIRING SYSTEM

BULKHEAD WIRING HARNESS (IN ENGINE ROOM)

4. RHD 6-CYLINDER ENGINE MODEL

Connector

Connecting to

No.

Pole

Color

Area

No.

Name

B6

2

Brown

B-2

Front ABS sensor RH

B7

6

Black

B-3

Cruise control actuator

B8

5

★

B-3

Front wiper motor

B11

20

Black

B-3

T4

Transmission (AT)

B12

12

★

B-3

T3

B14

1

Black

B-3

Starter (Magnet)

B15

2

Brown

B-3

Front ABS sensor LH

B16

2

Gray

B-2

Brake fluid level switch

B19

6

★

B-2

T5

Rear oxygen sensor cord

B20

16

Dark gray

B-2

E1

Engine wiring harness

B21

20

★

B-2

E2

B22

16

Brown

B-2

E3

B143

3

★

B-4

Main fuse box (M/B)

B144

6

Black

C-3

B145

1

★

B-3

B146

2

Green

C-2

Front washer motor

B147

2

★

B-3

Rear washer motor

B148

2

Black

B-4

Side turn signal light LH

B186

4

Black

C-4

Main fuse box (M/B)

B212

1

Gray

C-3

F86

Front wiring harness

B252

8

★

B-2

E49

Engine wiring harness

B253

5

★

B-4

Fan control relay

★

: Non-colored

WI-345

WIRING SYSTEM

BULKHEAD WIRING HARNESS (IN ENGINE ROOM)

WI-01035

1

2

3

4

5

1

2

3

4

5

A

B

C

D

A

B

C

D

B6

B19

B16

B20

B22

B252

B21

B146

B147

B15

B11

B12

B144

B186

B143

B145

B7

B148

B14

GB-4

GB-3

B8

B253

GB-10

B212
