Subaru Legacy III (2000-2003 year). Manual - part 1095
WI-334
WIRING SYSTEM
FRONT WIRING HARNESS
50.Front Wiring Harness
A: LOCATION
1. LHD MODEL
Connector
Connecting to
No.
Pole
Color
Area
No.
Name
F2
24
Black
B-4
B100
Bulkhead wiring har-
ness
F3
2
★
B-1
Front turn signal light
RH
F4
3
★
B-1
Front clearance light RH
F5
1
Black
C-1
Horn
F6
2
★
C-1
Front fog light RH
F7
3
Gray
C-1
Headlight RH
F16
2
Balck
C-1
Sub fan motor (4-cylin-
der engine model)
4
Gray
C-1
Sub fan motor (6-cylin-
der engine model)
F17
2
Balck
C-2
Radiator main fan motor
(4-cylinder engine
model)
4
Gray
C-2
Radiator main fan motor
(6-cylinder engine
model)
F19
2
★
C-3
Front turn signal light
LH
F21
2
★
D-3
Front fog light LH
F22
3
★
C-3
Front clearance light LH
F23
3
Gray
C-2
Headlight LH
F24
1
Black
C-2
A/C magnet clutch (4-
cylinder engine model)
F25
1
★
C-2
Generator
F26
3
Green
C-2
F27
4
★
A-3
A/C fuse (Relay holder)
F28
5
★
A-3
A/C sub fan relay (Relay
holder-4 cylinder engine
model)
5
★
A-4
A/C sub fan relay-1
(Relay holder-6 cylinder
engine model)
F29
5
★
A-4
A/C sub fan relay-2
(Relay holder-6 cylinder
engine model)
F30
5
★
A-3
Radiator main fan relay-
2 (Relay holder-6 cylin-
der engine model)
F31
5
★
A-3
A/C relay (Relay holder)
F32
2
Green
C-3
Front washer motor
F33
2
★
B-3
Rear washer motor
F34
4
★
C-3
SBF holder
F35
2
Black
B-4
Main fuse box (M/B)
F36
3
★
C-4
F37
6
Black
C-4
F38
1
★
C-4
F39
8
Black
B-3
F40
9
Brown
C-4
Fuse & relay box (F/B)
F41
7
Gray
B-4
F44
8
★
B-4
B61
Bulkhead wiring har-
ness
F45
16
★
B-3
B62
Bulkhead wiring har-
ness
F46
4
★
B-4
B108
Bulkhead wiring har-
ness
F47
1
Black
C-2
Horn
F49
31
★
B-2
ABS control module
F51
2
Black
B-2
Side turn signal light RH
F54
2
Black
B-4
Side turn signal light LH
F55
8
★
B-4
R49
Rear wiring harness
(without VDC model)
12
★
Rear wiring harness
(with VDC model)
F58
3
★
D-2
Headlight leveler LH
F59
3
★
C-1
Headlight leveler RH
F65
5
★
A-4
Front fog light relay
(Relay holder)
F66
5
★
A-3
Radiator main fan relay
(Realy holder-4-cylin-
der engine model)
5
★
A-3
Radiator main fan relay-
1 (Realy holder-6-cylin-
der engine model)
F67
2
★
A-4
FWD switch (Relay
holder-without VDC
model)
F68
4
Black
C-4
Main fuse box (M/B)
F73
1
★
B-2
ABS motor ground
F78
2
Black
C-1
Ambient sensor
F82
3
Black
C-2
A/C magnet clutch (6-
cylinder engine model)
F87
83
★
B-4
VDC module
F88
6
★
B-4
Shield joint connector
(VDC)
F89
2
Gray
B-1
Hydraulic module (VDC)
F90
6
Black
B-2
F91
16
★
B-2
Hydraulic module (VDC)
F96
14
★
B-4
B255
Bulkhead wiring har-
ness
★
: Non-colored
Connector
Connecting to
No.
Pole
Color
Area
No.
Name
